KOYO Flanged Miniature Ball Bearings (Open, ZZ, ZZX)

KOYO Flanged Miniature Ball Bearings (Open, ZZ, ZZX)

Extra-small and miniature ball bearings with a flanged outer ring (F, MLF prefixes) in open and shielded (ZZ, ZZX) versions, bore 1 to 9 mm.

Key features

  • Flanged outer ring for axial location without housing shoulder
  • Open and shielded (ZZ, ZZX) versions
  • F and MLF series, W-prefix wide shielded types
  • Bore 1-9 mm
  • Compact designs for precision instruments

Specifications

Bearing type Flanged miniature ball bearing
Bore range 1 - 9 mm
Seal / shield Open, ZZ, ZZX
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B44-B49
F681 d: 1 mm | D: 3 mm | B: 1 mm | Cr: 0.10 kN | C0r: 0.03 kN | Flange dia D1: 3.8 mm
F691 d: 1 mm | D: 4 mm | B: 1.6 mm | Cr: 0.14 kN | C0r: 0.04 kN | Flange dia D1: 5 mm
F68/1.5 d: 1.5 mm | D: 4 mm | B: 1.2 mm | Cr: 0.11 kN | C0r: 0.03 kN | Flange dia D1: 5 mm
WF68/1.5 ZZ d: 1.5 mm | D: 4 mm | B: 2 mm | Cr: 0.11 kN | C0r: 0.03 kN | Flange dia D1: 5 mm
F69/1.5 d: 1.5 mm | D: 5 mm | B: 2 mm | Cr: 0.24 kN | C0r: 0.07 kN | Flange dia D1: 6.5 mm
WF69/1.5 ZZ d: 1.5 mm | D: 5 mm | B: 2.6 mm | Cr: 0.24 kN | C0r: 0.07 kN | Flange dia D1: 6.5 mm
MLF1506 d: 1.5 mm | D: 6 mm | B: 2.5 mm | Cr: 0.33 kN | C0r: 0.10 kN | Flange dia D1: 7.5 mm
WMLF1506 ZZ d: 1.5 mm | D: 6 mm | B: 3 mm | Cr: 0.33 kN | C0r: 0.10 kN | Flange dia D1: 7.5 mm
F682 d: 2 mm | D: 5 mm | B: 1.5 mm | Cr: 0.17 kN | C0r: 0.05 kN | Flange dia D1: 6.1 mm
WF682 ZZ d: 2 mm | D: 5 mm | B: 2.3 mm | Cr: 0.17 kN | C0r: 0.05 kN | Flange dia D1: 6.1 mm
MLF2005 d: 2 mm | D: 5 mm | B: 2 mm | Cr: 0.17 kN | C0r: 0.05 kN | Flange dia D1: 6.2 mm
WMLF2005 ZZ d: 2 mm | D: 5 mm | B: 2.5 mm | Cr: 0.17 kN | C0r: 0.05 kN | Flange dia D1: 6.2 mm
F692 d: 2 mm | D: 6 mm | B: 2.3 mm | Cr: 0.33 kN | C0r: 0.10 kN | Flange dia D1: 7.5 mm
WF692 ZZ d: 2 mm | D: 6 mm | B: 3 mm | Cr: 0.33 kN | C0r: 0.10 kN | Flange dia D1: 7.5 mm
MLF2006 d: 2 mm | D: 6 mm | B: 2.5 mm | Cr: 0.33 kN | C0r: 0.10 kN | Flange dia D1: 7.2 mm
WMLF2006 ZZ d: 2 mm | D: 6 mm | B: 3 mm | Cr: 0.33 kN | C0r: 0.10 kN | Flange dia D1: 7.2 mm
MLF2007 d: 2 mm | D: 7 mm | B: 2.5 mm | Cr: 0.39 kN | C0r: 0.13 kN | Flange dia D1: 8.2 mm
WMLF2007 ZZ d: 2 mm | D: 7 mm | B: 3 mm | Cr: 0.39 kN | C0r: 0.13 kN | Flange dia D1: 8.2 mm
F602 d: 2 mm | D: 7 mm | B: 2.8 mm | Cr: 0.39 kN | C0r: 0.13 kN | Flange dia D1: 8.5 mm
WF602 ZZ d: 2 mm | D: 7 mm | B: 3.5 mm | Cr: 0.39 kN | C0r: 0.13 kN | Flange dia D1: 8.5 mm
F68/2.5 d: 2.5 mm | D: 6 mm | B: 1.8 mm | Cr: 0.21 kN | C0r: 0.07 kN | Flange dia D1: 7.1 mm
WF68/2.5 ZZ d: 2.5 mm | D: 6 mm | B: 2.6 mm | Cr: 0.21 kN | C0r: 0.07 kN | Flange dia D1: 7.1 mm
F69/2.5 d: 2.5 mm | D: 7 mm | B: 2.5 mm | Cr: 0.39 kN | C0r: 0.13 kN | Flange dia D1: 8.5 mm
WF69/2.5 ZZX d: 2.5 mm | D: 7 mm | B: 3.5 mm | Cr: 0.39 kN | C0r: 0.13 kN | Flange dia D1: 8.5 mm
MLF2508/1B d: 2.5 mm | D: 8 mm | B: 2.5 mm | Cr: 0.56 kN | C0r: 0.18 kN | Flange dia D1: 9.2 mm
MLF2508 d: 2.5 mm | D: 8 mm | B: 2.8 mm | Cr: 0.56 kN | C0r: 0.18 kN | Flange dia D1: 9.5 mm
WMLF2508 ZZ d: 2.5 mm | D: 8 mm | B: 4 mm | Cr: 0.56 kN | C0r: 0.18 kN | Flange dia D1: 9.5 mm
MLF3006 d: 3 mm | D: 6 mm | B: 2 mm | Cr: 0.21 kN | C0r: 0.07 kN | Flange dia D1: 7.2 mm
WMLF3006 ZZ d: 3 mm | D: 6 mm | B: 2.5 mm | Cr: 0.21 kN | C0r: 0.07 kN | Flange dia D1: 7.2 mm
F683 d: 3 mm | D: 7 mm | B: 2 mm | Cr: 0.31 kN | C0r: 0.11 kN | Flange dia D1: 8.1 mm
WF683 ZZ d: 3 mm | D: 7 mm | B: 3 mm | Cr: 0.31 kN | C0r: 0.11 kN | Flange dia D1: 8.1 mm
MLF3008 d: 3 mm | D: 8 mm | B: 2.5 mm | Cr: 0.40 kN | C0r: 0.14 kN | Flange dia D1: 9.2 mm
F693 d: 3 mm | D: 8 mm | B: 3 mm | Cr: 0.56 kN | C0r: 0.18 kN | Flange dia D1: 9.5 mm
WF693 ZZ d: 3 mm | D: 8 mm | B: 4 mm | Cr: 0.56 kN | C0r: 0.18 kN | Flange dia D1: 9.5 mm
F603 d: 3 mm | D: 9 mm | B: 3 mm | Cr: 0.57 kN | C0r: 0.19 kN | Flange dia D1: 10.5 mm
WF603 ZZ d: 3 mm | D: 9 mm | B: 5 mm | Cr: 0.57 kN | C0r: 0.19 kN | Flange dia D1: 10.5 mm
F623 d: 3 mm | D: 10 mm | B: 4 mm | Cr: 0.63 kN | C0r: 0.22 kN | Flange dia D1: 11.5 mm
F623 ZZ d: 3 mm | D: 10 mm | B: 4 mm | Cr: 0.63 kN | C0r: 0.22 kN | Flange dia D1: 11.5 mm
MLF4007 d: 4 mm | D: 7 mm | B: 2 mm | Cr: 0.25 kN | C0r: 0.11 kN | Flange dia D1: 8.2 mm
WMLF4007 ZZX d: 4 mm | D: 7 mm | B: 2.5 mm | Cr: 0.25 kN | C0r: 0.11 kN | Flange dia D1: 8.2 mm
MLF4008 d: 4 mm | D: 8 mm | B: 2 mm | Cr: 0.40 kN | C0r: 0.14 kN | Flange dia D1: 9.2 mm
WMLF4008 ZZ d: 4 mm | D: 8 mm | B: 3 mm | Cr: 0.40 kN | C0r: 0.14 kN | Flange dia D1: 9.2 mm
F684 d: 4 mm | D: 9 mm | B: 2.5 mm | Cr: 0.64 kN | C0r: 0.23 kN | Flange dia D1: 10.3 mm
WF684 ZZ d: 4 mm | D: 9 mm | B: 4 mm | Cr: 0.64 kN | C0r: 0.23 kN | Flange dia D1: 10.3 mm
MLF4010 d: 4 mm | D: 10 mm | B: 3 mm | Cr: 0.71 kN | C0r: 0.27 kN | Flange dia D1: 11.2 mm
WMLF4010 ZZ d: 4 mm | D: 10 mm | B: 4 mm | Cr: 0.71 kN | C0r: 0.27 kN | Flange dia D1: 11.6 mm
F694 d: 4 mm | D: 11 mm | B: 4 mm | Cr: 0.96 kN | C0r: 0.35 kN | Flange dia D1: 12.5 mm
F694 ZZ d: 4 mm | D: 11 mm | B: 4 mm | Cr: 0.96 kN | C0r: 0.35 kN | Flange dia D1: 12.5 mm
F604 d: 4 mm | D: 12 mm | B: 4 mm | Cr: 0.96 kN | C0r: 0.35 kN | Flange dia D1: 13.5 mm
F604 ZZ d: 4 mm | D: 12 mm | B: 4 mm | Cr: 0.96 kN | C0r: 0.35 kN | Flange dia D1: 13.5 mm
F624 d: 4 mm | D: 13 mm | B: 5 mm | Cr: 1.30 kN | C0r: 0.48 kN | Flange dia D1: 15 mm
F624 ZZ d: 4 mm | D: 13 mm | B: 5 mm | Cr: 1.30 kN | C0r: 0.48 kN | Flange dia D1: 15 mm
F634 d: 4 mm | D: 16 mm | B: 5 mm | Cr: 1.35 kN | C0r: 0.52 kN | Flange dia D1: 18 mm
F634 ZZ d: 4 mm | D: 16 mm | B: 5 mm | Cr: 1.35 kN | C0r: 0.52 kN | Flange dia D1: 18 mm
MLF5008 d: 5 mm | D: 8 mm | B: 2 mm | Cr: 0.22 kN | C0r: 0.09 kN | Flange dia D1: 9.2 mm
WMLF5008 ZZX d: 5 mm | D: 8 mm | B: 2.5 mm | Cr: 0.22 kN | C0r: 0.09 kN | Flange dia D1: 9.2 mm
MLF5009 d: 5 mm | D: 9 mm | B: 2.5 mm | Cr: 0.43 kN | C0r: 0.17 kN | Flange dia D1: 10.2 mm
WMLF5009 ZZX d: 5 mm | D: 9 mm | B: 3 mm | Cr: 0.43 kN | C0r: 0.17 kN | Flange dia D1: 10.2 mm
MLF5010 d: 5 mm | D: 10 mm | B: 3 mm | Cr: 0.43 kN | C0r: 0.17 kN | Flange dia D1: 11.2 mm
WMLF5010 ZZ d: 5 mm | D: 10 mm | B: 4 mm | Cr: 0.43 kN | C0r: 0.17 kN | Flange dia D1: 11.6 mm
F685 d: 5 mm | D: 11 mm | B: 3 mm | Cr: 0.71 kN | C0r: 0.28 kN | Flange dia D1: 12.5 mm
WF685 ZZ d: 5 mm | D: 11 mm | B: 5 mm | Cr: 0.71 kN | C0r: 0.28 kN | Flange dia D1: 12.5 mm
F695 d: 5 mm | D: 13 mm | B: 4 mm | Cr: 1.10 kN | C0r: 0.43 kN | Flange dia D1: 15 mm
F695 ZZ d: 5 mm | D: 13 mm | B: 4 mm | Cr: 1.10 kN | C0r: 0.43 kN | Flange dia D1: 15 mm
F605 d: 5 mm | D: 14 mm | B: 5 mm | Cr: 1.35 kN | C0r: 0.51 kN | Flange dia D1: 16 mm
F605 ZZ d: 5 mm | D: 14 mm | B: 5 mm | Cr: 1.35 kN | C0r: 0.51 kN | Flange dia D1: 16 mm
F625 d: 5 mm | D: 16 mm | B: 5 mm | Cr: 1.75 kN | C0r: 0.67 kN | Flange dia D1: 18 mm
F625 ZZ d: 5 mm | D: 16 mm | B: 5 mm | Cr: 1.75 kN | C0r: 0.67 kN | Flange dia D1: 18 mm
F635 d: 5 mm | D: 19 mm | B: 6 mm | Cr: 2.35 kN | C0r: 0.89 kN | Flange dia D1: 22 mm
F635 ZZ d: 5 mm | D: 19 mm | B: 6 mm | Cr: 2.35 kN | C0r: 0.89 kN | Flange dia D1: 22 mm
MLF6010 d: 6 mm | D: 10 mm | B: 2.5 mm | Cr: 0.50 kN | C0r: 0.22 kN | Flange dia D1: 11.2 mm
WMLF6010 ZZX d: 6 mm | D: 10 mm | B: 3 mm | Cr: 0.50 kN | C0r: 0.22 kN | Flange dia D1: 11.2 mm
MLF6012 d: 6 mm | D: 12 mm | B: 3 mm | Cr: 0.71 kN | C0r: 0.29 kN | Flange dia D1: 13.2 mm
WMLF6012 ZZ d: 6 mm | D: 12 mm | B: 4 mm | Cr: 0.71 kN | C0r: 0.29 kN | Flange dia D1: 13.6 mm
F686 d: 6 mm | D: 13 mm | B: 3.5 mm | Cr: 1.10 kN | C0r: 0.44 kN | Flange dia D1: 15 mm
WF686 ZZ d: 6 mm | D: 13 mm | B: 5 mm | Cr: 1.10 kN | C0r: 0.44 kN | Flange dia D1: 15 mm
F696 d: 6 mm | D: 15 mm | B: 5 mm | Cr: 1.35 kN | C0r: 0.52 kN | Flange dia D1: 17 mm
F696 ZZ d: 6 mm | D: 15 mm | B: 5 mm | Cr: 1.35 kN | C0r: 0.52 kN | Flange dia D1: 17 mm
F606 d: 6 mm | D: 17 mm | B: 6 mm | Cr: 2.25 kN | C0r: 0.84 kN | Flange dia D1: 19 mm
F606 ZZ d: 6 mm | D: 17 mm | B: 6 mm | Cr: 2.25 kN | C0r: 0.84 kN | Flange dia D1: 19 mm
F626 d: 6 mm | D: 19 mm | B: 6 mm | Cr: 2.35 kN | C0r: 0.89 kN | Flange dia D1: 22 mm
F626 ZZ d: 6 mm | D: 19 mm | B: 6 mm | Cr: 2.35 kN | C0r: 0.89 kN | Flange dia D1: 22 mm
F636 d: 6 mm | D: 22 mm | B: 7 mm | Cr: 3.30 kN | C0r: 1.35 kN | Flange dia D1: 25 mm
F636 ZZ d: 6 mm | D: 22 mm | B: 7 mm | Cr: 3.30 kN | C0r: 1.35 kN | Flange dia D1: 25 mm
MLF7011 d: 7 mm | D: 11 mm | B: 2.5 mm | Cr: 0.46 kN | C0r: 0.20 kN | Flange dia D1: 12.2 mm
WMLF7011 ZZX d: 7 mm | D: 11 mm | B: 3 mm | Cr: 0.46 kN | C0r: 0.20 kN | Flange dia D1: 12.2 mm
MLF7013 d: 7 mm | D: 13 mm | B: 3 mm | Cr: 0.54 kN | C0r: 0.28 kN | Flange dia D1: 14.2 mm
WMLF7013 ZZ d: 7 mm | D: 13 mm | B: 4 mm | Cr: 0.54 kN | C0r: 0.28 kN | Flange dia D1: 14.6 mm
F687 d: 7 mm | D: 14 mm | B: 3.5 mm | Cr: 1.15 kN | C0r: 0.51 kN | Flange dia D1: 16 mm
WF687 ZZ d: 7 mm | D: 14 mm | B: 5 mm | Cr: 1.15 kN | C0r: 0.51 kN | Flange dia D1: 16 mm
F697 d: 7 mm | D: 17 mm | B: 5 mm | Cr: 1.60 kN | C0r: 0.71 kN | Flange dia D1: 19 mm
F697 ZZ d: 7 mm | D: 17 mm | B: 5 mm | Cr: 1.60 kN | C0r: 0.71 kN | Flange dia D1: 19 mm
F607 d: 7 mm | D: 19 mm | B: 6 mm | Cr: 2.35 kN | C0r: 0.89 kN | Flange dia D1: 22 mm
F607 ZZ d: 7 mm | D: 19 mm | B: 6 mm | Cr: 2.35 kN | C0r: 0.89 kN | Flange dia D1: 22 mm
F627 d: 7 mm | D: 22 mm | B: 7 mm | Cr: 3.30 kN | C0r: 1.35 kN | Flange dia D1: 25 mm
F627 ZZ d: 7 mm | D: 22 mm | B: 7 mm | Cr: 3.30 kN | C0r: 1.35 kN | Flange dia D1: 25 mm
MLF8012 d: 8 mm | D: 12 mm | B: 2.5 mm | Cr: 0.54 kN | C0r: 0.27 kN | Flange dia D1: 13.2 mm
WMLF8012 ZZX d: 8 mm | D: 12 mm | B: 3.5 mm | Cr: 0.54 kN | C0r: 0.27 kN | Flange dia D1: 13.6 mm
MLF8014 d: 8 mm | D: 14 mm | B: 3.5 mm | Cr: 0.87 kN | C0r: 0.42 kN | Flange dia D1: 15.6 mm
WMLF8014 ZZ d: 8 mm | D: 14 mm | B: 4 mm | Cr: 0.87 kN | C0r: 0.42 kN | Flange dia D1: 15.6 mm
F688 d: 8 mm | D: 16 mm | B: 4 mm | Cr: 1.25 kN | C0r: 0.59 kN | Flange dia D1: 18 mm
WF688 ZZ d: 8 mm | D: 16 mm | B: 5 mm | Cr: 1.25 kN | C0r: 0.59 kN | Flange dia D1: 18 mm
F698 d: 8 mm | D: 19 mm | B: 6 mm | Cr: 2.25 kN | C0r: 0.91 kN | Flange dia D1: 22 mm
F698 ZZ d: 8 mm | D: 19 mm | B: 6 mm | Cr: 2.25 kN | C0r: 0.91 kN | Flange dia D1: 22 mm
F608 d: 8 mm | D: 22 mm | B: 7 mm | Cr: 3.30 kN | C0r: 1.35 kN | Flange dia D1: 25 mm
F608 ZZ d: 8 mm | D: 22 mm | B: 7 mm | Cr: 3.30 kN | C0r: 1.35 kN | Flange dia D1: 25 mm
F689 d: 9 mm | D: 17 mm | B: 4 mm | Cr: 1.35 kN | C0r: 0.66 kN | Flange dia D1: 19 mm
WF689 ZZ d: 9 mm | D: 17 mm | B: 5 mm | Cr: 1.35 kN | C0r: 0.66 kN | Flange dia D1: 19 mm
F699 d: 9 mm | D: 20 mm | B: 6 mm | Cr: 2.45 kN | C0r: 1.05 kN | Flange dia D1: 23 mm
F699 ZZ d: 9 mm | D: 20 mm | B: 6 mm | Cr: 2.45 kN | C0r: 1.05 kN | Flange dia D1: 23 mm
F609 d: 9 mm | D: 24 mm | B: 7 mm | Cr: 3.35 kN | C0r: 1.45 kN | Flange dia D1: 27 mm
F609 ZZ d: 9 mm | D: 24 mm | B: 7 mm | Cr: 3.35 kN | C0r: 1.45 kN | Flange dia D1: 27 mm
