Mitsubishi Electric MS-T100PM Push-Button Enclosed Magnetic Starter

Mitsubishi Electric MS-T100PM Push-Button Enclosed Magnetic Starter

The Mitsubishi Electric MS-T100PM is an MS-T/N series enclosed magnetic starter with ON/OFF push-buttons built into the cover.

Key features

  • ON and OFF push-buttons mounted on the enclosure face - wire only supply and load
  • MS-T10PM/T12PM have a separate reset button; MS-T21PM and larger reset via the OFF button
  • Rated AC-3 capacity 22 / 45 / 45 kW at 220/440/550V; heaters 15A-82A
  • Operation coil cannot be specified by designation - specify main-circuit and control voltage/frequency at order
  • Steel enclosure IP20, Munsell 5Y7/1; KPPM (2E) and PS (no external reset) versions available on request

Specifications

Series MS-T/N
Frame T100
Construction Enclosed (IP20) with ON/OFF buttons
Rated capacity AC-3 (200/400/500V) 22/45/45 kW
Rated current AC-3 (220/440/550V) 100/93/75 A
Auxiliary contacts 2a2b
Model MS-T100PM
Source Mitsubishi Electric MS-T/N Series catalogue (Korea ed.), p. 117-118, 125
MS-T100PM 15A Heater: 15A | Setting range: 12-18A | Thermal relay: TH-T65
MS-T100PM 22A Heater: 22A | Setting range: 18-26A | Thermal relay: TH-T65
MS-T100PM 29A Heater: 29A | Setting range: 24-34A | Thermal relay: TH-T65
MS-T100PM 35A Heater: 35A | Setting range: 30-40A | Thermal relay: TH-T65
MS-T100PM 42A Heater: 42A | Setting range: 34-50A | Thermal relay: TH-T65
MS-T100PM 54A Heater: 54A | Setting range: 43-65A | Thermal relay: TH-T65
MS-T100PM 67A Heater: 67A | Setting range: 54-80A | Thermal relay: TH-T100
MS-T100PM 82A Heater: 82A | Setting range: 65-100A | Thermal relay: TH-T100
