KOYO Thrust Collars for Cylindrical Roller Bearings (HJ)

KOYO Thrust Collars for Cylindrical Roller Bearings (HJ)

HJ thrust collars (L-shaped angle rings) used with NJ and NU cylindrical roller bearings to provide axial location; NJ + HJ forms an NH type bearing.

Key features

  • L-section angle ring for axial guidance
  • Combined with NJ to give NH configuration
  • Combined with NU to locate in one direction
  • Matched to 2, 22, 3, 23 and 4 series incl. R types

Specifications

Product type Thrust collar (angle ring)
Use with NJ / NU cylindrical roller bearings
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B184-B193
HJ204 d: 20 mm | d1: 29.7 mm | B1: 3 mm | B2: 6.75 mm | Mass: 0.012 kg | For: NJ204, NU204
HJ2207R d: 35 mm | d1: 48.2 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.035 kg | For: NJ2207R, NU2207R
HJ204R d: 20 mm | d1: 29.8 mm | B1: 3 mm | B2: 5.5 mm | Mass: 0.011 kg | For: NJ204R, NU204R
HJ307 d: 35 mm | d1: 50.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.056 kg | For: NJ307, NU307
HJ2204 d: 20 mm | d1: 30 mm | B1: 3 mm | B2: 7.5 mm | Mass: 0.012 kg | For: NJ2204, NU2204
HJ307R d: 35 mm | d1: 51.1 mm | B1: 6 mm | B2: 9.5 mm | Mass: 0.060 kg | For: NJ307R, NU307R
HJ2204R d: 20 mm | d1: 29.8 mm | B1: 3 mm | B2: 6.5 mm | Mass: 0.012 kg | For: NJ2204R, NU2204R
HJ2307 d: 35 mm | d1: 50.8 mm | B1: 6 mm | B2: 14 mm | Mass: 0.056 kg | For: NJ2307, NU2307
HJ304 d: 20 mm | d1: 31.8 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.017 kg | For: NJ304, NU304
HJ2307R d: 35 mm | d1: 51.1 mm | B1: 6 mm | B2: 11 mm | Mass: 0.062 kg | For: NJ2307R, NU2307R
HJ304R d: 20 mm | d1: 31.4 mm | B1: 4 mm | B2: 6.5 mm | Mass: 0.017 kg | For: NJ304R, NU304R
HJ407 d: 35 mm | d1: 59 mm | B1: 8 mm | B2: 13 mm | Mass: 0.120 kg | For: NJ407, NU407
HJ2304 d: 20 mm | d1: 31.8 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.020 kg | For: NJ2304, NU2304
HJ208 d: 40 mm | d1: 54.2 mm | B1: 5 mm | B2: 9 mm | Mass: 0.046 kg | For: NJ208, NU208
HJ2304R d: 20 mm | d1: 31.4 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.018 kg | For: NJ2304R, NU2304R
HJ208R d: 40 mm | d1: 54.1 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.049 kg | For: NJ208R, NU208R
HJ2208 d: 40 mm | d1: 54.2 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.046 kg | For: NJ2208, NU2208
HJ205 d: 25 mm | d1: 34.7 mm | B1: 3 mm | B2: 7.25 mm | Mass: 0.015 kg | For: NJ205, NU205
HJ205R d: 25 mm | d1: 34.8 mm | B1: 3 mm | B2: 6 mm | Mass: 0.014 kg | For: NJ205R, NU205R
HJ2208R d: 40 mm | d1: 54.1 mm | B1: 5 mm | B2: 9 mm | Mass: 0.050 kg | For: NJ2208R, NU2208R
HJ2205 d: 25 mm | d1: 34.7 mm | B1: 3 mm | B2: 7.5 mm | Mass: 0.015 kg | For: NJ2205, NU2205
HJ308 d: 40 mm | d1: 58.4 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.083 kg | For: NJ308, NU308
HJ308R d: 40 mm | d1: 57.7 mm | B1: 7 mm | B2: 11 mm | Mass: 0.088 kg | For: NJ308R, NU308R
HJ2205R d: 25 mm | d1: 34.8 mm | B1: 3 mm | B2: 6.5 mm | Mass: 0.014 kg | For: NJ2205R, NU2205R
HJ305 d: 25 mm | d1: 39 mm | B1: 4 mm | B2: 8 mm | Mass: 0.025 kg | For: NJ305, NU305
HJ2308 d: 40 mm | d1: 58.4 mm | B1: 7 mm | B2: 14.5 mm | Mass: 0.083 kg | For: NJ2308, NU2308
HJ305R d: 25 mm | d1: 38.2 mm | B1: 4 mm | B2: 7 mm | Mass: 0.025 kg | For: NJ305R, NU305R
HJ2308R d: 40 mm | d1: 57.7 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.091 kg | For: NJ2308R, NU2308R
HJ408 d: 40 mm | d1: 64.8 mm | B1: 8 mm | B2: 13 mm | Mass: 0.140 kg | For: NJ408, NU408
HJ2305 d: 25 mm | d1: 39 mm | B1: 4 mm | B2: 9 mm | Mass: 0.025 kg | For: NJ2305, NU2305
HJ2305R d: 25 mm | d1: 38.2 mm | B1: 4 mm | B2: 8 mm | Mass: 0.026 kg | For: NJ2305R, NU2305R
HJ209 d: 45 mm | d1: 59 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.053 kg | For: NJ209, NU209
HJ209R d: 45 mm | d1: 59.1 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.055 kg | For: NJ209R, NU209R
HJ206 d: 30 mm | d1: 41.8 mm | B1: 4 mm | B2: 8.25 mm | Mass: 0.025 kg | For: NJ206, NU206
HJ2209 d: 45 mm | d1: 59 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.053 kg | For: NJ2209, NU2209
HJ206R d: 30 mm | d1: 41.4 mm | B1: 4 mm | B2: 7 mm | Mass: 0.025 kg | For: NJ206R, NU206R
HJ2206 d: 30 mm | d1: 41.8 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.025 kg | For: NJ2206, NU2206
HJ2209R d: 45 mm | d1: 59.1 mm | B1: 5 mm | B2: 9 mm | Mass: 0.055 kg | For: NJ2209R, NU2209R
HJ309 d: 45 mm | d1: 64 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.099 kg | For: NJ309, NU309
HJ2206R d: 30 mm | d1: 41.4 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.025 kg | For: NJ2206R, NU2206R
HJ309R d: 45 mm | d1: 64.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.110 kg | For: NJ309R, NU309R
HJ306 d: 30 mm | d1: 45.9 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.039 kg | For: NJ306, NU306
HJ306R d: 30 mm | d1: 45.1 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.042 kg | For: NJ306R, NU306R
HJ2309 d: 45 mm | d1: 64 mm | B1: 7 mm | B2: 15 mm | Mass: 0.099 kg | For: NJ2309, NU2309
HJ2309R d: 45 mm | d1: 64.5 mm | B1: 7 mm | B2: 13 mm | Mass: 0.113 kg | For: NJ2309R, NU2309R
HJ2306 d: 30 mm | d1: 45.9 mm | B1: 5 mm | B2: 11.5 mm | Mass: 0.039 kg | For: NJ2306, NU2306
HJ409 d: 45 mm | d1: 71.8 mm | B1: 8 mm | B2: 13.5 mm | Mass: 0.175 kg | For: NJ409, NU409
HJ2306R d: 30 mm | d1: 45.1 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.043 kg | For: NJ2306R, NU2306R
HJ406 d: 30 mm | d1: 50.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.080 kg | For: NJ406, NU406
HJ210 d: 50 mm | d1: 64.6 mm | B1: 5 mm | B2: 10 mm | Mass: 0.063 kg | For: NJ210, NU210
HJ210R d: 50 mm | d1: 64.1 mm | B1: 5 mm | B2: 9 mm | Mass: 0.061 kg | For: NJ210R, NU210R
HJ207 d: 35 mm | d1: 47.6 mm | B1: 4 mm | B2: 8 mm | Mass: 0.030 kg | For: NJ207, NU207
HJ2210 d: 50 mm | d1: 64.6 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.063 kg | For: NJ2210, NU2210
HJ207R d: 35 mm | d1: 48.2 mm | B1: 4 mm | B2: 7 mm | Mass: 0.033 kg | For: NJ207R, NU207R
HJ2207 d: 35 mm | d1: 47.6 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.030 kg | For: NJ2207, NU2207
HJ2210R d: 50 mm | d1: 64.1 mm | B1: 5 mm | B2: 9 mm | Mass: 0.061 kg | For: NJ2210R, NU2210R
HJ310 d: 50 mm | d1: 71 mm | B1: 8 mm | B2: 14 mm | Mass: 0.142 kg | For: NJ310, NU310
HJ310R d: 50 mm | d1: 71.4 mm | B1: 8 mm | B2: 13 mm | Mass: 0.151 kg | For: NJ310R, NU310R
HJ2313 d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 20 mm | Mass: 0.280 kg | For: NJ2313, NU2313
HJ2310 d: 50 mm | d1: 71 mm | B1: 8 mm | B2: 17 mm | Mass: 0.142 kg | For: NJ2310, NU2310
HJ2313R d: 65 mm | d1: 90.6 mm | B1: 10 mm | B2: 18 mm | Mass: 0.298 kg | For: NJ2313R, NU2313R
HJ2310R d: 50 mm | d1: 71.4 mm | B1: 8 mm | B2: 14.5 mm | Mass: 0.155 kg | For: NJ2310R, NU2310R
HJ413 d: 65 mm | d1: 98.5 mm | B1: 11 mm | B2: 18 mm | Mass: 0.420 kg | For: NJ413, NU413
HJ410 d: 50 mm | d1: 78.8 mm | B1: 9 mm | B2: 14.5 mm | Mass: 0.230 kg | For: NJ410, NU410
HJ214 d: 70 mm | d1: 89.6 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.150 kg | For: NJ214, NU214
HJ214R d: 70 mm | d1: 89.5 mm | B1: 7 mm | B2: 11 mm | Mass: 0.157 kg | For: NJ214R, NU214R
HJ211 d: 55 mm | d1: 70.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.084 kg | For: NJ211, NU211
HJ2214 d: 70 mm | d1: 89.6 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.150 kg | For: NJ2214, NU2214
HJ211R d: 55 mm | d1: 70.9 mm | B1: 6 mm | B2: 9.5 mm | Mass: 0.087 kg | For: NJ211R, NU211R
HJ2211 d: 55 mm | d1: 70.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.084 kg | For: NJ2211, NU2211
HJ2214R d: 70 mm | d1: 89.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.158 kg | For: NJ2214R, NU2214R
HJ314 d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 17.5 mm | Mass: 0.330 kg | For: NJ314, NU314
HJ2211R d: 55 mm | d1: 70.9 mm | B1: 6 mm | B2: 10 mm | Mass: 0.088 kg | For: NJ2211R, NU2211R
HJ314R d: 70 mm | d1: 97.5 mm | B1: 10 mm | B2: 15.5 mm | Mass: 0.330 kg | For: NJ314R, NU314R
HJ311 d: 55 mm | d1: 77.2 mm | B1: 9 mm | B2: 15 mm | Mass: 0.182 kg | For: NJ311, NU311
HJ311R d: 55 mm | d1: 77.6 mm | B1: 9 mm | B2: 14 mm | Mass: 0.195 kg | For: NJ311R, NU311R
HJ2314 d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 20.5 mm | Mass: 0.330 kg | For: NJ2314, NU2314
HJ2314R d: 70 mm | d1: 97.5 mm | B1: 10 mm | B2: 18.5 mm | Mass: 0.345 kg | For: NJ2314R, NU2314R
HJ2311 d: 55 mm | d1: 77.2 mm | B1: 9 mm | B2: 18.5 mm | Mass: 0.182 kg | For: NJ2311, NU2311
HJ414 d: 70 mm | d1: 110.5 mm | B1: 12 mm | B2: 20 mm | Mass: 0.605 kg | For: NJ414, NU414
HJ2311R d: 55 mm | d1: 77.6 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.200 kg | For: NJ2311R, NU2311R
HJ411 d: 55 mm | d1: 85.2 mm | B1: 10 mm | B2: 16.5 mm | Mass: 0.290 kg | For: NJ411, NU411
HJ215 d: 75 mm | d1: 94 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.156 kg | For: NJ215, NU215
HJ215R d: 75 mm | d1: 94.5 mm | B1: 7 mm | B2: 11 mm | Mass: 0.166 kg | For: NJ215R, NU215R
HJ212 d: 60 mm | d1: 78.4 mm | B1: 6 mm | B2: 11 mm | Mass: 0.108 kg | For: NJ212, NU212
HJ2215 d: 75 mm | d1: 94 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.156 kg | For: NJ2215, NU2215
HJ212R d: 60 mm | d1: 77.7 mm | B1: 6 mm | B2: 10 mm | Mass: 0.108 kg | For: NJ212R, NU212R
HJ2212 d: 60 mm | d1: 78.4 mm | B1: 6 mm | B2: 11 mm | Mass: 0.108 kg | For: NJ2212, NU2212
HJ2215R d: 75 mm | d1: 94.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.167 kg | For: NJ2215R, NU2215R
HJ315 d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 18.5 mm | Mass: 0.400 kg | For: NJ315, NU315
HJ2212R d: 60 mm | d1: 77.7 mm | B1: 6 mm | B2: 10 mm | Mass: 0.108 kg | For: NJ2212R, NU2212R
HJ315R d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 16.5 mm | Mass: 0.410 kg | For: NJ315R, NU315R
HJ312 d: 60 mm | d1: 84.2 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.220 kg | For: NJ312, NU312
HJ312R d: 60 mm | d1: 84.5 mm | B1: 9 mm | B2: 14.5 mm | Mass: 0.231 kg | For: NJ312R, NU312R
HJ2315 d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 21.5 mm | Mass: 0.400 kg | For: NJ2315, NU2315
HJ2315R d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.430 kg | For: NJ2315R, NU2315R
HJ2312 d: 60 mm | d1: 84.2 mm | B1: 9 mm | B2: 19 mm | Mass: 0.220 kg | For: NJ2312, NU2312
HJ415 d: 75 mm | d1: 116 mm | B1: 13 mm | B2: 21.5 mm | Mass: 0.710 kg | For: NJ415, NU415
HJ2312R d: 60 mm | d1: 84.5 mm | B1: 9 mm | B2: 16 mm | Mass: 0.237 kg | For: NJ2312R, NU2312R
HJ412 d: 60 mm | d1: 91.8 mm | B1: 10 mm | B2: 16.5 mm | Mass: 0.340 kg | For: NJ412, NU412
HJ216 d: 80 mm | d1: 101.2 mm | B1: 8 mm | B2: 13.5 mm | Mass: 0.207 kg | For: NJ216, NU216
HJ216R d: 80 mm | d1: 101.6 mm | B1: 8 mm | B2: 12.5 mm | Mass: 0.222 kg | For: NJ216R, NU216R
HJ213 d: 65 mm | d1: 84.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.123 kg | For: NJ213, NU213
HJ2216 d: 80 mm | d1: 101.2 mm | B1: 8 mm | B2: 13.5 mm | Mass: 0.207 kg | For: NJ2216, NU2216
HJ213R d: 65 mm | d1: 84.5 mm | B1: 6 mm | B2: 10 mm | Mass: 0.129 kg | For: NJ213R, NU213R
HJ2213 d: 65 mm | d1: 84.8 mm | B1: 6 mm | B2: 11.5 mm | Mass: 0.123 kg | For: NJ2213, NU2213
HJ2216R d: 80 mm | d1: 101.6 mm | B1: 8 mm | B2: 12.5 mm | Mass: 0.222 kg | For: NJ2216R, NU2216R
HJ316 d: 80 mm | d1: 111.8 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.470 kg | For: NJ316, NU316
HJ2213R d: 65 mm | d1: 84.5 mm | B1: 6 mm | B2: 10.5 mm | Mass: 0.131 kg | For: NJ2213R, NU2213R
HJ316R d: 80 mm | d1: 110.6 mm | B1: 11 mm | B2: 17 mm | Mass: 0.460 kg | For: NJ316R, NU316R
HJ313 d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 17 mm | Mass: 0.280 kg | For: NJ313, NU313
HJ313R d: 65 mm | d1: 90.6 mm | B1: 10 mm | B2: 15.5 mm | Mass: 0.288 kg | For: NJ313R, NU313R
HJ2316 d: 80 mm | d1: 111.8 mm | B1: 11 mm | B2: 23 mm | Mass: 0.470 kg | For: NJ2316, NU2316
HJ2316R d: 80 mm | d1: 110.6 mm | B1: 11 mm | B2: 20 mm | Mass: 0.480 kg | For: NJ2316R, NU2316R
HJ416 d: 80 mm | d1: 122 mm | B1: 13 mm | B2: 22 mm | Mass: 0.780 kg | For: NJ416, NU416
HJ220R d: 100 mm | d1: 127.5 mm | B1: 10 mm | B2: 15 mm | Mass: 0.435 kg | For: NJ220R, NU220R
HJ2220 d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 18 mm | Mass: 0.444 kg | For: NJ2220, NU2220
HJ217 d: 85 mm | d1: 108.2 mm | B1: 8 mm | B2: 14 mm | Mass: 0.250 kg | For: NJ217, NU217
HJ2220R d: 100 mm | d1: 127.5 mm | B1: 10 mm | B2: 16 mm | Mass: 0.450 kg | For: NJ2220R, NU2220R
HJ217R d: 85 mm | d1: 107.6 mm | B1: 8 mm | B2: 12.5 mm | Mass: 0.250 kg | For: NJ217R, NU217R
HJ320 d: 100 mm | d1: 140.5 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.895 kg | For: NJ320, NU320
HJ2217 d: 85 mm | d1: 108.2 mm | B1: 8 mm | B2: 14 mm | Mass: 0.250 kg | For: NJ2217, NU2217
HJ320R d: 100 mm | d1: 139.6 mm | B1: 13 mm | B2: 20.5 mm | Mass: 0.890 kg | For: NJ320R, NU320R
HJ2217R d: 85 mm | d1: 107.6 mm | B1: 8 mm | B2: 13 mm | Mass: 0.252 kg | For: NJ2217R, NU2217R
HJ2320 d: 100 mm | d1: 140.5 mm | B1: 13 mm | B2: 27.5 mm | Mass: 0.895 kg | For: NJ2320, NU2320
HJ317 d: 85 mm | d1: 117.5 mm | B1: 12 mm | B2: 20.5 mm | Mass: 0.560 kg | For: NJ317, NU317
HJ2320R d: 100 mm | d1: 139.6 mm | B1: 13 mm | B2: 23.5 mm | Mass: 0.920 kg | For: NJ2320R, NU2320R
HJ317R d: 85 mm | d1: 117.9 mm | B1: 12 mm | B2: 18.5 mm | Mass: 0.575 kg | For: NJ317R, NU317R
HJ420 d: 100 mm | d1: 153.5 mm | B1: 16 mm | B2: 27 mm | Mass: 1.50 kg | For: NJ420, NU420
HJ2317 d: 85 mm | d1: 117.5 mm | B1: 12 mm | B2: 24 mm | Mass: 0.560 kg | For: NJ2317, NU2317
HJ2317R d: 85 mm | d1: 117.9 mm | B1: 12 mm | B2: 22 mm | Mass: 0.595 kg | For: NJ2317R, NU2317R
HJ221 d: 105 mm | d1: 135 mm | B1: 10 mm | B2: 17.5 mm | Mass: 0.505 kg | For: NJ221, NU221
HJ417 d: 85 mm | d1: 126 mm | B1: 14 mm | B2: 24 mm | Mass: 0.880 kg | For: NJ417, NU417
HJ321 d: 105 mm | d1: 147 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.970 kg | For: NJ321, NU321
HJ421 d: 105 mm | d1: 159.5 mm | B1: 16 mm | B2: 27 mm | Mass: 1.65 kg | For: NJ421, NU421
HJ218 d: 90 mm | d1: 114.2 mm | B1: 9 mm | B2: 15 mm | Mass: 0.305 kg | For: NJ218, NU218
HJ218R d: 90 mm | d1: 114.4 mm | B1: 9 mm | B2: 14 mm | Mass: 0.320 kg | For: NJ218R, NU218R
HJ222 d: 110 mm | d1: 141.5 mm | B1: 11 mm | B2: 18.5 mm | Mass: 0.615 kg | For: NJ222, NU222
HJ2218 d: 90 mm | d1: 114.2 mm | B1: 9 mm | B2: 16 mm | Mass: 0.305 kg | For: NJ2218, NU2218
HJ222R d: 110 mm | d1: 141.7 mm | B1: 11 mm | B2: 17 mm | Mass: 0.620 kg | For: NJ222R, NU222R
HJ2222 d: 110 mm | d1: 141.5 mm | B1: 11 mm | B2: 20.5 mm | Mass: 0.615 kg | For: NJ2222, NU2222
HJ2218R d: 90 mm | d1: 114.4 mm | B1: 9 mm | B2: 15 mm | Mass: 0.325 kg | For: NJ2218R, NU2218R
HJ318 d: 90 mm | d1: 125 mm | B1: 12 mm | B2: 21 mm | Mass: 0.630 kg | For: NJ318, NU318
HJ2222R d: 110 mm | d1: 141.7 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.645 kg | For: NJ2222R, NU2222R
HJ318R d: 90 mm | d1: 124.2 mm | B1: 12 mm | B2: 18.5 mm | Mass: 0.630 kg | For: NJ318R, NU318R
HJ322 d: 110 mm | d1: 155.5 mm | B1: 14 mm | B2: 23 mm | Mass: 1.17 kg | For: NJ322, NU322
HJ322R d: 110 mm | d1: 155.8 mm | B1: 14 mm | B2: 22 mm | Mass: 1.21 kg | For: NJ322R, NU322R
HJ2318 d: 90 mm | d1: 125 mm | B1: 12 mm | B2: 26 mm | Mass: 0.630 kg | For: NJ2318, NU2318
HJ2318R d: 90 mm | d1: 124.2 mm | B1: 12 mm | B2: 22 mm | Mass: 0.660 kg | For: NJ2318R, NU2318R
HJ2322 d: 110 mm | d1: 155.5 mm | B1: 14 mm | B2: 28 mm | Mass: 1.17 kg | For: NJ2322, NU2322
HJ418 d: 90 mm | d1: 137 mm | B1: 14 mm | B2: 24 mm | Mass: 1.05 kg | For: NJ418, NU418
HJ2322R d: 110 mm | d1: 155.8 mm | B1: 14 mm | B2: 26.5 mm | Mass: 1.27 kg | For: NJ2322R, NU2322R
HJ422 d: 110 mm | d1: 171 mm | B1: 17 mm | B2: 29.5 mm | Mass: 2.10 kg | For: NJ422, NU422
HJ219 d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.352 kg | For: NJ219, NU219
HJ219R d: 95 mm | d1: 120.6 mm | B1: 9 mm | B2: 14 mm | Mass: 0.355 kg | For: NJ219R, NU219R
HJ224 d: 120 mm | d1: 153 mm | B1: 11 mm | B2: 19 mm | Mass: 0.715 kg | For: NJ224, NU224
HJ2219 d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 16.5 mm | Mass: 0.352 kg | For: NJ2219, NU2219
HJ224R d: 120 mm | d1: 153.4 mm | B1: 11 mm | B2: 17 mm | Mass: 0.710 kg | For: NJ224R, NU224R
HJ2224 d: 120 mm | d1: 153 mm | B1: 11 mm | B2: 22 mm | Mass: 0.715 kg | For: NJ2224, NU2224
HJ2219R d: 95 mm | d1: 120.6 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.365 kg | For: NJ2219R, NU2219R
HJ319 d: 95 mm | d1: 132 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.760 kg | For: NJ319, NU319
HJ2224R d: 120 mm | d1: 153.4 mm | B1: 11 mm | B2: 20 mm | Mass: 0.745 kg | For: NJ2224R, NU2224R
HJ319R d: 95 mm | d1: 132.2 mm | B1: 13 mm | B2: 20.5 mm | Mass: 0.785 kg | For: NJ319R, NU319R
HJ324 d: 120 mm | d1: 168.5 mm | B1: 14 mm | B2: 23.5 mm | Mass: 1.40 kg | For: NJ324, NU324
HJ324R d: 120 mm | d1: 168.6 mm | B1: 14 mm | B2: 22.5 mm | Mass: 1.41 kg | For: NJ324R, NU324R
HJ2319 d: 95 mm | d1: 132 mm | B1: 13 mm | B2: 26.5 mm | Mass: 0.760 kg | For: NJ2319, NU2319
HJ419 d: 95 mm | d1: 147 mm | B1: 15 mm | B2: 25.5 mm | Mass: 1.30 kg | For: NJ419, NU419
HJ2324 d: 120 mm | d1: 168.5 mm | B1: 14 mm | B2: 28 mm | Mass: 1.40 kg | For: NJ2324, NU2324
HJ2324R d: 120 mm | d1: 168.6 mm | B1: 14 mm | B2: 26 mm | Mass: 1.46 kg | For: NJ2324R, NU2324R
HJ220 d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 17 mm | Mass: 0.444 kg | For: NJ220, NU220
HJ424 d: 120 mm | d1: 188 mm | B1: 17 mm | B2: 30.5 mm | Mass: 2.60 kg | For: NJ424, NU424
HJ226 d: 130 mm | d1: 165.5 mm | B1: 11 mm | B2: 19 mm | Mass: 0.840 kg | For: NJ226, NU226
HJ2232 d: 160 mm | d1: 205 mm | B1: 12 mm | B2: 28 mm | Mass: 1.48 kg | For: NJ2232, NU2232
HJ226R d: 130 mm | d1: 164.2 mm | B1: 11 mm | B2: 17 mm | Mass: 0.790 kg | For: NJ226R, NU226R
HJ2232R d: 160 mm | d1: 206.1 mm | B1: 12 mm | B2: 24.5 mm | Mass: 1.55 kg | For: NJ2232R, NU2232R
HJ2226 d: 130 mm | d1: 165.5 mm | B1: 11 mm | B2: 25 mm | Mass: 0.840 kg | For: NJ2226, NU2226
HJ332 d: 160 mm | d1: 225 mm | B1: 15 mm | B2: 28 mm | Mass: 2.75 kg | For: NJ332, NU332
HJ2226R d: 130 mm | d1: 164.2 mm | B1: 11 mm | B2: 21 mm | Mass: 0.840 kg | For: NJ2226R, NU2226R
HJ332R d: 160 mm | d1: 222.1 mm | B1: 15 mm | B2: 25 mm | Mass: 2.59 kg | For: NJ332R, NU332R
HJ326 d: 130 mm | d1: 182 mm | B1: 14 mm | B2: 24 mm | Mass: 1.62 kg | For: NJ326, NU326
HJ2332 d: 160 mm | d1: 225 mm | B1: 15 mm | B2: 37 mm | Mass: 2.75 kg | For: NJ2332, NU2332
HJ326R d: 130 mm | d1: 182.3 mm | B1: 14 mm | B2: 23 mm | Mass: 1.65 kg | For: NJ326R, NU326R
HJ2332R d: 160 mm | d1: 222.1 mm | B1: 15 mm | B2: 32 mm | Mass: 2.76 kg | For: NJ2332R, NU2332R
HJ2326 d: 130 mm | d1: 182 mm | B1: 14 mm | B2: 29.5 mm | Mass: 1.62 kg | For: NJ2326, NU2326
HJ234 d: 170 mm | d1: 220.5 mm | B1: 12 mm | B2: 22 mm | Mass: 1.70 kg | For: NJ234, NU234
HJ2326R d: 130 mm | d1: 182.3 mm | B1: 14 mm | B2: 28 mm | Mass: 1.73 kg | For: NJ2326R, NU2326R
HJ234R d: 170 mm | d1: 220.8 mm | B1: 12 mm | B2: 20 mm | Mass: 1.70 kg | For: NJ234R, NU234R
HJ426 d: 130 mm | d1: 205 mm | B1: 18 mm | B2: 32 mm | Mass: 3.30 kg | For: NJ426, NU426
HJ2234 d: 170 mm | d1: 219 mm | B1: 12 mm | B2: 29 mm | Mass: 1.70 kg | For: NJ2234, NU2234
HJ228 d: 140 mm | d1: 179.5 mm | B1: 11 mm | B2: 19 mm | Mass: 1.00 kg | For: NJ228, NU228
HJ2234R d: 170 mm | d1: 219.5 mm | B1: 12 mm | B2: 24 mm | Mass: 1.79 kg | For: NJ2234R, NU2234R
HJ228R d: 140 mm | d1: 180 mm | B1: 11 mm | B2: 18 mm | Mass: 0.990 kg | For: NJ228R, NU228R
HJ334 d: 170 mm | d1: 238 mm | B1: 16 mm | B2: 29.5 mm | Mass: 3.25 kg | For: NJ334, NU334
HJ2228 d: 140 mm | d1: 179.5 mm | B1: 11 mm | B2: 25 mm | Mass: 1.00 kg | For: NJ2228, NU2228
HJ2334 d: 170 mm | d1: 238 mm | B1: 16 mm | B2: 38.5 mm | Mass: 3.25 kg | For: NJ2334, NU2334
HJ2228R d: 140 mm | d1: 180 mm | B1: 11 mm | B2: 23 mm | Mass: 1.07 kg | For: NJ2228R, NU2228R
HJ236 d: 180 mm | d1: 230.5 mm | B1: 12 mm | B2: 22 mm | Mass: 1.80 kg | For: NJ236, NU236
HJ328 d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 26 mm | Mass: 1.93 kg | For: NJ328, NU328
HJ236R d: 180 mm | d1: 230.8 mm | B1: 12 mm | B2: 20 mm | Mass: 1.79 kg | For: NJ236R, NU236R
HJ328R d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 25 mm | Mass: 2.04 kg | For: NJ328R, NU328R
HJ2236 d: 180 mm | d1: 229 mm | B1: 12 mm | B2: 29 mm | Mass: 1.80 kg | For: NJ2236, NU2236
HJ2328 d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 33.5 mm | Mass: 1.98 kg | For: NJ2328, NU2328
HJ2236R d: 180 mm | d1: 229.5 mm | B1: 12 mm | B2: 24 mm | Mass: 1.88 kg | For: NJ2236R, NU2236R
HJ2328R d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 31 mm | Mass: 2.14 kg | For: NJ2328R, NU2328R
HJ336 d: 180 mm | d1: 252 mm | B1: 17 mm | B2: 30.5 mm | Mass: 3.85 kg | For: NJ336, NU336
HJ428 d: 140 mm | d1: 219 mm | B1: 18 mm | B2: 33 mm | Mass: 3.75 kg | For: NJ428, NU428
HJ2336 d: 180 mm | d1: 252 mm | B1: 17 mm | B2: 40 mm | Mass: 3.85 kg | For: NJ2336, NU2336
HJ230 d: 150 mm | d1: 193 mm | B1: 12 mm | B2: 20.5 mm | Mass: 1.24 kg | For: NJ230, NU230
HJ238 d: 190 mm | d1: 244.5 mm | B1: 13 mm | B2: 23.5 mm | Mass: 2.20 kg | For: NJ238, NU238
HJ230R d: 150 mm | d1: 193.7 mm | B1: 12 mm | B2: 19.5 mm | Mass: 1.26 kg | For: NJ230R, NU230R
HJ238R d: 190 mm | d1: 244.5 mm | B1: 13 mm | B2: 21.5 mm | Mass: 2.19 kg | For: NJ238R, NU238R
HJ2230 d: 150 mm | d1: 193 mm | B1: 12 mm | B2: 26.5 mm | Mass: 1.24 kg | For: NJ2230, NU2230
HJ2238 d: 190 mm | d1: 243 mm | B1: 13 mm | B2: 31.5 mm | Mass: 2.20 kg | For: NJ2238, NU2238
HJ2230R d: 150 mm | d1: 193.7 mm | B1: 12 mm | B2: 24.5 mm | Mass: 1.35 kg | For: NJ2230R, NU2230R
HJ2238R d: 190 mm | d1: 243.2 mm | B1: 13 mm | B2: 26.5 mm | Mass: 2.31 kg | For: NJ2238R, NU2238R
HJ330 d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 26.5 mm | Mass: 2.37 kg | For: NJ330, NU330
HJ338 d: 190 mm | d1: 265 mm | B1: 18 mm | B2: 32 mm | Mass: 4.45 kg | For: NJ338, NU338
HJ330R d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 25 mm | Mass: 2.35 kg | For: NJ330R, NU330R
HJ2338 d: 190 mm | d1: 265 mm | B1: 18 mm | B2: 41.5 mm | Mass: 4.45 kg | For: NJ2338, NU2338
HJ2330 d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 34 mm | Mass: 2.37 kg | For: NJ2330, NU2330
HJ2330R d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 31.5 mm | Mass: 2.48 kg | For: NJ2330R, NU2330R
HJ240 d: 200 mm | d1: 258 mm | B1: 14 mm | B2: 25 mm | Mass: 2.60 kg | For: NJ240, NU240
HJ430 d: 150 mm | d1: 234 mm | B1: 20 mm | B2: 36.5 mm | Mass: 4.70 kg | For: NJ430, NU430
HJ240R d: 200 mm | d1: 258.2 mm | B1: 14 mm | B2: 23 mm | Mass: 2.65 kg | For: NJ240R, NU240R
HJ2240 d: 200 mm | d1: 258 mm | B1: 14 mm | B2: 34 mm | Mass: 2.60 kg | For: NJ2240, NU2240
HJ232 d: 160 mm | d1: 207 mm | B1: 12 mm | B2: 21 mm | Mass: 1.48 kg | For: NJ232, NU232
HJ2240R d: 200 mm | d1: 256.9 mm | B1: 14 mm | B2: 28 mm | Mass: 2.78 kg | For: NJ2240R, NU2240R
HJ232R d: 160 mm | d1: 207.3 mm | B1: 12 mm | B2: 20 mm | Mass: 1.48 kg | For: NJ232R, NU232R
HJ340 d: 200 mm | d1: 280 mm | B1: 18 mm | B2: 33 mm | Mass: 5.00 kg | For: NJ340, NU340
HJ2340 d: 200 mm | d1: 280 mm | B1: 18 mm | B2: 44.5 mm | Mass: 5.00 kg | For: NJ2340, NU2340
HJ244 d: 220 mm | d1: 286 mm | B1: 15 mm | B2: 27.5 mm | Mass: 3.55 kg | For: NJ244, NU244
HJ2244 d: 220 mm | d1: 286 mm | B1: 15 mm | B2: 36.5 mm | Mass: 3.55 kg | For: NJ2244, NU2244
HJ344 d: 220 mm | d1: 307 mm | B1: 20 mm | B2: 36 mm | Mass: 7.05 kg | For: NJ344, NU344
HJ248 d: 240 mm | d1: 313 mm | B1: 16 mm | B2: 29.5 mm | Mass: 4.65 kg | For: NJ248, NU248
HJ2248 d: 240 mm | d1: 313 mm | B1: 16 mm | B2: 38.5 mm | Mass: 4.65 kg | For: NJ2248, NU2248
HJ348 d: 240 mm | d1: 335 mm | B1: 22 mm | B2: 39.5 mm | Mass: 8.20 kg | For: NJ348, NU348
HJ252 d: 260 mm | d1: 340 mm | B1: 18 mm | B2: 33 mm | Mass: 6.20 kg | For: NJ252, NU252
HJ2252 d: 260 mm | d1: 340 mm | B1: 18 mm | B2: 40.5 mm | Mass: 6.20 kg | For: NJ2252, NU2252
HJ256 d: 280 mm | d1: 360 mm | B1: 18 mm | B2: 33 mm | Mass: 7.15 kg | For: NJ256, NU256
HJ260 d: 300 mm | d1: 387 mm | B1: 20 mm | B2: 34.5 mm | Mass: 7.40 kg | For: NJ260, NU260
HJ264 d: 320 mm | d1: 415 mm | B1: 21 mm | B2: 37 mm | Mass: 11.3 kg | For: NJ264, NU264
Bearing AccessoriesKOYO
241 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO Thrust Collars for Cylindrical Roller Bearings (HJ)

Brand KOYO·Bearing Accessories

Available part numbers (241)

HJ204, HJ2207R, HJ204R, HJ307, HJ2204, HJ307R, HJ2204R, HJ2307, HJ304, HJ2307R + 231 more — see full table ↓

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HJ204d: 20 mm | d1: 29.7 mm | B1: 3 mm | B2: 6.75 mm | Mass: 0.012 kg | For: NJ204, NU204
HJ2207Rd: 35 mm | d1: 48.2 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.035 kg | For: NJ2207R, NU2207R
HJ204Rd: 20 mm | d1: 29.8 mm | B1: 3 mm | B2: 5.5 mm | Mass: 0.011 kg | For: NJ204R, NU204R
HJ307d: 35 mm | d1: 50.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.056 kg | For: NJ307, NU307
HJ2204d: 20 mm | d1: 30 mm | B1: 3 mm | B2: 7.5 mm | Mass: 0.012 kg | For: NJ2204, NU2204
HJ307Rd: 35 mm | d1: 51.1 mm | B1: 6 mm | B2: 9.5 mm | Mass: 0.060 kg | For: NJ307R, NU307R
HJ2204Rd: 20 mm | d1: 29.8 mm | B1: 3 mm | B2: 6.5 mm | Mass: 0.012 kg | For: NJ2204R, NU2204R
HJ2307d: 35 mm | d1: 50.8 mm | B1: 6 mm | B2: 14 mm | Mass: 0.056 kg | For: NJ2307, NU2307
HJ304d: 20 mm | d1: 31.8 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.017 kg | For: NJ304, NU304
HJ2307Rd: 35 mm | d1: 51.1 mm | B1: 6 mm | B2: 11 mm | Mass: 0.062 kg | For: NJ2307R, NU2307R
HJ304Rd: 20 mm | d1: 31.4 mm | B1: 4 mm | B2: 6.5 mm | Mass: 0.017 kg | For: NJ304R, NU304R
HJ407d: 35 mm | d1: 59 mm | B1: 8 mm | B2: 13 mm | Mass: 0.120 kg | For: NJ407, NU407
HJ2304d: 20 mm | d1: 31.8 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.020 kg | For: NJ2304, NU2304
HJ208d: 40 mm | d1: 54.2 mm | B1: 5 mm | B2: 9 mm | Mass: 0.046 kg | For: NJ208, NU208
HJ2304Rd: 20 mm | d1: 31.4 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.018 kg | For: NJ2304R, NU2304R
HJ208Rd: 40 mm | d1: 54.1 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.049 kg | For: NJ208R, NU208R
HJ2208d: 40 mm | d1: 54.2 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.046 kg | For: NJ2208, NU2208
HJ205d: 25 mm | d1: 34.7 mm | B1: 3 mm | B2: 7.25 mm | Mass: 0.015 kg | For: NJ205, NU205
HJ205Rd: 25 mm | d1: 34.8 mm | B1: 3 mm | B2: 6 mm | Mass: 0.014 kg | For: NJ205R, NU205R
HJ2208Rd: 40 mm | d1: 54.1 mm | B1: 5 mm | B2: 9 mm | Mass: 0.050 kg | For: NJ2208R, NU2208R
HJ2205d: 25 mm | d1: 34.7 mm | B1: 3 mm | B2: 7.5 mm | Mass: 0.015 kg | For: NJ2205, NU2205
HJ308d: 40 mm | d1: 58.4 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.083 kg | For: NJ308, NU308
HJ308Rd: 40 mm | d1: 57.7 mm | B1: 7 mm | B2: 11 mm | Mass: 0.088 kg | For: NJ308R, NU308R
HJ2205Rd: 25 mm | d1: 34.8 mm | B1: 3 mm | B2: 6.5 mm | Mass: 0.014 kg | For: NJ2205R, NU2205R
HJ305d: 25 mm | d1: 39 mm | B1: 4 mm | B2: 8 mm | Mass: 0.025 kg | For: NJ305, NU305
HJ2308d: 40 mm | d1: 58.4 mm | B1: 7 mm | B2: 14.5 mm | Mass: 0.083 kg | For: NJ2308, NU2308
HJ305Rd: 25 mm | d1: 38.2 mm | B1: 4 mm | B2: 7 mm | Mass: 0.025 kg | For: NJ305R, NU305R
HJ2308Rd: 40 mm | d1: 57.7 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.091 kg | For: NJ2308R, NU2308R
HJ408d: 40 mm | d1: 64.8 mm | B1: 8 mm | B2: 13 mm | Mass: 0.140 kg | For: NJ408, NU408
HJ2305d: 25 mm | d1: 39 mm | B1: 4 mm | B2: 9 mm | Mass: 0.025 kg | For: NJ2305, NU2305
HJ2305Rd: 25 mm | d1: 38.2 mm | B1: 4 mm | B2: 8 mm | Mass: 0.026 kg | For: NJ2305R, NU2305R
HJ209d: 45 mm | d1: 59 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.053 kg | For: NJ209, NU209
HJ209Rd: 45 mm | d1: 59.1 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.055 kg | For: NJ209R, NU209R
HJ206d: 30 mm | d1: 41.8 mm | B1: 4 mm | B2: 8.25 mm | Mass: 0.025 kg | For: NJ206, NU206
HJ2209d: 45 mm | d1: 59 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.053 kg | For: NJ2209, NU2209
HJ206Rd: 30 mm | d1: 41.4 mm | B1: 4 mm | B2: 7 mm | Mass: 0.025 kg | For: NJ206R, NU206R
HJ2206d: 30 mm | d1: 41.8 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.025 kg | For: NJ2206, NU2206
HJ2209Rd: 45 mm | d1: 59.1 mm | B1: 5 mm | B2: 9 mm | Mass: 0.055 kg | For: NJ2209R, NU2209R
HJ309d: 45 mm | d1: 64 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.099 kg | For: NJ309, NU309
HJ2206Rd: 30 mm | d1: 41.4 mm | B1: 4 mm | B2: 7.5 mm | Mass: 0.025 kg | For: NJ2206R, NU2206R
HJ309Rd: 45 mm | d1: 64.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.110 kg | For: NJ309R, NU309R
HJ306d: 30 mm | d1: 45.9 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.039 kg | For: NJ306, NU306
HJ306Rd: 30 mm | d1: 45.1 mm | B1: 5 mm | B2: 8.5 mm | Mass: 0.042 kg | For: NJ306R, NU306R
HJ2309d: 45 mm | d1: 64 mm | B1: 7 mm | B2: 15 mm | Mass: 0.099 kg | For: NJ2309, NU2309
HJ2309Rd: 45 mm | d1: 64.5 mm | B1: 7 mm | B2: 13 mm | Mass: 0.113 kg | For: NJ2309R, NU2309R
HJ2306d: 30 mm | d1: 45.9 mm | B1: 5 mm | B2: 11.5 mm | Mass: 0.039 kg | For: NJ2306, NU2306
HJ409d: 45 mm | d1: 71.8 mm | B1: 8 mm | B2: 13.5 mm | Mass: 0.175 kg | For: NJ409, NU409
HJ2306Rd: 30 mm | d1: 45.1 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.043 kg | For: NJ2306R, NU2306R
HJ406d: 30 mm | d1: 50.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.080 kg | For: NJ406, NU406
HJ210d: 50 mm | d1: 64.6 mm | B1: 5 mm | B2: 10 mm | Mass: 0.063 kg | For: NJ210, NU210
HJ210Rd: 50 mm | d1: 64.1 mm | B1: 5 mm | B2: 9 mm | Mass: 0.061 kg | For: NJ210R, NU210R
HJ207d: 35 mm | d1: 47.6 mm | B1: 4 mm | B2: 8 mm | Mass: 0.030 kg | For: NJ207, NU207
HJ2210d: 50 mm | d1: 64.6 mm | B1: 5 mm | B2: 9.5 mm | Mass: 0.063 kg | For: NJ2210, NU2210
HJ207Rd: 35 mm | d1: 48.2 mm | B1: 4 mm | B2: 7 mm | Mass: 0.033 kg | For: NJ207R, NU207R
HJ2207d: 35 mm | d1: 47.6 mm | B1: 4 mm | B2: 8.5 mm | Mass: 0.030 kg | For: NJ2207, NU2207
HJ2210Rd: 50 mm | d1: 64.1 mm | B1: 5 mm | B2: 9 mm | Mass: 0.061 kg | For: NJ2210R, NU2210R
HJ310d: 50 mm | d1: 71 mm | B1: 8 mm | B2: 14 mm | Mass: 0.142 kg | For: NJ310, NU310
HJ310Rd: 50 mm | d1: 71.4 mm | B1: 8 mm | B2: 13 mm | Mass: 0.151 kg | For: NJ310R, NU310R
HJ2313d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 20 mm | Mass: 0.280 kg | For: NJ2313, NU2313
HJ2310d: 50 mm | d1: 71 mm | B1: 8 mm | B2: 17 mm | Mass: 0.142 kg | For: NJ2310, NU2310
HJ2313Rd: 65 mm | d1: 90.6 mm | B1: 10 mm | B2: 18 mm | Mass: 0.298 kg | For: NJ2313R, NU2313R
HJ2310Rd: 50 mm | d1: 71.4 mm | B1: 8 mm | B2: 14.5 mm | Mass: 0.155 kg | For: NJ2310R, NU2310R
HJ413d: 65 mm | d1: 98.5 mm | B1: 11 mm | B2: 18 mm | Mass: 0.420 kg | For: NJ413, NU413
HJ410d: 50 mm | d1: 78.8 mm | B1: 9 mm | B2: 14.5 mm | Mass: 0.230 kg | For: NJ410, NU410
HJ214d: 70 mm | d1: 89.6 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.150 kg | For: NJ214, NU214
HJ214Rd: 70 mm | d1: 89.5 mm | B1: 7 mm | B2: 11 mm | Mass: 0.157 kg | For: NJ214R, NU214R
HJ211d: 55 mm | d1: 70.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.084 kg | For: NJ211, NU211
HJ2214d: 70 mm | d1: 89.6 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.150 kg | For: NJ2214, NU2214
HJ211Rd: 55 mm | d1: 70.9 mm | B1: 6 mm | B2: 9.5 mm | Mass: 0.087 kg | For: NJ211R, NU211R
HJ2211d: 55 mm | d1: 70.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.084 kg | For: NJ2211, NU2211
HJ2214Rd: 70 mm | d1: 89.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.158 kg | For: NJ2214R, NU2214R
HJ314d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 17.5 mm | Mass: 0.330 kg | For: NJ314, NU314
HJ2211Rd: 55 mm | d1: 70.9 mm | B1: 6 mm | B2: 10 mm | Mass: 0.088 kg | For: NJ2211R, NU2211R
HJ314Rd: 70 mm | d1: 97.5 mm | B1: 10 mm | B2: 15.5 mm | Mass: 0.330 kg | For: NJ314R, NU314R
HJ311d: 55 mm | d1: 77.2 mm | B1: 9 mm | B2: 15 mm | Mass: 0.182 kg | For: NJ311, NU311
HJ311Rd: 55 mm | d1: 77.6 mm | B1: 9 mm | B2: 14 mm | Mass: 0.195 kg | For: NJ311R, NU311R
HJ2314d: 70 mm | d1: 98 mm | B1: 10 mm | B2: 20.5 mm | Mass: 0.330 kg | For: NJ2314, NU2314
HJ2314Rd: 70 mm | d1: 97.5 mm | B1: 10 mm | B2: 18.5 mm | Mass: 0.345 kg | For: NJ2314R, NU2314R
HJ2311d: 55 mm | d1: 77.2 mm | B1: 9 mm | B2: 18.5 mm | Mass: 0.182 kg | For: NJ2311, NU2311
HJ414d: 70 mm | d1: 110.5 mm | B1: 12 mm | B2: 20 mm | Mass: 0.605 kg | For: NJ414, NU414
HJ2311Rd: 55 mm | d1: 77.6 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.200 kg | For: NJ2311R, NU2311R
HJ411d: 55 mm | d1: 85.2 mm | B1: 10 mm | B2: 16.5 mm | Mass: 0.290 kg | For: NJ411, NU411
HJ215d: 75 mm | d1: 94 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.156 kg | For: NJ215, NU215
HJ215Rd: 75 mm | d1: 94.5 mm | B1: 7 mm | B2: 11 mm | Mass: 0.166 kg | For: NJ215R, NU215R
HJ212d: 60 mm | d1: 78.4 mm | B1: 6 mm | B2: 11 mm | Mass: 0.108 kg | For: NJ212, NU212
HJ2215d: 75 mm | d1: 94 mm | B1: 7 mm | B2: 12.5 mm | Mass: 0.156 kg | For: NJ2215, NU2215
HJ212Rd: 60 mm | d1: 77.7 mm | B1: 6 mm | B2: 10 mm | Mass: 0.108 kg | For: NJ212R, NU212R
HJ2212d: 60 mm | d1: 78.4 mm | B1: 6 mm | B2: 11 mm | Mass: 0.108 kg | For: NJ2212, NU2212
HJ2215Rd: 75 mm | d1: 94.5 mm | B1: 7 mm | B2: 11.5 mm | Mass: 0.167 kg | For: NJ2215R, NU2215R
HJ315d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 18.5 mm | Mass: 0.400 kg | For: NJ315, NU315
HJ2212Rd: 60 mm | d1: 77.7 mm | B1: 6 mm | B2: 10 mm | Mass: 0.108 kg | For: NJ2212R, NU2212R
HJ315Rd: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 16.5 mm | Mass: 0.410 kg | For: NJ315R, NU315R
HJ312d: 60 mm | d1: 84.2 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.220 kg | For: NJ312, NU312
HJ312Rd: 60 mm | d1: 84.5 mm | B1: 9 mm | B2: 14.5 mm | Mass: 0.231 kg | For: NJ312R, NU312R
HJ2315d: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 21.5 mm | Mass: 0.400 kg | For: NJ2315, NU2315
HJ2315Rd: 75 mm | d1: 104.2 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.430 kg | For: NJ2315R, NU2315R
HJ2312d: 60 mm | d1: 84.2 mm | B1: 9 mm | B2: 19 mm | Mass: 0.220 kg | For: NJ2312, NU2312
HJ415d: 75 mm | d1: 116 mm | B1: 13 mm | B2: 21.5 mm | Mass: 0.710 kg | For: NJ415, NU415
HJ2312Rd: 60 mm | d1: 84.5 mm | B1: 9 mm | B2: 16 mm | Mass: 0.237 kg | For: NJ2312R, NU2312R
HJ412d: 60 mm | d1: 91.8 mm | B1: 10 mm | B2: 16.5 mm | Mass: 0.340 kg | For: NJ412, NU412
HJ216d: 80 mm | d1: 101.2 mm | B1: 8 mm | B2: 13.5 mm | Mass: 0.207 kg | For: NJ216, NU216
HJ216Rd: 80 mm | d1: 101.6 mm | B1: 8 mm | B2: 12.5 mm | Mass: 0.222 kg | For: NJ216R, NU216R
HJ213d: 65 mm | d1: 84.8 mm | B1: 6 mm | B2: 11 mm | Mass: 0.123 kg | For: NJ213, NU213
HJ2216d: 80 mm | d1: 101.2 mm | B1: 8 mm | B2: 13.5 mm | Mass: 0.207 kg | For: NJ2216, NU2216
HJ213Rd: 65 mm | d1: 84.5 mm | B1: 6 mm | B2: 10 mm | Mass: 0.129 kg | For: NJ213R, NU213R
HJ2213d: 65 mm | d1: 84.8 mm | B1: 6 mm | B2: 11.5 mm | Mass: 0.123 kg | For: NJ2213, NU2213
HJ2216Rd: 80 mm | d1: 101.6 mm | B1: 8 mm | B2: 12.5 mm | Mass: 0.222 kg | For: NJ2216R, NU2216R
HJ316d: 80 mm | d1: 111.8 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.470 kg | For: NJ316, NU316
HJ2213Rd: 65 mm | d1: 84.5 mm | B1: 6 mm | B2: 10.5 mm | Mass: 0.131 kg | For: NJ2213R, NU2213R
HJ316Rd: 80 mm | d1: 110.6 mm | B1: 11 mm | B2: 17 mm | Mass: 0.460 kg | For: NJ316R, NU316R
HJ313d: 65 mm | d1: 91 mm | B1: 10 mm | B2: 17 mm | Mass: 0.280 kg | For: NJ313, NU313
HJ313Rd: 65 mm | d1: 90.6 mm | B1: 10 mm | B2: 15.5 mm | Mass: 0.288 kg | For: NJ313R, NU313R
HJ2316d: 80 mm | d1: 111.8 mm | B1: 11 mm | B2: 23 mm | Mass: 0.470 kg | For: NJ2316, NU2316
HJ2316Rd: 80 mm | d1: 110.6 mm | B1: 11 mm | B2: 20 mm | Mass: 0.480 kg | For: NJ2316R, NU2316R
HJ416d: 80 mm | d1: 122 mm | B1: 13 mm | B2: 22 mm | Mass: 0.780 kg | For: NJ416, NU416
HJ220Rd: 100 mm | d1: 127.5 mm | B1: 10 mm | B2: 15 mm | Mass: 0.435 kg | For: NJ220R, NU220R
HJ2220d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 18 mm | Mass: 0.444 kg | For: NJ2220, NU2220
HJ217d: 85 mm | d1: 108.2 mm | B1: 8 mm | B2: 14 mm | Mass: 0.250 kg | For: NJ217, NU217
HJ2220Rd: 100 mm | d1: 127.5 mm | B1: 10 mm | B2: 16 mm | Mass: 0.450 kg | For: NJ2220R, NU2220R
HJ217Rd: 85 mm | d1: 107.6 mm | B1: 8 mm | B2: 12.5 mm | Mass: 0.250 kg | For: NJ217R, NU217R
HJ320d: 100 mm | d1: 140.5 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.895 kg | For: NJ320, NU320
HJ2217d: 85 mm | d1: 108.2 mm | B1: 8 mm | B2: 14 mm | Mass: 0.250 kg | For: NJ2217, NU2217
HJ320Rd: 100 mm | d1: 139.6 mm | B1: 13 mm | B2: 20.5 mm | Mass: 0.890 kg | For: NJ320R, NU320R
HJ2217Rd: 85 mm | d1: 107.6 mm | B1: 8 mm | B2: 13 mm | Mass: 0.252 kg | For: NJ2217R, NU2217R
HJ2320d: 100 mm | d1: 140.5 mm | B1: 13 mm | B2: 27.5 mm | Mass: 0.895 kg | For: NJ2320, NU2320
HJ317d: 85 mm | d1: 117.5 mm | B1: 12 mm | B2: 20.5 mm | Mass: 0.560 kg | For: NJ317, NU317
HJ2320Rd: 100 mm | d1: 139.6 mm | B1: 13 mm | B2: 23.5 mm | Mass: 0.920 kg | For: NJ2320R, NU2320R
HJ317Rd: 85 mm | d1: 117.9 mm | B1: 12 mm | B2: 18.5 mm | Mass: 0.575 kg | For: NJ317R, NU317R
HJ420d: 100 mm | d1: 153.5 mm | B1: 16 mm | B2: 27 mm | Mass: 1.50 kg | For: NJ420, NU420
HJ2317d: 85 mm | d1: 117.5 mm | B1: 12 mm | B2: 24 mm | Mass: 0.560 kg | For: NJ2317, NU2317
HJ2317Rd: 85 mm | d1: 117.9 mm | B1: 12 mm | B2: 22 mm | Mass: 0.595 kg | For: NJ2317R, NU2317R
HJ221d: 105 mm | d1: 135 mm | B1: 10 mm | B2: 17.5 mm | Mass: 0.505 kg | For: NJ221, NU221
HJ417d: 85 mm | d1: 126 mm | B1: 14 mm | B2: 24 mm | Mass: 0.880 kg | For: NJ417, NU417
HJ321d: 105 mm | d1: 147 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.970 kg | For: NJ321, NU321
HJ421d: 105 mm | d1: 159.5 mm | B1: 16 mm | B2: 27 mm | Mass: 1.65 kg | For: NJ421, NU421
HJ218d: 90 mm | d1: 114.2 mm | B1: 9 mm | B2: 15 mm | Mass: 0.305 kg | For: NJ218, NU218
HJ218Rd: 90 mm | d1: 114.4 mm | B1: 9 mm | B2: 14 mm | Mass: 0.320 kg | For: NJ218R, NU218R
HJ222d: 110 mm | d1: 141.5 mm | B1: 11 mm | B2: 18.5 mm | Mass: 0.615 kg | For: NJ222, NU222
HJ2218d: 90 mm | d1: 114.2 mm | B1: 9 mm | B2: 16 mm | Mass: 0.305 kg | For: NJ2218, NU2218
HJ222Rd: 110 mm | d1: 141.7 mm | B1: 11 mm | B2: 17 mm | Mass: 0.620 kg | For: NJ222R, NU222R
HJ2222d: 110 mm | d1: 141.5 mm | B1: 11 mm | B2: 20.5 mm | Mass: 0.615 kg | For: NJ2222, NU2222
HJ2218Rd: 90 mm | d1: 114.4 mm | B1: 9 mm | B2: 15 mm | Mass: 0.325 kg | For: NJ2218R, NU2218R
HJ318d: 90 mm | d1: 125 mm | B1: 12 mm | B2: 21 mm | Mass: 0.630 kg | For: NJ318, NU318
HJ2222Rd: 110 mm | d1: 141.7 mm | B1: 11 mm | B2: 19.5 mm | Mass: 0.645 kg | For: NJ2222R, NU2222R
HJ318Rd: 90 mm | d1: 124.2 mm | B1: 12 mm | B2: 18.5 mm | Mass: 0.630 kg | For: NJ318R, NU318R
HJ322d: 110 mm | d1: 155.5 mm | B1: 14 mm | B2: 23 mm | Mass: 1.17 kg | For: NJ322, NU322
HJ322Rd: 110 mm | d1: 155.8 mm | B1: 14 mm | B2: 22 mm | Mass: 1.21 kg | For: NJ322R, NU322R
HJ2318d: 90 mm | d1: 125 mm | B1: 12 mm | B2: 26 mm | Mass: 0.630 kg | For: NJ2318, NU2318
HJ2318Rd: 90 mm | d1: 124.2 mm | B1: 12 mm | B2: 22 mm | Mass: 0.660 kg | For: NJ2318R, NU2318R
HJ2322d: 110 mm | d1: 155.5 mm | B1: 14 mm | B2: 28 mm | Mass: 1.17 kg | For: NJ2322, NU2322
HJ418d: 90 mm | d1: 137 mm | B1: 14 mm | B2: 24 mm | Mass: 1.05 kg | For: NJ418, NU418
HJ2322Rd: 110 mm | d1: 155.8 mm | B1: 14 mm | B2: 26.5 mm | Mass: 1.27 kg | For: NJ2322R, NU2322R
HJ422d: 110 mm | d1: 171 mm | B1: 17 mm | B2: 29.5 mm | Mass: 2.10 kg | For: NJ422, NU422
HJ219d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.352 kg | For: NJ219, NU219
HJ219Rd: 95 mm | d1: 120.6 mm | B1: 9 mm | B2: 14 mm | Mass: 0.355 kg | For: NJ219R, NU219R
HJ224d: 120 mm | d1: 153 mm | B1: 11 mm | B2: 19 mm | Mass: 0.715 kg | For: NJ224, NU224
HJ2219d: 95 mm | d1: 121 mm | B1: 9 mm | B2: 16.5 mm | Mass: 0.352 kg | For: NJ2219, NU2219
HJ224Rd: 120 mm | d1: 153.4 mm | B1: 11 mm | B2: 17 mm | Mass: 0.710 kg | For: NJ224R, NU224R
HJ2224d: 120 mm | d1: 153 mm | B1: 11 mm | B2: 22 mm | Mass: 0.715 kg | For: NJ2224, NU2224
HJ2219Rd: 95 mm | d1: 120.6 mm | B1: 9 mm | B2: 15.5 mm | Mass: 0.365 kg | For: NJ2219R, NU2219R
HJ319d: 95 mm | d1: 132 mm | B1: 13 mm | B2: 22.5 mm | Mass: 0.760 kg | For: NJ319, NU319
HJ2224Rd: 120 mm | d1: 153.4 mm | B1: 11 mm | B2: 20 mm | Mass: 0.745 kg | For: NJ2224R, NU2224R
HJ319Rd: 95 mm | d1: 132.2 mm | B1: 13 mm | B2: 20.5 mm | Mass: 0.785 kg | For: NJ319R, NU319R
HJ324d: 120 mm | d1: 168.5 mm | B1: 14 mm | B2: 23.5 mm | Mass: 1.40 kg | For: NJ324, NU324
HJ324Rd: 120 mm | d1: 168.6 mm | B1: 14 mm | B2: 22.5 mm | Mass: 1.41 kg | For: NJ324R, NU324R
HJ2319d: 95 mm | d1: 132 mm | B1: 13 mm | B2: 26.5 mm | Mass: 0.760 kg | For: NJ2319, NU2319
HJ419d: 95 mm | d1: 147 mm | B1: 15 mm | B2: 25.5 mm | Mass: 1.30 kg | For: NJ419, NU419
HJ2324d: 120 mm | d1: 168.5 mm | B1: 14 mm | B2: 28 mm | Mass: 1.40 kg | For: NJ2324, NU2324
HJ2324Rd: 120 mm | d1: 168.6 mm | B1: 14 mm | B2: 26 mm | Mass: 1.46 kg | For: NJ2324R, NU2324R
HJ220d: 100 mm | d1: 128 mm | B1: 10 mm | B2: 17 mm | Mass: 0.444 kg | For: NJ220, NU220
HJ424d: 120 mm | d1: 188 mm | B1: 17 mm | B2: 30.5 mm | Mass: 2.60 kg | For: NJ424, NU424
HJ226d: 130 mm | d1: 165.5 mm | B1: 11 mm | B2: 19 mm | Mass: 0.840 kg | For: NJ226, NU226
HJ2232d: 160 mm | d1: 205 mm | B1: 12 mm | B2: 28 mm | Mass: 1.48 kg | For: NJ2232, NU2232
HJ226Rd: 130 mm | d1: 164.2 mm | B1: 11 mm | B2: 17 mm | Mass: 0.790 kg | For: NJ226R, NU226R
HJ2232Rd: 160 mm | d1: 206.1 mm | B1: 12 mm | B2: 24.5 mm | Mass: 1.55 kg | For: NJ2232R, NU2232R
HJ2226d: 130 mm | d1: 165.5 mm | B1: 11 mm | B2: 25 mm | Mass: 0.840 kg | For: NJ2226, NU2226
HJ332d: 160 mm | d1: 225 mm | B1: 15 mm | B2: 28 mm | Mass: 2.75 kg | For: NJ332, NU332
HJ2226Rd: 130 mm | d1: 164.2 mm | B1: 11 mm | B2: 21 mm | Mass: 0.840 kg | For: NJ2226R, NU2226R
HJ332Rd: 160 mm | d1: 222.1 mm | B1: 15 mm | B2: 25 mm | Mass: 2.59 kg | For: NJ332R, NU332R
HJ326d: 130 mm | d1: 182 mm | B1: 14 mm | B2: 24 mm | Mass: 1.62 kg | For: NJ326, NU326
HJ2332d: 160 mm | d1: 225 mm | B1: 15 mm | B2: 37 mm | Mass: 2.75 kg | For: NJ2332, NU2332
HJ326Rd: 130 mm | d1: 182.3 mm | B1: 14 mm | B2: 23 mm | Mass: 1.65 kg | For: NJ326R, NU326R
HJ2332Rd: 160 mm | d1: 222.1 mm | B1: 15 mm | B2: 32 mm | Mass: 2.76 kg | For: NJ2332R, NU2332R
HJ2326d: 130 mm | d1: 182 mm | B1: 14 mm | B2: 29.5 mm | Mass: 1.62 kg | For: NJ2326, NU2326
HJ234d: 170 mm | d1: 220.5 mm | B1: 12 mm | B2: 22 mm | Mass: 1.70 kg | For: NJ234, NU234
HJ2326Rd: 130 mm | d1: 182.3 mm | B1: 14 mm | B2: 28 mm | Mass: 1.73 kg | For: NJ2326R, NU2326R
HJ234Rd: 170 mm | d1: 220.8 mm | B1: 12 mm | B2: 20 mm | Mass: 1.70 kg | For: NJ234R, NU234R
HJ426d: 130 mm | d1: 205 mm | B1: 18 mm | B2: 32 mm | Mass: 3.30 kg | For: NJ426, NU426
HJ2234d: 170 mm | d1: 219 mm | B1: 12 mm | B2: 29 mm | Mass: 1.70 kg | For: NJ2234, NU2234
HJ228d: 140 mm | d1: 179.5 mm | B1: 11 mm | B2: 19 mm | Mass: 1.00 kg | For: NJ228, NU228
HJ2234Rd: 170 mm | d1: 219.5 mm | B1: 12 mm | B2: 24 mm | Mass: 1.79 kg | For: NJ2234R, NU2234R
HJ228Rd: 140 mm | d1: 180 mm | B1: 11 mm | B2: 18 mm | Mass: 0.990 kg | For: NJ228R, NU228R
HJ334d: 170 mm | d1: 238 mm | B1: 16 mm | B2: 29.5 mm | Mass: 3.25 kg | For: NJ334, NU334
HJ2228d: 140 mm | d1: 179.5 mm | B1: 11 mm | B2: 25 mm | Mass: 1.00 kg | For: NJ2228, NU2228
HJ2334d: 170 mm | d1: 238 mm | B1: 16 mm | B2: 38.5 mm | Mass: 3.25 kg | For: NJ2334, NU2334
HJ2228Rd: 140 mm | d1: 180 mm | B1: 11 mm | B2: 23 mm | Mass: 1.07 kg | For: NJ2228R, NU2228R
HJ236d: 180 mm | d1: 230.5 mm | B1: 12 mm | B2: 22 mm | Mass: 1.80 kg | For: NJ236, NU236
HJ328d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 26 mm | Mass: 1.93 kg | For: NJ328, NU328
HJ236Rd: 180 mm | d1: 230.8 mm | B1: 12 mm | B2: 20 mm | Mass: 1.79 kg | For: NJ236R, NU236R
HJ328Rd: 140 mm | d1: 196 mm | B1: 15 mm | B2: 25 mm | Mass: 2.04 kg | For: NJ328R, NU328R
HJ2236d: 180 mm | d1: 229 mm | B1: 12 mm | B2: 29 mm | Mass: 1.80 kg | For: NJ2236, NU2236
HJ2328d: 140 mm | d1: 196 mm | B1: 15 mm | B2: 33.5 mm | Mass: 1.98 kg | For: NJ2328, NU2328
HJ2236Rd: 180 mm | d1: 229.5 mm | B1: 12 mm | B2: 24 mm | Mass: 1.88 kg | For: NJ2236R, NU2236R
HJ2328Rd: 140 mm | d1: 196 mm | B1: 15 mm | B2: 31 mm | Mass: 2.14 kg | For: NJ2328R, NU2328R
HJ336d: 180 mm | d1: 252 mm | B1: 17 mm | B2: 30.5 mm | Mass: 3.85 kg | For: NJ336, NU336
HJ428d: 140 mm | d1: 219 mm | B1: 18 mm | B2: 33 mm | Mass: 3.75 kg | For: NJ428, NU428
HJ2336d: 180 mm | d1: 252 mm | B1: 17 mm | B2: 40 mm | Mass: 3.85 kg | For: NJ2336, NU2336
HJ230d: 150 mm | d1: 193 mm | B1: 12 mm | B2: 20.5 mm | Mass: 1.24 kg | For: NJ230, NU230
HJ238d: 190 mm | d1: 244.5 mm | B1: 13 mm | B2: 23.5 mm | Mass: 2.20 kg | For: NJ238, NU238
HJ230Rd: 150 mm | d1: 193.7 mm | B1: 12 mm | B2: 19.5 mm | Mass: 1.26 kg | For: NJ230R, NU230R
HJ238Rd: 190 mm | d1: 244.5 mm | B1: 13 mm | B2: 21.5 mm | Mass: 2.19 kg | For: NJ238R, NU238R
HJ2230d: 150 mm | d1: 193 mm | B1: 12 mm | B2: 26.5 mm | Mass: 1.24 kg | For: NJ2230, NU2230
HJ2238d: 190 mm | d1: 243 mm | B1: 13 mm | B2: 31.5 mm | Mass: 2.20 kg | For: NJ2238, NU2238
HJ2230Rd: 150 mm | d1: 193.7 mm | B1: 12 mm | B2: 24.5 mm | Mass: 1.35 kg | For: NJ2230R, NU2230R
HJ2238Rd: 190 mm | d1: 243.2 mm | B1: 13 mm | B2: 26.5 mm | Mass: 2.31 kg | For: NJ2238R, NU2238R
HJ330d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 26.5 mm | Mass: 2.37 kg | For: NJ330, NU330
HJ338d: 190 mm | d1: 265 mm | B1: 18 mm | B2: 32 mm | Mass: 4.45 kg | For: NJ338, NU338
HJ330Rd: 150 mm | d1: 210 mm | B1: 15 mm | B2: 25 mm | Mass: 2.35 kg | For: NJ330R, NU330R
HJ2338d: 190 mm | d1: 265 mm | B1: 18 mm | B2: 41.5 mm | Mass: 4.45 kg | For: NJ2338, NU2338
HJ2330d: 150 mm | d1: 210 mm | B1: 15 mm | B2: 34 mm | Mass: 2.37 kg | For: NJ2330, NU2330
HJ2330Rd: 150 mm | d1: 210 mm | B1: 15 mm | B2: 31.5 mm | Mass: 2.48 kg | For: NJ2330R, NU2330R
HJ240d: 200 mm | d1: 258 mm | B1: 14 mm | B2: 25 mm | Mass: 2.60 kg | For: NJ240, NU240
HJ430d: 150 mm | d1: 234 mm | B1: 20 mm | B2: 36.5 mm | Mass: 4.70 kg | For: NJ430, NU430
HJ240Rd: 200 mm | d1: 258.2 mm | B1: 14 mm | B2: 23 mm | Mass: 2.65 kg | For: NJ240R, NU240R
HJ2240d: 200 mm | d1: 258 mm | B1: 14 mm | B2: 34 mm | Mass: 2.60 kg | For: NJ2240, NU2240
HJ232d: 160 mm | d1: 207 mm | B1: 12 mm | B2: 21 mm | Mass: 1.48 kg | For: NJ232, NU232
HJ2240Rd: 200 mm | d1: 256.9 mm | B1: 14 mm | B2: 28 mm | Mass: 2.78 kg | For: NJ2240R, NU2240R
HJ232Rd: 160 mm | d1: 207.3 mm | B1: 12 mm | B2: 20 mm | Mass: 1.48 kg | For: NJ232R, NU232R
HJ340d: 200 mm | d1: 280 mm | B1: 18 mm | B2: 33 mm | Mass: 5.00 kg | For: NJ340, NU340
HJ2340d: 200 mm | d1: 280 mm | B1: 18 mm | B2: 44.5 mm | Mass: 5.00 kg | For: NJ2340, NU2340
HJ244d: 220 mm | d1: 286 mm | B1: 15 mm | B2: 27.5 mm | Mass: 3.55 kg | For: NJ244, NU244
HJ2244d: 220 mm | d1: 286 mm | B1: 15 mm | B2: 36.5 mm | Mass: 3.55 kg | For: NJ2244, NU2244
HJ344d: 220 mm | d1: 307 mm | B1: 20 mm | B2: 36 mm | Mass: 7.05 kg | For: NJ344, NU344
HJ248d: 240 mm | d1: 313 mm | B1: 16 mm | B2: 29.5 mm | Mass: 4.65 kg | For: NJ248, NU248
HJ2248d: 240 mm | d1: 313 mm | B1: 16 mm | B2: 38.5 mm | Mass: 4.65 kg | For: NJ2248, NU2248
HJ348d: 240 mm | d1: 335 mm | B1: 22 mm | B2: 39.5 mm | Mass: 8.20 kg | For: NJ348, NU348
HJ252d: 260 mm | d1: 340 mm | B1: 18 mm | B2: 33 mm | Mass: 6.20 kg | For: NJ252, NU252
HJ2252d: 260 mm | d1: 340 mm | B1: 18 mm | B2: 40.5 mm | Mass: 6.20 kg | For: NJ2252, NU2252
HJ256d: 280 mm | d1: 360 mm | B1: 18 mm | B2: 33 mm | Mass: 7.15 kg | For: NJ256, NU256
HJ260d: 300 mm | d1: 387 mm | B1: 20 mm | B2: 34.5 mm | Mass: 7.40 kg | For: NJ260, NU260
HJ264d: 320 mm | d1: 415 mm | B1: 21 mm | B2: 37 mm | Mass: 11.3 kg | For: NJ264, NU264

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
