• KOYO BLF Light Duty Rhombic Flanged Units
1 1

KOYO BLF Light Duty Rhombic Flanged Units

KOYO BLF Light Duty Rhombic Flanged Units

Light duty 2-bolt rhombic flanged units with SB insert bearings.

Key features

  • Pre-lubricated sealed ball bearing insert
  • Spherical seating compensates for shaft misalignment
  • Housing and insert replaceable separately
  • Unit number, housing number and insert bearing listed
  • Shaft diameter given in mm

Specifications

Product type Ball bearing unit
Series BLF Light Duty Flange Units
Seal Insert bearing sealed both sides
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B504-B505
BLF201 Shaft d: 12 mm | Housing: LF203 | Bearing: SB201 | Cr: 9.55 kN
BLF202 Shaft d: 15 mm | Housing: LF203 | Bearing: SB202 | Cr: 9.55 kN
BLF203 Shaft d: 17 mm | Housing: LF203 | Bearing: SB203 | Cr: 9.55 kN
BLF204 Shaft d: 20 mm | Housing: LF204 | Bearing: SB204 | Cr: 12.8 kN
BLF205 Shaft d: 25 mm | Housing: LF205 | Bearing: SB205 | Cr: 14.0 kN
BLF206 Shaft d: 30 mm | Housing: LF206 | Bearing: SB206 | Cr: 19.5 kN
BLF207 Shaft d: 35 mm | Housing: LF207 | Bearing: SB207 | Cr: 25.7 kN
Mounted Bearing UnitsKOYO
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO BLF Light Duty Rhombic Flanged Units

Brand KOYO·Mounted Bearing Units

Available part numbers (7)

BLF201, BLF202, BLF203, BLF204, BLF205, BLF206, BLF207

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
BLF201Shaft d: 12 mm | Housing: LF203 | Bearing: SB201 | Cr: 9.55 kN
BLF202Shaft d: 15 mm | Housing: LF203 | Bearing: SB202 | Cr: 9.55 kN
BLF203Shaft d: 17 mm | Housing: LF203 | Bearing: SB203 | Cr: 9.55 kN
BLF204Shaft d: 20 mm | Housing: LF204 | Bearing: SB204 | Cr: 12.8 kN
BLF205Shaft d: 25 mm | Housing: LF205 | Bearing: SB205 | Cr: 14.0 kN
BLF206Shaft d: 30 mm | Housing: LF206 | Bearing: SB206 | Cr: 19.5 kN
BLF207Shaft d: 35 mm | Housing: LF207 | Bearing: SB207 | Cr: 25.7 kN
