Mitsubishi Electric MS-T35PM Push-Button Enclosed Magnetic Starter

Mitsubishi Electric MS-T35PM Push-Button Enclosed Magnetic Starter

The Mitsubishi Electric MS-T35PM is an MS-T/N series enclosed magnetic starter with ON/OFF push-buttons built into the cover.

Key features

  • ON and OFF push-buttons mounted on the enclosure face - wire only supply and load
  • MS-T10PM/T12PM have a separate reset button; MS-T21PM and larger reset via the OFF button
  • Rated AC-3 capacity 7.5 / 15 / 15 kW at 220/440/550V; heaters 0.24A-29A
  • Operation coil cannot be specified by designation - specify main-circuit and control voltage/frequency at order
  • Steel enclosure IP20, Munsell 5Y7/1; KPPM (2E) and PS (no external reset) versions available on request

Specifications

Series MS-T/N
Frame T35
Construction Enclosed (IP20) with ON/OFF buttons
Rated capacity AC-3 (200/400/500V) 7.5/15/15 kW
Rated current AC-3 (220/440/550V) 34/32/26 A
Auxiliary contacts 2a2b
Model MS-T35PM
Source Mitsubishi Electric MS-T/N Series catalogue (Korea ed.), p. 117-118, 125
MS-T35PM 0.24A Heater: 0.24A | Setting range: 0.2-0.32A | Thermal relay: TH-T25
MS-T35PM 0.35A Heater: 0.35A | Setting range: 0.28-0.42A | Thermal relay: TH-T25
MS-T35PM 0.5A Heater: 0.5A | Setting range: 0.4-0.6A | Thermal relay: TH-T25
MS-T35PM 0.7A Heater: 0.7A | Setting range: 0.55-0.85A | Thermal relay: TH-T25
MS-T35PM 0.9A Heater: 0.9A | Setting range: 0.7-1.1A | Thermal relay: TH-T25
MS-T35PM 1.3A Heater: 1.3A | Setting range: 1-1.6A | Thermal relay: TH-T25
MS-T35PM 1.7A Heater: 1.7A | Setting range: 1.4-2A | Thermal relay: TH-T25
MS-T35PM 2.1A Heater: 2.1A | Setting range: 1.7-2.5A | Thermal relay: TH-T25
MS-T35PM 2.5A Heater: 2.5A | Setting range: 2-3A | Thermal relay: TH-T25
MS-T35PM 3.6A Heater: 3.6A | Setting range: 2.8-4.4A | Thermal relay: TH-T25
MS-T35PM 5A Heater: 5A | Setting range: 4-6A | Thermal relay: TH-T25
MS-T35PM 6.6A Heater: 6.6A | Setting range: 5.2-8A | Thermal relay: TH-T25
MS-T35PM 9A Heater: 9A | Setting range: 7-11A | Thermal relay: TH-T25
MS-T35PM 11A Heater: 11A | Setting range: 9-13A | Thermal relay: TH-T25
MS-T35PM 15A Heater: 15A | Setting range: 12-18A | Thermal relay: TH-T25
MS-T35PM 22A Heater: 22A | Setting range: 18-26A | Thermal relay: TH-T25
MS-T35PM 29A Heater: 29A | Setting range: 24-34A | Thermal relay: TH-T50
