KYK SR Locating Rings for SN Plummer Blocks

KYK SR Locating Rings for SN Plummer Blocks

KYK SR locating rings used in SN plummer block housings to fix the bearing axially at the locating (fixed) side.

Key features

  • Designation gives housing seat diameter x ring width in mm
  • Fitted on either side of the bearing outer ring in the housing
  • Quantity per housing (1 or 2) depends on the bearing listed in the selection table
  • Selected together with the bearing and adapter sleeve for each SN housing

Specifications

Brand KYK
Product Locating ring for plummer block
Use SN 500 / SN 600 housings
Dimensions mm
Quantity 1 or 2 per housing as listed
Source KYK Bearing Catalogue, p. 93-95
SR52x5 Outside diameter: 52 mm | Width: 5 mm | Housing: SN plummer block
SR52x7 Outside diameter: 52 mm | Width: 7 mm | Housing: SN plummer block
SR62x8.5 Outside diameter: 62 mm | Width: 8.5 mm | Housing: SN plummer block
SR62x10 Outside diameter: 62 mm | Width: 10 mm | Housing: SN plummer block
SR62x7 Outside diameter: 62 mm | Width: 7 mm | Housing: SN plummer block
SR72x9 Outside diameter: 72 mm | Width: 9 mm | Housing: SN plummer block
SR72x10 Outside diameter: 72 mm | Width: 10 mm | Housing: SN plummer block
SR72x8 Outside diameter: 72 mm | Width: 8 mm | Housing: SN plummer block
SR80x10 Outside diameter: 80 mm | Width: 10 mm | Housing: SN plummer block
SR80x7.5 Outside diameter: 80 mm | Width: 7.5 mm | Housing: SN plummer block
SR90x10 Outside diameter: 90 mm | Width: 10 mm | Housing: SN plummer block
SR85x6 Outside diameter: 85 mm | Width: 6 mm | Housing: SN plummer block
SR85x8 Outside diameter: 85 mm | Width: 8 mm | Housing: SN plummer block
SR100x10.5 Outside diameter: 100 mm | Width: 10.5 mm | Housing: SN plummer block
SR100x10 Outside diameter: 100 mm | Width: 10 mm | Housing: SN plummer block
SR90x6.5 Outside diameter: 90 mm | Width: 6.5 mm | Housing: SN plummer block
SR110x11.5 Outside diameter: 110 mm | Width: 11.5 mm | Housing: SN plummer block
SR110x10 Outside diameter: 110 mm | Width: 10 mm | Housing: SN plummer block
SR100x6 Outside diameter: 100 mm | Width: 6 mm | Housing: SN plummer block
SR100x8 Outside diameter: 100 mm | Width: 8 mm | Housing: SN plummer block
SR120x12 Outside diameter: 120 mm | Width: 12 mm | Housing: SN plummer block
SR120x10 Outside diameter: 120 mm | Width: 10 mm | Housing: SN plummer block
SR110x8 Outside diameter: 110 mm | Width: 8 mm | Housing: SN plummer block
SR130x12.5 Outside diameter: 130 mm | Width: 12.5 mm | Housing: SN plummer block
SR130x10 Outside diameter: 130 mm | Width: 10 mm | Housing: SN plummer block
SR140x12.5 Outside diameter: 140 mm | Width: 12.5 mm | Housing: SN plummer block
SR140x10 Outside diameter: 140 mm | Width: 10 mm | Housing: SN plummer block
SR130x8 Outside diameter: 130 mm | Width: 8 mm | Housing: SN plummer block
SR160x14 Outside diameter: 160 mm | Width: 14 mm | Housing: SN plummer block
SR160x10 Outside diameter: 160 mm | Width: 10 mm | Housing: SN plummer block
SR140x8.5 Outside diameter: 140 mm | Width: 8.5 mm | Housing: SN plummer block
SR170x14.5 Outside diameter: 170 mm | Width: 14.5 mm | Housing: SN plummer block
SR170x10 Outside diameter: 170 mm | Width: 10 mm | Housing: SN plummer block
SR150x9 Outside diameter: 150 mm | Width: 9 mm | Housing: SN plummer block
SR150x10 Outside diameter: 150 mm | Width: 10 mm | Housing: SN plummer block
SR180x14.5 Outside diameter: 180 mm | Width: 14.5 mm | Housing: SN plummer block
SR180x10 Outside diameter: 180 mm | Width: 10 mm | Housing: SN plummer block
SR160x16.2 Outside diameter: 160 mm | Width: 16.2 mm | Housing: SN plummer block
SR160x11.2 Outside diameter: 160 mm | Width: 11.2 mm | Housing: SN plummer block
SR190x15.5 Outside diameter: 190 mm | Width: 15.5 mm | Housing: SN plummer block
SR190x10 Outside diameter: 190 mm | Width: 10 mm | Housing: SN plummer block
SR170x10.5 Outside diameter: 170 mm | Width: 10.5 mm | Housing: SN plummer block
SR200x16 Outside diameter: 200 mm | Width: 16 mm | Housing: SN plummer block
SR200x10 Outside diameter: 200 mm | Width: 10 mm | Housing: SN plummer block
SR180x12.1 Outside diameter: 180 mm | Width: 12.1 mm | Housing: SN plummer block
SR215x18 Outside diameter: 215 mm | Width: 18 mm | Housing: SN plummer block
SR215x10 Outside diameter: 215 mm | Width: 10 mm | Housing: SN plummer block
SR200x13.5 Outside diameter: 200 mm | Width: 13.5 mm | Housing: SN plummer block
SR240x20 Outside diameter: 240 mm | Width: 20 mm | Housing: SN plummer block
SR240x10 Outside diameter: 240 mm | Width: 10 mm | Housing: SN plummer block
SR215x14 Outside diameter: 215 mm | Width: 14 mm | Housing: SN plummer block
SR260x10 Outside diameter: 260 mm | Width: 10 mm | Housing: SN plummer block
SR230x13 Outside diameter: 230 mm | Width: 13 mm | Housing: SN plummer block
SR230x10 Outside diameter: 230 mm | Width: 10 mm | Housing: SN plummer block
SR280x10 Outside diameter: 280 mm | Width: 10 mm | Housing: SN plummer block
SR250x15 Outside diameter: 250 mm | Width: 15 mm | Housing: SN plummer block
SR250x10 Outside diameter: 250 mm | Width: 10 mm | Housing: SN plummer block
SR300x10 Outside diameter: 300 mm | Width: 10 mm | Housing: SN plummer block
SR270x16.5 Outside diameter: 270 mm | Width: 16.5 mm | Housing: SN plummer block
SR270x10 Outside diameter: 270 mm | Width: 10 mm | Housing: SN plummer block
SR320x10 Outside diameter: 320 mm | Width: 10 mm | Housing: SN plummer block
