KOYO UCF Square Flanged Units

KOYO UCF Square Flanged Units

Cast iron 4-bolt square flanged units with UC/UCX insert bearings and set screw locking, with optional covers.

Key features

  • Pre-lubricated sealed ball bearing insert
  • Spherical seating compensates for shaft misalignment
  • Housing and insert replaceable separately
  • Unit number, housing number and insert bearing listed
  • Shaft diameter given in mm

Specifications

Product type Ball bearing unit
Series UCF Square Flange Units
Seal Insert bearing sealed both sides
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B490-B495
UCF201 Shaft d: 12 mm | Housing: F204 | Bearing: UC201 | Cr: 12.8 kN
UCF201C Shaft d: 12 mm | Base unit: UCF201 | Cover, open end | Bearing: UC201 | Cr: 12.8 kN
UCF201D Shaft d: 12 mm | Base unit: UCF201 | Cover, closed end | Bearing: UC201 | Cr: 12.8 kN
UCF202 Shaft d: 15 mm | Housing: F204 | Bearing: UC202 | Cr: 12.8 kN
UCF202C Shaft d: 15 mm | Base unit: UCF202 | Cover, open end | Bearing: UC202 | Cr: 12.8 kN
UCF202D Shaft d: 15 mm | Base unit: UCF202 | Cover, closed end | Bearing: UC202 | Cr: 12.8 kN
UCF203 Shaft d: 17 mm | Housing: F204 | Bearing: UC203 | Cr: 12.8 kN
UCF203C Shaft d: 17 mm | Base unit: UCF203 | Cover, open end | Bearing: UC203 | Cr: 12.8 kN
UCF203D Shaft d: 17 mm | Base unit: UCF203 | Cover, closed end | Bearing: UC203 | Cr: 12.8 kN
UCF204 Shaft d: 20 mm | Housing: F204 | Bearing: UC204 | Cr: 12.8 kN
UCF204C Shaft d: 20 mm | Base unit: UCF204 | Cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCF204D Shaft d: 20 mm | Base unit: UCF204 | Cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCF204FC Shaft d: 20 mm | Base unit: UCF204 | Cast iron cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCF204FD Shaft d: 20 mm | Base unit: UCF204 | Cast iron cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCF205 Shaft d: 25 mm | Housing: F205 | Bearing: UC205 | Cr: 14.0 kN
UCF205C Shaft d: 25 mm | Base unit: UCF205 | Cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCF205D Shaft d: 25 mm | Base unit: UCF205 | Cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCF205FC Shaft d: 25 mm | Base unit: UCF205 | Cast iron cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCF205FD Shaft d: 25 mm | Base unit: UCF205 | Cast iron cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCFX05 Shaft d: 25 mm | Housing: FX05 | Bearing: UCX05 | Cr: 19.5 kN
UCFX05C Shaft d: 25 mm | Base unit: UCFX05 | Cover, open end | Bearing: UCX05 | Cr: 19.5 kN
UCFX05D Shaft d: 25 mm | Base unit: UCFX05 | Cover, closed end | Bearing: UCX05 | Cr: 19.5 kN
UCF305 Shaft d: 25 mm | Housing: F305 | Bearing: UC305 | Cr: 21.2 kN
UCF305C Shaft d: 25 mm | Base unit: UCF305 | Cover, open end | Bearing: UC305 | Cr: 21.2 kN
UCF305D Shaft d: 25 mm | Base unit: UCF305 | Cover, closed end | Bearing: UC305 | Cr: 21.2 kN
UCF206 Shaft d: 30 mm | Housing: F206 | Bearing: UC206 | Cr: 19.5 kN
UCF206C Shaft d: 30 mm | Base unit: UCF206 | Cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCF206D Shaft d: 30 mm | Base unit: UCF206 | Cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCF206FC Shaft d: 30 mm | Base unit: UCF206 | Cast iron cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCF206FD Shaft d: 30 mm | Base unit: UCF206 | Cast iron cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCFX06 Shaft d: 30 mm | Housing: FX06 | Bearing: UCX06 | Cr: 25.7 kN
UCFX06C Shaft d: 30 mm | Base unit: UCFX06 | Cover, open end | Bearing: UCX06 | Cr: 25.7 kN
UCFX06D Shaft d: 30 mm | Base unit: UCFX06 | Cover, closed end | Bearing: UCX06 | Cr: 25.7 kN
UCF306 Shaft d: 30 mm | Housing: F306 | Bearing: UC306 | Cr: 26.7 kN
UCF306C Shaft d: 30 mm | Base unit: UCF306 | Cover, open end | Bearing: UC306 | Cr: 26.7 kN
UCF306D Shaft d: 30 mm | Base unit: UCF306 | Cover, closed end | Bearing: UC306 | Cr: 26.7 kN
UCF207 Shaft d: 35 mm | Housing: F207 | Bearing: UC207 | Cr: 25.7 kN
UCF207C Shaft d: 35 mm | Base unit: UCF207 | Cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCF207D Shaft d: 35 mm | Base unit: UCF207 | Cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCF207FC Shaft d: 35 mm | Base unit: UCF207 | Cast iron cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCF207FD Shaft d: 35 mm | Base unit: UCF207 | Cast iron cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCFX07 Shaft d: 35 mm | Housing: FX07 | Bearing: UCX07 | Cr: 29.1 kN
UCFX07C Shaft d: 35 mm | Base unit: UCFX07 | Cover, open end | Bearing: UCX07 | Cr: 29.1 kN
UCFX07D Shaft d: 35 mm | Base unit: UCFX07 | Cover, closed end | Bearing: UCX07 | Cr: 29.1 kN
UCF307 Shaft d: 35 mm | Housing: F307 | Bearing: UC307 | Cr: 33.4 kN
UCF307C Shaft d: 35 mm | Base unit: UCF307 | Cover, open end | Bearing: UC307 | Cr: 33.4 kN
UCF307D Shaft d: 35 mm | Base unit: UCF307 | Cover, closed end | Bearing: UC307 | Cr: 33.4 kN
UCF208 Shaft d: 40 mm | Housing: F208 | Bearing: UC208 | Cr: 29.1 kN
UCF208C Shaft d: 40 mm | Base unit: UCF208 | Cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCF208D Shaft d: 40 mm | Base unit: UCF208 | Cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCF208FC Shaft d: 40 mm | Base unit: UCF208 | Cast iron cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCF208FD Shaft d: 40 mm | Base unit: UCF208 | Cast iron cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCFX08 Shaft d: 40 mm | Housing: FX08 | Bearing: UCX08 | Cr: 32.7 kN
UCFX08C Shaft d: 40 mm | Base unit: UCFX08 | Cover, open end | Bearing: UCX08 | Cr: 32.7 kN
UCFX08D Shaft d: 40 mm | Base unit: UCFX08 | Cover, closed end | Bearing: UCX08 | Cr: 32.7 kN
UCF308 Shaft d: 40 mm | Housing: F308 | Bearing: UC308 | Cr: 40.7 kN
UCF308C Shaft d: 40 mm | Base unit: UCF308 | Cover, open end | Bearing: UC308 | Cr: 40.7 kN
UCF308D Shaft d: 40 mm | Base unit: UCF308 | Cover, closed end | Bearing: UC308 | Cr: 40.7 kN
UCF209 Shaft d: 45 mm | Housing: F209 | Bearing: UC209 | Cr: 32.7 kN
UCF209C Shaft d: 45 mm | Base unit: UCF209 | Cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCF209D Shaft d: 45 mm | Base unit: UCF209 | Cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCF209FC Shaft d: 45 mm | Base unit: UCF209 | Cast iron cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCF209FD Shaft d: 45 mm | Base unit: UCF209 | Cast iron cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCFX09 Shaft d: 45 mm | Housing: FX09 | Bearing: UCX09 | Cr: 35.1 kN
UCFX09C Shaft d: 45 mm | Base unit: UCFX09 | Cover, open end | Bearing: UCX09 | Cr: 35.1 kN
UCFX09D Shaft d: 45 mm | Base unit: UCFX09 | Cover, closed end | Bearing: UCX09 | Cr: 35.1 kN
UCF309 Shaft d: 45 mm | Housing: F309 | Bearing: UC309 | Cr: 48.9 kN
UCF309C Shaft d: 45 mm | Base unit: UCF309 | Cover, open end | Bearing: UC309 | Cr: 48.9 kN
UCF309D Shaft d: 45 mm | Base unit: UCF309 | Cover, closed end | Bearing: UC309 | Cr: 48.9 kN
UCF210 Shaft d: 50 mm | Housing: F210 | Bearing: UC210 | Cr: 35.1 kN
UCF210C Shaft d: 50 mm | Base unit: UCF210 | Cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCF210D Shaft d: 50 mm | Base unit: UCF210 | Cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCF210FC Shaft d: 50 mm | Base unit: UCF210 | Cast iron cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCF210FD Shaft d: 50 mm | Base unit: UCF210 | Cast iron cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCFX10 Shaft d: 50 mm | Housing: FX10 | Bearing: UCX10 | Cr: 43.4 kN
UCFX10C Shaft d: 50 mm | Base unit: UCFX10 | Cover, open end | Bearing: UCX10 | Cr: 43.4 kN
UCFX10D Shaft d: 50 mm | Base unit: UCFX10 | Cover, closed end | Bearing: UCX10 | Cr: 43.4 kN
UCF310 Shaft d: 50 mm | Housing: F310 | Bearing: UC310 | Cr: 62.0 kN
UCF310C Shaft d: 50 mm | Base unit: UCF310 | Cover, open end | Bearing: UC310 | Cr: 62.0 kN
UCF310D Shaft d: 50 mm | Base unit: UCF310 | Cover, closed end | Bearing: UC310 | Cr: 62.0 kN
UCF211 Shaft d: 55 mm | Housing: F211 | Bearing: UC211 | Cr: 43.4 kN
UCF211C Shaft d: 55 mm | Base unit: UCF211 | Cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCF211D Shaft d: 55 mm | Base unit: UCF211 | Cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCF211FC Shaft d: 55 mm | Base unit: UCF211 | Cast iron cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCF211FD Shaft d: 55 mm | Base unit: UCF211 | Cast iron cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCFX11 Shaft d: 55 mm | Housing: FX11 | Bearing: UCX11 | Cr: 52.4 kN
UCFX11C Shaft d: 55 mm | Base unit: UCFX11 | Cover, open end | Bearing: UCX11 | Cr: 52.4 kN
UCFX11D Shaft d: 55 mm | Base unit: UCFX11 | Cover, closed end | Bearing: UCX11 | Cr: 52.4 kN
UCF311 Shaft d: 55 mm | Housing: F311 | Bearing: UC311 | Cr: 71.6 kN
UCF311C Shaft d: 55 mm | Base unit: UCF311 | Cover, open end | Bearing: UC311 | Cr: 71.6 kN
UCF311D Shaft d: 55 mm | Base unit: UCF311 | Cover, closed end | Bearing: UC311 | Cr: 71.6 kN
UCF212 Shaft d: 60 mm | Housing: F212 | Bearing: UC212 | Cr: 52.4 kN
UCF212C Shaft d: 60 mm | Base unit: UCF212 | Cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCF212D Shaft d: 60 mm | Base unit: UCF212 | Cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCF212FC Shaft d: 60 mm | Base unit: UCF212 | Cast iron cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCF212FD Shaft d: 60 mm | Base unit: UCF212 | Cast iron cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCFX12 Shaft d: 60 mm | Housing: FX12 | Bearing: UCX12 | Cr: 57.2 kN
UCFX12C Shaft d: 60 mm | Base unit: UCFX12 | Cover, open end | Bearing: UCX12 | Cr: 57.2 kN
UCFX12D Shaft d: 60 mm | Base unit: UCFX12 | Cover, closed end | Bearing: UCX12 | Cr: 57.2 kN
UCF312 Shaft d: 60 mm | Housing: F312 | Bearing: UC312 | Cr: 81.9 kN
UCF312C Shaft d: 60 mm | Base unit: UCF312 | Cover, open end | Bearing: UC312 | Cr: 81.9 kN
UCF312D Shaft d: 60 mm | Base unit: UCF312 | Cover, closed end | Bearing: UC312 | Cr: 81.9 kN
UCF213 Shaft d: 65 mm | Housing: F213 | Bearing: UC213 | Cr: 57.2 kN
UCF213C Shaft d: 65 mm | Base unit: UCF213 | Cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCF213D Shaft d: 65 mm | Base unit: UCF213 | Cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCF213FC Shaft d: 65 mm | Base unit: UCF213 | Cast iron cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCF213FD Shaft d: 65 mm | Base unit: UCF213 | Cast iron cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCFX13 Shaft d: 65 mm | Housing: FX13 | Bearing: UCX13 | Cr: 62.2 kN
UCFX13C Shaft d: 65 mm | Base unit: UCFX13 | Cover, open end | Bearing: UCX13 | Cr: 62.2 kN
UCFX13D Shaft d: 65 mm | Base unit: UCFX13 | Cover, closed end | Bearing: UCX13 | Cr: 62.2 kN
UCF313 Shaft d: 65 mm | Housing: F313 | Bearing: UC313 | Cr: 92.7 kN
UCF313C Shaft d: 65 mm | Base unit: UCF313 | Cover, open end | Bearing: UC313 | Cr: 92.7 kN
UCF313D Shaft d: 65 mm | Base unit: UCF313 | Cover, closed end | Bearing: UC313 | Cr: 92.7 kN
UCF214 Shaft d: 70 mm | Housing: F214 | Bearing: UC214 | Cr: 62.2 kN
UCF214C Shaft d: 70 mm | Base unit: UCF214 | Cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCF214D Shaft d: 70 mm | Base unit: UCF214 | Cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCF214FC Shaft d: 70 mm | Base unit: UCF214 | Cast iron cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCF214FD Shaft d: 70 mm | Base unit: UCF214 | Cast iron cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCFX14 Shaft d: 70 mm | Housing: FX14 | Bearing: UCX14 | Cr: 67.4 kN
UCFX14C Shaft d: 70 mm | Base unit: UCFX14 | Cover, open end | Bearing: UCX14 | Cr: 67.4 kN
UCFX14D Shaft d: 70 mm | Base unit: UCFX14 | Cover, closed end | Bearing: UCX14 | Cr: 67.4 kN
UCF314 Shaft d: 70 mm | Housing: F314 | Bearing: UC314 | Cr: 104 kN
UCF314C Shaft d: 70 mm | Base unit: UCF314 | Cover, open end | Bearing: UC314 | Cr: 104 kN
UCF314D Shaft d: 70 mm | Base unit: UCF314 | Cover, closed end | Bearing: UC314 | Cr: 104 kN
UCF215 Shaft d: 75 mm | Housing: F215 | Bearing: UC215 | Cr: 67.4 kN
UCF215C Shaft d: 75 mm | Base unit: UCF215 | Cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCF215D Shaft d: 75 mm | Base unit: UCF215 | Cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCF215FC Shaft d: 75 mm | Base unit: UCF215 | Cast iron cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCF215FD Shaft d: 75 mm | Base unit: UCF215 | Cast iron cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCFX15 Shaft d: 75 mm | Housing: FX15 | Bearing: UCX15 | Cr: 72.7 kN
UCFX15C Shaft d: 75 mm | Base unit: UCFX15 | Cover, open end | Bearing: UCX15 | Cr: 72.7 kN
UCFX15D Shaft d: 75 mm | Base unit: UCFX15 | Cover, closed end | Bearing: UCX15 | Cr: 72.7 kN
UCF315 Shaft d: 75 mm | Housing: F315 | Bearing: UC315 | Cr: 113 kN
UCF315C Shaft d: 75 mm | Base unit: UCF315 | Cover, open end | Bearing: UC315 | Cr: 113 kN
UCF315D Shaft d: 75 mm | Base unit: UCF315 | Cover, closed end | Bearing: UC315 | Cr: 113 kN
UCF216 Shaft d: 80 mm | Housing: F216 | Bearing: UC216 | Cr: 72.7 kN
UCF216C Shaft d: 80 mm | Base unit: UCF216 | Cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCF216D Shaft d: 80 mm | Base unit: UCF216 | Cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCF216FC Shaft d: 80 mm | Base unit: UCF216 | Cast iron cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCF216FD Shaft d: 80 mm | Base unit: UCF216 | Cast iron cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCFX16 Shaft d: 80 mm | Housing: FX16 | Bearing: UCX16 | Cr: 84.0 kN
UCFX16C Shaft d: 80 mm | Base unit: UCFX16 | Cover, open end | Bearing: UCX16 | Cr: 84.0 kN
UCFX16D Shaft d: 80 mm | Base unit: UCFX16 | Cover, closed end | Bearing: UCX16 | Cr: 84.0 kN
UCF316 Shaft d: 80 mm | Housing: F316 | Bearing: UC316 | Cr: 123 kN
UCF316C Shaft d: 80 mm | Base unit: UCF316 | Cover, open end | Bearing: UC316 | Cr: 123 kN
UCF316D Shaft d: 80 mm | Base unit: UCF316 | Cover, closed end | Bearing: UC316 | Cr: 123 kN
UCF217 Shaft d: 85 mm | Housing: F217 | Bearing: UC217 | Cr: 84.0 kN
UCF217C Shaft d: 85 mm | Base unit: UCF217 | Cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCF217D Shaft d: 85 mm | Base unit: UCF217 | Cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCF217FC Shaft d: 85 mm | Base unit: UCF217 | Cast iron cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCF217FD Shaft d: 85 mm | Base unit: UCF217 | Cast iron cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCFX17 Shaft d: 85 mm | Housing: FX17 | Bearing: UCX17 | Cr: 96.1 kN
UCFX17C Shaft d: 85 mm | Base unit: UCFX17 | Cover, open end | Bearing: UCX17 | Cr: 96.1 kN
UCFX17D Shaft d: 85 mm | Base unit: UCFX17 | Cover, closed end | Bearing: UCX17 | Cr: 96.1 kN
UCF317 Shaft d: 85 mm | Housing: F317 | Bearing: UC317 | Cr: 133 kN
UCF317C Shaft d: 85 mm | Base unit: UCF317 | Cover, open end | Bearing: UC317 | Cr: 133 kN
UCF317D Shaft d: 85 mm | Base unit: UCF317 | Cover, closed end | Bearing: UC317 | Cr: 133 kN
UCF218 Shaft d: 90 mm | Housing: F218 | Bearing: UC218 | Cr: 96.1 kN
UCF218C Shaft d: 90 mm | Base unit: UCF218 | Cover, open end | Bearing: UC218 | Cr: 96.1 kN
UCF218D Shaft d: 90 mm | Base unit: UCF218 | Cover, closed end | Bearing: UC218 | Cr: 96.1 kN
UCF218FC Shaft d: 90 mm | Base unit: UCF218 | Cast iron cover, open end | Bearing: UC218 | Cr: 96.1 kN
UCF218FD Shaft d: 90 mm | Base unit: UCF218 | Cast iron cover, closed end | Bearing: UC218 | Cr: 96.1 kN
UCFX18 Shaft d: 90 mm | Housing: FX18 | Bearing: UCX18 | Cr: 109 kN
UCFX18C Shaft d: 90 mm | Base unit: UCFX18 | Cover, open end | Bearing: UCX18 | Cr: 109 kN
UCFX18D Shaft d: 90 mm | Base unit: UCFX18 | Cover, closed end | Bearing: UCX18 | Cr: 109 kN
UCF318 Shaft d: 90 mm | Housing: F318 | Bearing: UC318 | Cr: 143 kN
UCF318C Shaft d: 90 mm | Base unit: UCF318 | Cover, open end | Bearing: UC318 | Cr: 143 kN
UCF318D Shaft d: 90 mm | Base unit: UCF318 | Cover, closed end | Bearing: UC318 | Cr: 143 kN
UCF319 Shaft d: 95 mm | Housing: F319 | Bearing: UC319 | Cr: 153 kN
UCF319C Shaft d: 95 mm | Base unit: UCF319 | Cover, open end | Bearing: UC319 | Cr: 153 kN
UCF319D Shaft d: 95 mm | Base unit: UCF319 | Cover, closed end | Bearing: UC319 | Cr: 153 kN
UCFX20 Shaft d: 100 mm | Housing: FX20 | Bearing: UCX20 | Cr: 133 kN
UCFX20C Shaft d: 100 mm | Base unit: UCFX20 | Cover, open end | Bearing: UCX20 | Cr: 133 kN
UCFX20D Shaft d: 100 mm | Base unit: UCFX20 | Cover, closed end | Bearing: UCX20 | Cr: 133 kN
UCF320 Shaft d: 100 mm | Housing: F320 | Bearing: UC320 | Cr: 173 kN
UCF320C Shaft d: 100 mm | Base unit: UCF320 | Cover, open end | Bearing: UC320 | Cr: 173 kN
UCF320D Shaft d: 100 mm | Base unit: UCF320 | Cover, closed end | Bearing: UC320 | Cr: 173 kN
UCF321 Shaft d: 105 mm | Housing: F321 | Bearing: UC321 | Cr: 184 kN
UCF321C Shaft d: 105 mm | Base unit: UCF321 | Cover, open end | Bearing: UC321 | Cr: 184 kN
UCF321D Shaft d: 105 mm | Base unit: UCF321 | Cover, closed end | Bearing: UC321 | Cr: 184 kN
UCF322 Shaft d: 110 mm | Housing: F322 | Bearing: UC322 | Cr: 205 kN
UCF322C Shaft d: 110 mm | Base unit: UCF322 | Cover, open end | Bearing: UC322 | Cr: 205 kN
UCF322D Shaft d: 110 mm | Base unit: UCF322 | Cover, closed end | Bearing: UC322 | Cr: 205 kN
UCF324 Shaft d: 120 mm | Housing: F324 | Bearing: UC324 | Cr: 207 kN
UCF324C Shaft d: 120 mm | Base unit: UCF324 | Cover, open end | Bearing: UC324 | Cr: 207 kN
UCF324D Shaft d: 120 mm | Base unit: UCF324 | Cover, closed end | Bearing: UC324 | Cr: 207 kN
UCF326 Shaft d: 130 mm | Housing: F326 | Bearing: UC326 | Cr: 229 kN
UCF326C Shaft d: 130 mm | Base unit: UCF326 | Cover, open end | Bearing: UC326 | Cr: 229 kN
UCF326D Shaft d: 130 mm | Base unit: UCF326 | Cover, closed end | Bearing: UC326 | Cr: 229 kN
UCF328 Shaft d: 140 mm | Housing: F328 | Bearing: UC328 | Cr: 253 kN
UCF328C Shaft d: 140 mm | Base unit: UCF328 | Cover, open end | Bearing: UC328 | Cr: 253 kN
UCF328D Shaft d: 140 mm | Base unit: UCF328 | Cover, closed end | Bearing: UC328 | Cr: 253 kN
Mounted Bearing UnitsKOYO
192 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO UCF Square Flanged Units

Brand KOYO·Mounted Bearing Units

Available part numbers (192)

UCF201, UCF201C, UCF201D, UCF202, UCF202C, UCF202D, UCF203, UCF203C, UCF203D, UCF204 + 182 more — see full table ↓

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UCF201Shaft d: 12 mm | Housing: F204 | Bearing: UC201 | Cr: 12.8 kN
UCF201CShaft d: 12 mm | Base unit: UCF201 | Cover, open end | Bearing: UC201 | Cr: 12.8 kN
UCF201DShaft d: 12 mm | Base unit: UCF201 | Cover, closed end | Bearing: UC201 | Cr: 12.8 kN
UCF202Shaft d: 15 mm | Housing: F204 | Bearing: UC202 | Cr: 12.8 kN
UCF202CShaft d: 15 mm | Base unit: UCF202 | Cover, open end | Bearing: UC202 | Cr: 12.8 kN
UCF202DShaft d: 15 mm | Base unit: UCF202 | Cover, closed end | Bearing: UC202 | Cr: 12.8 kN
UCF203Shaft d: 17 mm | Housing: F204 | Bearing: UC203 | Cr: 12.8 kN
UCF203CShaft d: 17 mm | Base unit: UCF203 | Cover, open end | Bearing: UC203 | Cr: 12.8 kN
UCF203DShaft d: 17 mm | Base unit: UCF203 | Cover, closed end | Bearing: UC203 | Cr: 12.8 kN
UCF204Shaft d: 20 mm | Housing: F204 | Bearing: UC204 | Cr: 12.8 kN
UCF204CShaft d: 20 mm | Base unit: UCF204 | Cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCF204DShaft d: 20 mm | Base unit: UCF204 | Cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCF204FCShaft d: 20 mm | Base unit: UCF204 | Cast iron cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCF204FDShaft d: 20 mm | Base unit: UCF204 | Cast iron cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCF205Shaft d: 25 mm | Housing: F205 | Bearing: UC205 | Cr: 14.0 kN
UCF205CShaft d: 25 mm | Base unit: UCF205 | Cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCF205DShaft d: 25 mm | Base unit: UCF205 | Cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCF205FCShaft d: 25 mm | Base unit: UCF205 | Cast iron cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCF205FDShaft d: 25 mm | Base unit: UCF205 | Cast iron cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCFX05Shaft d: 25 mm | Housing: FX05 | Bearing: UCX05 | Cr: 19.5 kN
UCFX05CShaft d: 25 mm | Base unit: UCFX05 | Cover, open end | Bearing: UCX05 | Cr: 19.5 kN
UCFX05DShaft d: 25 mm | Base unit: UCFX05 | Cover, closed end | Bearing: UCX05 | Cr: 19.5 kN
UCF305Shaft d: 25 mm | Housing: F305 | Bearing: UC305 | Cr: 21.2 kN
UCF305CShaft d: 25 mm | Base unit: UCF305 | Cover, open end | Bearing: UC305 | Cr: 21.2 kN
UCF305DShaft d: 25 mm | Base unit: UCF305 | Cover, closed end | Bearing: UC305 | Cr: 21.2 kN
UCF206Shaft d: 30 mm | Housing: F206 | Bearing: UC206 | Cr: 19.5 kN
UCF206CShaft d: 30 mm | Base unit: UCF206 | Cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCF206DShaft d: 30 mm | Base unit: UCF206 | Cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCF206FCShaft d: 30 mm | Base unit: UCF206 | Cast iron cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCF206FDShaft d: 30 mm | Base unit: UCF206 | Cast iron cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCFX06Shaft d: 30 mm | Housing: FX06 | Bearing: UCX06 | Cr: 25.7 kN
UCFX06CShaft d: 30 mm | Base unit: UCFX06 | Cover, open end | Bearing: UCX06 | Cr: 25.7 kN
UCFX06DShaft d: 30 mm | Base unit: UCFX06 | Cover, closed end | Bearing: UCX06 | Cr: 25.7 kN
UCF306Shaft d: 30 mm | Housing: F306 | Bearing: UC306 | Cr: 26.7 kN
UCF306CShaft d: 30 mm | Base unit: UCF306 | Cover, open end | Bearing: UC306 | Cr: 26.7 kN
UCF306DShaft d: 30 mm | Base unit: UCF306 | Cover, closed end | Bearing: UC306 | Cr: 26.7 kN
UCF207Shaft d: 35 mm | Housing: F207 | Bearing: UC207 | Cr: 25.7 kN
UCF207CShaft d: 35 mm | Base unit: UCF207 | Cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCF207DShaft d: 35 mm | Base unit: UCF207 | Cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCF207FCShaft d: 35 mm | Base unit: UCF207 | Cast iron cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCF207FDShaft d: 35 mm | Base unit: UCF207 | Cast iron cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCFX07Shaft d: 35 mm | Housing: FX07 | Bearing: UCX07 | Cr: 29.1 kN
UCFX07CShaft d: 35 mm | Base unit: UCFX07 | Cover, open end | Bearing: UCX07 | Cr: 29.1 kN
UCFX07DShaft d: 35 mm | Base unit: UCFX07 | Cover, closed end | Bearing: UCX07 | Cr: 29.1 kN
UCF307Shaft d: 35 mm | Housing: F307 | Bearing: UC307 | Cr: 33.4 kN
UCF307CShaft d: 35 mm | Base unit: UCF307 | Cover, open end | Bearing: UC307 | Cr: 33.4 kN
UCF307DShaft d: 35 mm | Base unit: UCF307 | Cover, closed end | Bearing: UC307 | Cr: 33.4 kN
UCF208Shaft d: 40 mm | Housing: F208 | Bearing: UC208 | Cr: 29.1 kN
UCF208CShaft d: 40 mm | Base unit: UCF208 | Cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCF208DShaft d: 40 mm | Base unit: UCF208 | Cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCF208FCShaft d: 40 mm | Base unit: UCF208 | Cast iron cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCF208FDShaft d: 40 mm | Base unit: UCF208 | Cast iron cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCFX08Shaft d: 40 mm | Housing: FX08 | Bearing: UCX08 | Cr: 32.7 kN
UCFX08CShaft d: 40 mm | Base unit: UCFX08 | Cover, open end | Bearing: UCX08 | Cr: 32.7 kN
UCFX08DShaft d: 40 mm | Base unit: UCFX08 | Cover, closed end | Bearing: UCX08 | Cr: 32.7 kN
UCF308Shaft d: 40 mm | Housing: F308 | Bearing: UC308 | Cr: 40.7 kN
UCF308CShaft d: 40 mm | Base unit: UCF308 | Cover, open end | Bearing: UC308 | Cr: 40.7 kN
UCF308DShaft d: 40 mm | Base unit: UCF308 | Cover, closed end | Bearing: UC308 | Cr: 40.7 kN
UCF209Shaft d: 45 mm | Housing: F209 | Bearing: UC209 | Cr: 32.7 kN
UCF209CShaft d: 45 mm | Base unit: UCF209 | Cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCF209DShaft d: 45 mm | Base unit: UCF209 | Cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCF209FCShaft d: 45 mm | Base unit: UCF209 | Cast iron cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCF209FDShaft d: 45 mm | Base unit: UCF209 | Cast iron cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCFX09Shaft d: 45 mm | Housing: FX09 | Bearing: UCX09 | Cr: 35.1 kN
UCFX09CShaft d: 45 mm | Base unit: UCFX09 | Cover, open end | Bearing: UCX09 | Cr: 35.1 kN
UCFX09DShaft d: 45 mm | Base unit: UCFX09 | Cover, closed end | Bearing: UCX09 | Cr: 35.1 kN
UCF309Shaft d: 45 mm | Housing: F309 | Bearing: UC309 | Cr: 48.9 kN
UCF309CShaft d: 45 mm | Base unit: UCF309 | Cover, open end | Bearing: UC309 | Cr: 48.9 kN
UCF309DShaft d: 45 mm | Base unit: UCF309 | Cover, closed end | Bearing: UC309 | Cr: 48.9 kN
UCF210Shaft d: 50 mm | Housing: F210 | Bearing: UC210 | Cr: 35.1 kN
UCF210CShaft d: 50 mm | Base unit: UCF210 | Cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCF210DShaft d: 50 mm | Base unit: UCF210 | Cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCF210FCShaft d: 50 mm | Base unit: UCF210 | Cast iron cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCF210FDShaft d: 50 mm | Base unit: UCF210 | Cast iron cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCFX10Shaft d: 50 mm | Housing: FX10 | Bearing: UCX10 | Cr: 43.4 kN
UCFX10CShaft d: 50 mm | Base unit: UCFX10 | Cover, open end | Bearing: UCX10 | Cr: 43.4 kN
UCFX10DShaft d: 50 mm | Base unit: UCFX10 | Cover, closed end | Bearing: UCX10 | Cr: 43.4 kN
UCF310Shaft d: 50 mm | Housing: F310 | Bearing: UC310 | Cr: 62.0 kN
UCF310CShaft d: 50 mm | Base unit: UCF310 | Cover, open end | Bearing: UC310 | Cr: 62.0 kN
UCF310DShaft d: 50 mm | Base unit: UCF310 | Cover, closed end | Bearing: UC310 | Cr: 62.0 kN
UCF211Shaft d: 55 mm | Housing: F211 | Bearing: UC211 | Cr: 43.4 kN
UCF211CShaft d: 55 mm | Base unit: UCF211 | Cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCF211DShaft d: 55 mm | Base unit: UCF211 | Cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCF211FCShaft d: 55 mm | Base unit: UCF211 | Cast iron cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCF211FDShaft d: 55 mm | Base unit: UCF211 | Cast iron cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCFX11Shaft d: 55 mm | Housing: FX11 | Bearing: UCX11 | Cr: 52.4 kN
UCFX11CShaft d: 55 mm | Base unit: UCFX11 | Cover, open end | Bearing: UCX11 | Cr: 52.4 kN
UCFX11DShaft d: 55 mm | Base unit: UCFX11 | Cover, closed end | Bearing: UCX11 | Cr: 52.4 kN
UCF311Shaft d: 55 mm | Housing: F311 | Bearing: UC311 | Cr: 71.6 kN
UCF311CShaft d: 55 mm | Base unit: UCF311 | Cover, open end | Bearing: UC311 | Cr: 71.6 kN
UCF311DShaft d: 55 mm | Base unit: UCF311 | Cover, closed end | Bearing: UC311 | Cr: 71.6 kN
UCF212Shaft d: 60 mm | Housing: F212 | Bearing: UC212 | Cr: 52.4 kN
UCF212CShaft d: 60 mm | Base unit: UCF212 | Cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCF212DShaft d: 60 mm | Base unit: UCF212 | Cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCF212FCShaft d: 60 mm | Base unit: UCF212 | Cast iron cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCF212FDShaft d: 60 mm | Base unit: UCF212 | Cast iron cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCFX12Shaft d: 60 mm | Housing: FX12 | Bearing: UCX12 | Cr: 57.2 kN
UCFX12CShaft d: 60 mm | Base unit: UCFX12 | Cover, open end | Bearing: UCX12 | Cr: 57.2 kN
UCFX12DShaft d: 60 mm | Base unit: UCFX12 | Cover, closed end | Bearing: UCX12 | Cr: 57.2 kN
UCF312Shaft d: 60 mm | Housing: F312 | Bearing: UC312 | Cr: 81.9 kN
UCF312CShaft d: 60 mm | Base unit: UCF312 | Cover, open end | Bearing: UC312 | Cr: 81.9 kN
UCF312DShaft d: 60 mm | Base unit: UCF312 | Cover, closed end | Bearing: UC312 | Cr: 81.9 kN
UCF213Shaft d: 65 mm | Housing: F213 | Bearing: UC213 | Cr: 57.2 kN
UCF213CShaft d: 65 mm | Base unit: UCF213 | Cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCF213DShaft d: 65 mm | Base unit: UCF213 | Cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCF213FCShaft d: 65 mm | Base unit: UCF213 | Cast iron cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCF213FDShaft d: 65 mm | Base unit: UCF213 | Cast iron cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCFX13Shaft d: 65 mm | Housing: FX13 | Bearing: UCX13 | Cr: 62.2 kN
UCFX13CShaft d: 65 mm | Base unit: UCFX13 | Cover, open end | Bearing: UCX13 | Cr: 62.2 kN
UCFX13DShaft d: 65 mm | Base unit: UCFX13 | Cover, closed end | Bearing: UCX13 | Cr: 62.2 kN
UCF313Shaft d: 65 mm | Housing: F313 | Bearing: UC313 | Cr: 92.7 kN
UCF313CShaft d: 65 mm | Base unit: UCF313 | Cover, open end | Bearing: UC313 | Cr: 92.7 kN
UCF313DShaft d: 65 mm | Base unit: UCF313 | Cover, closed end | Bearing: UC313 | Cr: 92.7 kN
UCF214Shaft d: 70 mm | Housing: F214 | Bearing: UC214 | Cr: 62.2 kN
UCF214CShaft d: 70 mm | Base unit: UCF214 | Cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCF214DShaft d: 70 mm | Base unit: UCF214 | Cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCF214FCShaft d: 70 mm | Base unit: UCF214 | Cast iron cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCF214FDShaft d: 70 mm | Base unit: UCF214 | Cast iron cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCFX14Shaft d: 70 mm | Housing: FX14 | Bearing: UCX14 | Cr: 67.4 kN
UCFX14CShaft d: 70 mm | Base unit: UCFX14 | Cover, open end | Bearing: UCX14 | Cr: 67.4 kN
UCFX14DShaft d: 70 mm | Base unit: UCFX14 | Cover, closed end | Bearing: UCX14 | Cr: 67.4 kN
UCF314Shaft d: 70 mm | Housing: F314 | Bearing: UC314 | Cr: 104 kN
UCF314CShaft d: 70 mm | Base unit: UCF314 | Cover, open end | Bearing: UC314 | Cr: 104 kN
UCF314DShaft d: 70 mm | Base unit: UCF314 | Cover, closed end | Bearing: UC314 | Cr: 104 kN
UCF215Shaft d: 75 mm | Housing: F215 | Bearing: UC215 | Cr: 67.4 kN
UCF215CShaft d: 75 mm | Base unit: UCF215 | Cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCF215DShaft d: 75 mm | Base unit: UCF215 | Cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCF215FCShaft d: 75 mm | Base unit: UCF215 | Cast iron cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCF215FDShaft d: 75 mm | Base unit: UCF215 | Cast iron cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCFX15Shaft d: 75 mm | Housing: FX15 | Bearing: UCX15 | Cr: 72.7 kN
UCFX15CShaft d: 75 mm | Base unit: UCFX15 | Cover, open end | Bearing: UCX15 | Cr: 72.7 kN
UCFX15DShaft d: 75 mm | Base unit: UCFX15 | Cover, closed end | Bearing: UCX15 | Cr: 72.7 kN
UCF315Shaft d: 75 mm | Housing: F315 | Bearing: UC315 | Cr: 113 kN
UCF315CShaft d: 75 mm | Base unit: UCF315 | Cover, open end | Bearing: UC315 | Cr: 113 kN
UCF315DShaft d: 75 mm | Base unit: UCF315 | Cover, closed end | Bearing: UC315 | Cr: 113 kN
UCF216Shaft d: 80 mm | Housing: F216 | Bearing: UC216 | Cr: 72.7 kN
UCF216CShaft d: 80 mm | Base unit: UCF216 | Cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCF216DShaft d: 80 mm | Base unit: UCF216 | Cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCF216FCShaft d: 80 mm | Base unit: UCF216 | Cast iron cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCF216FDShaft d: 80 mm | Base unit: UCF216 | Cast iron cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCFX16Shaft d: 80 mm | Housing: FX16 | Bearing: UCX16 | Cr: 84.0 kN
UCFX16CShaft d: 80 mm | Base unit: UCFX16 | Cover, open end | Bearing: UCX16 | Cr: 84.0 kN
UCFX16DShaft d: 80 mm | Base unit: UCFX16 | Cover, closed end | Bearing: UCX16 | Cr: 84.0 kN
UCF316Shaft d: 80 mm | Housing: F316 | Bearing: UC316 | Cr: 123 kN
UCF316CShaft d: 80 mm | Base unit: UCF316 | Cover, open end | Bearing: UC316 | Cr: 123 kN
UCF316DShaft d: 80 mm | Base unit: UCF316 | Cover, closed end | Bearing: UC316 | Cr: 123 kN
UCF217Shaft d: 85 mm | Housing: F217 | Bearing: UC217 | Cr: 84.0 kN
UCF217CShaft d: 85 mm | Base unit: UCF217 | Cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCF217DShaft d: 85 mm | Base unit: UCF217 | Cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCF217FCShaft d: 85 mm | Base unit: UCF217 | Cast iron cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCF217FDShaft d: 85 mm | Base unit: UCF217 | Cast iron cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCFX17Shaft d: 85 mm | Housing: FX17 | Bearing: UCX17 | Cr: 96.1 kN
UCFX17CShaft d: 85 mm | Base unit: UCFX17 | Cover, open end | Bearing: UCX17 | Cr: 96.1 kN
UCFX17DShaft d: 85 mm | Base unit: UCFX17 | Cover, closed end | Bearing: UCX17 | Cr: 96.1 kN
UCF317Shaft d: 85 mm | Housing: F317 | Bearing: UC317 | Cr: 133 kN
UCF317CShaft d: 85 mm | Base unit: UCF317 | Cover, open end | Bearing: UC317 | Cr: 133 kN
UCF317DShaft d: 85 mm | Base unit: UCF317 | Cover, closed end | Bearing: UC317 | Cr: 133 kN
UCF218Shaft d: 90 mm | Housing: F218 | Bearing: UC218 | Cr: 96.1 kN
UCF218CShaft d: 90 mm | Base unit: UCF218 | Cover, open end | Bearing: UC218 | Cr: 96.1 kN
UCF218DShaft d: 90 mm | Base unit: UCF218 | Cover, closed end | Bearing: UC218 | Cr: 96.1 kN
UCF218FCShaft d: 90 mm | Base unit: UCF218 | Cast iron cover, open end | Bearing: UC218 | Cr: 96.1 kN
UCF218FDShaft d: 90 mm | Base unit: UCF218 | Cast iron cover, closed end | Bearing: UC218 | Cr: 96.1 kN
UCFX18Shaft d: 90 mm | Housing: FX18 | Bearing: UCX18 | Cr: 109 kN
UCFX18CShaft d: 90 mm | Base unit: UCFX18 | Cover, open end | Bearing: UCX18 | Cr: 109 kN
UCFX18DShaft d: 90 mm | Base unit: UCFX18 | Cover, closed end | Bearing: UCX18 | Cr: 109 kN
UCF318Shaft d: 90 mm | Housing: F318 | Bearing: UC318 | Cr: 143 kN
UCF318CShaft d: 90 mm | Base unit: UCF318 | Cover, open end | Bearing: UC318 | Cr: 143 kN
UCF318DShaft d: 90 mm | Base unit: UCF318 | Cover, closed end | Bearing: UC318 | Cr: 143 kN
UCF319Shaft d: 95 mm | Housing: F319 | Bearing: UC319 | Cr: 153 kN
UCF319CShaft d: 95 mm | Base unit: UCF319 | Cover, open end | Bearing: UC319 | Cr: 153 kN
UCF319DShaft d: 95 mm | Base unit: UCF319 | Cover, closed end | Bearing: UC319 | Cr: 153 kN
UCFX20Shaft d: 100 mm | Housing: FX20 | Bearing: UCX20 | Cr: 133 kN
UCFX20CShaft d: 100 mm | Base unit: UCFX20 | Cover, open end | Bearing: UCX20 | Cr: 133 kN
UCFX20DShaft d: 100 mm | Base unit: UCFX20 | Cover, closed end | Bearing: UCX20 | Cr: 133 kN
UCF320Shaft d: 100 mm | Housing: F320 | Bearing: UC320 | Cr: 173 kN
UCF320CShaft d: 100 mm | Base unit: UCF320 | Cover, open end | Bearing: UC320 | Cr: 173 kN
UCF320DShaft d: 100 mm | Base unit: UCF320 | Cover, closed end | Bearing: UC320 | Cr: 173 kN
UCF321Shaft d: 105 mm | Housing: F321 | Bearing: UC321 | Cr: 184 kN
UCF321CShaft d: 105 mm | Base unit: UCF321 | Cover, open end | Bearing: UC321 | Cr: 184 kN
UCF321DShaft d: 105 mm | Base unit: UCF321 | Cover, closed end | Bearing: UC321 | Cr: 184 kN
UCF322Shaft d: 110 mm | Housing: F322 | Bearing: UC322 | Cr: 205 kN
UCF322CShaft d: 110 mm | Base unit: UCF322 | Cover, open end | Bearing: UC322 | Cr: 205 kN
UCF322DShaft d: 110 mm | Base unit: UCF322 | Cover, closed end | Bearing: UC322 | Cr: 205 kN
UCF324Shaft d: 120 mm | Housing: F324 | Bearing: UC324 | Cr: 207 kN
UCF324CShaft d: 120 mm | Base unit: UCF324 | Cover, open end | Bearing: UC324 | Cr: 207 kN
UCF324DShaft d: 120 mm | Base unit: UCF324 | Cover, closed end | Bearing: UC324 | Cr: 207 kN
UCF326Shaft d: 130 mm | Housing: F326 | Bearing: UC326 | Cr: 229 kN
UCF326CShaft d: 130 mm | Base unit: UCF326 | Cover, open end | Bearing: UC326 | Cr: 229 kN
UCF326DShaft d: 130 mm | Base unit: UCF326 | Cover, closed end | Bearing: UC326 | Cr: 229 kN
UCF328Shaft d: 140 mm | Housing: F328 | Bearing: UC328 | Cr: 253 kN
UCF328CShaft d: 140 mm | Base unit: UCF328 | Cover, open end | Bearing: UC328 | Cr: 253 kN
UCF328DShaft d: 140 mm | Base unit: UCF328 | Cover, closed end | Bearing: UC328 | Cr: 253 kN

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
