KOYO SBPP Pressed Steel Pillow Block Units

KOYO SBPP Pressed Steel Pillow Block Units

Pressed steel pillow block units with SB insert bearings for light loads and compact, low-weight installations.

Key features

  • Pre-lubricated sealed ball bearing insert
  • Spherical seating compensates for shaft misalignment
  • Housing and insert replaceable separately
  • Unit number, housing number and insert bearing listed
  • Shaft diameter given in mm

Specifications

Product type Ball bearing unit
Series SBPP Pressed Steel Pillow Blocks
Seal Insert bearing sealed both sides
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B488-B489
SBPP201 Shaft d: 12 mm | Housing: PP203F | Bearing: SB201 | Cr: 9.55 kN
SBPP202 Shaft d: 15 mm | Housing: PP203F | Bearing: SB202 | Cr: 9.55 kN
SBPP203 Shaft d: 17 mm | Housing: PP203F | Bearing: SB203 | Cr: 9.55 kN
SBPP204 Shaft d: 20 mm | Housing: PP204F | Bearing: SB204 | Cr: 12.8 kN
SBPP205 Shaft d: 25 mm | Housing: PP205F | Bearing: SB205 | Cr: 14.0 kN
SBPP206 Shaft d: 30 mm | Housing: PP206F | Bearing: SB206 | Cr: 19.5 kN
SBPP207 Shaft d: 35 mm | Housing: PP207F | Bearing: SB207 | Cr: 25.7 kN
Mounted Bearing UnitsKOYO
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO SBPP Pressed Steel Pillow Block Units

Brand KOYO·Mounted Bearing Units

Available part numbers (7)

SBPP201, SBPP202, SBPP203, SBPP204, SBPP205, SBPP206, SBPP207

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SBPP201Shaft d: 12 mm | Housing: PP203F | Bearing: SB201 | Cr: 9.55 kN
SBPP202Shaft d: 15 mm | Housing: PP203F | Bearing: SB202 | Cr: 9.55 kN
SBPP203Shaft d: 17 mm | Housing: PP203F | Bearing: SB203 | Cr: 9.55 kN
SBPP204Shaft d: 20 mm | Housing: PP204F | Bearing: SB204 | Cr: 12.8 kN
SBPP205Shaft d: 25 mm | Housing: PP205F | Bearing: SB205 | Cr: 14.0 kN
SBPP206Shaft d: 30 mm | Housing: PP206F | Bearing: SB206 | Cr: 19.5 kN
SBPP207Shaft d: 35 mm | Housing: PP207F | Bearing: SB207 | Cr: 25.7 kN
