KOYO UCC Cartridge Units

Cast iron cartridge units with UC insert bearings for mounting in a bored housing.

Key features

Pre-lubricated sealed ball bearing insert
Spherical seating compensates for shaft misalignment
Housing and insert replaceable separately
Unit number, housing number and insert bearing listed
Shaft diameter given in mm

Specifications

Product type	Ball bearing unit
Series	UCC Cartridge Units
Seal	Insert bearing sealed both sides
Source	KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B524-B527

UCC201		Shaft d: 12 mm \| Housing: C204 \| Bearing: UC201 \| Cr: 12.8 kN
UCC211		Shaft d: 55 mm \| Housing: C211 \| Bearing: UC211 \| Cr: 43.4 kN
UCC202		Shaft d: 15 mm \| Housing: C204 \| Bearing: UC202 \| Cr: 12.8 kN
UCC311		Shaft d: 55 mm \| Housing: C311 \| Bearing: UC311 \| Cr: 71.6 kN
UCC203		Shaft d: 17 mm \| Housing: C204 \| Bearing: UC203 \| Cr: 12.8 kN
UCC212		Shaft d: 60 mm \| Housing: C212 \| Bearing: UC212 \| Cr: 52.4 kN
UCC204		Shaft d: 20 mm \| Housing: C204 \| Bearing: UC204 \| Cr: 12.8 kN
UCC312		Shaft d: 60 mm \| Housing: C312 \| Bearing: UC312 \| Cr: 81.9 kN
UCC205		Shaft d: 25 mm \| Housing: C205 \| Bearing: UC205 \| Cr: 14.0 kN
UCC213		Shaft d: 65 mm \| Housing: C213 \| Bearing: UC213 \| Cr: 57.2 kN
UCC313		Shaft d: 65 mm \| Housing: C313 \| Bearing: UC313 \| Cr: 92.7 kN
UCC305		Shaft d: 25 mm \| Housing: C305 \| Bearing: UC305 \| Cr: 21.2 kN
UCC314		Shaft d: 70 mm \| Housing: C314 \| Bearing: UC314 \| Cr: 104 kN
UCC206		Shaft d: 30 mm \| Housing: C206 \| Bearing: UC206 \| Cr: 19.5 kN
UCC315		Shaft d: 75 mm \| Housing: C315 \| Bearing: UC315 \| Cr: 113 kN
UCC306		Shaft d: 30 mm \| Housing: C306 \| Bearing: UC306 \| Cr: 26.7 kN
UCC316		Shaft d: 80 mm \| Housing: C316 \| Bearing: UC316 \| Cr: 123 kN
UCC207		Shaft d: 35 mm \| Housing: C207 \| Bearing: UC207 \| Cr: 25.7 kN
UCC317		Shaft d: 85 mm \| Housing: C317 \| Bearing: UC317 \| Cr: 133 kN
UCC307		Shaft d: 35 mm \| Housing: C307 \| Bearing: UC307 \| Cr: 33.4 kN
UCC318		Shaft d: 90 mm \| Housing: C318 \| Bearing: UC318 \| Cr: 143 kN
UCC208		Shaft d: 40 mm \| Housing: C208 \| Bearing: UC208 \| Cr: 29.1 kN
UCC319		Shaft d: 95 mm \| Housing: C319 \| Bearing: UC319 \| Cr: 153 kN
UCC308		Shaft d: 40 mm \| Housing: C308 \| Bearing: UC308 \| Cr: 40.7 kN
UCC320		Shaft d: 100 mm \| Housing: C320 \| Bearing: UC320 \| Cr: 173 kN
UCC209		Shaft d: 45 mm \| Housing: C209 \| Bearing: UC209 \| Cr: 32.7 kN
UCC321		Shaft d: 105 mm \| Housing: C321 \| Bearing: UC321 \| Cr: 184 kN
UCC309		Shaft d: 45 mm \| Housing: C309 \| Bearing: UC309 \| Cr: 48.9 kN
UCC322		Shaft d: 110 mm \| Housing: C322 \| Bearing: UC322 \| Cr: 205 kN
UCC210		Shaft d: 50 mm \| Housing: C210 \| Bearing: UC210 \| Cr: 35.1 kN
UCC324		Shaft d: 120 mm \| Housing: C324 \| Bearing: UC324 \| Cr: 207 kN
UCC310		Shaft d: 50 mm \| Housing: C310 \| Bearing: UC310 \| Cr: 62.0 kN
UCC326		Shaft d: 130 mm \| Housing: C326 \| Bearing: UC326 \| Cr: 229 kN
UCC328		Shaft d: 140 mm \| Housing: C328 \| Bearing: UC328 \| Cr: 253 kN
