KOYO UFL Compact Series Rhombic Flanged Units

KOYO UFL Compact Series Rhombic Flanged Units

"Compact" series 2-bolt rhombic flanged units with light alloy housing and SU insert bearings.

Key features

  • Pre-lubricated sealed ball bearing insert
  • Spherical seating compensates for shaft misalignment
  • Housing and insert replaceable separately
  • Unit number, housing number and insert bearing listed
  • Shaft diameter given in mm

Specifications

Product type Ball bearing unit
Series UFL Compact Flange Units
Seal Insert bearing sealed both sides
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B506-B507
UFL08 Shaft d: 8 mm | Housing: FL08 | Bearing: SU08 | Cr: 3.27 kN
UFL000 Shaft d: 10 mm | Housing: FL000 | Bearing: SU000 | Cr: 4.55 kN
UFL000C Shaft d: 10 mm | Base unit: UFL000 | Cover, open end | Bearing: SU000 | Cr: 4.55 kN
UFL000D Shaft d: 10 mm | Base unit: UFL000 | Cover, closed end | Bearing: SU000 | Cr: 4.55 kN
UFL001 Shaft d: 12 mm | Housing: FL001 | Bearing: SU001 | Cr: 5.10 kN
UFL001C Shaft d: 12 mm | Base unit: UFL001 | Cover, open end | Bearing: SU001 | Cr: 5.10 kN
UFL001D Shaft d: 12 mm | Base unit: UFL001 | Cover, closed end | Bearing: SU001 | Cr: 5.10 kN
UFL002 Shaft d: 15 mm | Housing: FL002 | Bearing: SU002 | Cr: 5.60 kN
UFL002C Shaft d: 15 mm | Base unit: UFL002 | Cover, open end | Bearing: SU002 | Cr: 5.60 kN
UFL002D Shaft d: 15 mm | Base unit: UFL002 | Cover, closed end | Bearing: SU002 | Cr: 5.60 kN
UFL003 Shaft d: 17 mm | Housing: FL003 | Bearing: SU003 | Cr: 6.00 kN
UFL003C Shaft d: 17 mm | Base unit: UFL003 | Cover, open end | Bearing: SU003 | Cr: 6.00 kN
UFL003D Shaft d: 17 mm | Base unit: UFL003 | Cover, closed end | Bearing: SU003 | Cr: 6.00 kN
UFL004 Shaft d: 20 mm | Housing: FL004 | Bearing: SU004 | Cr: 9.40 kN
UFL004C Shaft d: 20 mm | Base unit: UFL004 | Cover, open end | Bearing: SU004 | Cr: 9.40 kN
UFL004D Shaft d: 20 mm | Base unit: UFL004 | Cover, closed end | Bearing: SU004 | Cr: 9.40 kN
UFL005 Shaft d: 25 mm | Housing: FL005 | Bearing: SU005 | Cr: 10.1 kN
UFL005C Shaft d: 25 mm | Base unit: UFL005 | Cover, open end | Bearing: SU005 | Cr: 10.1 kN
UFL005D Shaft d: 25 mm | Base unit: UFL005 | Cover, closed end | Bearing: SU005 | Cr: 10.1 kN
UFL006 Shaft d: 30 mm | Housing: FL006 | Bearing: SU006 | Cr: 13.2 kN
UFL006C Shaft d: 30 mm | Base unit: UFL006 | Cover, open end | Bearing: SU006 | Cr: 13.2 kN
UFL006D Shaft d: 30 mm | Base unit: UFL006 | Cover, closed end | Bearing: SU006 | Cr: 13.2 kN
Mounted Bearing UnitsKOYO
22 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOYO UFL Compact Series Rhombic Flanged Units

Brand KOYO·Mounted Bearing Units

Available part numbers (22)

UFL08, UFL000, UFL000C, UFL000D, UFL001, UFL001C, UFL001D, UFL002, UFL002C, UFL002D + 12 more — see full table ↓

How to order

Send the KOYO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UFL08Shaft d: 8 mm | Housing: FL08 | Bearing: SU08 | Cr: 3.27 kN
UFL000Shaft d: 10 mm | Housing: FL000 | Bearing: SU000 | Cr: 4.55 kN
UFL000CShaft d: 10 mm | Base unit: UFL000 | Cover, open end | Bearing: SU000 | Cr: 4.55 kN
UFL000DShaft d: 10 mm | Base unit: UFL000 | Cover, closed end | Bearing: SU000 | Cr: 4.55 kN
UFL001Shaft d: 12 mm | Housing: FL001 | Bearing: SU001 | Cr: 5.10 kN
UFL001CShaft d: 12 mm | Base unit: UFL001 | Cover, open end | Bearing: SU001 | Cr: 5.10 kN
UFL001DShaft d: 12 mm | Base unit: UFL001 | Cover, closed end | Bearing: SU001 | Cr: 5.10 kN
UFL002Shaft d: 15 mm | Housing: FL002 | Bearing: SU002 | Cr: 5.60 kN
UFL002CShaft d: 15 mm | Base unit: UFL002 | Cover, open end | Bearing: SU002 | Cr: 5.60 kN
UFL002DShaft d: 15 mm | Base unit: UFL002 | Cover, closed end | Bearing: SU002 | Cr: 5.60 kN
UFL003Shaft d: 17 mm | Housing: FL003 | Bearing: SU003 | Cr: 6.00 kN
UFL003CShaft d: 17 mm | Base unit: UFL003 | Cover, open end | Bearing: SU003 | Cr: 6.00 kN
UFL003DShaft d: 17 mm | Base unit: UFL003 | Cover, closed end | Bearing: SU003 | Cr: 6.00 kN
UFL004Shaft d: 20 mm | Housing: FL004 | Bearing: SU004 | Cr: 9.40 kN
UFL004CShaft d: 20 mm | Base unit: UFL004 | Cover, open end | Bearing: SU004 | Cr: 9.40 kN
UFL004DShaft d: 20 mm | Base unit: UFL004 | Cover, closed end | Bearing: SU004 | Cr: 9.40 kN
UFL005Shaft d: 25 mm | Housing: FL005 | Bearing: SU005 | Cr: 10.1 kN
UFL005CShaft d: 25 mm | Base unit: UFL005 | Cover, open end | Bearing: SU005 | Cr: 10.1 kN
UFL005DShaft d: 25 mm | Base unit: UFL005 | Cover, closed end | Bearing: SU005 | Cr: 10.1 kN
UFL006Shaft d: 30 mm | Housing: FL006 | Bearing: SU006 | Cr: 13.2 kN
UFL006CShaft d: 30 mm | Base unit: UFL006 | Cover, open end | Bearing: SU006 | Cr: 13.2 kN
UFL006DShaft d: 30 mm | Base unit: UFL006 | Cover, closed end | Bearing: SU006 | Cr: 13.2 kN
