Mitsubishi Electric MS-T65PM Push-Button Enclosed Magnetic Starter

Mitsubishi Electric MS-T65PM Push-Button Enclosed Magnetic Starter

The Mitsubishi Electric MS-T65PM is an MS-T/N series enclosed magnetic starter with ON/OFF push-buttons built into the cover.

Key features

  • ON and OFF push-buttons mounted on the enclosure face - wire only supply and load
  • MS-T10PM/T12PM have a separate reset button; MS-T21PM and larger reset via the OFF button
  • Rated AC-3 capacity 15 / 30 / 30 kW at 220/440/550V; heaters 15A-54A
  • Operation coil cannot be specified by designation - specify main-circuit and control voltage/frequency at order
  • Steel enclosure IP20, Munsell 5Y7/1; KPPM (2E) and PS (no external reset) versions available on request

Specifications

Series MS-T/N
Frame T65
Construction Enclosed (IP20) with ON/OFF buttons
Rated capacity AC-3 (200/400/500V) 15/30/30 kW
Rated current AC-3 (220/440/550V) 65/65/45 A
Auxiliary contacts 2a2b
Thermal relay TH-T65
Source Mitsubishi Electric MS-T/N Series catalogue (Korea ed.), p. 117-118, 125
MS-T65PM 15A Model: MS-T65PM | Heater: 15A | Setting range: 12-18A
MS-T65PM 22A Model: MS-T65PM | Heater: 22A | Setting range: 18-26A
MS-T65PM 29A Model: MS-T65PM | Heater: 29A | Setting range: 24-34A
MS-T65PM 35A Model: MS-T65PM | Heater: 35A | Setting range: 30-40A
MS-T65PM 42A Model: MS-T65PM | Heater: 42A | Setting range: 34-50A
MS-T65PM 54A Model: MS-T65PM | Heater: 54A | Setting range: 43-65A
Magnetic StartersMitsubishi Electric
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T65PM Push-Button Enclosed Magnetic Starter

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (6)

MS-T65PM 15A, MS-T65PM 22A, MS-T65PM 29A, MS-T65PM 35A, MS-T65PM 42A, MS-T65PM 54A
