• MEAN WELL ELGC-300 Constant Power LED Driver (300 W, IP67)
1 1

MEAN WELL ELGC-300 Constant Power LED Driver (300 W, IP67)

MEAN WELL ELGC-300 Constant Power LED Driver (300 W, IP67)

The ELGC-300 is a constant power mode LED driver in an IP67 metal case, rated 300 W and offered in L, M and H output ranges.

Key features

  • Universal 100~305 VAC input, 6 kV surge immunity and Type HL rating for Class I, Division 2 hazardous location luminaires
  • Available in Blank, A, AB, D2/Dx and ADA (DALI-2) variants
  • Protections: short circuit, over current, over voltage and over temperature. 5-year warranty

Specifications

Dimensions 246x77x39.5 mm
Input voltage 100~305 VAC
IP rating IP67
ELGC-300-L Output voltage: 116~232 V | Output current (100~180 VAC): 650~1700 mA | Output current (200~305 VAC): 650~2000 mA | Dimensions: 246x77x39.5 mm | Input voltage: 100~305 VAC | IP rating: IP67
ELGC-300-M Output voltage: 58~116 V | Output current (100~180 VAC): 1300~3400 mA | Output current (200~305 VAC): 1300~4000 mA | Dimensions: 246x77x39.5 mm | Input voltage: 100~305 VAC | IP rating: IP67
ELGC-300-H Output voltage: 29~58 V | Output current (100~180 VAC): 2600~6800 mA | Output current (200~305 VAC): 2600~8000 mA | Dimensions: 246x77x39.5 mm | Input voltage: 100~305 VAC | IP rating: IP67
LED DriversMEAN WELL
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

MEAN WELL ELGC-300 Constant Power LED Driver (300 W, IP67)

Brand MEAN WELL·LED Drivers

Available part numbers (3)

ELGC-300-L, ELGC-300-M, ELGC-300-H

How to order

Send the MEAN WELL part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ELGC-300-LOutput voltage: 116~232 V | Output current (100~180 VAC): 650~1700 mA | Output current (200~305 VAC): 650~2000 mA | Dimensions: 246x77x39.5 mm | Input voltage: 100~305 VAC | IP rating: IP67
ELGC-300-MOutput voltage: 58~116 V | Output current (100~180 VAC): 1300~3400 mA | Output current (200~305 VAC): 1300~4000 mA | Dimensions: 246x77x39.5 mm | Input voltage: 100~305 VAC | IP rating: IP67
ELGC-300-HOutput voltage: 29~58 V | Output current (100~180 VAC): 2600~6800 mA | Output current (200~305 VAC): 2600~8000 mA | Dimensions: 246x77x39.5 mm | Input voltage: 100~305 VAC | IP rating: IP67
