KOYO AW Lockwashers (Bent & Flat Inner Tongue)

KOYO AW Lockwashers (Bent & Flat Inner Tongue)

AW series lockwashers for securing AN locknuts on adapter sleeves and shafts, with bent (AW) or flat (AW..X) inner tongue.

Key features

  • Locks AN locknut against loosening
  • Bent or flat (X) inner tongue
  • Matched to adapter sleeve bore number
  • Mass given per 100 pieces

Specifications

Product type Lockwasher
Series AW, AW..X
Use with AN locknuts
Source KOYO Special Bearings catalogue, p. C174-C175
AW 00 Type: Bent inner tongue | Bore d1: 10 mm | OD: 21 mm | Thickness: 1 mm | Mass/100 pcs: 0.131 kg
AW 00X Type: Flat inner tongue | Bore d1: 10 mm | OD: 21 mm | Thickness: 1 mm | Mass/100 pcs: 0.131 kg
AW 25 Type: Bent inner tongue | Bore d1: 125 mm | OD: 170 mm | Thickness: 2 mm | Mass/100 pcs: 11.8 kg
AW 25X Type: Flat inner tongue | Bore d1: 125 mm | OD: 170 mm | Thickness: 2 mm | Mass/100 pcs: 11.8 kg
AW 01 Type: Bent inner tongue | Bore d1: 12 mm | OD: 25 mm | Thickness: 1 mm | Mass/100 pcs: 0.192 kg
AW 01X Type: Flat inner tongue | Bore d1: 12 mm | OD: 25 mm | Thickness: 1 mm | Mass/100 pcs: 0.192 kg
AW 26 Type: Bent inner tongue | Bore d1: 130 mm | OD: 175 mm | Thickness: 2 mm | Mass/100 pcs: 11.3 kg
AW 26X Type: Flat inner tongue | Bore d1: 130 mm | OD: 175 mm | Thickness: 2 mm | Mass/100 pcs: 11.3 kg
AW 02 Type: Bent inner tongue | Bore d1: 15 mm | OD: 28 mm | Thickness: 1 mm | Mass/100 pcs: 0.253 kg
AW 02X Type: Flat inner tongue | Bore d1: 15 mm | OD: 28 mm | Thickness: 1 mm | Mass/100 pcs: 0.253 kg
AW 27 Type: Bent inner tongue | Bore d1: 135 mm | OD: 185 mm | Thickness: 2 mm | Mass/100 pcs: 14.4 kg
AW 27X Type: Flat inner tongue | Bore d1: 135 mm | OD: 185 mm | Thickness: 2 mm | Mass/100 pcs: 14.4 kg
AW 03 Type: Bent inner tongue | Bore d1: 17 mm | OD: 32 mm | Thickness: 1 mm | Mass/100 pcs: 0.313 kg
AW 03X Type: Flat inner tongue | Bore d1: 17 mm | OD: 32 mm | Thickness: 1 mm | Mass/100 pcs: 0.313 kg
AW 28 Type: Bent inner tongue | Bore d1: 140 mm | OD: 192 mm | Thickness: 2 mm | Mass/100 pcs: 14.2 kg
AW 28X Type: Flat inner tongue | Bore d1: 140 mm | OD: 192 mm | Thickness: 2 mm | Mass/100 pcs: 14.2 kg
AW 04 Type: Bent inner tongue | Bore d1: 20 mm | OD: 36 mm | Thickness: 1 mm | Mass/100 pcs: 0.350 kg
AW 04X Type: Flat inner tongue | Bore d1: 20 mm | OD: 36 mm | Thickness: 1 mm | Mass/100 pcs: 0.350 kg
AW 29 Type: Bent inner tongue | Bore d1: 145 mm | OD: 202 mm | Thickness: 2 mm | Mass/100 pcs: 16.8 kg
AW 29X Type: Flat inner tongue | Bore d1: 145 mm | OD: 202 mm | Thickness: 2 mm | Mass/100 pcs: 16.8 kg
AW 05 Type: Bent inner tongue | Bore d1: 25 mm | OD: 42 mm | Thickness: 1.2 mm | Mass/100 pcs: 0.640 kg
AW 05X Type: Flat inner tongue | Bore d1: 25 mm | OD: 42 mm | Thickness: 1.2 mm | Mass/100 pcs: 0.640 kg
AW 30 Type: Bent inner tongue | Bore d1: 150 mm | OD: 205 mm | Thickness: 2 mm | Mass/100 pcs: 15.5 kg
AW 30X Type: Flat inner tongue | Bore d1: 150 mm | OD: 205 mm | Thickness: 2 mm | Mass/100 pcs: 15.5 kg
AW 06 Type: Bent inner tongue | Bore d1: 30 mm | OD: 49 mm | Thickness: 1.2 mm | Mass/100 pcs: 0.780 kg
AW 06X Type: Flat inner tongue | Bore d1: 30 mm | OD: 49 mm | Thickness: 1.2 mm | Mass/100 pcs: 0.780 kg
AW 31 Type: Bent inner tongue | Bore d1: 155 mm | OD: 212 mm | Thickness: 2.5 mm | Mass/100 pcs: 20.9 kg
AW 31X Type: Flat inner tongue | Bore d1: 155 mm | OD: 212 mm | Thickness: 2.5 mm | Mass/100 pcs: 20.9 kg
AW 07 Type: Bent inner tongue | Bore d1: 35 mm | OD: 57 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.04 kg
AW 07X Type: Flat inner tongue | Bore d1: 35 mm | OD: 57 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.04 kg
AW 32 Type: Bent inner tongue | Bore d1: 160 mm | OD: 217 mm | Thickness: 2.5 mm | Mass/100 pcs: 22.2 kg
AW 32X Type: Flat inner tongue | Bore d1: 160 mm | OD: 217 mm | Thickness: 2.5 mm | Mass/100 pcs: 22.2 kg
AW 08 Type: Bent inner tongue | Bore d1: 40 mm | OD: 62 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.23 kg
AW 08X Type: Flat inner tongue | Bore d1: 40 mm | OD: 62 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.23 kg
AW 33 Type: Bent inner tongue | Bore d1: 165 mm | OD: 222 mm | Thickness: 2.5 mm | Mass/100 pcs: 24.1 kg
AW 33X Type: Flat inner tongue | Bore d1: 165 mm | OD: 222 mm | Thickness: 2.5 mm | Mass/100 pcs: 24.1 kg
AW 09 Type: Bent inner tongue | Bore d1: 45 mm | OD: 69 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.52 kg
AW 09X Type: Flat inner tongue | Bore d1: 45 mm | OD: 69 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.52 kg
AW 34 Type: Bent inner tongue | Bore d1: 170 mm | OD: 232 mm | Thickness: 2.5 mm | Mass/100 pcs: 24.7 kg
AW 34X Type: Flat inner tongue | Bore d1: 170 mm | OD: 232 mm | Thickness: 2.5 mm | Mass/100 pcs: 24.7 kg
AW 10 Type: Bent inner tongue | Bore d1: 50 mm | OD: 74 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.60 kg
AW 10X Type: Flat inner tongue | Bore d1: 50 mm | OD: 74 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.60 kg
AW 36 Type: Bent inner tongue | Bore d1: 180 mm | OD: 242 mm | Thickness: 2.5 mm | Mass/100 pcs: 26.8 kg
AW 36X Type: Flat inner tongue | Bore d1: 180 mm | OD: 242 mm | Thickness: 2.5 mm | Mass/100 pcs: 26.8 kg
AW 11 Type: Bent inner tongue | Bore d1: 55 mm | OD: 81 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.96 kg
AW 11X Type: Flat inner tongue | Bore d1: 55 mm | OD: 81 mm | Thickness: 1.2 mm | Mass/100 pcs: 1.96 kg
AW 38 Type: Bent inner tongue | Bore d1: 190 mm | OD: 252 mm | Thickness: 2.5 mm | Mass/100 pcs: 27.8 kg
AW 38X Type: Flat inner tongue | Bore d1: 190 mm | OD: 252 mm | Thickness: 2.5 mm | Mass/100 pcs: 27.8 kg
AW 12 Type: Bent inner tongue | Bore d1: 60 mm | OD: 86 mm | Thickness: 1.5 mm | Mass/100 pcs: 2.53 kg
AW 12X Type: Flat inner tongue | Bore d1: 60 mm | OD: 86 mm | Thickness: 1.5 mm | Mass/100 pcs: 2.53 kg
AW 40 Type: Bent inner tongue | Bore d1: 200 mm | OD: 262 mm | Thickness: 2.5 mm | Mass/100 pcs: 29.3 kg
AW 40X Type: Flat inner tongue | Bore d1: 200 mm | OD: 262 mm | Thickness: 2.5 mm | Mass/100 pcs: 29.3 kg
AW 13 Type: Bent inner tongue | Bore d1: 65 mm | OD: 92 mm | Thickness: 1.5 mm | Mass/100 pcs: 2.90 kg
AW 13X Type: Flat inner tongue | Bore d1: 65 mm | OD: 92 mm | Thickness: 1.5 mm | Mass/100 pcs: 2.90 kg
AW 14 Type: Bent inner tongue | Bore d1: 70 mm | OD: 98 mm | Thickness: 1.5 mm | Mass/100 pcs: 3.34 kg
AW 14X Type: Flat inner tongue | Bore d1: 70 mm | OD: 98 mm | Thickness: 1.5 mm | Mass/100 pcs: 3.34 kg
AWL24 Type: Bent inner tongue | Bore d1: 120 mm | OD: 155 mm | Thickness: 2 mm | Mass/100 pcs: 7.70 kg
AWL24X Type: Flat inner tongue | Bore d1: 120 mm | OD: 155 mm | Thickness: 2 mm | Mass/100 pcs: 7.70 kg
AW 15 Type: Bent inner tongue | Bore d1: 75 mm | OD: 104 mm | Thickness: 1.5 mm | Mass/100 pcs: 3.56 kg
AW 15X Type: Flat inner tongue | Bore d1: 75 mm | OD: 104 mm | Thickness: 1.5 mm | Mass/100 pcs: 3.56 kg
AWL26 Type: Bent inner tongue | Bore d1: 130 mm | OD: 165 mm | Thickness: 2 mm | Mass/100 pcs: 8.70 kg
AWL26X Type: Flat inner tongue | Bore d1: 130 mm | OD: 165 mm | Thickness: 2 mm | Mass/100 pcs: 8.70 kg
AW 16 Type: Bent inner tongue | Bore d1: 80 mm | OD: 112 mm | Thickness: 1.8 mm | Mass/100 pcs: 4.64 kg
AW 16X Type: Flat inner tongue | Bore d1: 80 mm | OD: 112 mm | Thickness: 1.8 mm | Mass/100 pcs: 4.64 kg
AWL28 Type: Bent inner tongue | Bore d1: 140 mm | OD: 175 mm | Thickness: 2 mm | Mass/100 pcs: 10.9 kg
AWL28X Type: Flat inner tongue | Bore d1: 140 mm | OD: 175 mm | Thickness: 2 mm | Mass/100 pcs: 10.9 kg
AW 17 Type: Bent inner tongue | Bore d1: 85 mm | OD: 119 mm | Thickness: 1.8 mm | Mass/100 pcs: 5.24 kg
AW 17X Type: Flat inner tongue | Bore d1: 85 mm | OD: 119 mm | Thickness: 1.8 mm | Mass/100 pcs: 5.24 kg
AWL30 Type: Bent inner tongue | Bore d1: 150 mm | OD: 190 mm | Thickness: 2 mm | Mass/100 pcs: 11.3 kg
AWL30X Type: Flat inner tongue | Bore d1: 150 mm | OD: 190 mm | Thickness: 2 mm | Mass/100 pcs: 11.3 kg
AW 18 Type: Bent inner tongue | Bore d1: 90 mm | OD: 126 mm | Thickness: 1.8 mm | Mass/100 pcs: 6.23 kg
AW 18X Type: Flat inner tongue | Bore d1: 90 mm | OD: 126 mm | Thickness: 1.8 mm | Mass/100 pcs: 6.23 kg
AWL32 Type: Bent inner tongue | Bore d1: 160 mm | OD: 200 mm | Thickness: 2.5 mm | Mass/100 pcs: 16.2 kg
AWL32X Type: Flat inner tongue | Bore d1: 160 mm | OD: 200 mm | Thickness: 2.5 mm | Mass/100 pcs: 16.2 kg
AW 19 Type: Bent inner tongue | Bore d1: 95 mm | OD: 133 mm | Thickness: 1.8 mm | Mass/100 pcs: 6.70 kg
AW 19X Type: Flat inner tongue | Bore d1: 95 mm | OD: 133 mm | Thickness: 1.8 mm | Mass/100 pcs: 6.70 kg
AWL34 Type: Bent inner tongue | Bore d1: 170 mm | OD: 210 mm | Thickness: 2.5 mm | Mass/100 pcs: 19.0 kg
AWL34X Type: Flat inner tongue | Bore d1: 170 mm | OD: 210 mm | Thickness: 2.5 mm | Mass/100 pcs: 19.0 kg
AW 20 Type: Bent inner tongue | Bore d1: 100 mm | OD: 142 mm | Thickness: 1.8 mm | Mass/100 pcs: 7.65 kg
AW 20X Type: Flat inner tongue | Bore d1: 100 mm | OD: 142 mm | Thickness: 1.8 mm | Mass/100 pcs: 7.65 kg
AWL36 Type: Bent inner tongue | Bore d1: 180 mm | OD: 220 mm | Thickness: 2.5 mm | Mass/100 pcs: 18.0 kg
AWL36X Type: Flat inner tongue | Bore d1: 180 mm | OD: 220 mm | Thickness: 2.5 mm | Mass/100 pcs: 18.0 kg
AW 21 Type: Bent inner tongue | Bore d1: 105 mm | OD: 145 mm | Thickness: 1.8 mm | Mass/100 pcs: 8.26 kg
AW 21X Type: Flat inner tongue | Bore d1: 105 mm | OD: 145 mm | Thickness: 1.8 mm | Mass/100 pcs: 8.26 kg
AWL38 Type: Bent inner tongue | Bore d1: 190 mm | OD: 230 mm | Thickness: 2.5 mm | Mass/100 pcs: 20.5 kg
AWL38X Type: Flat inner tongue | Bore d1: 190 mm | OD: 230 mm | Thickness: 2.5 mm | Mass/100 pcs: 20.5 kg
AW 22 Type: Bent inner tongue | Bore d1: 110 mm | OD: 154 mm | Thickness: 1.8 mm | Mass/100 pcs: 9.40 kg
AW 22X Type: Flat inner tongue | Bore d1: 110 mm | OD: 154 mm | Thickness: 1.8 mm | Mass/100 pcs: 9.40 kg
AWL40 Type: Bent inner tongue | Bore d1: 200 mm | OD: 250 mm | Thickness: 2.5 mm | Mass/100 pcs: 21.4 kg
AWL40X Type: Flat inner tongue | Bore d1: 200 mm | OD: 250 mm | Thickness: 2.5 mm | Mass/100 pcs: 21.4 kg
AW 23 Type: Bent inner tongue | Bore d1: 115 mm | OD: 159 mm | Thickness: 2 mm | Mass/100 pcs: 10.8 kg
AW 23X Type: Flat inner tongue | Bore d1: 115 mm | OD: 159 mm | Thickness: 2 mm | Mass/100 pcs: 10.8 kg
AW 24 Type: Bent inner tongue | Bore d1: 120 mm | OD: 164 mm | Thickness: 2 mm | Mass/100 pcs: 10.5 kg
AW 24X Type: Flat inner tongue | Bore d1: 120 mm | OD: 164 mm | Thickness: 2 mm | Mass/100 pcs: 10.5 kg
Lock Nuts & WashersKOYO
94 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO AW Lockwashers (Bent & Flat Inner Tongue)

Brand KOYO·Lock Nuts & Washers

Available part numbers (94)

AW 00, AW 00X, AW 25, AW 25X, AW 01, AW 01X, AW 26, AW 26X, AW 02, AW 02X + 84 more — see full table ↓

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
