KOYO SBPFL Pressed Steel Rhombic Flanged Units

KOYO SBPFL Pressed Steel Rhombic Flanged Units

Pressed steel 2-bolt rhombic flanged units with SB insert bearings.

Key features

  • Pre-lubricated sealed ball bearing insert
  • Spherical seating compensates for shaft misalignment
  • Housing and insert replaceable separately
  • Unit number, housing number and insert bearing listed
  • Shaft diameter given in mm

Specifications

Product type Ball bearing unit
Series SBPFL Pressed Steel Flange Units
Seal Insert bearing sealed both sides
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B516-B517
SBPFL201 Shaft d: 12 mm | Housing: PFL203 | Bearing: SB201 | Cr: 9.55 kN
SBPFL202 Shaft d: 15 mm | Housing: PFL203 | Bearing: SB202 | Cr: 9.55 kN
SBPFL203 Shaft d: 17 mm | Housing: PFL203 | Bearing: SB203 | Cr: 9.55 kN
SBPFL204 Shaft d: 20 mm | Housing: PFL204 | Bearing: SB204 | Cr: 12.8 kN
SBPFL205 Shaft d: 25 mm | Housing: PFL205 | Bearing: SB205 | Cr: 14.0 kN
SBPFL206 Shaft d: 30 mm | Housing: PFL206 | Bearing: SB206 | Cr: 19.5 kN
SBPFL207 Shaft d: 35 mm | Housing: PFL207 | Bearing: SB207 | Cr: 25.7 kN
Mounted Bearing UnitsKOYO
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO SBPFL Pressed Steel Rhombic Flanged Units

Brand KOYO·Mounted Bearing Units

Available part numbers (7)

SBPFL201, SBPFL202, SBPFL203, SBPFL204, SBPFL205, SBPFL206, SBPFL207

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SBPFL201Shaft d: 12 mm | Housing: PFL203 | Bearing: SB201 | Cr: 9.55 kN
SBPFL202Shaft d: 15 mm | Housing: PFL203 | Bearing: SB202 | Cr: 9.55 kN
SBPFL203Shaft d: 17 mm | Housing: PFL203 | Bearing: SB203 | Cr: 9.55 kN
SBPFL204Shaft d: 20 mm | Housing: PFL204 | Bearing: SB204 | Cr: 12.8 kN
SBPFL205Shaft d: 25 mm | Housing: PFL205 | Bearing: SB205 | Cr: 14.0 kN
SBPFL206Shaft d: 30 mm | Housing: PFL206 | Bearing: SB206 | Cr: 19.5 kN
SBPFL207Shaft d: 35 mm | Housing: PFL207 | Bearing: SB207 | Cr: 25.7 kN
