Mitsubishi Electric MS-T80PM Push-Button Enclosed Magnetic Starter

The Mitsubishi Electric MS-T80PM is an MS-T/N series enclosed magnetic starter with ON/OFF push-buttons built into the cover.

Key features

ON and OFF push-buttons mounted on the enclosure face - wire only supply and load
MS-T10PM/T12PM have a separate reset button; MS-T21PM and larger reset via the OFF button
Rated AC-3 capacity 19 / 37 / 45 kW at 220/440/550V; heaters 67A-67A
Operation coil cannot be specified by designation - specify main-circuit and control voltage/frequency at order
Steel enclosure IP20, Munsell 5Y7/1; KPPM (2E) and PS (no external reset) versions available on request

Specifications

Series	MS-T/N
Frame	T80
Construction	Enclosed (IP20) with ON/OFF buttons
Rated capacity AC-3 (200/400/500V)	19/37/45 kW
Rated current AC-3 (220/440/550V)	80/80/75 A
Auxiliary contacts	2a2b
Thermal relay	TH-T100
Source	Mitsubishi Electric MS-T/N Series catalogue (Korea ed.), p. 117-118, 125

MS-T80PM 67A

Model: MS-T80PM | Heater: 67A | Setting range: 54-80A

Magnetic StartersMitsubishi Electric

1 product code available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T80PM Push-Button Enclosed Magnetic Starter

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (1)

MS-T80PM 67A

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
