KOYO Self-Aligning Ball Bearings, Open (12, 13, 22, 23, K Bore)

KOYO Self-Aligning Ball Bearings, Open (12, 13, 22, 23, K Bore)

Open self-aligning ball bearings in the 12, 13, 22 and 23 series plus small 1xx sizes, with cylindrical bore or 1:12 tapered bore (K suffix). The spherical outer raceway tolerates shaft misalignment.

Key features

  • Spherical outer ring raceway accommodates misalignment
  • Cylindrical bore or 1:12 tapered bore (K)
  • Tapered bore types mount with adapter sleeves
  • Low friction and heat generation
  • Series 12, 13, 22, 23 and small 1xx sizes

Specifications

Bearing type Self-aligning ball bearing
Seal / shield Open
Bore Cylindrical or tapered 1:12 (K)
Series 12, 13, 22, 23
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B136-B143
135 d: 5 mm | D: 19 mm | B: 6 mm | Cr: 2.55 kN | C0r: 0.48 kN | Mass: 0.009 kg
126 d: 6 mm | D: 19 mm | B: 6 mm | Cr: 2.50 kN | C0r: 0.48 kN | Mass: 0.009 kg
127 d: 7 mm | D: 22 mm | B: 7 mm | Cr: 2.65 kN | C0r: 0.56 kN | Mass: 0.014 kg
108 d: 8 mm | D: 22 mm | B: 7 mm | Cr: 2.60 kN | C0r: 0.56 kN | Mass: 0.014 kg
129 d: 9 mm | D: 26 mm | B: 8 mm | Cr: 3.80 kN | C0r: 0.80 kN | Mass: 0.022 kg
1200 d: 10 mm | D: 30 mm | B: 9 mm | Cr: 5.50 kN | C0r: 1.20 kN | Mass: 0.034 kg
2200 d: 10 mm | D: 30 mm | B: 14 mm | Cr: 7.40 kN | C0r: 1.60 kN | Mass: 0.047 kg
1300 d: 10 mm | D: 35 mm | B: 11 mm | Cr: 7.25 kN | C0r: 1.60 kN | Mass: 0.058 kg
2300 d: 10 mm | D: 35 mm | B: 17 mm | Cr: 9.30 kN | C0r: 2.10 kN | Mass: 0.085 kg
1201 d: 12 mm | D: 32 mm | B: 10 mm | Cr: 5.60 kN | C0r: 1.25 kN | Mass: 0.040 kg
2201 d: 12 mm | D: 32 mm | B: 14 mm | Cr: 7.65 kN | C0r: 1.75 kN | Mass: 0.053 kg
1301 d: 12 mm | D: 37 mm | B: 12 mm | Cr: 9.40 kN | C0r: 2.15 kN | Mass: 0.067 kg
2301 d: 12 mm | D: 37 mm | B: 17 mm | Cr: 9.70 kN | C0r: 2.30 kN | Mass: 0.095 kg
1202 d: 15 mm | D: 35 mm | B: 11 mm | Cr: 7.45 kN | C0r: 1.75 kN | Mass: 0.049 kg
2202 d: 15 mm | D: 35 mm | B: 14 mm | Cr: 7.70 kN | C0r: 1.85 kN | Mass: 0.060 kg
1302 d: 15 mm | D: 42 mm | B: 13 mm | Cr: 9.55 kN | C0r: 2.30 kN | Mass: 0.094 kg
2302 d: 15 mm | D: 42 mm | B: 17 mm | Cr: 12.1 kN | C0r: 2.90 kN | Mass: 0.114 kg
1203 d: 17 mm | D: 40 mm | B: 12 mm | Cr: 7.90 kN | C0r: 2.00 kN | Mass: 0.073 kg
2203 d: 17 mm | D: 40 mm | B: 16 mm | Cr: 9.80 kN | C0r: 2.40 kN | Mass: 0.088 kg
1303 d: 17 mm | D: 47 mm | B: 14 mm | Cr: 12.5 kN | C0r: 3.20 kN | Mass: 0.130 kg
2303 d: 17 mm | D: 47 mm | B: 19 mm | Cr: 14.5 kN | C0r: 3.60 kN | Mass: 0.158 kg
1204 d: 20 mm | D: 47 mm | B: 14 mm | Cr: 9.90 kN | C0r: 2.60 kN | Mass: 0.120 kg
1204K d: 20 mm | D: 47 mm | B: 14 mm | Cr: 9.90 kN | C0r: 2.60 kN | Mass: 0.118 kg
2204 d: 20 mm | D: 47 mm | B: 18 mm | Cr: 12.6 kN | C0r: 3.30 kN | Mass: 0.140 kg
2204K d: 20 mm | D: 47 mm | B: 18 mm | Cr: 12.6 kN | C0r: 3.30 kN | Mass: 0.136 kg
1304 d: 20 mm | D: 52 mm | B: 15 mm | Cr: 12.4 kN | C0r: 3.30 kN | Mass: 0.163 kg
1304K d: 20 mm | D: 52 mm | B: 15 mm | Cr: 12.4 kN | C0r: 3.30 kN | Mass: 0.161 kg
2304 d: 20 mm | D: 52 mm | B: 21 mm | Cr: 18.0 kN | C0r: 4.70 kN | Mass: 0.209 kg
2304K d: 20 mm | D: 52 mm | B: 21 mm | Cr: 18.0 kN | C0r: 4.70 kN | Mass: 0.205 kg
1205 d: 25 mm | D: 52 mm | B: 15 mm | Cr: 12.1 kN | C0r: 3.30 kN | Mass: 0.141 kg
1205K d: 25 mm | D: 52 mm | B: 15 mm | Cr: 12.1 kN | C0r: 3.30 kN | Mass: 0.138 kg
2205 d: 25 mm | D: 52 mm | B: 18 mm | Cr: 12.6 kN | C0r: 3.50 kN | Mass: 0.163 kg
2205K d: 25 mm | D: 52 mm | B: 18 mm | Cr: 12.6 kN | C0r: 3.50 kN | Mass: 0.158 kg
1305 d: 25 mm | D: 62 mm | B: 17 mm | Cr: 18.0 kN | C0r: 5.00 kN | Mass: 0.257 kg
1305K d: 25 mm | D: 62 mm | B: 17 mm | Cr: 18.0 kN | C0r: 5.00 kN | Mass: 0.252 kg
2305 d: 25 mm | D: 62 mm | B: 24 mm | Cr: 24.4 kN | C0r: 6.60 kN | Mass: 0.335 kg
2305K d: 25 mm | D: 62 mm | B: 24 mm | Cr: 24.4 kN | C0r: 6.60 kN | Mass: 0.327 kg
1206 d: 30 mm | D: 62 mm | B: 16 mm | Cr: 15.6 kN | C0r: 4.65 kN | Mass: 0.220 kg
1206K d: 30 mm | D: 62 mm | B: 16 mm | Cr: 15.6 kN | C0r: 4.65 kN | Mass: 0.216 kg
2206 d: 30 mm | D: 62 mm | B: 20 mm | Cr: 15.6 kN | C0r: 4.65 kN | Mass: 0.260 kg
2206K d: 30 mm | D: 62 mm | B: 20 mm | Cr: 15.6 kN | C0r: 4.65 kN | Mass: 0.254 kg
1306 d: 30 mm | D: 72 mm | B: 19 mm | Cr: 21.3 kN | C0r: 6.30 kN | Mass: 0.387 kg
1306K d: 30 mm | D: 72 mm | B: 19 mm | Cr: 21.3 kN | C0r: 6.30 kN | Mass: 0.381 kg
2306 d: 30 mm | D: 72 mm | B: 27 mm | Cr: 31.4 kN | C0r: 8.75 kN | Mass: 0.500 kg
2306K d: 30 mm | D: 72 mm | B: 27 mm | Cr: 31.4 kN | C0r: 8.75 kN | Mass: 0.489 kg
1207 d: 35 mm | D: 72 mm | B: 17 mm | Cr: 15.8 kN | C0r: 5.10 kN | Mass: 0.323 kg
1207K d: 35 mm | D: 72 mm | B: 17 mm | Cr: 15.8 kN | C0r: 5.10 kN | Mass: 0.317 kg
2207 d: 35 mm | D: 72 mm | B: 23 mm | Cr: 21.6 kN | C0r: 6.60 kN | Mass: 0.403 kg
2207K d: 35 mm | D: 72 mm | B: 23 mm | Cr: 21.6 kN | C0r: 6.60 kN | Mass: 0.396 kg
1307 d: 35 mm | D: 80 mm | B: 21 mm | Cr: 25.1 kN | C0r: 7.85 kN | Mass: 0.510 kg
1307K d: 35 mm | D: 80 mm | B: 21 mm | Cr: 25.1 kN | C0r: 7.85 kN | Mass: 0.502 kg
2307 d: 35 mm | D: 80 mm | B: 31 mm | Cr: 39.4 kN | C0r: 11.3 kN | Mass: 0.675 kg
2307K d: 35 mm | D: 80 mm | B: 31 mm | Cr: 39.4 kN | C0r: 11.3 kN | Mass: 0.657 kg
1208 d: 40 mm | D: 80 mm | B: 18 mm | Cr: 19.2 kN | C0r: 6.50 kN | Mass: 0.417 kg
1208K d: 40 mm | D: 80 mm | B: 18 mm | Cr: 19.2 kN | C0r: 6.50 kN | Mass: 0.411 kg
2208 d: 40 mm | D: 80 mm | B: 23 mm | Cr: 22.4 kN | C0r: 7.40 kN | Mass: 0.505 kg
2208K d: 40 mm | D: 80 mm | B: 23 mm | Cr: 22.4 kN | C0r: 7.40 kN | Mass: 0.494 kg
1308 d: 40 mm | D: 90 mm | B: 23 mm | Cr: 29.5 kN | C0r: 9.70 kN | Mass: 0.715 kg
1308K d: 40 mm | D: 90 mm | B: 23 mm | Cr: 29.5 kN | C0r: 9.70 kN | Mass: 0.704 kg
2308 d: 40 mm | D: 90 mm | B: 33 mm | Cr: 44.9 kN | C0r: 13.5 kN | Mass: 0.925 kg
2308K d: 40 mm | D: 90 mm | B: 33 mm | Cr: 44.9 kN | C0r: 13.5 kN | Mass: 0.903 kg
1209 d: 45 mm | D: 85 mm | B: 19 mm | Cr: 21.8 kN | C0r: 7.35 kN | Mass: 0.465 kg
1209K d: 45 mm | D: 85 mm | B: 19 mm | Cr: 21.8 kN | C0r: 7.35 kN | Mass: 0.459 kg
2209 d: 45 mm | D: 85 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.15 kN | Mass: 0.545 kg
2209K d: 45 mm | D: 85 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.15 kN | Mass: 0.533 kg
1309 d: 45 mm | D: 100 mm | B: 25 mm | Cr: 38.1 kN | C0r: 12.7 kN | Mass: 0.957 kg
1309K d: 45 mm | D: 100 mm | B: 25 mm | Cr: 38.1 kN | C0r: 12.7 kN | Mass: 0.942 kg
2309 d: 45 mm | D: 100 mm | B: 36 mm | Cr: 54.4 kN | C0r: 16.7 kN | Mass: 1.23 kg
2309K d: 45 mm | D: 100 mm | B: 36 mm | Cr: 54.4 kN | C0r: 16.7 kN | Mass: 1.20 kg
1210 d: 50 mm | D: 90 mm | B: 20 mm | Cr: 22.7 kN | C0r: 8.10 kN | Mass: 0.525 kg
1210K d: 50 mm | D: 90 mm | B: 20 mm | Cr: 22.7 kN | C0r: 8.10 kN | Mass: 0.515 kg
2210 d: 50 mm | D: 90 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.50 kN | Mass: 0.590 kg
2210K d: 50 mm | D: 90 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.50 kN | Mass: 0.577 kg
1310 d: 50 mm | D: 110 mm | B: 27 mm | Cr: 43.4 kN | C0r: 14.1 kN | Mass: 1.21 kg
1310K d: 50 mm | D: 110 mm | B: 27 mm | Cr: 43.4 kN | C0r: 14.1 kN | Mass: 1.19 kg
2310 d: 50 mm | D: 110 mm | B: 40 mm | Cr: 64.6 kN | C0r: 20.3 kN | Mass: 1.64 kg
2310K d: 50 mm | D: 110 mm | B: 40 mm | Cr: 64.6 kN | C0r: 20.3 kN | Mass: 1.60 kg
1211 d: 55 mm | D: 100 mm | B: 21 mm | Cr: 26.8 kN | C0r: 10.0 kN | Mass: 0.705 kg
1211K d: 55 mm | D: 100 mm | B: 21 mm | Cr: 26.8 kN | C0r: 10.0 kN | Mass: 0.693 kg
2211 d: 55 mm | D: 100 mm | B: 25 mm | Cr: 26.8 kN | C0r: 10.0 kN | Mass: 0.810 kg
2211K d: 55 mm | D: 100 mm | B: 25 mm | Cr: 26.8 kN | C0r: 10.0 kN | Mass: 0.792 kg
1311 d: 55 mm | D: 120 mm | B: 29 mm | Cr: 51.3 kN | C0r: 17.9 kN | Mass: 1.58 kg
1311K d: 55 mm | D: 120 mm | B: 29 mm | Cr: 51.3 kN | C0r: 17.9 kN | Mass: 1.56 kg
2311 d: 55 mm | D: 120 mm | B: 43 mm | Cr: 75.3 kN | C0r: 24.0 kN | Mass: 2.10 kg
2311K d: 55 mm | D: 120 mm | B: 43 mm | Cr: 75.3 kN | C0r: 24.0 kN | Mass: 2.05 kg
1212 d: 60 mm | D: 110 mm | B: 22 mm | Cr: 30.2 kN | C0r: 11.5 kN | Mass: 0.900 kg
1212K d: 60 mm | D: 110 mm | B: 22 mm | Cr: 30.2 kN | C0r: 11.5 kN | Mass: 0.885 kg
2212 d: 60 mm | D: 110 mm | B: 28 mm | Cr: 34.1 kN | C0r: 12.6 kN | Mass: 1.09 kg
2212K d: 60 mm | D: 110 mm | B: 28 mm | Cr: 34.1 kN | C0r: 12.6 kN | Mass: 1.07 kg
1312 d: 60 mm | D: 130 mm | B: 31 mm | Cr: 57.2 kN | C0r: 20.8 kN | Mass: 1.96 kg
1312K d: 60 mm | D: 130 mm | B: 31 mm | Cr: 57.2 kN | C0r: 20.8 kN | Mass: 1.93 kg
2312 d: 60 mm | D: 130 mm | B: 46 mm | Cr: 87.2 kN | C0r: 28.3 kN | Mass: 2.60 kg
2312K d: 60 mm | D: 130 mm | B: 46 mm | Cr: 87.2 kN | C0r: 28.3 kN | Mass: 2.53 kg
1213 d: 65 mm | D: 120 mm | B: 23 mm | Cr: 31.0 kN | C0r: 12.5 kN | Mass: 1.15 kg
1213K d: 65 mm | D: 120 mm | B: 23 mm | Cr: 31.0 kN | C0r: 12.5 kN | Mass: 1.13 kg
2213 d: 65 mm | D: 120 mm | B: 31 mm | Cr: 43.5 kN | C0r: 16.4 kN | Mass: 1.46 kg
2213K d: 65 mm | D: 120 mm | B: 31 mm | Cr: 43.5 kN | C0r: 16.4 kN | Mass: 1.43 kg
1313 d: 65 mm | D: 140 mm | B: 33 mm | Cr: 61.7 kN | C0r: 22.9 kN | Mass: 2.45 kg
1313K d: 65 mm | D: 140 mm | B: 33 mm | Cr: 61.7 kN | C0r: 22.9 kN | Mass: 2.41 kg
2313 d: 65 mm | D: 140 mm | B: 48 mm | Cr: 95.8 kN | C0r: 32.5 kN | Mass: 3.23 kg
2313K d: 65 mm | D: 140 mm | B: 48 mm | Cr: 95.8 kN | C0r: 32.5 kN | Mass: 3.15 kg
1214 d: 70 mm | D: 125 mm | B: 24 mm | Cr: 34.6 kN | C0r: 13.8 kN | Mass: 1.26 kg
2214 d: 70 mm | D: 125 mm | B: 31 mm | Cr: 43.9 kN | C0r: 17.1 kN | Mass: 1.52 kg
1314 d: 70 mm | D: 150 mm | B: 35 mm | Cr: 74.0 kN | C0r: 27.7 kN | Mass: 2.99 kg
2314 d: 70 mm | D: 150 mm | B: 51 mm | Cr: 89.6 kN | C0r: 31.7 kN | Mass: 4.23 kg
1215 d: 75 mm | D: 130 mm | B: 25 mm | Cr: 38.8 kN | C0r: 15.7 kN | Mass: 1.36 kg
1215K d: 75 mm | D: 130 mm | B: 25 mm | Cr: 38.8 kN | C0r: 15.7 kN | Mass: 1.34 kg
2215 d: 75 mm | D: 130 mm | B: 31 mm | Cr: 44.2 kN | C0r: 17.8 kN | Mass: 1.62 kg
2215K d: 75 mm | D: 130 mm | B: 31 mm | Cr: 44.2 kN | C0r: 17.8 kN | Mass: 1.58 kg
1315 d: 75 mm | D: 160 mm | B: 37 mm | Cr: 78.9 kN | C0r: 29.9 kN | Mass: 3.56 kg
1315K d: 75 mm | D: 160 mm | B: 37 mm | Cr: 78.9 kN | C0r: 29.9 kN | Mass: 3.51 kg
2315 d: 75 mm | D: 160 mm | B: 55 mm | Cr: 103 kN | C0r: 36.8 kN | Mass: 5.13 kg
2315K d: 75 mm | D: 160 mm | B: 55 mm | Cr: 103 kN | C0r: 36.8 kN | Mass: 5.01 kg
1216 d: 80 mm | D: 140 mm | B: 26 mm | Cr: 39.8 kN | C0r: 17.0 kN | Mass: 1.67 kg
1216K d: 80 mm | D: 140 mm | B: 26 mm | Cr: 39.8 kN | C0r: 17.0 kN | Mass: 1.64 kg
2216 d: 80 mm | D: 140 mm | B: 33 mm | Cr: 49.0 kN | C0r: 19.9 kN | Mass: 2.01 kg
2216K d: 80 mm | D: 140 mm | B: 33 mm | Cr: 49.0 kN | C0r: 19.9 kN | Mass: 1.97 kg
1316 d: 80 mm | D: 170 mm | B: 39 mm | Cr: 88.1 kN | C0r: 33.1 kN | Mass: 4.18 kg
1316K d: 80 mm | D: 170 mm | B: 39 mm | Cr: 88.1 kN | C0r: 33.1 kN | Mass: 4.12 kg
2316 d: 80 mm | D: 170 mm | B: 58 mm | Cr: 129 kN | C0r: 45.7 kN | Mass: 6.10 kg
2316K d: 80 mm | D: 170 mm | B: 58 mm | Cr: 129 kN | C0r: 45.7 kN | Mass: 5.96 kg
1217 d: 85 mm | D: 150 mm | B: 28 mm | Cr: 49.2 kN | C0r: 20.8 kN | Mass: 2.07 kg
1217K d: 85 mm | D: 150 mm | B: 28 mm | Cr: 49.2 kN | C0r: 20.8 kN | Mass: 2.04 kg
2217 d: 85 mm | D: 150 mm | B: 36 mm | Cr: 58.3 kN | C0r: 23.6 kN | Mass: 2.52 kg
2217K d: 85 mm | D: 150 mm | B: 36 mm | Cr: 58.3 kN | C0r: 23.6 kN | Mass: 2.46 kg
1317 d: 85 mm | D: 180 mm | B: 41 mm | Cr: 97.3 kN | C0r: 37.8 kN | Mass: 4.98 kg
1317K d: 85 mm | D: 180 mm | B: 41 mm | Cr: 97.3 kN | C0r: 37.8 kN | Mass: 4.91 kg
2317 d: 85 mm | D: 180 mm | B: 60 mm | Cr: 141 kN | C0r: 51.5 kN | Mass: 7.05 kg
2317K d: 85 mm | D: 180 mm | B: 60 mm | Cr: 141 kN | C0r: 51.5 kN | Mass: 6.89 kg
1218 d: 90 mm | D: 160 mm | B: 30 mm | Cr: 56.8 kN | C0r: 23.4 kN | Mass: 2.52 kg
1218K d: 90 mm | D: 160 mm | B: 30 mm | Cr: 56.8 kN | C0r: 23.4 kN | Mass: 2.48 kg
2218 d: 90 mm | D: 160 mm | B: 40 mm | Cr: 67.7 kN | C0r: 27.2 kN | Mass: 3.40 kg
2218K d: 90 mm | D: 160 mm | B: 40 mm | Cr: 67.7 kN | C0r: 27.2 kN | Mass: 3.33 kg
1318 d: 90 mm | D: 190 mm | B: 43 mm | Cr: 116 kN | C0r: 44.4 kN | Mass: 5.80 kg
1318K d: 90 mm | D: 190 mm | B: 43 mm | Cr: 116 kN | C0r: 44.4 kN | Mass: 5.71 kg
2318 d: 90 mm | D: 190 mm | B: 64 mm | Cr: 153 kN | C0r: 57.9 kN | Mass: 8.44 kg
2318K d: 90 mm | D: 190 mm | B: 64 mm | Cr: 153 kN | C0r: 57.9 kN | Mass: 8.25 kg
1219 d: 95 mm | D: 170 mm | B: 32 mm | Cr: 57.0 kN | C0r: 24.3 kN | Mass: 3.10 kg
1219K d: 95 mm | D: 170 mm | B: 32 mm | Cr: 57.0 kN | C0r: 24.3 kN | Mass: 3.05 kg
2219 d: 95 mm | D: 170 mm | B: 43 mm | Cr: 82.7 kN | C0r: 34.3 kN | Mass: 4.10 kg
2219K d: 95 mm | D: 170 mm | B: 43 mm | Cr: 82.7 kN | C0r: 34.3 kN | Mass: 4.00 kg
1319 d: 95 mm | D: 200 mm | B: 45 mm | Cr: 132 kN | C0r: 50.8 kN | Mass: 6.69 kg
1319K d: 95 mm | D: 200 mm | B: 45 mm | Cr: 132 kN | C0r: 50.8 kN | Mass: 6.59 kg
2319 d: 95 mm | D: 200 mm | B: 67 mm | Cr: 166 kN | C0r: 64.8 kN | Mass: 9.79 kg
2319K d: 95 mm | D: 200 mm | B: 67 mm | Cr: 166 kN | C0r: 64.8 kN | Mass: 9.57 kg
1220 d: 100 mm | D: 180 mm | B: 34 mm | Cr: 69.0 kN | C0r: 29.7 kN | Mass: 3.70 kg
1220K d: 100 mm | D: 180 mm | B: 34 mm | Cr: 69.0 kN | C0r: 29.7 kN | Mass: 3.64 kg
2220 d: 100 mm | D: 180 mm | B: 46 mm | Cr: 80.9 kN | C0r: 34.0 kN | Mass: 4.98 kg
2220K d: 100 mm | D: 180 mm | B: 46 mm | Cr: 80.9 kN | C0r: 34.0 kN | Mass: 4.87 kg
1320 d: 100 mm | D: 215 mm | B: 47 mm | Cr: 143 kN | C0r: 57.3 kN | Mass: 8.30 kg
1320K d: 100 mm | D: 215 mm | B: 47 mm | Cr: 143 kN | C0r: 57.3 kN | Mass: 8.19 kg
2320 d: 100 mm | D: 215 mm | B: 73 mm | Cr: 183 kN | C0r: 73.4 kN | Mass: 12.4 kg
2320K d: 100 mm | D: 215 mm | B: 73 mm | Cr: 183 kN | C0r: 73.4 kN | Mass: 12.1 kg
1221 d: 105 mm | D: 190 mm | B: 36 mm | Cr: 77.0 kN | C0r: 34.0 kN | Mass: 4.37 kg
2221 d: 105 mm | D: 190 mm | B: 50 mm | Cr: 94.9 kN | C0r: 40.1 kN | Mass: 6.07 kg
1321 d: 105 mm | D: 225 mm | B: 49 mm | Cr: 149 kN | C0r: 60.2 kN | Mass: 10.0 kg
2321 d: 105 mm | D: 225 mm | B: 77 mm | Cr: 187 kN | C0r: 78.0 kN | Mass: 14.3 kg
1222 d: 110 mm | D: 200 mm | B: 38 mm | Cr: 80.2 kN | C0r: 35.2 kN | Mass: 5.15 kg
1222K d: 110 mm | D: 200 mm | B: 38 mm | Cr: 80.2 kN | C0r: 35.2 kN | Mass: 5.07 kg
2222 d: 110 mm | D: 200 mm | B: 53 mm | Cr: 120 kN | C0r: 48.9 kN | Mass: 7.10 kg
2222K d: 110 mm | D: 200 mm | B: 53 mm | Cr: 120 kN | C0r: 48.9 kN | Mass: 6.94 kg
1322 d: 110 mm | D: 240 mm | B: 50 mm | Cr: 150 kN | C0r: 63.2 kN | Mass: 11.8 kg
1322K d: 110 mm | D: 240 mm | B: 50 mm | Cr: 150 kN | C0r: 63.2 kN | Mass: 11.7 kg
2322 d: 110 mm | D: 240 mm | B: 80 mm | Cr: 200 kN | C0r: 85.7 kN | Mass: 17.3 kg
2322K d: 110 mm | D: 240 mm | B: 80 mm | Cr: 200 kN | C0r: 85.7 kN | Mass: 16.9 kg
Self-Aligning Ball BearingsKOYO
165 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO Self-Aligning Ball Bearings, Open (12, 13, 22, 23, K Bore)

Brand KOYO·Self-Aligning Ball Bearings

Available part numbers (165)

135, 126, 127, 108, 129, 1200, 2200, 1300, 2300, 1201 + 155 more — see full table ↓

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
135d: 5 mm | D: 19 mm | B: 6 mm | Cr: 2.55 kN | C0r: 0.48 kN | Mass: 0.009 kg
126d: 6 mm | D: 19 mm | B: 6 mm | Cr: 2.50 kN | C0r: 0.48 kN | Mass: 0.009 kg
127d: 7 mm | D: 22 mm | B: 7 mm | Cr: 2.65 kN | C0r: 0.56 kN | Mass: 0.014 kg
108d: 8 mm | D: 22 mm | B: 7 mm | Cr: 2.60 kN | C0r: 0.56 kN | Mass: 0.014 kg
129d: 9 mm | D: 26 mm | B: 8 mm | Cr: 3.80 kN | C0r: 0.80 kN | Mass: 0.022 kg
1200d: 10 mm | D: 30 mm | B: 9 mm | Cr: 5.50 kN | C0r: 1.20 kN | Mass: 0.034 kg
2200d: 10 mm | D: 30 mm | B: 14 mm | Cr: 7.40 kN | C0r: 1.60 kN | Mass: 0.047 kg
1300d: 10 mm | D: 35 mm | B: 11 mm | Cr: 7.25 kN | C0r: 1.60 kN | Mass: 0.058 kg
2300d: 10 mm | D: 35 mm | B: 17 mm | Cr: 9.30 kN | C0r: 2.10 kN | Mass: 0.085 kg
1201d: 12 mm | D: 32 mm | B: 10 mm | Cr: 5.60 kN | C0r: 1.25 kN | Mass: 0.040 kg
2201d: 12 mm | D: 32 mm | B: 14 mm | Cr: 7.65 kN | C0r: 1.75 kN | Mass: 0.053 kg
1301d: 12 mm | D: 37 mm | B: 12 mm | Cr: 9.40 kN | C0r: 2.15 kN | Mass: 0.067 kg
2301d: 12 mm | D: 37 mm | B: 17 mm | Cr: 9.70 kN | C0r: 2.30 kN | Mass: 0.095 kg
1202d: 15 mm | D: 35 mm | B: 11 mm | Cr: 7.45 kN | C0r: 1.75 kN | Mass: 0.049 kg
2202d: 15 mm | D: 35 mm | B: 14 mm | Cr: 7.70 kN | C0r: 1.85 kN | Mass: 0.060 kg
1302d: 15 mm | D: 42 mm | B: 13 mm | Cr: 9.55 kN | C0r: 2.30 kN | Mass: 0.094 kg
2302d: 15 mm | D: 42 mm | B: 17 mm | Cr: 12.1 kN | C0r: 2.90 kN | Mass: 0.114 kg
1203d: 17 mm | D: 40 mm | B: 12 mm | Cr: 7.90 kN | C0r: 2.00 kN | Mass: 0.073 kg
2203d: 17 mm | D: 40 mm | B: 16 mm | Cr: 9.80 kN | C0r: 2.40 kN | Mass: 0.088 kg
1303d: 17 mm | D: 47 mm | B: 14 mm | Cr: 12.5 kN | C0r: 3.20 kN | Mass: 0.130 kg
2303d: 17 mm | D: 47 mm | B: 19 mm | Cr: 14.5 kN | C0r: 3.60 kN | Mass: 0.158 kg
1204d: 20 mm | D: 47 mm | B: 14 mm | Cr: 9.90 kN | C0r: 2.60 kN | Mass: 0.120 kg
1204Kd: 20 mm | D: 47 mm | B: 14 mm | Cr: 9.90 kN | C0r: 2.60 kN | Mass: 0.118 kg
2204d: 20 mm | D: 47 mm | B: 18 mm | Cr: 12.6 kN | C0r: 3.30 kN | Mass: 0.140 kg
2204Kd: 20 mm | D: 47 mm | B: 18 mm | Cr: 12.6 kN | C0r: 3.30 kN | Mass: 0.136 kg
1304d: 20 mm | D: 52 mm | B: 15 mm | Cr: 12.4 kN | C0r: 3.30 kN | Mass: 0.163 kg
1304Kd: 20 mm | D: 52 mm | B: 15 mm | Cr: 12.4 kN | C0r: 3.30 kN | Mass: 0.161 kg
2304d: 20 mm | D: 52 mm | B: 21 mm | Cr: 18.0 kN | C0r: 4.70 kN | Mass: 0.209 kg
2304Kd: 20 mm | D: 52 mm | B: 21 mm | Cr: 18.0 kN | C0r: 4.70 kN | Mass: 0.205 kg
1205d: 25 mm | D: 52 mm | B: 15 mm | Cr: 12.1 kN | C0r: 3.30 kN | Mass: 0.141 kg
1205Kd: 25 mm | D: 52 mm | B: 15 mm | Cr: 12.1 kN | C0r: 3.30 kN | Mass: 0.138 kg
2205d: 25 mm | D: 52 mm | B: 18 mm | Cr: 12.6 kN | C0r: 3.50 kN | Mass: 0.163 kg
2205Kd: 25 mm | D: 52 mm | B: 18 mm | Cr: 12.6 kN | C0r: 3.50 kN | Mass: 0.158 kg
1305d: 25 mm | D: 62 mm | B: 17 mm | Cr: 18.0 kN | C0r: 5.00 kN | Mass: 0.257 kg
1305Kd: 25 mm | D: 62 mm | B: 17 mm | Cr: 18.0 kN | C0r: 5.00 kN | Mass: 0.252 kg
2305d: 25 mm | D: 62 mm | B: 24 mm | Cr: 24.4 kN | C0r: 6.60 kN | Mass: 0.335 kg
2305Kd: 25 mm | D: 62 mm | B: 24 mm | Cr: 24.4 kN | C0r: 6.60 kN | Mass: 0.327 kg
1206d: 30 mm | D: 62 mm | B: 16 mm | Cr: 15.6 kN | C0r: 4.65 kN | Mass: 0.220 kg
1206Kd: 30 mm | D: 62 mm | B: 16 mm | Cr: 15.6 kN | C0r: 4.65 kN | Mass: 0.216 kg
2206d: 30 mm | D: 62 mm | B: 20 mm | Cr: 15.6 kN | C0r: 4.65 kN | Mass: 0.260 kg
2206Kd: 30 mm | D: 62 mm | B: 20 mm | Cr: 15.6 kN | C0r: 4.65 kN | Mass: 0.254 kg
1306d: 30 mm | D: 72 mm | B: 19 mm | Cr: 21.3 kN | C0r: 6.30 kN | Mass: 0.387 kg
1306Kd: 30 mm | D: 72 mm | B: 19 mm | Cr: 21.3 kN | C0r: 6.30 kN | Mass: 0.381 kg
2306d: 30 mm | D: 72 mm | B: 27 mm | Cr: 31.4 kN | C0r: 8.75 kN | Mass: 0.500 kg
2306Kd: 30 mm | D: 72 mm | B: 27 mm | Cr: 31.4 kN | C0r: 8.75 kN | Mass: 0.489 kg
1207d: 35 mm | D: 72 mm | B: 17 mm | Cr: 15.8 kN | C0r: 5.10 kN | Mass: 0.323 kg
1207Kd: 35 mm | D: 72 mm | B: 17 mm | Cr: 15.8 kN | C0r: 5.10 kN | Mass: 0.317 kg
2207d: 35 mm | D: 72 mm | B: 23 mm | Cr: 21.6 kN | C0r: 6.60 kN | Mass: 0.403 kg
2207Kd: 35 mm | D: 72 mm | B: 23 mm | Cr: 21.6 kN | C0r: 6.60 kN | Mass: 0.396 kg
1307d: 35 mm | D: 80 mm | B: 21 mm | Cr: 25.1 kN | C0r: 7.85 kN | Mass: 0.510 kg
1307Kd: 35 mm | D: 80 mm | B: 21 mm | Cr: 25.1 kN | C0r: 7.85 kN | Mass: 0.502 kg
2307d: 35 mm | D: 80 mm | B: 31 mm | Cr: 39.4 kN | C0r: 11.3 kN | Mass: 0.675 kg
2307Kd: 35 mm | D: 80 mm | B: 31 mm | Cr: 39.4 kN | C0r: 11.3 kN | Mass: 0.657 kg
1208d: 40 mm | D: 80 mm | B: 18 mm | Cr: 19.2 kN | C0r: 6.50 kN | Mass: 0.417 kg
1208Kd: 40 mm | D: 80 mm | B: 18 mm | Cr: 19.2 kN | C0r: 6.50 kN | Mass: 0.411 kg
2208d: 40 mm | D: 80 mm | B: 23 mm | Cr: 22.4 kN | C0r: 7.40 kN | Mass: 0.505 kg
2208Kd: 40 mm | D: 80 mm | B: 23 mm | Cr: 22.4 kN | C0r: 7.40 kN | Mass: 0.494 kg
1308d: 40 mm | D: 90 mm | B: 23 mm | Cr: 29.5 kN | C0r: 9.70 kN | Mass: 0.715 kg
1308Kd: 40 mm | D: 90 mm | B: 23 mm | Cr: 29.5 kN | C0r: 9.70 kN | Mass: 0.704 kg
2308d: 40 mm | D: 90 mm | B: 33 mm | Cr: 44.9 kN | C0r: 13.5 kN | Mass: 0.925 kg
2308Kd: 40 mm | D: 90 mm | B: 33 mm | Cr: 44.9 kN | C0r: 13.5 kN | Mass: 0.903 kg
1209d: 45 mm | D: 85 mm | B: 19 mm | Cr: 21.8 kN | C0r: 7.35 kN | Mass: 0.465 kg
1209Kd: 45 mm | D: 85 mm | B: 19 mm | Cr: 21.8 kN | C0r: 7.35 kN | Mass: 0.459 kg
2209d: 45 mm | D: 85 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.15 kN | Mass: 0.545 kg
2209Kd: 45 mm | D: 85 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.15 kN | Mass: 0.533 kg
1309d: 45 mm | D: 100 mm | B: 25 mm | Cr: 38.1 kN | C0r: 12.7 kN | Mass: 0.957 kg
1309Kd: 45 mm | D: 100 mm | B: 25 mm | Cr: 38.1 kN | C0r: 12.7 kN | Mass: 0.942 kg
2309d: 45 mm | D: 100 mm | B: 36 mm | Cr: 54.4 kN | C0r: 16.7 kN | Mass: 1.23 kg
2309Kd: 45 mm | D: 100 mm | B: 36 mm | Cr: 54.4 kN | C0r: 16.7 kN | Mass: 1.20 kg
1210d: 50 mm | D: 90 mm | B: 20 mm | Cr: 22.7 kN | C0r: 8.10 kN | Mass: 0.525 kg
1210Kd: 50 mm | D: 90 mm | B: 20 mm | Cr: 22.7 kN | C0r: 8.10 kN | Mass: 0.515 kg
2210d: 50 mm | D: 90 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.50 kN | Mass: 0.590 kg
2210Kd: 50 mm | D: 90 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.50 kN | Mass: 0.577 kg
1310d: 50 mm | D: 110 mm | B: 27 mm | Cr: 43.4 kN | C0r: 14.1 kN | Mass: 1.21 kg
1310Kd: 50 mm | D: 110 mm | B: 27 mm | Cr: 43.4 kN | C0r: 14.1 kN | Mass: 1.19 kg
2310d: 50 mm | D: 110 mm | B: 40 mm | Cr: 64.6 kN | C0r: 20.3 kN | Mass: 1.64 kg
2310Kd: 50 mm | D: 110 mm | B: 40 mm | Cr: 64.6 kN | C0r: 20.3 kN | Mass: 1.60 kg
1211d: 55 mm | D: 100 mm | B: 21 mm | Cr: 26.8 kN | C0r: 10.0 kN | Mass: 0.705 kg
1211Kd: 55 mm | D: 100 mm | B: 21 mm | Cr: 26.8 kN | C0r: 10.0 kN | Mass: 0.693 kg
2211d: 55 mm | D: 100 mm | B: 25 mm | Cr: 26.8 kN | C0r: 10.0 kN | Mass: 0.810 kg
2211Kd: 55 mm | D: 100 mm | B: 25 mm | Cr: 26.8 kN | C0r: 10.0 kN | Mass: 0.792 kg
1311d: 55 mm | D: 120 mm | B: 29 mm | Cr: 51.3 kN | C0r: 17.9 kN | Mass: 1.58 kg
1311Kd: 55 mm | D: 120 mm | B: 29 mm | Cr: 51.3 kN | C0r: 17.9 kN | Mass: 1.56 kg
2311d: 55 mm | D: 120 mm | B: 43 mm | Cr: 75.3 kN | C0r: 24.0 kN | Mass: 2.10 kg
2311Kd: 55 mm | D: 120 mm | B: 43 mm | Cr: 75.3 kN | C0r: 24.0 kN | Mass: 2.05 kg
1212d: 60 mm | D: 110 mm | B: 22 mm | Cr: 30.2 kN | C0r: 11.5 kN | Mass: 0.900 kg
1212Kd: 60 mm | D: 110 mm | B: 22 mm | Cr: 30.2 kN | C0r: 11.5 kN | Mass: 0.885 kg
2212d: 60 mm | D: 110 mm | B: 28 mm | Cr: 34.1 kN | C0r: 12.6 kN | Mass: 1.09 kg
2212Kd: 60 mm | D: 110 mm | B: 28 mm | Cr: 34.1 kN | C0r: 12.6 kN | Mass: 1.07 kg
1312d: 60 mm | D: 130 mm | B: 31 mm | Cr: 57.2 kN | C0r: 20.8 kN | Mass: 1.96 kg
1312Kd: 60 mm | D: 130 mm | B: 31 mm | Cr: 57.2 kN | C0r: 20.8 kN | Mass: 1.93 kg
2312d: 60 mm | D: 130 mm | B: 46 mm | Cr: 87.2 kN | C0r: 28.3 kN | Mass: 2.60 kg
2312Kd: 60 mm | D: 130 mm | B: 46 mm | Cr: 87.2 kN | C0r: 28.3 kN | Mass: 2.53 kg
1213d: 65 mm | D: 120 mm | B: 23 mm | Cr: 31.0 kN | C0r: 12.5 kN | Mass: 1.15 kg
1213Kd: 65 mm | D: 120 mm | B: 23 mm | Cr: 31.0 kN | C0r: 12.5 kN | Mass: 1.13 kg
2213d: 65 mm | D: 120 mm | B: 31 mm | Cr: 43.5 kN | C0r: 16.4 kN | Mass: 1.46 kg
2213Kd: 65 mm | D: 120 mm | B: 31 mm | Cr: 43.5 kN | C0r: 16.4 kN | Mass: 1.43 kg
1313d: 65 mm | D: 140 mm | B: 33 mm | Cr: 61.7 kN | C0r: 22.9 kN | Mass: 2.45 kg
1313Kd: 65 mm | D: 140 mm | B: 33 mm | Cr: 61.7 kN | C0r: 22.9 kN | Mass: 2.41 kg
2313d: 65 mm | D: 140 mm | B: 48 mm | Cr: 95.8 kN | C0r: 32.5 kN | Mass: 3.23 kg
2313Kd: 65 mm | D: 140 mm | B: 48 mm | Cr: 95.8 kN | C0r: 32.5 kN | Mass: 3.15 kg
1214d: 70 mm | D: 125 mm | B: 24 mm | Cr: 34.6 kN | C0r: 13.8 kN | Mass: 1.26 kg
2214d: 70 mm | D: 125 mm | B: 31 mm | Cr: 43.9 kN | C0r: 17.1 kN | Mass: 1.52 kg
1314d: 70 mm | D: 150 mm | B: 35 mm | Cr: 74.0 kN | C0r: 27.7 kN | Mass: 2.99 kg
2314d: 70 mm | D: 150 mm | B: 51 mm | Cr: 89.6 kN | C0r: 31.7 kN | Mass: 4.23 kg
1215d: 75 mm | D: 130 mm | B: 25 mm | Cr: 38.8 kN | C0r: 15.7 kN | Mass: 1.36 kg
1215Kd: 75 mm | D: 130 mm | B: 25 mm | Cr: 38.8 kN | C0r: 15.7 kN | Mass: 1.34 kg
2215d: 75 mm | D: 130 mm | B: 31 mm | Cr: 44.2 kN | C0r: 17.8 kN | Mass: 1.62 kg
2215Kd: 75 mm | D: 130 mm | B: 31 mm | Cr: 44.2 kN | C0r: 17.8 kN | Mass: 1.58 kg
1315d: 75 mm | D: 160 mm | B: 37 mm | Cr: 78.9 kN | C0r: 29.9 kN | Mass: 3.56 kg
1315Kd: 75 mm | D: 160 mm | B: 37 mm | Cr: 78.9 kN | C0r: 29.9 kN | Mass: 3.51 kg
2315d: 75 mm | D: 160 mm | B: 55 mm | Cr: 103 kN | C0r: 36.8 kN | Mass: 5.13 kg
2315Kd: 75 mm | D: 160 mm | B: 55 mm | Cr: 103 kN | C0r: 36.8 kN | Mass: 5.01 kg
1216d: 80 mm | D: 140 mm | B: 26 mm | Cr: 39.8 kN | C0r: 17.0 kN | Mass: 1.67 kg
1216Kd: 80 mm | D: 140 mm | B: 26 mm | Cr: 39.8 kN | C0r: 17.0 kN | Mass: 1.64 kg
2216d: 80 mm | D: 140 mm | B: 33 mm | Cr: 49.0 kN | C0r: 19.9 kN | Mass: 2.01 kg
2216Kd: 80 mm | D: 140 mm | B: 33 mm | Cr: 49.0 kN | C0r: 19.9 kN | Mass: 1.97 kg
1316d: 80 mm | D: 170 mm | B: 39 mm | Cr: 88.1 kN | C0r: 33.1 kN | Mass: 4.18 kg
1316Kd: 80 mm | D: 170 mm | B: 39 mm | Cr: 88.1 kN | C0r: 33.1 kN | Mass: 4.12 kg
2316d: 80 mm | D: 170 mm | B: 58 mm | Cr: 129 kN | C0r: 45.7 kN | Mass: 6.10 kg
2316Kd: 80 mm | D: 170 mm | B: 58 mm | Cr: 129 kN | C0r: 45.7 kN | Mass: 5.96 kg
1217d: 85 mm | D: 150 mm | B: 28 mm | Cr: 49.2 kN | C0r: 20.8 kN | Mass: 2.07 kg
1217Kd: 85 mm | D: 150 mm | B: 28 mm | Cr: 49.2 kN | C0r: 20.8 kN | Mass: 2.04 kg
2217d: 85 mm | D: 150 mm | B: 36 mm | Cr: 58.3 kN | C0r: 23.6 kN | Mass: 2.52 kg
2217Kd: 85 mm | D: 150 mm | B: 36 mm | Cr: 58.3 kN | C0r: 23.6 kN | Mass: 2.46 kg
1317d: 85 mm | D: 180 mm | B: 41 mm | Cr: 97.3 kN | C0r: 37.8 kN | Mass: 4.98 kg
1317Kd: 85 mm | D: 180 mm | B: 41 mm | Cr: 97.3 kN | C0r: 37.8 kN | Mass: 4.91 kg
2317d: 85 mm | D: 180 mm | B: 60 mm | Cr: 141 kN | C0r: 51.5 kN | Mass: 7.05 kg
2317Kd: 85 mm | D: 180 mm | B: 60 mm | Cr: 141 kN | C0r: 51.5 kN | Mass: 6.89 kg
1218d: 90 mm | D: 160 mm | B: 30 mm | Cr: 56.8 kN | C0r: 23.4 kN | Mass: 2.52 kg
1218Kd: 90 mm | D: 160 mm | B: 30 mm | Cr: 56.8 kN | C0r: 23.4 kN | Mass: 2.48 kg
2218d: 90 mm | D: 160 mm | B: 40 mm | Cr: 67.7 kN | C0r: 27.2 kN | Mass: 3.40 kg
2218Kd: 90 mm | D: 160 mm | B: 40 mm | Cr: 67.7 kN | C0r: 27.2 kN | Mass: 3.33 kg
1318d: 90 mm | D: 190 mm | B: 43 mm | Cr: 116 kN | C0r: 44.4 kN | Mass: 5.80 kg
1318Kd: 90 mm | D: 190 mm | B: 43 mm | Cr: 116 kN | C0r: 44.4 kN | Mass: 5.71 kg
2318d: 90 mm | D: 190 mm | B: 64 mm | Cr: 153 kN | C0r: 57.9 kN | Mass: 8.44 kg
2318Kd: 90 mm | D: 190 mm | B: 64 mm | Cr: 153 kN | C0r: 57.9 kN | Mass: 8.25 kg
1219d: 95 mm | D: 170 mm | B: 32 mm | Cr: 57.0 kN | C0r: 24.3 kN | Mass: 3.10 kg
1219Kd: 95 mm | D: 170 mm | B: 32 mm | Cr: 57.0 kN | C0r: 24.3 kN | Mass: 3.05 kg
2219d: 95 mm | D: 170 mm | B: 43 mm | Cr: 82.7 kN | C0r: 34.3 kN | Mass: 4.10 kg
2219Kd: 95 mm | D: 170 mm | B: 43 mm | Cr: 82.7 kN | C0r: 34.3 kN | Mass: 4.00 kg
1319d: 95 mm | D: 200 mm | B: 45 mm | Cr: 132 kN | C0r: 50.8 kN | Mass: 6.69 kg
1319Kd: 95 mm | D: 200 mm | B: 45 mm | Cr: 132 kN | C0r: 50.8 kN | Mass: 6.59 kg
2319d: 95 mm | D: 200 mm | B: 67 mm | Cr: 166 kN | C0r: 64.8 kN | Mass: 9.79 kg
2319Kd: 95 mm | D: 200 mm | B: 67 mm | Cr: 166 kN | C0r: 64.8 kN | Mass: 9.57 kg
1220d: 100 mm | D: 180 mm | B: 34 mm | Cr: 69.0 kN | C0r: 29.7 kN | Mass: 3.70 kg
1220Kd: 100 mm | D: 180 mm | B: 34 mm | Cr: 69.0 kN | C0r: 29.7 kN | Mass: 3.64 kg
2220d: 100 mm | D: 180 mm | B: 46 mm | Cr: 80.9 kN | C0r: 34.0 kN | Mass: 4.98 kg
2220Kd: 100 mm | D: 180 mm | B: 46 mm | Cr: 80.9 kN | C0r: 34.0 kN | Mass: 4.87 kg
1320d: 100 mm | D: 215 mm | B: 47 mm | Cr: 143 kN | C0r: 57.3 kN | Mass: 8.30 kg
1320Kd: 100 mm | D: 215 mm | B: 47 mm | Cr: 143 kN | C0r: 57.3 kN | Mass: 8.19 kg
2320d: 100 mm | D: 215 mm | B: 73 mm | Cr: 183 kN | C0r: 73.4 kN | Mass: 12.4 kg
2320Kd: 100 mm | D: 215 mm | B: 73 mm | Cr: 183 kN | C0r: 73.4 kN | Mass: 12.1 kg
1221d: 105 mm | D: 190 mm | B: 36 mm | Cr: 77.0 kN | C0r: 34.0 kN | Mass: 4.37 kg
2221d: 105 mm | D: 190 mm | B: 50 mm | Cr: 94.9 kN | C0r: 40.1 kN | Mass: 6.07 kg
1321d: 105 mm | D: 225 mm | B: 49 mm | Cr: 149 kN | C0r: 60.2 kN | Mass: 10.0 kg
2321d: 105 mm | D: 225 mm | B: 77 mm | Cr: 187 kN | C0r: 78.0 kN | Mass: 14.3 kg
1222d: 110 mm | D: 200 mm | B: 38 mm | Cr: 80.2 kN | C0r: 35.2 kN | Mass: 5.15 kg
1222Kd: 110 mm | D: 200 mm | B: 38 mm | Cr: 80.2 kN | C0r: 35.2 kN | Mass: 5.07 kg
2222d: 110 mm | D: 200 mm | B: 53 mm | Cr: 120 kN | C0r: 48.9 kN | Mass: 7.10 kg
2222Kd: 110 mm | D: 200 mm | B: 53 mm | Cr: 120 kN | C0r: 48.9 kN | Mass: 6.94 kg
1322d: 110 mm | D: 240 mm | B: 50 mm | Cr: 150 kN | C0r: 63.2 kN | Mass: 11.8 kg
1322Kd: 110 mm | D: 240 mm | B: 50 mm | Cr: 150 kN | C0r: 63.2 kN | Mass: 11.7 kg
2322d: 110 mm | D: 240 mm | B: 80 mm | Cr: 200 kN | C0r: 85.7 kN | Mass: 17.3 kg
2322Kd: 110 mm | D: 240 mm | B: 80 mm | Cr: 200 kN | C0r: 85.7 kN | Mass: 16.9 kg

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
