KOYO V 5, 6 One-Piece Plummer Block Housings

KOYO V 5, 6 One-Piece Plummer Block Housings

One-piece (non-split) plummer block housings of the V 5 and 6 series for self-aligning ball bearings and spherical roller bearings.

Key features

  • Cast iron housing with grease nipple and drain plug
  • Fixed or free side arrangement with stabilizing rings
  • For self-aligning ball and spherical roller bearings
  • Applicable bearings, adapters and oil seals listed
  • Housing mass given for reference

Specifications

Product type Plummer block housing
Series V
Lubrication Grease nipple R 1/8
Supplied Housing only (bearing, adapter, seals separate)
Source KOYO Ball & Roller Bearings catalogue (Bearing specification tables), p. B570-B575
V607 Shaft d1: 30 mm | D: 80 mm | H: 60 mm | Bearings: 1307K, 2307K | Mass: 4.8 kg
V508 Shaft d1: 35 mm | D: 80 mm | H: 60 mm | Bearings: 1208K, 2208K, 22208RHRK | Mass: 4.4 kg
V608 Shaft d1: 35 mm | D: 90 mm | H: 67 mm | Bearings: 1308K, 21308RHK, 2308K | Mass: 5.1 kg
V509 Shaft d1: 40 mm | D: 85 mm | H: 63 mm | Bearings: 1209K, 2209K, 22209RHRK | Mass: 4.6 kg
V609 Shaft d1: 40 mm | D: 100 mm | H: 71 mm | Bearings: 1309K, 21309RHK, 2309K | Mass: 6.6 kg
V510 Shaft d1: 45 mm | D: 90 mm | H: 67 mm | Bearings: 1210K, 2210K, 22210RHRK | Mass: 4.7 kg
V610 Shaft d1: 45 mm | D: 110 mm | H: 80 mm | Bearings: 1310K, 21310RHK, 2310K | Mass: 8.3 kg
V511 Shaft d1: 50 mm | D: 100 mm | H: 71 mm | Bearings: 1211K, 2211K, 22211RHRK | Mass: 6.2 kg
V611 Shaft d1: 50 mm | D: 120 mm | H: 85 mm | Bearings: 1311K, 21311RHK, 2311K | Mass: 10 kg
V512 Shaft d1: 55 mm | D: 110 mm | H: 80 mm | Bearings: 1212K, 2212K, 22212RHRK | Mass: 7.6 kg
V612 Shaft d1: 55 mm | D: 130 mm | H: 90 mm | Bearings: 1312K, 21312RHK, 2312K | Mass: 11 kg
V513 Shaft d1: 60 mm | D: 120 mm | H: 85 mm | Bearings: 1213K, 2213K, 22213RHRK | Mass: 9.9 kg
V514 Shaft d1: 60 mm | D: 125 mm | H: 90 mm | Bearings: 22214RHRK | Mass: 10 kg
V613 Shaft d1: 60 mm | D: 140 mm | H: 100 mm | Bearings: 1313K, 21313RHK, 2313K | Mass: 17 kg
V614 Shaft d1: 60 mm | D: 150 mm | H: 100 mm | Bearings: 21314RHK, 22314RHRK | Mass: 16 kg
V515 Shaft d1: 65 mm | D: 130 mm | H: 90 mm | Bearings: 1215K, 2215K, 22215RHRK | Mass: 10 kg
V615 Shaft d1: 65 mm | D: 160 mm | H: 112 mm | Bearings: 1315K, 21315RHK, 2315K | Mass: 23 kg
V516 Shaft d1: 70 mm | D: 140 mm | H: 100 mm | Bearings: 1216K, 2216K, 22216RHRK | Mass: 16 kg
V616 Shaft d1: 70 mm | D: 170 mm | H: 112 mm | Bearings: 1316K, 21316RHK, 2316K | Mass: 22 kg
V517 Shaft d1: 75 mm | D: 150 mm | H: 100 mm | Bearings: 1217K, 2217K, 22217RHRK | Mass: 15 kg
V617 Shaft d1: 75 mm | D: 180 mm | H: 125 mm | Bearings: 1317K, 21317RHK, 2317K | Mass: 28 kg
V518 Shaft d1: 80 mm | D: 160 mm | H: 112 mm | Bearings: 1218K, 2218K, 22218RHRK | Mass: 22 kg
V618 Shaft d1: 80 mm | D: 190 mm | H: 125 mm | Bearings: 1318K, 21318RHK, 2318K | Mass: 27 kg
V519 Shaft d1: 85 mm | D: 170 mm | H: 112 mm | Bearings: 1219K, 2219K, 22219RHRK | Mass: 21 kg
V619 Shaft d1: 85 mm | D: 200 mm | H: 132 mm | Bearings: 1319K, 21319RHK, 2319K | Mass: 37 kg
V520 Shaft d1: 90 mm | D: 180 mm | H: 125 mm | Bearings: 1220K, 2220K, 22220RHRK | Mass: 27 kg
V620 Shaft d1: 90 mm | D: 215 mm | H: 140 mm | Bearings: 1320K, 21320RHK, 2320K | Mass: 40 kg
V522 Shaft d1: 100 mm | D: 200 mm | H: 132 mm | Bearings: 1222K, 2222K, 22222RHRK | Mass: 36 kg
V622 Shaft d1: 100 mm | D: 240 mm | H: 160 mm | Bearings: 1322K, 21322RHK, 2322K | Mass: 56 kg
V524 Shaft d1: 110 mm | D: 215 mm | H: 140 mm | Bearings: 22224RHRK, 23224RHK | Mass: 39 kg
V624 Shaft d1: 110 mm | D: 260 mm | H: 170 mm | Bearings: 22324RHRK | Mass: 71 kg
V526 Shaft d1: 115 mm | D: 230 mm | H: 150 mm | Bearings: 22226RHRK, 23226RHK | Mass: 48 kg
V626 Shaft d1: 115 mm | D: 280 mm | H: 180 mm | Bearings: 22326RHRK | Mass: 82 kg
V528 Shaft d1: 125 mm | D: 250 mm | H: 160 mm | Bearings: 22228RHRK, 23228RHK | Mass: 54 kg
V628 Shaft d1: 125 mm | D: 300 mm | H: 190 mm | Bearings: 22328RK | Mass: 101 kg
V530 Shaft d1: 135 mm | D: 270 mm | H: 170 mm | Bearings: 22230RHRK, 23230RHK | Mass: 64 kg
V630 Shaft d1: 135 mm | D: 320 mm | H: 200 mm | Bearings: 22330RK | Mass: 129 kg
V532 Shaft d1: 140 mm | D: 290 mm | H: 190 mm | Bearings: 22232RK, 23232RK | Mass: 92 kg
V632 Shaft d1: 140 mm | D: 340 mm | H: 212 mm | Bearings: 22332RK | Mass: 149 kg
V534 Shaft d1: 150 mm | D: 310 mm | H: 200 mm | Bearings: 22234RK, 23234RK | Mass: 110 kg
V536 Shaft d1: 160 mm | D: 320 mm | H: 200 mm | Bearings: 22236RK, 23236RK | Mass: 110 kg
V538 Shaft d1: 170 mm | D: 340 mm | H: 212 mm | Bearings: 22238RK, 23238RK | Mass: 130 kg
