KOYO UCFL Rhombic (2-Bolt) Flanged Units

KOYO UCFL Rhombic (2-Bolt) Flanged Units

Cast iron 2-bolt rhombic flanged units with UC/UCX insert bearings and set screw locking, with optional covers.

Key features

  • Pre-lubricated sealed ball bearing insert
  • Spherical seating compensates for shaft misalignment
  • Housing and insert replaceable separately
  • Unit number, housing number and insert bearing listed
  • Shaft diameter given in mm

Specifications

Product type Ball bearing unit
Series UCFL Rhombic Flange Units
Seal Insert bearing sealed both sides
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B500-B503
UCFL201 Shaft d: 12 mm | Housing: FL204 | Bearing: UC201 | Cr: 12.8 kN
UCFL201C Shaft d: 12 mm | Base unit: UCFL201 | Cover, open end | Bearing: UC201 | Cr: 12.8 kN
UCFL201D Shaft d: 12 mm | Base unit: UCFL201 | Cover, closed end | Bearing: UC201 | Cr: 12.8 kN
UCFL202 Shaft d: 15 mm | Housing: FL204 | Bearing: UC202 | Cr: 12.8 kN
UCFL202C Shaft d: 15 mm | Base unit: UCFL202 | Cover, open end | Bearing: UC202 | Cr: 12.8 kN
UCFL202D Shaft d: 15 mm | Base unit: UCFL202 | Cover, closed end | Bearing: UC202 | Cr: 12.8 kN
UCFL203 Shaft d: 17 mm | Housing: FL204 | Bearing: UC203 | Cr: 12.8 kN
UCFL203C Shaft d: 17 mm | Base unit: UCFL203 | Cover, open end | Bearing: UC203 | Cr: 12.8 kN
UCFL203D Shaft d: 17 mm | Base unit: UCFL203 | Cover, closed end | Bearing: UC203 | Cr: 12.8 kN
UCFL204 Shaft d: 20 mm | Housing: FL204 | Bearing: UC204 | Cr: 12.8 kN
UCFL204C Shaft d: 20 mm | Base unit: UCFL204 | Cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCFL204D Shaft d: 20 mm | Base unit: UCFL204 | Cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCFL204FC Shaft d: 20 mm | Base unit: UCFL204 | Cast iron cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCFL204FD Shaft d: 20 mm | Base unit: UCFL204 | Cast iron cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCFL205 Shaft d: 25 mm | Housing: FL205 | Bearing: UC205 | Cr: 14.0 kN
UCFL205C Shaft d: 25 mm | Base unit: UCFL205 | Cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCFL205D Shaft d: 25 mm | Base unit: UCFL205 | Cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCFL205FC Shaft d: 25 mm | Base unit: UCFL205 | Cast iron cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCFL205FD Shaft d: 25 mm | Base unit: UCFL205 | Cast iron cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCFLX05 Shaft d: 25 mm | Housing: FLX05 | Bearing: UCX05 | Cr: 19.5 kN
UCFLX05C Shaft d: 25 mm | Base unit: UCFLX05 | Cover, open end | Bearing: UCX05 | Cr: 19.5 kN
UCFLX05D Shaft d: 25 mm | Base unit: UCFLX05 | Cover, closed end | Bearing: UCX05 | Cr: 19.5 kN
UCFL305 Shaft d: 25 mm | Housing: FL305 | Bearing: UC305 | Cr: 21.2 kN
UCFL305C Shaft d: 25 mm | Base unit: UCFL305 | Cover, open end | Bearing: UC305 | Cr: 21.2 kN
UCFL305D Shaft d: 25 mm | Base unit: UCFL305 | Cover, closed end | Bearing: UC305 | Cr: 21.2 kN
UCFL206 Shaft d: 30 mm | Housing: FL206 | Bearing: UC206 | Cr: 19.5 kN
UCFL206C Shaft d: 30 mm | Base unit: UCFL206 | Cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCFL206D Shaft d: 30 mm | Base unit: UCFL206 | Cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCFL206FC Shaft d: 30 mm | Base unit: UCFL206 | Cast iron cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCFL206FD Shaft d: 30 mm | Base unit: UCFL206 | Cast iron cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCFLX06 Shaft d: 30 mm | Housing: FLX06 | Bearing: UCX06 | Cr: 25.7 kN
UCFLX06C Shaft d: 30 mm | Base unit: UCFLX06 | Cover, open end | Bearing: UCX06 | Cr: 25.7 kN
UCFLX06D Shaft d: 30 mm | Base unit: UCFLX06 | Cover, closed end | Bearing: UCX06 | Cr: 25.7 kN
UCFL306 Shaft d: 30 mm | Housing: FL306 | Bearing: UC306 | Cr: 26.7 kN
UCFL306C Shaft d: 30 mm | Base unit: UCFL306 | Cover, open end | Bearing: UC306 | Cr: 26.7 kN
UCFL306D Shaft d: 30 mm | Base unit: UCFL306 | Cover, closed end | Bearing: UC306 | Cr: 26.7 kN
UCFL207 Shaft d: 35 mm | Housing: FL207 | Bearing: UC207 | Cr: 25.7 kN
UCFL207C Shaft d: 35 mm | Base unit: UCFL207 | Cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCFL207D Shaft d: 35 mm | Base unit: UCFL207 | Cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCFL207FC Shaft d: 35 mm | Base unit: UCFL207 | Cast iron cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCFL207FD Shaft d: 35 mm | Base unit: UCFL207 | Cast iron cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCFLX07 Shaft d: 35 mm | Housing: FLX07 | Bearing: UCX07 | Cr: 29.1 kN
UCFLX07C Shaft d: 35 mm | Base unit: UCFLX07 | Cover, open end | Bearing: UCX07 | Cr: 29.1 kN
UCFLX07D Shaft d: 35 mm | Base unit: UCFLX07 | Cover, closed end | Bearing: UCX07 | Cr: 29.1 kN
UCFL307 Shaft d: 35 mm | Housing: FL307 | Bearing: UC307 | Cr: 33.4 kN
UCFL307C Shaft d: 35 mm | Base unit: UCFL307 | Cover, open end | Bearing: UC307 | Cr: 33.4 kN
UCFL307D Shaft d: 35 mm | Base unit: UCFL307 | Cover, closed end | Bearing: UC307 | Cr: 33.4 kN
UCFL208 Shaft d: 40 mm | Housing: FL208 | Bearing: UC208 | Cr: 29.1 kN
UCFL208C Shaft d: 40 mm | Base unit: UCFL208 | Cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCFL208D Shaft d: 40 mm | Base unit: UCFL208 | Cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCFL208FC Shaft d: 40 mm | Base unit: UCFL208 | Cast iron cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCFL208FD Shaft d: 40 mm | Base unit: UCFL208 | Cast iron cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCFLX08 Shaft d: 40 mm | Housing: FLX08 | Bearing: UCX08 | Cr: 32.7 kN
UCFLX08C Shaft d: 40 mm | Base unit: UCFLX08 | Cover, open end | Bearing: UCX08 | Cr: 32.7 kN
UCFLX08D Shaft d: 40 mm | Base unit: UCFLX08 | Cover, closed end | Bearing: UCX08 | Cr: 32.7 kN
UCFL308 Shaft d: 40 mm | Housing: FL308 | Bearing: UC308 | Cr: 40.7 kN
UCFL308C Shaft d: 40 mm | Base unit: UCFL308 | Cover, open end | Bearing: UC308 | Cr: 40.7 kN
UCFL308D Shaft d: 40 mm | Base unit: UCFL308 | Cover, closed end | Bearing: UC308 | Cr: 40.7 kN
UCFL209 Shaft d: 45 mm | Housing: FL209 | Bearing: UC209 | Cr: 32.7 kN
UCFL209C Shaft d: 45 mm | Base unit: UCFL209 | Cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCFL209D Shaft d: 45 mm | Base unit: UCFL209 | Cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCFL209FC Shaft d: 45 mm | Base unit: UCFL209 | Cast iron cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCFL209FD Shaft d: 45 mm | Base unit: UCFL209 | Cast iron cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCFLX09 Shaft d: 45 mm | Housing: FLX09 | Bearing: UCX09 | Cr: 35.1 kN
UCFLX09C Shaft d: 45 mm | Base unit: UCFLX09 | Cover, open end | Bearing: UCX09 | Cr: 35.1 kN
UCFLX09D Shaft d: 45 mm | Base unit: UCFLX09 | Cover, closed end | Bearing: UCX09 | Cr: 35.1 kN
UCFL309 Shaft d: 45 mm | Housing: FL309 | Bearing: UC309 | Cr: 48.9 kN
UCFL309C Shaft d: 45 mm | Base unit: UCFL309 | Cover, open end | Bearing: UC309 | Cr: 48.9 kN
UCFL309D Shaft d: 45 mm | Base unit: UCFL309 | Cover, closed end | Bearing: UC309 | Cr: 48.9 kN
UCFL210 Shaft d: 50 mm | Housing: FL210 | Bearing: UC210 | Cr: 35.1 kN
UCFL210C Shaft d: 50 mm | Base unit: UCFL210 | Cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCFL210D Shaft d: 50 mm | Base unit: UCFL210 | Cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCFL210FC Shaft d: 50 mm | Base unit: UCFL210 | Cast iron cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCFL210FD Shaft d: 50 mm | Base unit: UCFL210 | Cast iron cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCFLX10 Shaft d: 50 mm | Housing: FLX10 | Bearing: UCX10 | Cr: 43.4 kN
UCFLX10C Shaft d: 50 mm | Base unit: UCFLX10 | Cover, open end | Bearing: UCX10 | Cr: 43.4 kN
UCFLX10D Shaft d: 50 mm | Base unit: UCFLX10 | Cover, closed end | Bearing: UCX10 | Cr: 43.4 kN
UCFL310 Shaft d: 50 mm | Housing: FL310 | Bearing: UC310 | Cr: 62.0 kN
UCFL310C Shaft d: 50 mm | Base unit: UCFL310 | Cover, open end | Bearing: UC310 | Cr: 62.0 kN
UCFL310D Shaft d: 50 mm | Base unit: UCFL310 | Cover, closed end | Bearing: UC310 | Cr: 62.0 kN
UCFL211 Shaft d: 55 mm | Housing: FL211 | Bearing: UC211 | Cr: 43.4 kN
UCFL211C Shaft d: 55 mm | Base unit: UCFL211 | Cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCFL211D Shaft d: 55 mm | Base unit: UCFL211 | Cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCFL211FC Shaft d: 55 mm | Base unit: UCFL211 | Cast iron cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCFL211FD Shaft d: 55 mm | Base unit: UCFL211 | Cast iron cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCFL311 Shaft d: 55 mm | Housing: FL311 | Bearing: UC311 | Cr: 71.6 kN
UCFL311C Shaft d: 55 mm | Base unit: UCFL311 | Cover, open end | Bearing: UC311 | Cr: 71.6 kN
UCFL311D Shaft d: 55 mm | Base unit: UCFL311 | Cover, closed end | Bearing: UC311 | Cr: 71.6 kN
UCFL212 Shaft d: 60 mm | Housing: FL212 | Bearing: UC212 | Cr: 52.4 kN
UCFL212C Shaft d: 60 mm | Base unit: UCFL212 | Cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCFL212D Shaft d: 60 mm | Base unit: UCFL212 | Cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCFL212FC Shaft d: 60 mm | Base unit: UCFL212 | Cast iron cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCFL212FD Shaft d: 60 mm | Base unit: UCFL212 | Cast iron cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCFL312 Shaft d: 60 mm | Housing: FL312 | Bearing: UC312 | Cr: 81.9 kN
UCFL312C Shaft d: 60 mm | Base unit: UCFL312 | Cover, open end | Bearing: UC312 | Cr: 81.9 kN
UCFL312D Shaft d: 60 mm | Base unit: UCFL312 | Cover, closed end | Bearing: UC312 | Cr: 81.9 kN
UCFL213 Shaft d: 65 mm | Housing: FL213 | Bearing: UC213 | Cr: 57.2 kN
UCFL213C Shaft d: 65 mm | Base unit: UCFL213 | Cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCFL213D Shaft d: 65 mm | Base unit: UCFL213 | Cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCFL213FC Shaft d: 65 mm | Base unit: UCFL213 | Cast iron cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCFL213FD Shaft d: 65 mm | Base unit: UCFL213 | Cast iron cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCFL313 Shaft d: 65 mm | Housing: FL313 | Bearing: UC313 | Cr: 92.7 kN
UCFL313C Shaft d: 65 mm | Base unit: UCFL313 | Cover, open end | Bearing: UC313 | Cr: 92.7 kN
UCFL313D Shaft d: 65 mm | Base unit: UCFL313 | Cover, closed end | Bearing: UC313 | Cr: 92.7 kN
UCFL214 Shaft d: 70 mm | Housing: FL214 | Bearing: UC214 | Cr: 62.2 kN
UCFL214C Shaft d: 70 mm | Base unit: UCFL214 | Cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCFL214D Shaft d: 70 mm | Base unit: UCFL214 | Cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCFL214FC Shaft d: 70 mm | Base unit: UCFL214 | Cast iron cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCFL214FD Shaft d: 70 mm | Base unit: UCFL214 | Cast iron cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCFL314 Shaft d: 70 mm | Housing: FL314 | Bearing: UC314 | Cr: 104 kN
UCFL314C Shaft d: 70 mm | Base unit: UCFL314 | Cover, open end | Bearing: UC314 | Cr: 104 kN
UCFL314D Shaft d: 70 mm | Base unit: UCFL314 | Cover, closed end | Bearing: UC314 | Cr: 104 kN
UCFL215 Shaft d: 75 mm | Housing: FL215 | Bearing: UC215 | Cr: 67.4 kN
UCFL215C Shaft d: 75 mm | Base unit: UCFL215 | Cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCFL215D Shaft d: 75 mm | Base unit: UCFL215 | Cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCFL215FC Shaft d: 75 mm | Base unit: UCFL215 | Cast iron cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCFL215FD Shaft d: 75 mm | Base unit: UCFL215 | Cast iron cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCFL315 Shaft d: 75 mm | Housing: FL315 | Bearing: UC315 | Cr: 113 kN
UCFL315C Shaft d: 75 mm | Base unit: UCFL315 | Cover, open end | Bearing: UC315 | Cr: 113 kN
UCFL315D Shaft d: 75 mm | Base unit: UCFL315 | Cover, closed end | Bearing: UC315 | Cr: 113 kN
UCFL216 Shaft d: 80 mm | Housing: FL216 | Bearing: UC216 | Cr: 72.7 kN
UCFL216C Shaft d: 80 mm | Base unit: UCFL216 | Cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCFL216D Shaft d: 80 mm | Base unit: UCFL216 | Cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCFL216FC Shaft d: 80 mm | Base unit: UCFL216 | Cast iron cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCFL216FD Shaft d: 80 mm | Base unit: UCFL216 | Cast iron cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCFL316 Shaft d: 80 mm | Housing: FL316 | Bearing: UC316 | Cr: 123 kN
UCFL316C Shaft d: 80 mm | Base unit: UCFL316 | Cover, open end | Bearing: UC316 | Cr: 123 kN
UCFL316D Shaft d: 80 mm | Base unit: UCFL316 | Cover, closed end | Bearing: UC316 | Cr: 123 kN
UCFL217 Shaft d: 85 mm | Housing: FL217 | Bearing: UC217 | Cr: 84.0 kN
UCFL217C Shaft d: 85 mm | Base unit: UCFL217 | Cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCFL217D Shaft d: 85 mm | Base unit: UCFL217 | Cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCFL217FC Shaft d: 85 mm | Base unit: UCFL217 | Cast iron cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCFL217FD Shaft d: 85 mm | Base unit: UCFL217 | Cast iron cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCFL317 Shaft d: 85 mm | Housing: FL317 | Bearing: UC317 | Cr: 133 kN
UCFL317C Shaft d: 85 mm | Base unit: UCFL317 | Cover, open end | Bearing: UC317 | Cr: 133 kN
UCFL317D Shaft d: 85 mm | Base unit: UCFL317 | Cover, closed end | Bearing: UC317 | Cr: 133 kN
UCFL218 Shaft d: 90 mm | Housing: FL218 | Bearing: UC218 | Cr: 96.1 kN
UCFL218C Shaft d: 90 mm | Base unit: UCFL218 | Cover, open end | Bearing: UC218 | Cr: 96.1 kN
UCFL218D Shaft d: 90 mm | Base unit: UCFL218 | Cover, closed end | Bearing: UC218 | Cr: 96.1 kN
UCFL218FC Shaft d: 90 mm | Base unit: UCFL218 | Cast iron cover, open end | Bearing: UC218 | Cr: 96.1 kN
UCFL218FD Shaft d: 90 mm | Base unit: UCFL218 | Cast iron cover, closed end | Bearing: UC218 | Cr: 96.1 kN
UCFL318 Shaft d: 90 mm | Housing: FL318 | Bearing: UC318 | Cr: 143 kN
UCFL318C Shaft d: 90 mm | Base unit: UCFL318 | Cover, open end | Bearing: UC318 | Cr: 143 kN
UCFL318D Shaft d: 90 mm | Base unit: UCFL318 | Cover, closed end | Bearing: UC318 | Cr: 143 kN
UCFL319 Shaft d: 95 mm | Housing: FL319 | Bearing: UC319 | Cr: 153 kN
UCFL319C Shaft d: 95 mm | Base unit: UCFL319 | Cover, open end | Bearing: UC319 | Cr: 153 kN
UCFL319D Shaft d: 95 mm | Base unit: UCFL319 | Cover, closed end | Bearing: UC319 | Cr: 153 kN
UCFL320 Shaft d: 100 mm | Housing: FL320 | Bearing: UC320 | Cr: 173 kN
UCFL320C Shaft d: 100 mm | Base unit: UCFL320 | Cover, open end | Bearing: UC320 | Cr: 173 kN
UCFL320D Shaft d: 100 mm | Base unit: UCFL320 | Cover, closed end | Bearing: UC320 | Cr: 173 kN
UCFL321 Shaft d: 105 mm | Housing: FL321 | Bearing: UC321 | Cr: 184 kN
UCFL321C Shaft d: 105 mm | Base unit: UCFL321 | Cover, open end | Bearing: UC321 | Cr: 184 kN
UCFL321D Shaft d: 105 mm | Base unit: UCFL321 | Cover, closed end | Bearing: UC321 | Cr: 184 kN
UCFL322 Shaft d: 110 mm | Housing: FL322 | Bearing: UC322 | Cr: 205 kN
UCFL322C Shaft d: 110 mm | Base unit: UCFL322 | Cover, open end | Bearing: UC322 | Cr: 205 kN
UCFL322D Shaft d: 110 mm | Base unit: UCFL322 | Cover, closed end | Bearing: UC322 | Cr: 205 kN
UCFL324 Shaft d: 120 mm | Housing: FL324 | Bearing: UC324 | Cr: 207 kN
UCFL324C Shaft d: 120 mm | Base unit: UCFL324 | Cover, open end | Bearing: UC324 | Cr: 207 kN
UCFL324D Shaft d: 120 mm | Base unit: UCFL324 | Cover, closed end | Bearing: UC324 | Cr: 207 kN
UCFL326 Shaft d: 130 mm | Housing: FL326 | Bearing: UC326 | Cr: 229 kN
UCFL326C Shaft d: 130 mm | Base unit: UCFL326 | Cover, open end | Bearing: UC326 | Cr: 229 kN
UCFL326D Shaft d: 130 mm | Base unit: UCFL326 | Cover, closed end | Bearing: UC326 | Cr: 229 kN
UCFL328 Shaft d: 140 mm | Housing: FL328 | Bearing: UC328 | Cr: 253 kN
UCFL328C Shaft d: 140 mm | Base unit: UCFL328 | Cover, open end | Bearing: UC328 | Cr: 253 kN
UCFL328D Shaft d: 140 mm | Base unit: UCFL328 | Cover, closed end | Bearing: UC328 | Cr: 253 kN
Mounted Bearing UnitsKOYO
165 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO UCFL Rhombic (2-Bolt) Flanged Units

Brand KOYO·Mounted Bearing Units

Available part numbers (165)

UCFL201, UCFL201C, UCFL201D, UCFL202, UCFL202C, UCFL202D, UCFL203, UCFL203C, UCFL203D, UCFL204 + 155 more — see full table ↓

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UCFL201Shaft d: 12 mm | Housing: FL204 | Bearing: UC201 | Cr: 12.8 kN
UCFL201CShaft d: 12 mm | Base unit: UCFL201 | Cover, open end | Bearing: UC201 | Cr: 12.8 kN
UCFL201DShaft d: 12 mm | Base unit: UCFL201 | Cover, closed end | Bearing: UC201 | Cr: 12.8 kN
UCFL202Shaft d: 15 mm | Housing: FL204 | Bearing: UC202 | Cr: 12.8 kN
UCFL202CShaft d: 15 mm | Base unit: UCFL202 | Cover, open end | Bearing: UC202 | Cr: 12.8 kN
UCFL202DShaft d: 15 mm | Base unit: UCFL202 | Cover, closed end | Bearing: UC202 | Cr: 12.8 kN
UCFL203Shaft d: 17 mm | Housing: FL204 | Bearing: UC203 | Cr: 12.8 kN
UCFL203CShaft d: 17 mm | Base unit: UCFL203 | Cover, open end | Bearing: UC203 | Cr: 12.8 kN
UCFL203DShaft d: 17 mm | Base unit: UCFL203 | Cover, closed end | Bearing: UC203 | Cr: 12.8 kN
UCFL204Shaft d: 20 mm | Housing: FL204 | Bearing: UC204 | Cr: 12.8 kN
UCFL204CShaft d: 20 mm | Base unit: UCFL204 | Cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCFL204DShaft d: 20 mm | Base unit: UCFL204 | Cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCFL204FCShaft d: 20 mm | Base unit: UCFL204 | Cast iron cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCFL204FDShaft d: 20 mm | Base unit: UCFL204 | Cast iron cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCFL205Shaft d: 25 mm | Housing: FL205 | Bearing: UC205 | Cr: 14.0 kN
UCFL205CShaft d: 25 mm | Base unit: UCFL205 | Cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCFL205DShaft d: 25 mm | Base unit: UCFL205 | Cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCFL205FCShaft d: 25 mm | Base unit: UCFL205 | Cast iron cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCFL205FDShaft d: 25 mm | Base unit: UCFL205 | Cast iron cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCFLX05Shaft d: 25 mm | Housing: FLX05 | Bearing: UCX05 | Cr: 19.5 kN
UCFLX05CShaft d: 25 mm | Base unit: UCFLX05 | Cover, open end | Bearing: UCX05 | Cr: 19.5 kN
UCFLX05DShaft d: 25 mm | Base unit: UCFLX05 | Cover, closed end | Bearing: UCX05 | Cr: 19.5 kN
UCFL305Shaft d: 25 mm | Housing: FL305 | Bearing: UC305 | Cr: 21.2 kN
UCFL305CShaft d: 25 mm | Base unit: UCFL305 | Cover, open end | Bearing: UC305 | Cr: 21.2 kN
UCFL305DShaft d: 25 mm | Base unit: UCFL305 | Cover, closed end | Bearing: UC305 | Cr: 21.2 kN
UCFL206Shaft d: 30 mm | Housing: FL206 | Bearing: UC206 | Cr: 19.5 kN
UCFL206CShaft d: 30 mm | Base unit: UCFL206 | Cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCFL206DShaft d: 30 mm | Base unit: UCFL206 | Cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCFL206FCShaft d: 30 mm | Base unit: UCFL206 | Cast iron cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCFL206FDShaft d: 30 mm | Base unit: UCFL206 | Cast iron cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCFLX06Shaft d: 30 mm | Housing: FLX06 | Bearing: UCX06 | Cr: 25.7 kN
UCFLX06CShaft d: 30 mm | Base unit: UCFLX06 | Cover, open end | Bearing: UCX06 | Cr: 25.7 kN
UCFLX06DShaft d: 30 mm | Base unit: UCFLX06 | Cover, closed end | Bearing: UCX06 | Cr: 25.7 kN
UCFL306Shaft d: 30 mm | Housing: FL306 | Bearing: UC306 | Cr: 26.7 kN
UCFL306CShaft d: 30 mm | Base unit: UCFL306 | Cover, open end | Bearing: UC306 | Cr: 26.7 kN
UCFL306DShaft d: 30 mm | Base unit: UCFL306 | Cover, closed end | Bearing: UC306 | Cr: 26.7 kN
UCFL207Shaft d: 35 mm | Housing: FL207 | Bearing: UC207 | Cr: 25.7 kN
UCFL207CShaft d: 35 mm | Base unit: UCFL207 | Cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCFL207DShaft d: 35 mm | Base unit: UCFL207 | Cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCFL207FCShaft d: 35 mm | Base unit: UCFL207 | Cast iron cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCFL207FDShaft d: 35 mm | Base unit: UCFL207 | Cast iron cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCFLX07Shaft d: 35 mm | Housing: FLX07 | Bearing: UCX07 | Cr: 29.1 kN
UCFLX07CShaft d: 35 mm | Base unit: UCFLX07 | Cover, open end | Bearing: UCX07 | Cr: 29.1 kN
UCFLX07DShaft d: 35 mm | Base unit: UCFLX07 | Cover, closed end | Bearing: UCX07 | Cr: 29.1 kN
UCFL307Shaft d: 35 mm | Housing: FL307 | Bearing: UC307 | Cr: 33.4 kN
UCFL307CShaft d: 35 mm | Base unit: UCFL307 | Cover, open end | Bearing: UC307 | Cr: 33.4 kN
UCFL307DShaft d: 35 mm | Base unit: UCFL307 | Cover, closed end | Bearing: UC307 | Cr: 33.4 kN
UCFL208Shaft d: 40 mm | Housing: FL208 | Bearing: UC208 | Cr: 29.1 kN
UCFL208CShaft d: 40 mm | Base unit: UCFL208 | Cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCFL208DShaft d: 40 mm | Base unit: UCFL208 | Cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCFL208FCShaft d: 40 mm | Base unit: UCFL208 | Cast iron cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCFL208FDShaft d: 40 mm | Base unit: UCFL208 | Cast iron cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCFLX08Shaft d: 40 mm | Housing: FLX08 | Bearing: UCX08 | Cr: 32.7 kN
UCFLX08CShaft d: 40 mm | Base unit: UCFLX08 | Cover, open end | Bearing: UCX08 | Cr: 32.7 kN
UCFLX08DShaft d: 40 mm | Base unit: UCFLX08 | Cover, closed end | Bearing: UCX08 | Cr: 32.7 kN
UCFL308Shaft d: 40 mm | Housing: FL308 | Bearing: UC308 | Cr: 40.7 kN
UCFL308CShaft d: 40 mm | Base unit: UCFL308 | Cover, open end | Bearing: UC308 | Cr: 40.7 kN
UCFL308DShaft d: 40 mm | Base unit: UCFL308 | Cover, closed end | Bearing: UC308 | Cr: 40.7 kN
UCFL209Shaft d: 45 mm | Housing: FL209 | Bearing: UC209 | Cr: 32.7 kN
UCFL209CShaft d: 45 mm | Base unit: UCFL209 | Cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCFL209DShaft d: 45 mm | Base unit: UCFL209 | Cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCFL209FCShaft d: 45 mm | Base unit: UCFL209 | Cast iron cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCFL209FDShaft d: 45 mm | Base unit: UCFL209 | Cast iron cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCFLX09Shaft d: 45 mm | Housing: FLX09 | Bearing: UCX09 | Cr: 35.1 kN
UCFLX09CShaft d: 45 mm | Base unit: UCFLX09 | Cover, open end | Bearing: UCX09 | Cr: 35.1 kN
UCFLX09DShaft d: 45 mm | Base unit: UCFLX09 | Cover, closed end | Bearing: UCX09 | Cr: 35.1 kN
UCFL309Shaft d: 45 mm | Housing: FL309 | Bearing: UC309 | Cr: 48.9 kN
UCFL309CShaft d: 45 mm | Base unit: UCFL309 | Cover, open end | Bearing: UC309 | Cr: 48.9 kN
UCFL309DShaft d: 45 mm | Base unit: UCFL309 | Cover, closed end | Bearing: UC309 | Cr: 48.9 kN
UCFL210Shaft d: 50 mm | Housing: FL210 | Bearing: UC210 | Cr: 35.1 kN
UCFL210CShaft d: 50 mm | Base unit: UCFL210 | Cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCFL210DShaft d: 50 mm | Base unit: UCFL210 | Cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCFL210FCShaft d: 50 mm | Base unit: UCFL210 | Cast iron cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCFL210FDShaft d: 50 mm | Base unit: UCFL210 | Cast iron cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCFLX10Shaft d: 50 mm | Housing: FLX10 | Bearing: UCX10 | Cr: 43.4 kN
UCFLX10CShaft d: 50 mm | Base unit: UCFLX10 | Cover, open end | Bearing: UCX10 | Cr: 43.4 kN
UCFLX10DShaft d: 50 mm | Base unit: UCFLX10 | Cover, closed end | Bearing: UCX10 | Cr: 43.4 kN
UCFL310Shaft d: 50 mm | Housing: FL310 | Bearing: UC310 | Cr: 62.0 kN
UCFL310CShaft d: 50 mm | Base unit: UCFL310 | Cover, open end | Bearing: UC310 | Cr: 62.0 kN
UCFL310DShaft d: 50 mm | Base unit: UCFL310 | Cover, closed end | Bearing: UC310 | Cr: 62.0 kN
UCFL211Shaft d: 55 mm | Housing: FL211 | Bearing: UC211 | Cr: 43.4 kN
UCFL211CShaft d: 55 mm | Base unit: UCFL211 | Cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCFL211DShaft d: 55 mm | Base unit: UCFL211 | Cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCFL211FCShaft d: 55 mm | Base unit: UCFL211 | Cast iron cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCFL211FDShaft d: 55 mm | Base unit: UCFL211 | Cast iron cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCFL311Shaft d: 55 mm | Housing: FL311 | Bearing: UC311 | Cr: 71.6 kN
UCFL311CShaft d: 55 mm | Base unit: UCFL311 | Cover, open end | Bearing: UC311 | Cr: 71.6 kN
UCFL311DShaft d: 55 mm | Base unit: UCFL311 | Cover, closed end | Bearing: UC311 | Cr: 71.6 kN
UCFL212Shaft d: 60 mm | Housing: FL212 | Bearing: UC212 | Cr: 52.4 kN
UCFL212CShaft d: 60 mm | Base unit: UCFL212 | Cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCFL212DShaft d: 60 mm | Base unit: UCFL212 | Cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCFL212FCShaft d: 60 mm | Base unit: UCFL212 | Cast iron cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCFL212FDShaft d: 60 mm | Base unit: UCFL212 | Cast iron cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCFL312Shaft d: 60 mm | Housing: FL312 | Bearing: UC312 | Cr: 81.9 kN
UCFL312CShaft d: 60 mm | Base unit: UCFL312 | Cover, open end | Bearing: UC312 | Cr: 81.9 kN
UCFL312DShaft d: 60 mm | Base unit: UCFL312 | Cover, closed end | Bearing: UC312 | Cr: 81.9 kN
UCFL213Shaft d: 65 mm | Housing: FL213 | Bearing: UC213 | Cr: 57.2 kN
UCFL213CShaft d: 65 mm | Base unit: UCFL213 | Cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCFL213DShaft d: 65 mm | Base unit: UCFL213 | Cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCFL213FCShaft d: 65 mm | Base unit: UCFL213 | Cast iron cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCFL213FDShaft d: 65 mm | Base unit: UCFL213 | Cast iron cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCFL313Shaft d: 65 mm | Housing: FL313 | Bearing: UC313 | Cr: 92.7 kN
UCFL313CShaft d: 65 mm | Base unit: UCFL313 | Cover, open end | Bearing: UC313 | Cr: 92.7 kN
UCFL313DShaft d: 65 mm | Base unit: UCFL313 | Cover, closed end | Bearing: UC313 | Cr: 92.7 kN
UCFL214Shaft d: 70 mm | Housing: FL214 | Bearing: UC214 | Cr: 62.2 kN
UCFL214CShaft d: 70 mm | Base unit: UCFL214 | Cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCFL214DShaft d: 70 mm | Base unit: UCFL214 | Cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCFL214FCShaft d: 70 mm | Base unit: UCFL214 | Cast iron cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCFL214FDShaft d: 70 mm | Base unit: UCFL214 | Cast iron cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCFL314Shaft d: 70 mm | Housing: FL314 | Bearing: UC314 | Cr: 104 kN
UCFL314CShaft d: 70 mm | Base unit: UCFL314 | Cover, open end | Bearing: UC314 | Cr: 104 kN
UCFL314DShaft d: 70 mm | Base unit: UCFL314 | Cover, closed end | Bearing: UC314 | Cr: 104 kN
UCFL215Shaft d: 75 mm | Housing: FL215 | Bearing: UC215 | Cr: 67.4 kN
UCFL215CShaft d: 75 mm | Base unit: UCFL215 | Cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCFL215DShaft d: 75 mm | Base unit: UCFL215 | Cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCFL215FCShaft d: 75 mm | Base unit: UCFL215 | Cast iron cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCFL215FDShaft d: 75 mm | Base unit: UCFL215 | Cast iron cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCFL315Shaft d: 75 mm | Housing: FL315 | Bearing: UC315 | Cr: 113 kN
UCFL315CShaft d: 75 mm | Base unit: UCFL315 | Cover, open end | Bearing: UC315 | Cr: 113 kN
UCFL315DShaft d: 75 mm | Base unit: UCFL315 | Cover, closed end | Bearing: UC315 | Cr: 113 kN
UCFL216Shaft d: 80 mm | Housing: FL216 | Bearing: UC216 | Cr: 72.7 kN
UCFL216CShaft d: 80 mm | Base unit: UCFL216 | Cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCFL216DShaft d: 80 mm | Base unit: UCFL216 | Cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCFL216FCShaft d: 80 mm | Base unit: UCFL216 | Cast iron cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCFL216FDShaft d: 80 mm | Base unit: UCFL216 | Cast iron cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCFL316Shaft d: 80 mm | Housing: FL316 | Bearing: UC316 | Cr: 123 kN
UCFL316CShaft d: 80 mm | Base unit: UCFL316 | Cover, open end | Bearing: UC316 | Cr: 123 kN
UCFL316DShaft d: 80 mm | Base unit: UCFL316 | Cover, closed end | Bearing: UC316 | Cr: 123 kN
UCFL217Shaft d: 85 mm | Housing: FL217 | Bearing: UC217 | Cr: 84.0 kN
UCFL217CShaft d: 85 mm | Base unit: UCFL217 | Cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCFL217DShaft d: 85 mm | Base unit: UCFL217 | Cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCFL217FCShaft d: 85 mm | Base unit: UCFL217 | Cast iron cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCFL217FDShaft d: 85 mm | Base unit: UCFL217 | Cast iron cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCFL317Shaft d: 85 mm | Housing: FL317 | Bearing: UC317 | Cr: 133 kN
UCFL317CShaft d: 85 mm | Base unit: UCFL317 | Cover, open end | Bearing: UC317 | Cr: 133 kN
UCFL317DShaft d: 85 mm | Base unit: UCFL317 | Cover, closed end | Bearing: UC317 | Cr: 133 kN
UCFL218Shaft d: 90 mm | Housing: FL218 | Bearing: UC218 | Cr: 96.1 kN
UCFL218CShaft d: 90 mm | Base unit: UCFL218 | Cover, open end | Bearing: UC218 | Cr: 96.1 kN
UCFL218DShaft d: 90 mm | Base unit: UCFL218 | Cover, closed end | Bearing: UC218 | Cr: 96.1 kN
UCFL218FCShaft d: 90 mm | Base unit: UCFL218 | Cast iron cover, open end | Bearing: UC218 | Cr: 96.1 kN
UCFL218FDShaft d: 90 mm | Base unit: UCFL218 | Cast iron cover, closed end | Bearing: UC218 | Cr: 96.1 kN
UCFL318Shaft d: 90 mm | Housing: FL318 | Bearing: UC318 | Cr: 143 kN
UCFL318CShaft d: 90 mm | Base unit: UCFL318 | Cover, open end | Bearing: UC318 | Cr: 143 kN
UCFL318DShaft d: 90 mm | Base unit: UCFL318 | Cover, closed end | Bearing: UC318 | Cr: 143 kN
UCFL319Shaft d: 95 mm | Housing: FL319 | Bearing: UC319 | Cr: 153 kN
UCFL319CShaft d: 95 mm | Base unit: UCFL319 | Cover, open end | Bearing: UC319 | Cr: 153 kN
UCFL319DShaft d: 95 mm | Base unit: UCFL319 | Cover, closed end | Bearing: UC319 | Cr: 153 kN
UCFL320Shaft d: 100 mm | Housing: FL320 | Bearing: UC320 | Cr: 173 kN
UCFL320CShaft d: 100 mm | Base unit: UCFL320 | Cover, open end | Bearing: UC320 | Cr: 173 kN
UCFL320DShaft d: 100 mm | Base unit: UCFL320 | Cover, closed end | Bearing: UC320 | Cr: 173 kN
UCFL321Shaft d: 105 mm | Housing: FL321 | Bearing: UC321 | Cr: 184 kN
UCFL321CShaft d: 105 mm | Base unit: UCFL321 | Cover, open end | Bearing: UC321 | Cr: 184 kN
UCFL321DShaft d: 105 mm | Base unit: UCFL321 | Cover, closed end | Bearing: UC321 | Cr: 184 kN
UCFL322Shaft d: 110 mm | Housing: FL322 | Bearing: UC322 | Cr: 205 kN
UCFL322CShaft d: 110 mm | Base unit: UCFL322 | Cover, open end | Bearing: UC322 | Cr: 205 kN
UCFL322DShaft d: 110 mm | Base unit: UCFL322 | Cover, closed end | Bearing: UC322 | Cr: 205 kN
UCFL324Shaft d: 120 mm | Housing: FL324 | Bearing: UC324 | Cr: 207 kN
UCFL324CShaft d: 120 mm | Base unit: UCFL324 | Cover, open end | Bearing: UC324 | Cr: 207 kN
UCFL324DShaft d: 120 mm | Base unit: UCFL324 | Cover, closed end | Bearing: UC324 | Cr: 207 kN
UCFL326Shaft d: 130 mm | Housing: FL326 | Bearing: UC326 | Cr: 229 kN
UCFL326CShaft d: 130 mm | Base unit: UCFL326 | Cover, open end | Bearing: UC326 | Cr: 229 kN
UCFL326DShaft d: 130 mm | Base unit: UCFL326 | Cover, closed end | Bearing: UC326 | Cr: 229 kN
UCFL328Shaft d: 140 mm | Housing: FL328 | Bearing: UC328 | Cr: 253 kN
UCFL328CShaft d: 140 mm | Base unit: UCFL328 | Cover, open end | Bearing: UC328 | Cr: 253 kN
UCFL328DShaft d: 140 mm | Base unit: UCFL328 | Cover, closed end | Bearing: UC328 | Cr: 253 kN

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
