Mitsubishi Electric MSO-N150DL Delay-Open Magnetic Starter (42-125A)

The Mitsubishi Electric MSO-N150DL is an MS-T/N series delay-open magnetic starter that keeps the motor circuit closed through momentary power failures.

Key features

Holds the contactor closed for 2 (+2/-1) s during momentary power failures or voltage dips
Capacitor-backed coil circuit - no re-closing operation needed after the dip, load keeps running
For lighting, building automation and other circuits that must ride through brief outages
Rated AC-3 capacity 37 / 75 / 90 kW at 220/440/550V; heaters 42A-125A
Operation coil AC100V (100-110V) or AC200V (200-220V); main-circuit rated voltage must be specified at order

Specifications

Series	MS-T/N
Frame	N150
Construction	Open type
Rated capacity AC-3 (200/400/500V)	37/75/90 kW
Rated current AC-3 (220/440/550V)	150/150/140 A
Delay time	2 (+2/-1) s fixed
Auxiliary contacts	1a1b
Model	MSO-N150DL
Source	Mitsubishi Electric MS-T/N Series catalogue (Korea ed.), p. 110-111, 124, 127

MSO-N150DL 42A AC100V		Heater: 42A \| Setting range: 34-50A \| Coil: AC100V \| Coil rating: 100-110V 50/60Hz \| Thermal relay: TH-N120
MSO-N150DL 42A AC200V		Heater: 42A \| Setting range: 34-50A \| Coil: AC200V \| Coil rating: 200-220V 50/60Hz \| Thermal relay: TH-N120
MSO-N150DL 54A AC100V		Heater: 54A \| Setting range: 43-65A \| Coil: AC100V \| Coil rating: 100-110V 50/60Hz \| Thermal relay: TH-N120
MSO-N150DL 54A AC200V		Heater: 54A \| Setting range: 43-65A \| Coil: AC200V \| Coil rating: 200-220V 50/60Hz \| Thermal relay: TH-N120
MSO-N150DL 67A AC100V		Heater: 67A \| Setting range: 54-80A \| Coil: AC100V \| Coil rating: 100-110V 50/60Hz \| Thermal relay: TH-N120
MSO-N150DL 67A AC200V		Heater: 67A \| Setting range: 54-80A \| Coil: AC200V \| Coil rating: 200-220V 50/60Hz \| Thermal relay: TH-N120
MSO-N150DL 82A AC100V		Heater: 82A \| Setting range: 65-100A \| Coil: AC100V \| Coil rating: 100-110V 50/60Hz \| Thermal relay: TH-N120
MSO-N150DL 82A AC200V		Heater: 82A \| Setting range: 65-100A \| Coil: AC200V \| Coil rating: 200-220V 50/60Hz \| Thermal relay: TH-N120
MSO-N150DL 105A AC100V		Heater: 105A \| Setting range: 85-125A \| Coil: AC100V \| Coil rating: 100-110V 50/60Hz \| Thermal relay: TH-N120TA
MSO-N150DL 105A AC200V		Heater: 105A \| Setting range: 85-125A \| Coil: AC200V \| Coil rating: 200-220V 50/60Hz \| Thermal relay: TH-N120TA
MSO-N150DL 125A AC100V		Heater: 125A \| Setting range: 100-150A \| Coil: AC100V \| Coil rating: 100-110V 50/60Hz \| Thermal relay: TH-N120TA
MSO-N150DL 125A AC200V		Heater: 125A \| Setting range: 100-150A \| Coil: AC200V \| Coil rating: 200-220V 50/60Hz \| Thermal relay: TH-N120TA
