KOYO AL Lock Plates for Large Locknuts

KOYO AL Lock Plates for Large Locknuts

AL series lock plates for securing large AN / ANL locknuts by bolting to the nut face.

Key features

  • Bolted locking for large locknuts
  • Matched to AN and ANL locknut sizes
  • Mass given per 100 pieces

Specifications

Product type Lock plate
Series AL
Use with AN, ANL locknuts
Source KOYO Special Bearings catalogue, p. C176
AL 44 B3: 4 mm | B4: 20 mm | L2: 12 mm | Hole d7: 9 mm | Mass/100 pcs: 2.60 kg
AL 52 B3: 4 mm | B4: 24 mm | L2: 12 mm | Hole d7: 12 mm | Mass/100 pcs: 3.39 kg
AL 60 B3: 4 mm | B4: 24 mm | L2: 12 mm | Hole d7: 12 mm | Mass/100 pcs: 3.79 kg
AL 64 B3: 5 mm | B4: 24 mm | L2: 15 mm | Hole d7: 12 mm | Mass/100 pcs: 5.35 kg
AL 68 B3: 5 mm | B4: 28 mm | L2: 15 mm | Hole d7: 14 mm | Mass/100 pcs: 6.65 kg
AL 76 B3: 5 mm | B4: 32 mm | L2: 15 mm | Hole d7: 14 mm | Mass/100 pcs: 7.96 kg
AL 80 B3: 5 mm | B4: 32 mm | L2: 15 mm | Hole d7: 18 mm | Mass/100 pcs: 8.20 kg
AL 88 B3: 5 mm | B4: 36 mm | L2: 15 mm | Hole d7: 18 mm | Mass/100 pcs: 9.00 kg
AL 96 B3: 5 mm | B4: 36 mm | L2: 15 mm | Hole d7: 18 mm | Mass/100 pcs: 10.4 kg
AL 100 B3: 5 mm | B4: 40 mm | L2: 15 mm | Hole d7: 18 mm | Mass/100 pcs: 10.5 kg
ALL44 B3: 4 mm | B4: 20 mm | L2: 12 mm | Hole d7: 7 mm | Mass/100 pcs: 2.12 kg
ALL48 B3: 4 mm | B4: 20 mm | L2: 12 mm | Hole d7: 9 mm | Mass/100 pcs: 2.29 kg
ALL56 B3: 4 mm | B4: 24 mm | L2: 12 mm | Hole d7: 9 mm | Mass/100 pcs: 2.92 kg
ALL60 B3: 4 mm | B4: 24 mm | L2: 12 mm | Hole d7: 9 mm | Mass/100 pcs: 3.16 kg
ALL64 B3: 5 mm | B4: 24 mm | L2: 15 mm | Hole d7: 9 mm | Mass/100 pcs: 4.56 kg
ALL72 B3: 5 mm | B4: 28 mm | L2: 15 mm | Hole d7: 9 mm | Mass/100 pcs: 5.03 kg
ALL76 B3: 5 mm | B4: 28 mm | L2: 15 mm | Hole d7: 12 mm | Mass/100 pcs: 5.28 kg
ALL84 B3: 5 mm | B4: 32 mm | L2: 15 mm | Hole d7: 12 mm | Mass/100 pcs: 6.11 kg
ALL88 B3: 5 mm | B4: 32 mm | L2: 15 mm | Hole d7: 14 mm | Mass/100 pcs: 6.45 kg
ALL96 B3: 5 mm | B4: 36 mm | L2: 15 mm | Hole d7: 14 mm | Mass/100 pcs: 7.29 kg
Lock Nuts & WashersKOYO
20 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO AL Lock Plates for Large Locknuts

Brand KOYO·Lock Nuts & Washers

Available part numbers (20)

AL 44, AL 52, AL 60, AL 64, AL 68, AL 76, AL 80, AL 88, AL 96, AL 100 + 10 more — see full table ↓

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AL 44B3: 4 mm | B4: 20 mm | L2: 12 mm | Hole d7: 9 mm | Mass/100 pcs: 2.60 kg
AL 52B3: 4 mm | B4: 24 mm | L2: 12 mm | Hole d7: 12 mm | Mass/100 pcs: 3.39 kg
AL 60B3: 4 mm | B4: 24 mm | L2: 12 mm | Hole d7: 12 mm | Mass/100 pcs: 3.79 kg
AL 64B3: 5 mm | B4: 24 mm | L2: 15 mm | Hole d7: 12 mm | Mass/100 pcs: 5.35 kg
AL 68B3: 5 mm | B4: 28 mm | L2: 15 mm | Hole d7: 14 mm | Mass/100 pcs: 6.65 kg
AL 76B3: 5 mm | B4: 32 mm | L2: 15 mm | Hole d7: 14 mm | Mass/100 pcs: 7.96 kg
AL 80B3: 5 mm | B4: 32 mm | L2: 15 mm | Hole d7: 18 mm | Mass/100 pcs: 8.20 kg
AL 88B3: 5 mm | B4: 36 mm | L2: 15 mm | Hole d7: 18 mm | Mass/100 pcs: 9.00 kg
AL 96B3: 5 mm | B4: 36 mm | L2: 15 mm | Hole d7: 18 mm | Mass/100 pcs: 10.4 kg
AL 100B3: 5 mm | B4: 40 mm | L2: 15 mm | Hole d7: 18 mm | Mass/100 pcs: 10.5 kg
ALL44B3: 4 mm | B4: 20 mm | L2: 12 mm | Hole d7: 7 mm | Mass/100 pcs: 2.12 kg
ALL48B3: 4 mm | B4: 20 mm | L2: 12 mm | Hole d7: 9 mm | Mass/100 pcs: 2.29 kg
ALL56B3: 4 mm | B4: 24 mm | L2: 12 mm | Hole d7: 9 mm | Mass/100 pcs: 2.92 kg
ALL60B3: 4 mm | B4: 24 mm | L2: 12 mm | Hole d7: 9 mm | Mass/100 pcs: 3.16 kg
ALL64B3: 5 mm | B4: 24 mm | L2: 15 mm | Hole d7: 9 mm | Mass/100 pcs: 4.56 kg
ALL72B3: 5 mm | B4: 28 mm | L2: 15 mm | Hole d7: 9 mm | Mass/100 pcs: 5.03 kg
ALL76B3: 5 mm | B4: 28 mm | L2: 15 mm | Hole d7: 12 mm | Mass/100 pcs: 5.28 kg
ALL84B3: 5 mm | B4: 32 mm | L2: 15 mm | Hole d7: 12 mm | Mass/100 pcs: 6.11 kg
ALL88B3: 5 mm | B4: 32 mm | L2: 15 mm | Hole d7: 14 mm | Mass/100 pcs: 6.45 kg
ALL96B3: 5 mm | B4: 36 mm | L2: 15 mm | Hole d7: 14 mm | Mass/100 pcs: 7.29 kg
