KOYO UCT Take-Up Units

KOYO UCT Take-Up Units

Cast iron take-up units with UC/UCX insert bearings for belt and conveyor tensioning, with optional covers.

Key features

  • Pre-lubricated sealed ball bearing insert
  • Spherical seating compensates for shaft misalignment
  • Housing and insert replaceable separately
  • Unit number, housing number and insert bearing listed
  • Shaft diameter given in mm

Specifications

Product type Ball bearing unit
Series UCT Take-Up Units
Seal Insert bearing sealed both sides
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B518-B523
UCT201 Shaft d: 12 mm | Housing: T204 | Bearing: UC201 | Cr: 12.8 kN
UCT201C Shaft d: 12 mm | Base unit: UCT201 | Cover, open end | Bearing: UC201 | Cr: 12.8 kN
UCT201CD Shaft d: 12 mm | Base unit: UCT201 | Cover, closed end | Bearing: UC201 | Cr: 12.8 kN
UCT202 Shaft d: 15 mm | Housing: T204 | Bearing: UC202 | Cr: 12.8 kN
UCT202C Shaft d: 15 mm | Base unit: UCT202 | Cover, open end | Bearing: UC202 | Cr: 12.8 kN
UCT202CD Shaft d: 15 mm | Base unit: UCT202 | Cover, closed end | Bearing: UC202 | Cr: 12.8 kN
UCT203 Shaft d: 17 mm | Housing: T204 | Bearing: UC203 | Cr: 12.8 kN
UCT203C Shaft d: 17 mm | Base unit: UCT203 | Cover, open end | Bearing: UC203 | Cr: 12.8 kN
UCT203CD Shaft d: 17 mm | Base unit: UCT203 | Cover, closed end | Bearing: UC203 | Cr: 12.8 kN
UCT204 Shaft d: 20 mm | Housing: T204 | Bearing: UC204 | Cr: 12.8 kN
UCT204C Shaft d: 20 mm | Base unit: UCT204 | Cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCT204CD Shaft d: 20 mm | Base unit: UCT204 | Cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCT204FC Shaft d: 20 mm | Base unit: UCT204 | Cast iron cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCT204FCD Shaft d: 20 mm | Base unit: UCT204 | Cast iron cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCT205 Shaft d: 25 mm | Housing: T205 | Bearing: UC205 | Cr: 14.0 kN
UCT205C Shaft d: 25 mm | Base unit: UCT205 | Cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCT205CD Shaft d: 25 mm | Base unit: UCT205 | Cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCT205FC Shaft d: 25 mm | Base unit: UCT205 | Cast iron cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCT205FCD Shaft d: 25 mm | Base unit: UCT205 | Cast iron cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCTX05 Shaft d: 25 mm | Housing: TX05 | Bearing: UCX05 | Cr: 19.5 kN
UCTX05C Shaft d: 25 mm | Base unit: UCTX05 | Cover, open end | Bearing: UCX05 | Cr: 19.5 kN
UCTX05CD Shaft d: 25 mm | Base unit: UCTX05 | Cover, closed end | Bearing: UCX05 | Cr: 19.5 kN
UCT305 Shaft d: 25 mm | Housing: T305 | Bearing: UC305 | Cr: 21.2 kN
UCT305C Shaft d: 25 mm | Base unit: UCT305 | Cover, open end | Bearing: UC305 | Cr: 21.2 kN
UCT305CD Shaft d: 25 mm | Base unit: UCT305 | Cover, closed end | Bearing: UC305 | Cr: 21.2 kN
UCT206 Shaft d: 30 mm | Housing: T206 | Bearing: UC206 | Cr: 19.5 kN
UCT206C Shaft d: 30 mm | Base unit: UCT206 | Cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCT206CD Shaft d: 30 mm | Base unit: UCT206 | Cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCT206FC Shaft d: 30 mm | Base unit: UCT206 | Cast iron cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCT206FCD Shaft d: 30 mm | Base unit: UCT206 | Cast iron cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCTX06 Shaft d: 30 mm | Housing: TX06 | Bearing: UCX06 | Cr: 25.7 kN
UCTX06C Shaft d: 30 mm | Base unit: UCTX06 | Cover, open end | Bearing: UCX06 | Cr: 25.7 kN
UCTX06CD Shaft d: 30 mm | Base unit: UCTX06 | Cover, closed end | Bearing: UCX06 | Cr: 25.7 kN
UCT306 Shaft d: 30 mm | Housing: T306 | Bearing: UC306 | Cr: 26.7 kN
UCT306C Shaft d: 30 mm | Base unit: UCT306 | Cover, open end | Bearing: UC306 | Cr: 26.7 kN
UCT306CD Shaft d: 30 mm | Base unit: UCT306 | Cover, closed end | Bearing: UC306 | Cr: 26.7 kN
UCT207 Shaft d: 35 mm | Housing: T207 | Bearing: UC207 | Cr: 25.7 kN
UCT207C Shaft d: 35 mm | Base unit: UCT207 | Cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCT207CD Shaft d: 35 mm | Base unit: UCT207 | Cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCT207FC Shaft d: 35 mm | Base unit: UCT207 | Cast iron cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCT207FCD Shaft d: 35 mm | Base unit: UCT207 | Cast iron cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCTX07 Shaft d: 35 mm | Housing: TX07 | Bearing: UCX07 | Cr: 29.1 kN
UCTX07C Shaft d: 35 mm | Base unit: UCTX07 | Cover, open end | Bearing: UCX07 | Cr: 29.1 kN
UCTX07CD Shaft d: 35 mm | Base unit: UCTX07 | Cover, closed end | Bearing: UCX07 | Cr: 29.1 kN
UCT307 Shaft d: 35 mm | Housing: T307 | Bearing: UC307 | Cr: 33.4 kN
UCT307C Shaft d: 35 mm | Base unit: UCT307 | Cover, open end | Bearing: UC307 | Cr: 33.4 kN
UCT307CD Shaft d: 35 mm | Base unit: UCT307 | Cover, closed end | Bearing: UC307 | Cr: 33.4 kN
UCT208 Shaft d: 40 mm | Housing: T208 | Bearing: UC208 | Cr: 29.1 kN
UCT208C Shaft d: 40 mm | Base unit: UCT208 | Cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCT208CD Shaft d: 40 mm | Base unit: UCT208 | Cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCT208FC Shaft d: 40 mm | Base unit: UCT208 | Cast iron cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCT208FCD Shaft d: 40 mm | Base unit: UCT208 | Cast iron cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCTX08 Shaft d: 40 mm | Housing: TX08 | Bearing: UCX08 | Cr: 32.7 kN
UCTX08C Shaft d: 40 mm | Base unit: UCTX08 | Cover, open end | Bearing: UCX08 | Cr: 32.7 kN
UCTX08CD Shaft d: 40 mm | Base unit: UCTX08 | Cover, closed end | Bearing: UCX08 | Cr: 32.7 kN
UCT308 Shaft d: 40 mm | Housing: T308 | Bearing: UC308 | Cr: 40.7 kN
UCT308C Shaft d: 40 mm | Base unit: UCT308 | Cover, open end | Bearing: UC308 | Cr: 40.7 kN
UCT308CD Shaft d: 40 mm | Base unit: UCT308 | Cover, closed end | Bearing: UC308 | Cr: 40.7 kN
UCT209 Shaft d: 45 mm | Housing: T209 | Bearing: UC209 | Cr: 32.7 kN
UCT209C Shaft d: 45 mm | Base unit: UCT209 | Cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCT209CD Shaft d: 45 mm | Base unit: UCT209 | Cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCT209FC Shaft d: 45 mm | Base unit: UCT209 | Cast iron cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCT209FCD Shaft d: 45 mm | Base unit: UCT209 | Cast iron cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCTX09 Shaft d: 45 mm | Housing: TX09 | Bearing: UCX09 | Cr: 35.1 kN
UCTX09C Shaft d: 45 mm | Base unit: UCTX09 | Cover, open end | Bearing: UCX09 | Cr: 35.1 kN
UCTX09CD Shaft d: 45 mm | Base unit: UCTX09 | Cover, closed end | Bearing: UCX09 | Cr: 35.1 kN
UCT309 Shaft d: 45 mm | Housing: T309 | Bearing: UC309 | Cr: 48.9 kN
UCT309C Shaft d: 45 mm | Base unit: UCT309 | Cover, open end | Bearing: UC309 | Cr: 48.9 kN
UCT309CD Shaft d: 45 mm | Base unit: UCT309 | Cover, closed end | Bearing: UC309 | Cr: 48.9 kN
UCT210 Shaft d: 50 mm | Housing: T210 | Bearing: UC210 | Cr: 35.1 kN
UCT210C Shaft d: 50 mm | Base unit: UCT210 | Cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCT210CD Shaft d: 50 mm | Base unit: UCT210 | Cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCT210FC Shaft d: 50 mm | Base unit: UCT210 | Cast iron cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCT210FCD Shaft d: 50 mm | Base unit: UCT210 | Cast iron cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCTX10 Shaft d: 50 mm | Housing: TX10 | Bearing: UCX10 | Cr: 43.4 kN
UCTX10C Shaft d: 50 mm | Base unit: UCTX10 | Cover, open end | Bearing: UCX10 | Cr: 43.4 kN
UCTX10CD Shaft d: 50 mm | Base unit: UCTX10 | Cover, closed end | Bearing: UCX10 | Cr: 43.4 kN
UCT310 Shaft d: 50 mm | Housing: T310 | Bearing: UC310 | Cr: 62.0 kN
UCT310C Shaft d: 50 mm | Base unit: UCT310 | Cover, open end | Bearing: UC310 | Cr: 62.0 kN
UCT310CD Shaft d: 50 mm | Base unit: UCT310 | Cover, closed end | Bearing: UC310 | Cr: 62.0 kN
UCT211 Shaft d: 55 mm | Housing: T211 | Bearing: UC211 | Cr: 43.4 kN
UCT211C Shaft d: 55 mm | Base unit: UCT211 | Cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCT211CD Shaft d: 55 mm | Base unit: UCT211 | Cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCT211FC Shaft d: 55 mm | Base unit: UCT211 | Cast iron cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCT211FCD Shaft d: 55 mm | Base unit: UCT211 | Cast iron cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCTX11 Shaft d: 55 mm | Housing: TX11 | Bearing: UCX11 | Cr: 52.4 kN
UCTX11C Shaft d: 55 mm | Base unit: UCTX11 | Cover, open end | Bearing: UCX11 | Cr: 52.4 kN
UCTX11CD Shaft d: 55 mm | Base unit: UCTX11 | Cover, closed end | Bearing: UCX11 | Cr: 52.4 kN
UCT311 Shaft d: 55 mm | Housing: T311 | Bearing: UC311 | Cr: 71.6 kN
UCT311C Shaft d: 55 mm | Base unit: UCT311 | Cover, open end | Bearing: UC311 | Cr: 71.6 kN
UCT311CD Shaft d: 55 mm | Base unit: UCT311 | Cover, closed end | Bearing: UC311 | Cr: 71.6 kN
UCT212 Shaft d: 60 mm | Housing: T212 | Bearing: UC212 | Cr: 52.4 kN
UCT212C Shaft d: 60 mm | Base unit: UCT212 | Cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCT212CD Shaft d: 60 mm | Base unit: UCT212 | Cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCT212FC Shaft d: 60 mm | Base unit: UCT212 | Cast iron cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCT212FCD Shaft d: 60 mm | Base unit: UCT212 | Cast iron cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCTX12 Shaft d: 60 mm | Housing: TX12 | Bearing: UCX12 | Cr: 57.2 kN
UCTX12C Shaft d: 60 mm | Base unit: UCTX12 | Cover, open end | Bearing: UCX12 | Cr: 57.2 kN
UCTX12CD Shaft d: 60 mm | Base unit: UCTX12 | Cover, closed end | Bearing: UCX12 | Cr: 57.2 kN
UCT312 Shaft d: 60 mm | Housing: T312 | Bearing: UC312 | Cr: 81.9 kN
UCT312C Shaft d: 60 mm | Base unit: UCT312 | Cover, open end | Bearing: UC312 | Cr: 81.9 kN
UCT312CD Shaft d: 60 mm | Base unit: UCT312 | Cover, closed end | Bearing: UC312 | Cr: 81.9 kN
UCT213 Shaft d: 65 mm | Housing: T213 | Bearing: UC213 | Cr: 57.2 kN
UCT213C Shaft d: 65 mm | Base unit: UCT213 | Cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCT213CD Shaft d: 65 mm | Base unit: UCT213 | Cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCT213FC Shaft d: 65 mm | Base unit: UCT213 | Cast iron cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCT213FCD Shaft d: 65 mm | Base unit: UCT213 | Cast iron cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCTX13 Shaft d: 65 mm | Housing: TX13 | Bearing: UCX13 | Cr: 62.2 kN
UCTX13C Shaft d: 65 mm | Base unit: UCTX13 | Cover, open end | Bearing: UCX13 | Cr: 62.2 kN
UCTX13CD Shaft d: 65 mm | Base unit: UCTX13 | Cover, closed end | Bearing: UCX13 | Cr: 62.2 kN
UCT313 Shaft d: 65 mm | Housing: T313 | Bearing: UC313 | Cr: 92.7 kN
UCT313C Shaft d: 65 mm | Base unit: UCT313 | Cover, open end | Bearing: UC313 | Cr: 92.7 kN
UCT313CD Shaft d: 65 mm | Base unit: UCT313 | Cover, closed end | Bearing: UC313 | Cr: 92.7 kN
UCT214 Shaft d: 70 mm | Housing: T214 | Bearing: UC214 | Cr: 62.2 kN
UCT214C Shaft d: 70 mm | Base unit: UCT214 | Cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCT214CD Shaft d: 70 mm | Base unit: UCT214 | Cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCT214FC Shaft d: 70 mm | Base unit: UCT214 | Cast iron cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCT214FCD Shaft d: 70 mm | Base unit: UCT214 | Cast iron cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCTX14 Shaft d: 70 mm | Housing: TX14 | Bearing: UCX14 | Cr: 67.4 kN
UCTX14C Shaft d: 70 mm | Base unit: UCTX14 | Cover, open end | Bearing: UCX14 | Cr: 67.4 kN
UCTX14CD Shaft d: 70 mm | Base unit: UCTX14 | Cover, closed end | Bearing: UCX14 | Cr: 67.4 kN
UCT314 Shaft d: 70 mm | Housing: T314 | Bearing: UC314 | Cr: 104 kN
UCT314C Shaft d: 70 mm | Base unit: UCT314 | Cover, open end | Bearing: UC314 | Cr: 104 kN
UCT314CD Shaft d: 70 mm | Base unit: UCT314 | Cover, closed end | Bearing: UC314 | Cr: 104 kN
UCT215 Shaft d: 75 mm | Housing: T215 | Bearing: UC215 | Cr: 67.4 kN
UCT215C Shaft d: 75 mm | Base unit: UCT215 | Cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCT215CD Shaft d: 75 mm | Base unit: UCT215 | Cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCT215FC Shaft d: 75 mm | Base unit: UCT215 | Cast iron cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCT215FCD Shaft d: 75 mm | Base unit: UCT215 | Cast iron cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCTX15 Shaft d: 75 mm | Housing: TX15 | Bearing: UCX15 | Cr: 72.7 kN
UCTX15C Shaft d: 75 mm | Base unit: UCTX15 | Cover, open end | Bearing: UCX15 | Cr: 72.7 kN
UCTX15CD Shaft d: 75 mm | Base unit: UCTX15 | Cover, closed end | Bearing: UCX15 | Cr: 72.7 kN
UCT315 Shaft d: 75 mm | Housing: T315 | Bearing: UC315 | Cr: 113 kN
UCT315C Shaft d: 75 mm | Base unit: UCT315 | Cover, open end | Bearing: UC315 | Cr: 113 kN
UCT315CD Shaft d: 75 mm | Base unit: UCT315 | Cover, closed end | Bearing: UC315 | Cr: 113 kN
UCT216 Shaft d: 80 mm | Housing: T216 | Bearing: UC216 | Cr: 72.7 kN
UCT216C Shaft d: 80 mm | Base unit: UCT216 | Cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCT216CD Shaft d: 80 mm | Base unit: UCT216 | Cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCT216FC Shaft d: 80 mm | Base unit: UCT216 | Cast iron cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCT216FCD Shaft d: 80 mm | Base unit: UCT216 | Cast iron cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCTX16 Shaft d: 80 mm | Housing: TX16 | Bearing: UCX16 | Cr: 84.0 kN
UCTX16C Shaft d: 80 mm | Base unit: UCTX16 | Cover, open end | Bearing: UCX16 | Cr: 84.0 kN
UCTX16CD Shaft d: 80 mm | Base unit: UCTX16 | Cover, closed end | Bearing: UCX16 | Cr: 84.0 kN
UCT316 Shaft d: 80 mm | Housing: T316 | Bearing: UC316 | Cr: 123 kN
UCT316C Shaft d: 80 mm | Base unit: UCT316 | Cover, open end | Bearing: UC316 | Cr: 123 kN
UCT316CD Shaft d: 80 mm | Base unit: UCT316 | Cover, closed end | Bearing: UC316 | Cr: 123 kN
UCT217 Shaft d: 85 mm | Housing: T217 | Bearing: UC217 | Cr: 84.0 kN
UCT217C Shaft d: 85 mm | Base unit: UCT217 | Cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCT217CD Shaft d: 85 mm | Base unit: UCT217 | Cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCT217FC Shaft d: 85 mm | Base unit: UCT217 | Cast iron cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCT217FCD Shaft d: 85 mm | Base unit: UCT217 | Cast iron cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCTX17 Shaft d: 85 mm | Housing: TX17 | Bearing: UCX17 | Cr: 96.1 kN
UCTX17C Shaft d: 85 mm | Base unit: UCTX17 | Cover, open end | Bearing: UCX17 | Cr: 96.1 kN
UCTX17CD Shaft d: 85 mm | Base unit: UCTX17 | Cover, closed end | Bearing: UCX17 | Cr: 96.1 kN
UCT317 Shaft d: 85 mm | Housing: T317 | Bearing: UC317 | Cr: 133 kN
UCT317C Shaft d: 85 mm | Base unit: UCT317 | Cover, open end | Bearing: UC317 | Cr: 133 kN
UCT317CD Shaft d: 85 mm | Base unit: UCT317 | Cover, closed end | Bearing: UC317 | Cr: 133 kN
UCT318 Shaft d: 90 mm | Housing: T318 | Bearing: UC318 | Cr: 143 kN
UCT318C Shaft d: 90 mm | Base unit: UCT318 | Cover, open end | Bearing: UC318 | Cr: 143 kN
UCT318CD Shaft d: 90 mm | Base unit: UCT318 | Cover, closed end | Bearing: UC318 | Cr: 143 kN
UCT319 Shaft d: 95 mm | Housing: T319 | Bearing: UC319 | Cr: 153 kN
UCT319C Shaft d: 95 mm | Base unit: UCT319 | Cover, open end | Bearing: UC319 | Cr: 153 kN
UCT319CD Shaft d: 95 mm | Base unit: UCT319 | Cover, closed end | Bearing: UC319 | Cr: 153 kN
UCT320 Shaft d: 100 mm | Housing: T320 | Bearing: UC320 | Cr: 173 kN
UCT320C Shaft d: 100 mm | Base unit: UCT320 | Cover, open end | Bearing: UC320 | Cr: 173 kN
UCT320CD Shaft d: 100 mm | Base unit: UCT320 | Cover, closed end | Bearing: UC320 | Cr: 173 kN
UCT321 Shaft d: 105 mm | Housing: T321 | Bearing: UC321 | Cr: 184 kN
UCT321C Shaft d: 105 mm | Base unit: UCT321 | Cover, open end | Bearing: UC321 | Cr: 184 kN
UCT321CD Shaft d: 105 mm | Base unit: UCT321 | Cover, closed end | Bearing: UC321 | Cr: 184 kN
UCT322 Shaft d: 110 mm | Housing: T322 | Bearing: UC322 | Cr: 205 kN
UCT322C Shaft d: 110 mm | Base unit: UCT322 | Cover, open end | Bearing: UC322 | Cr: 205 kN
UCT322CD Shaft d: 110 mm | Base unit: UCT322 | Cover, closed end | Bearing: UC322 | Cr: 205 kN
UCT324 Shaft d: 120 mm | Housing: T324 | Bearing: UC324 | Cr: 207 kN
UCT324C Shaft d: 120 mm | Base unit: UCT324 | Cover, open end | Bearing: UC324 | Cr: 207 kN
UCT324CD Shaft d: 120 mm | Base unit: UCT324 | Cover, closed end | Bearing: UC324 | Cr: 207 kN
UCT326 Shaft d: 130 mm | Housing: T326 | Bearing: UC326 | Cr: 229 kN
UCT326C Shaft d: 130 mm | Base unit: UCT326 | Cover, open end | Bearing: UC326 | Cr: 229 kN
UCT326CD Shaft d: 130 mm | Base unit: UCT326 | Cover, closed end | Bearing: UC326 | Cr: 229 kN
UCT328 Shaft d: 140 mm | Housing: T328 | Bearing: UC328 | Cr: 253 kN
UCT328C Shaft d: 140 mm | Base unit: UCT328 | Cover, open end | Bearing: UC328 | Cr: 253 kN
UCT328CD Shaft d: 140 mm | Base unit: UCT328 | Cover, closed end | Bearing: UC328 | Cr: 253 kN
Mounted Bearing UnitsKOYO
181 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO UCT Take-Up Units

Brand KOYO·Mounted Bearing Units

Available part numbers (181)

UCT201, UCT201C, UCT201CD, UCT202, UCT202C, UCT202CD, UCT203, UCT203C, UCT203CD, UCT204 + 171 more — see full table ↓

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UCT201Shaft d: 12 mm | Housing: T204 | Bearing: UC201 | Cr: 12.8 kN
UCT201CShaft d: 12 mm | Base unit: UCT201 | Cover, open end | Bearing: UC201 | Cr: 12.8 kN
UCT201CDShaft d: 12 mm | Base unit: UCT201 | Cover, closed end | Bearing: UC201 | Cr: 12.8 kN
UCT202Shaft d: 15 mm | Housing: T204 | Bearing: UC202 | Cr: 12.8 kN
UCT202CShaft d: 15 mm | Base unit: UCT202 | Cover, open end | Bearing: UC202 | Cr: 12.8 kN
UCT202CDShaft d: 15 mm | Base unit: UCT202 | Cover, closed end | Bearing: UC202 | Cr: 12.8 kN
UCT203Shaft d: 17 mm | Housing: T204 | Bearing: UC203 | Cr: 12.8 kN
UCT203CShaft d: 17 mm | Base unit: UCT203 | Cover, open end | Bearing: UC203 | Cr: 12.8 kN
UCT203CDShaft d: 17 mm | Base unit: UCT203 | Cover, closed end | Bearing: UC203 | Cr: 12.8 kN
UCT204Shaft d: 20 mm | Housing: T204 | Bearing: UC204 | Cr: 12.8 kN
UCT204CShaft d: 20 mm | Base unit: UCT204 | Cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCT204CDShaft d: 20 mm | Base unit: UCT204 | Cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCT204FCShaft d: 20 mm | Base unit: UCT204 | Cast iron cover, open end | Bearing: UC204 | Cr: 12.8 kN
UCT204FCDShaft d: 20 mm | Base unit: UCT204 | Cast iron cover, closed end | Bearing: UC204 | Cr: 12.8 kN
UCT205Shaft d: 25 mm | Housing: T205 | Bearing: UC205 | Cr: 14.0 kN
UCT205CShaft d: 25 mm | Base unit: UCT205 | Cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCT205CDShaft d: 25 mm | Base unit: UCT205 | Cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCT205FCShaft d: 25 mm | Base unit: UCT205 | Cast iron cover, open end | Bearing: UC205 | Cr: 14.0 kN
UCT205FCDShaft d: 25 mm | Base unit: UCT205 | Cast iron cover, closed end | Bearing: UC205 | Cr: 14.0 kN
UCTX05Shaft d: 25 mm | Housing: TX05 | Bearing: UCX05 | Cr: 19.5 kN
UCTX05CShaft d: 25 mm | Base unit: UCTX05 | Cover, open end | Bearing: UCX05 | Cr: 19.5 kN
UCTX05CDShaft d: 25 mm | Base unit: UCTX05 | Cover, closed end | Bearing: UCX05 | Cr: 19.5 kN
UCT305Shaft d: 25 mm | Housing: T305 | Bearing: UC305 | Cr: 21.2 kN
UCT305CShaft d: 25 mm | Base unit: UCT305 | Cover, open end | Bearing: UC305 | Cr: 21.2 kN
UCT305CDShaft d: 25 mm | Base unit: UCT305 | Cover, closed end | Bearing: UC305 | Cr: 21.2 kN
UCT206Shaft d: 30 mm | Housing: T206 | Bearing: UC206 | Cr: 19.5 kN
UCT206CShaft d: 30 mm | Base unit: UCT206 | Cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCT206CDShaft d: 30 mm | Base unit: UCT206 | Cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCT206FCShaft d: 30 mm | Base unit: UCT206 | Cast iron cover, open end | Bearing: UC206 | Cr: 19.5 kN
UCT206FCDShaft d: 30 mm | Base unit: UCT206 | Cast iron cover, closed end | Bearing: UC206 | Cr: 19.5 kN
UCTX06Shaft d: 30 mm | Housing: TX06 | Bearing: UCX06 | Cr: 25.7 kN
UCTX06CShaft d: 30 mm | Base unit: UCTX06 | Cover, open end | Bearing: UCX06 | Cr: 25.7 kN
UCTX06CDShaft d: 30 mm | Base unit: UCTX06 | Cover, closed end | Bearing: UCX06 | Cr: 25.7 kN
UCT306Shaft d: 30 mm | Housing: T306 | Bearing: UC306 | Cr: 26.7 kN
UCT306CShaft d: 30 mm | Base unit: UCT306 | Cover, open end | Bearing: UC306 | Cr: 26.7 kN
UCT306CDShaft d: 30 mm | Base unit: UCT306 | Cover, closed end | Bearing: UC306 | Cr: 26.7 kN
UCT207Shaft d: 35 mm | Housing: T207 | Bearing: UC207 | Cr: 25.7 kN
UCT207CShaft d: 35 mm | Base unit: UCT207 | Cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCT207CDShaft d: 35 mm | Base unit: UCT207 | Cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCT207FCShaft d: 35 mm | Base unit: UCT207 | Cast iron cover, open end | Bearing: UC207 | Cr: 25.7 kN
UCT207FCDShaft d: 35 mm | Base unit: UCT207 | Cast iron cover, closed end | Bearing: UC207 | Cr: 25.7 kN
UCTX07Shaft d: 35 mm | Housing: TX07 | Bearing: UCX07 | Cr: 29.1 kN
UCTX07CShaft d: 35 mm | Base unit: UCTX07 | Cover, open end | Bearing: UCX07 | Cr: 29.1 kN
UCTX07CDShaft d: 35 mm | Base unit: UCTX07 | Cover, closed end | Bearing: UCX07 | Cr: 29.1 kN
UCT307Shaft d: 35 mm | Housing: T307 | Bearing: UC307 | Cr: 33.4 kN
UCT307CShaft d: 35 mm | Base unit: UCT307 | Cover, open end | Bearing: UC307 | Cr: 33.4 kN
UCT307CDShaft d: 35 mm | Base unit: UCT307 | Cover, closed end | Bearing: UC307 | Cr: 33.4 kN
UCT208Shaft d: 40 mm | Housing: T208 | Bearing: UC208 | Cr: 29.1 kN
UCT208CShaft d: 40 mm | Base unit: UCT208 | Cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCT208CDShaft d: 40 mm | Base unit: UCT208 | Cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCT208FCShaft d: 40 mm | Base unit: UCT208 | Cast iron cover, open end | Bearing: UC208 | Cr: 29.1 kN
UCT208FCDShaft d: 40 mm | Base unit: UCT208 | Cast iron cover, closed end | Bearing: UC208 | Cr: 29.1 kN
UCTX08Shaft d: 40 mm | Housing: TX08 | Bearing: UCX08 | Cr: 32.7 kN
UCTX08CShaft d: 40 mm | Base unit: UCTX08 | Cover, open end | Bearing: UCX08 | Cr: 32.7 kN
UCTX08CDShaft d: 40 mm | Base unit: UCTX08 | Cover, closed end | Bearing: UCX08 | Cr: 32.7 kN
UCT308Shaft d: 40 mm | Housing: T308 | Bearing: UC308 | Cr: 40.7 kN
UCT308CShaft d: 40 mm | Base unit: UCT308 | Cover, open end | Bearing: UC308 | Cr: 40.7 kN
UCT308CDShaft d: 40 mm | Base unit: UCT308 | Cover, closed end | Bearing: UC308 | Cr: 40.7 kN
UCT209Shaft d: 45 mm | Housing: T209 | Bearing: UC209 | Cr: 32.7 kN
UCT209CShaft d: 45 mm | Base unit: UCT209 | Cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCT209CDShaft d: 45 mm | Base unit: UCT209 | Cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCT209FCShaft d: 45 mm | Base unit: UCT209 | Cast iron cover, open end | Bearing: UC209 | Cr: 32.7 kN
UCT209FCDShaft d: 45 mm | Base unit: UCT209 | Cast iron cover, closed end | Bearing: UC209 | Cr: 32.7 kN
UCTX09Shaft d: 45 mm | Housing: TX09 | Bearing: UCX09 | Cr: 35.1 kN
UCTX09CShaft d: 45 mm | Base unit: UCTX09 | Cover, open end | Bearing: UCX09 | Cr: 35.1 kN
UCTX09CDShaft d: 45 mm | Base unit: UCTX09 | Cover, closed end | Bearing: UCX09 | Cr: 35.1 kN
UCT309Shaft d: 45 mm | Housing: T309 | Bearing: UC309 | Cr: 48.9 kN
UCT309CShaft d: 45 mm | Base unit: UCT309 | Cover, open end | Bearing: UC309 | Cr: 48.9 kN
UCT309CDShaft d: 45 mm | Base unit: UCT309 | Cover, closed end | Bearing: UC309 | Cr: 48.9 kN
UCT210Shaft d: 50 mm | Housing: T210 | Bearing: UC210 | Cr: 35.1 kN
UCT210CShaft d: 50 mm | Base unit: UCT210 | Cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCT210CDShaft d: 50 mm | Base unit: UCT210 | Cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCT210FCShaft d: 50 mm | Base unit: UCT210 | Cast iron cover, open end | Bearing: UC210 | Cr: 35.1 kN
UCT210FCDShaft d: 50 mm | Base unit: UCT210 | Cast iron cover, closed end | Bearing: UC210 | Cr: 35.1 kN
UCTX10Shaft d: 50 mm | Housing: TX10 | Bearing: UCX10 | Cr: 43.4 kN
UCTX10CShaft d: 50 mm | Base unit: UCTX10 | Cover, open end | Bearing: UCX10 | Cr: 43.4 kN
UCTX10CDShaft d: 50 mm | Base unit: UCTX10 | Cover, closed end | Bearing: UCX10 | Cr: 43.4 kN
UCT310Shaft d: 50 mm | Housing: T310 | Bearing: UC310 | Cr: 62.0 kN
UCT310CShaft d: 50 mm | Base unit: UCT310 | Cover, open end | Bearing: UC310 | Cr: 62.0 kN
UCT310CDShaft d: 50 mm | Base unit: UCT310 | Cover, closed end | Bearing: UC310 | Cr: 62.0 kN
UCT211Shaft d: 55 mm | Housing: T211 | Bearing: UC211 | Cr: 43.4 kN
UCT211CShaft d: 55 mm | Base unit: UCT211 | Cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCT211CDShaft d: 55 mm | Base unit: UCT211 | Cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCT211FCShaft d: 55 mm | Base unit: UCT211 | Cast iron cover, open end | Bearing: UC211 | Cr: 43.4 kN
UCT211FCDShaft d: 55 mm | Base unit: UCT211 | Cast iron cover, closed end | Bearing: UC211 | Cr: 43.4 kN
UCTX11Shaft d: 55 mm | Housing: TX11 | Bearing: UCX11 | Cr: 52.4 kN
UCTX11CShaft d: 55 mm | Base unit: UCTX11 | Cover, open end | Bearing: UCX11 | Cr: 52.4 kN
UCTX11CDShaft d: 55 mm | Base unit: UCTX11 | Cover, closed end | Bearing: UCX11 | Cr: 52.4 kN
UCT311Shaft d: 55 mm | Housing: T311 | Bearing: UC311 | Cr: 71.6 kN
UCT311CShaft d: 55 mm | Base unit: UCT311 | Cover, open end | Bearing: UC311 | Cr: 71.6 kN
UCT311CDShaft d: 55 mm | Base unit: UCT311 | Cover, closed end | Bearing: UC311 | Cr: 71.6 kN
UCT212Shaft d: 60 mm | Housing: T212 | Bearing: UC212 | Cr: 52.4 kN
UCT212CShaft d: 60 mm | Base unit: UCT212 | Cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCT212CDShaft d: 60 mm | Base unit: UCT212 | Cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCT212FCShaft d: 60 mm | Base unit: UCT212 | Cast iron cover, open end | Bearing: UC212 | Cr: 52.4 kN
UCT212FCDShaft d: 60 mm | Base unit: UCT212 | Cast iron cover, closed end | Bearing: UC212 | Cr: 52.4 kN
UCTX12Shaft d: 60 mm | Housing: TX12 | Bearing: UCX12 | Cr: 57.2 kN
UCTX12CShaft d: 60 mm | Base unit: UCTX12 | Cover, open end | Bearing: UCX12 | Cr: 57.2 kN
UCTX12CDShaft d: 60 mm | Base unit: UCTX12 | Cover, closed end | Bearing: UCX12 | Cr: 57.2 kN
UCT312Shaft d: 60 mm | Housing: T312 | Bearing: UC312 | Cr: 81.9 kN
UCT312CShaft d: 60 mm | Base unit: UCT312 | Cover, open end | Bearing: UC312 | Cr: 81.9 kN
UCT312CDShaft d: 60 mm | Base unit: UCT312 | Cover, closed end | Bearing: UC312 | Cr: 81.9 kN
UCT213Shaft d: 65 mm | Housing: T213 | Bearing: UC213 | Cr: 57.2 kN
UCT213CShaft d: 65 mm | Base unit: UCT213 | Cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCT213CDShaft d: 65 mm | Base unit: UCT213 | Cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCT213FCShaft d: 65 mm | Base unit: UCT213 | Cast iron cover, open end | Bearing: UC213 | Cr: 57.2 kN
UCT213FCDShaft d: 65 mm | Base unit: UCT213 | Cast iron cover, closed end | Bearing: UC213 | Cr: 57.2 kN
UCTX13Shaft d: 65 mm | Housing: TX13 | Bearing: UCX13 | Cr: 62.2 kN
UCTX13CShaft d: 65 mm | Base unit: UCTX13 | Cover, open end | Bearing: UCX13 | Cr: 62.2 kN
UCTX13CDShaft d: 65 mm | Base unit: UCTX13 | Cover, closed end | Bearing: UCX13 | Cr: 62.2 kN
UCT313Shaft d: 65 mm | Housing: T313 | Bearing: UC313 | Cr: 92.7 kN
UCT313CShaft d: 65 mm | Base unit: UCT313 | Cover, open end | Bearing: UC313 | Cr: 92.7 kN
UCT313CDShaft d: 65 mm | Base unit: UCT313 | Cover, closed end | Bearing: UC313 | Cr: 92.7 kN
UCT214Shaft d: 70 mm | Housing: T214 | Bearing: UC214 | Cr: 62.2 kN
UCT214CShaft d: 70 mm | Base unit: UCT214 | Cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCT214CDShaft d: 70 mm | Base unit: UCT214 | Cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCT214FCShaft d: 70 mm | Base unit: UCT214 | Cast iron cover, open end | Bearing: UC214 | Cr: 62.2 kN
UCT214FCDShaft d: 70 mm | Base unit: UCT214 | Cast iron cover, closed end | Bearing: UC214 | Cr: 62.2 kN
UCTX14Shaft d: 70 mm | Housing: TX14 | Bearing: UCX14 | Cr: 67.4 kN
UCTX14CShaft d: 70 mm | Base unit: UCTX14 | Cover, open end | Bearing: UCX14 | Cr: 67.4 kN
UCTX14CDShaft d: 70 mm | Base unit: UCTX14 | Cover, closed end | Bearing: UCX14 | Cr: 67.4 kN
UCT314Shaft d: 70 mm | Housing: T314 | Bearing: UC314 | Cr: 104 kN
UCT314CShaft d: 70 mm | Base unit: UCT314 | Cover, open end | Bearing: UC314 | Cr: 104 kN
UCT314CDShaft d: 70 mm | Base unit: UCT314 | Cover, closed end | Bearing: UC314 | Cr: 104 kN
UCT215Shaft d: 75 mm | Housing: T215 | Bearing: UC215 | Cr: 67.4 kN
UCT215CShaft d: 75 mm | Base unit: UCT215 | Cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCT215CDShaft d: 75 mm | Base unit: UCT215 | Cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCT215FCShaft d: 75 mm | Base unit: UCT215 | Cast iron cover, open end | Bearing: UC215 | Cr: 67.4 kN
UCT215FCDShaft d: 75 mm | Base unit: UCT215 | Cast iron cover, closed end | Bearing: UC215 | Cr: 67.4 kN
UCTX15Shaft d: 75 mm | Housing: TX15 | Bearing: UCX15 | Cr: 72.7 kN
UCTX15CShaft d: 75 mm | Base unit: UCTX15 | Cover, open end | Bearing: UCX15 | Cr: 72.7 kN
UCTX15CDShaft d: 75 mm | Base unit: UCTX15 | Cover, closed end | Bearing: UCX15 | Cr: 72.7 kN
UCT315Shaft d: 75 mm | Housing: T315 | Bearing: UC315 | Cr: 113 kN
UCT315CShaft d: 75 mm | Base unit: UCT315 | Cover, open end | Bearing: UC315 | Cr: 113 kN
UCT315CDShaft d: 75 mm | Base unit: UCT315 | Cover, closed end | Bearing: UC315 | Cr: 113 kN
UCT216Shaft d: 80 mm | Housing: T216 | Bearing: UC216 | Cr: 72.7 kN
UCT216CShaft d: 80 mm | Base unit: UCT216 | Cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCT216CDShaft d: 80 mm | Base unit: UCT216 | Cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCT216FCShaft d: 80 mm | Base unit: UCT216 | Cast iron cover, open end | Bearing: UC216 | Cr: 72.7 kN
UCT216FCDShaft d: 80 mm | Base unit: UCT216 | Cast iron cover, closed end | Bearing: UC216 | Cr: 72.7 kN
UCTX16Shaft d: 80 mm | Housing: TX16 | Bearing: UCX16 | Cr: 84.0 kN
UCTX16CShaft d: 80 mm | Base unit: UCTX16 | Cover, open end | Bearing: UCX16 | Cr: 84.0 kN
UCTX16CDShaft d: 80 mm | Base unit: UCTX16 | Cover, closed end | Bearing: UCX16 | Cr: 84.0 kN
UCT316Shaft d: 80 mm | Housing: T316 | Bearing: UC316 | Cr: 123 kN
UCT316CShaft d: 80 mm | Base unit: UCT316 | Cover, open end | Bearing: UC316 | Cr: 123 kN
UCT316CDShaft d: 80 mm | Base unit: UCT316 | Cover, closed end | Bearing: UC316 | Cr: 123 kN
UCT217Shaft d: 85 mm | Housing: T217 | Bearing: UC217 | Cr: 84.0 kN
UCT217CShaft d: 85 mm | Base unit: UCT217 | Cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCT217CDShaft d: 85 mm | Base unit: UCT217 | Cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCT217FCShaft d: 85 mm | Base unit: UCT217 | Cast iron cover, open end | Bearing: UC217 | Cr: 84.0 kN
UCT217FCDShaft d: 85 mm | Base unit: UCT217 | Cast iron cover, closed end | Bearing: UC217 | Cr: 84.0 kN
UCTX17Shaft d: 85 mm | Housing: TX17 | Bearing: UCX17 | Cr: 96.1 kN
UCTX17CShaft d: 85 mm | Base unit: UCTX17 | Cover, open end | Bearing: UCX17 | Cr: 96.1 kN
UCTX17CDShaft d: 85 mm | Base unit: UCTX17 | Cover, closed end | Bearing: UCX17 | Cr: 96.1 kN
UCT317Shaft d: 85 mm | Housing: T317 | Bearing: UC317 | Cr: 133 kN
UCT317CShaft d: 85 mm | Base unit: UCT317 | Cover, open end | Bearing: UC317 | Cr: 133 kN
UCT317CDShaft d: 85 mm | Base unit: UCT317 | Cover, closed end | Bearing: UC317 | Cr: 133 kN
UCT318Shaft d: 90 mm | Housing: T318 | Bearing: UC318 | Cr: 143 kN
UCT318CShaft d: 90 mm | Base unit: UCT318 | Cover, open end | Bearing: UC318 | Cr: 143 kN
UCT318CDShaft d: 90 mm | Base unit: UCT318 | Cover, closed end | Bearing: UC318 | Cr: 143 kN
UCT319Shaft d: 95 mm | Housing: T319 | Bearing: UC319 | Cr: 153 kN
UCT319CShaft d: 95 mm | Base unit: UCT319 | Cover, open end | Bearing: UC319 | Cr: 153 kN
UCT319CDShaft d: 95 mm | Base unit: UCT319 | Cover, closed end | Bearing: UC319 | Cr: 153 kN
UCT320Shaft d: 100 mm | Housing: T320 | Bearing: UC320 | Cr: 173 kN
UCT320CShaft d: 100 mm | Base unit: UCT320 | Cover, open end | Bearing: UC320 | Cr: 173 kN
UCT320CDShaft d: 100 mm | Base unit: UCT320 | Cover, closed end | Bearing: UC320 | Cr: 173 kN
UCT321Shaft d: 105 mm | Housing: T321 | Bearing: UC321 | Cr: 184 kN
UCT321CShaft d: 105 mm | Base unit: UCT321 | Cover, open end | Bearing: UC321 | Cr: 184 kN
UCT321CDShaft d: 105 mm | Base unit: UCT321 | Cover, closed end | Bearing: UC321 | Cr: 184 kN
UCT322Shaft d: 110 mm | Housing: T322 | Bearing: UC322 | Cr: 205 kN
UCT322CShaft d: 110 mm | Base unit: UCT322 | Cover, open end | Bearing: UC322 | Cr: 205 kN
UCT322CDShaft d: 110 mm | Base unit: UCT322 | Cover, closed end | Bearing: UC322 | Cr: 205 kN
UCT324Shaft d: 120 mm | Housing: T324 | Bearing: UC324 | Cr: 207 kN
UCT324CShaft d: 120 mm | Base unit: UCT324 | Cover, open end | Bearing: UC324 | Cr: 207 kN
UCT324CDShaft d: 120 mm | Base unit: UCT324 | Cover, closed end | Bearing: UC324 | Cr: 207 kN
UCT326Shaft d: 130 mm | Housing: T326 | Bearing: UC326 | Cr: 229 kN
UCT326CShaft d: 130 mm | Base unit: UCT326 | Cover, open end | Bearing: UC326 | Cr: 229 kN
UCT326CDShaft d: 130 mm | Base unit: UCT326 | Cover, closed end | Bearing: UC326 | Cr: 229 kN
UCT328Shaft d: 140 mm | Housing: T328 | Bearing: UC328 | Cr: 253 kN
UCT328CShaft d: 140 mm | Base unit: UCT328 | Cover, open end | Bearing: UC328 | Cr: 253 kN
UCT328CDShaft d: 140 mm | Base unit: UCT328 | Cover, closed end | Bearing: UC328 | Cr: 253 kN

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
