LuBo LPSFC Spring Guide Retainer (Cast-Die Type)

LuBo LPSFC Spring Guide Retainer (Cast-Die Type)

LuBo LPSFC is a screw-in spring guide retainer for cast die bodies, locating coil die springs on a threaded shank.

Key features

  • GC250 body with SCM435 parts
  • Threaded shank M6-M12 for cast die plates
  • Black oxide finish
  • Pin diameter 14-36 mm, length 12-120 mm
  • Type A (solid) and type B (bored) versions per size

Specifications

Series LPSFC
Material GC250 / SCM435
Finish Black oxide
Thread M6 to M12
Order format LPSFC - D x L (e.g. LPSFC 23X100)
Lead time 7 days (catalogue)
Source LuBo Spring Units catalogue (Spring Guide Retainers)
LPSFC 14X12 Pin dia D: 14 mm | Length L: 12 mm | Thread: M6xP1.0 | Shank D1: 10 mm
LPSFC 14X30 Pin dia D: 14 mm | Length L: 30 mm | Thread: M6xP1.0 | Shank D1: 10 mm
LPSFC 14X60 Pin dia D: 14 mm | Length L: 60 mm | Thread: M6xP1.0 | Shank D1: 10 mm
LPSFC 16X18 Pin dia D: 16 mm | Length L: 18 mm | Thread: M8xP1.25 | Shank D1: 13 mm
LPSFC 16X30 Pin dia D: 16 mm | Length L: 30 mm | Thread: M8xP1.25 | Shank D1: 13 mm
LPSFC 16X60 Pin dia D: 16 mm | Length L: 60 mm | Thread: M8xP1.25 | Shank D1: 13 mm
LPSFC 16X80 Pin dia D: 16 mm | Length L: 80 mm | Thread: M8xP1.25 | Shank D1: 13 mm
LPSFC 19X28 Pin dia D: 19 mm | Length L: 28 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 19X40 Pin dia D: 19 mm | Length L: 40 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 19X60 Pin dia D: 19 mm | Length L: 60 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 19X80 Pin dia D: 19 mm | Length L: 80 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 19X100 Pin dia D: 19 mm | Length L: 100 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 20X23 Pin dia D: 20 mm | Length L: 23 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 20X40 Pin dia D: 20 mm | Length L: 40 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 20X60 Pin dia D: 20 mm | Length L: 60 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 20X80 Pin dia D: 20 mm | Length L: 80 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 20X100 Pin dia D: 20 mm | Length L: 100 mm | Thread: M10xP1.5 | Shank D1: 16 mm
LPSFC 23X30 Pin dia D: 23 mm | Length L: 30 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 23X40 Pin dia D: 23 mm | Length L: 40 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 23X60 Pin dia D: 23 mm | Length L: 60 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 23X80 Pin dia D: 23 mm | Length L: 80 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 23X100 Pin dia D: 23 mm | Length L: 100 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 23X120 Pin dia D: 23 mm | Length L: 120 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 26X28 Pin dia D: 26 mm | Length L: 28 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 26X60 Pin dia D: 26 mm | Length L: 60 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 26X80 Pin dia D: 26 mm | Length L: 80 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 26X100 Pin dia D: 26 mm | Length L: 100 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 26X120 Pin dia D: 26 mm | Length L: 120 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 28X30 Pin dia D: 28 mm | Length L: 30 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 28X40 Pin dia D: 28 mm | Length L: 40 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 28X60 Pin dia D: 28 mm | Length L: 60 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 28X80 Pin dia D: 28 mm | Length L: 80 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 28X100 Pin dia D: 28 mm | Length L: 100 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 28X120 Pin dia D: 28 mm | Length L: 120 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 31X28 Pin dia D: 31 mm | Length L: 28 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 31X40 Pin dia D: 31 mm | Length L: 40 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 31X60 Pin dia D: 31 mm | Length L: 60 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 31X80 Pin dia D: 31 mm | Length L: 80 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 31X100 Pin dia D: 31 mm | Length L: 100 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 31X120 Pin dia D: 31 mm | Length L: 120 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 36X40 Pin dia D: 36 mm | Length L: 40 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 36X60 Pin dia D: 36 mm | Length L: 60 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 36X80 Pin dia D: 36 mm | Length L: 80 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 36X100 Pin dia D: 36 mm | Length L: 100 mm | Thread: M12xP1.75 | Shank D1: 18 mm
LPSFC 36X120 Pin dia D: 36 mm | Length L: 120 mm | Thread: M12xP1.75 | Shank D1: 18 mm
Spring Guide PinLuBo
45 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
