LuBo LRA Rear Gauges (Stroke ST 50-300 mm)

LuBo LRA Rear Gauges (Stroke ST 50-300 mm)

LuBo LRA / LRAM / LRAV / LRAD Rear Gauges from the LuBo Locating & Checking Components catalogue, listed in 22 orderable catalogue codes. Select the code from the size table below; dimensions follow the LuBo drawing for each series.

Key features

  • Rear Gauges - series LRA / LRAM / LRAV / LRAD
  • Standard press die / mold component from LuBo
  • Sizes selected from the catalogue table
  • Dimensions per LuBo catalogue drawing
  • 22 catalogue codes covering the full printed size range

Specifications

Brand LuBo
Series LRA / LRAM / LRAV / LRAD
Product Rear Gauges
Catalogue chapter Locating & Checking Components
Orderable codes 22
Size range Stroke ST 50-300 mm
Code example LRA-50
Row spec keys Stroke ST, Key dimension, Type
Source LuBo Locating & Checking Components catalogue
LRA-50 Stroke ST: 50 mm | Key dimension: D 265 mm | Type: Standard
LRA-100 Stroke ST: 100 mm | Key dimension: D 315 mm | Type: Standard
LRA-150 Stroke ST: 150 mm | Key dimension: D 365 mm | Type: Standard
LRA-200 Stroke ST: 200 mm | Key dimension: D 415 mm | Type: Standard
LRAM-50 Stroke ST: 50 mm | Key dimension: H 290 mm | Type: Moveable
LRAM-75 Stroke ST: 75 mm | Key dimension: H 315 mm | Type: Moveable
LRAM-100 Stroke ST: 100 mm | Key dimension: H 340 mm | Type: Moveable
LRAM-125 Stroke ST: 125 mm | Key dimension: H 365 mm | Type: Moveable
LRAM-150 Stroke ST: 150 mm | Key dimension: H 390 mm | Type: Moveable
LRAM-200 Stroke ST: 200 mm | Key dimension: H 440 mm | Type: Moveable
LRAV-75 Stroke ST: 75 mm | Key dimension: L 205 mm | Type: With gauge set
LRAV-100 Stroke ST: 100 mm | Key dimension: L 230 mm | Type: With gauge set
LRAV-125 Stroke ST: 125 mm | Key dimension: L 255 mm | Type: With gauge set
LRAV-150 Stroke ST: 150 mm | Key dimension: L 280 mm | Type: With gauge set
LRAV-175 Stroke ST: 175 mm | Key dimension: L 305 mm | Type: With gauge set
LRAV-200 Stroke ST: 200 mm | Key dimension: L 330 mm | Type: With gauge set
LRAV-250 Stroke ST: 250 mm | Key dimension: L 380 mm | Type: With gauge set
LRAV-300 Stroke ST: 300 mm | Key dimension: L 430 mm | Type: With gauge set
LRAD-50 Stroke ST: 50 mm | Key dimension: A 220 mm | Type: Small
LRAD-100 Stroke ST: 100 mm | Key dimension: A 270 mm | Type: Small
LRAD-150 Stroke ST: 150 mm | Key dimension: A 320 mm | Type: Small
LRAD-200 Stroke ST: 200 mm | Key dimension: A 370 mm | Type: Small
Panel Locating GaugeLuBo
22 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LuBo LRA Rear Gauges (Stroke ST 50-300 mm)

Brand LuBo·Panel Locating Gauge

Available part numbers (22)

LRA-50, LRA-100, LRA-150, LRA-200, LRAM-50, LRAM-75, LRAM-100, LRAM-125, LRAM-150, LRAM-200 + 12 more — see full table ↓
