• Mitsubishi Electric MSOL(D)-T35 Mechanically Latched Magnetic Starter
1 1

Mitsubishi Electric MSO-T35DL Delay-Open Magnetic Starter (0.24-29A)

Mitsubishi Electric MSO-T35DL Delay-Open Magnetic Starter (0.24-29A)

The Mitsubishi Electric MSO-T35DL is an MS-T/N series delay-open magnetic starter that keeps the motor circuit closed through momentary power failures.

Key features

  • Holds the contactor closed for 2 (+2/-1) s during momentary power failures or voltage dips
  • Capacitor-backed coil circuit - no re-closing operation needed after the dip, load keeps running
  • For lighting, building automation and other circuits that must ride through brief outages
  • Rated AC-3 capacity 7.5 / 15 / 15 kW at 220/440/550V; heaters 0.24A-29A
  • Operation coil AC100V (100-110V) or AC200V (200-220V); main-circuit rated voltage must be specified at order

Specifications

Series MS-T/N
Frame T35
Construction Open type
Rated capacity AC-3 (200/400/500V) 7.5/15/15 kW
Rated current AC-3 (220/440/550V) 34/32/26 A
Delay time 2 (+2/-1) s fixed
Auxiliary contacts 1a1b
Model MSO-T35DL
Source Mitsubishi Electric MS-T/N Series catalogue (Korea ed.), p. 110-111, 124, 127
MSO-T35DL 0.24A AC100V Heater: 0.24A | Setting range: 0.2-0.32A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.24A AC200V Heater: 0.24A | Setting range: 0.2-0.32A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.35A AC100V Heater: 0.35A | Setting range: 0.28-0.42A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.35A AC200V Heater: 0.35A | Setting range: 0.28-0.42A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.5A AC100V Heater: 0.5A | Setting range: 0.4-0.6A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.5A AC200V Heater: 0.5A | Setting range: 0.4-0.6A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.7A AC100V Heater: 0.7A | Setting range: 0.55-0.85A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.7A AC200V Heater: 0.7A | Setting range: 0.55-0.85A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.9A AC100V Heater: 0.9A | Setting range: 0.7-1.1A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 0.9A AC200V Heater: 0.9A | Setting range: 0.7-1.1A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 1.3A AC100V Heater: 1.3A | Setting range: 1-1.6A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 1.3A AC200V Heater: 1.3A | Setting range: 1-1.6A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 1.7A AC100V Heater: 1.7A | Setting range: 1.4-2A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 1.7A AC200V Heater: 1.7A | Setting range: 1.4-2A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 2.1A AC100V Heater: 2.1A | Setting range: 1.7-2.5A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 2.1A AC200V Heater: 2.1A | Setting range: 1.7-2.5A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 2.5A AC100V Heater: 2.5A | Setting range: 2-3A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 2.5A AC200V Heater: 2.5A | Setting range: 2-3A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 3.6A AC100V Heater: 3.6A | Setting range: 2.8-4.4A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 3.6A AC200V Heater: 3.6A | Setting range: 2.8-4.4A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 5A AC100V Heater: 5A | Setting range: 4-6A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 5A AC200V Heater: 5A | Setting range: 4-6A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 6.6A AC100V Heater: 6.6A | Setting range: 5.2-8A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 6.6A AC200V Heater: 6.6A | Setting range: 5.2-8A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 9A AC100V Heater: 9A | Setting range: 7-11A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 9A AC200V Heater: 9A | Setting range: 7-11A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 11A AC100V Heater: 11A | Setting range: 9-13A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 11A AC200V Heater: 11A | Setting range: 9-13A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 15A AC100V Heater: 15A | Setting range: 12-18A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 15A AC200V Heater: 15A | Setting range: 12-18A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 22A AC100V Heater: 22A | Setting range: 18-26A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 22A AC200V Heater: 22A | Setting range: 18-26A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T25
MSO-T35DL 29A AC100V Heater: 29A | Setting range: 24-34A | Coil: AC100V | Coil rating: 100-110V 50/60Hz | Thermal relay: TH-T50
MSO-T35DL 29A AC200V Heater: 29A | Setting range: 24-34A | Coil: AC200V | Coil rating: 200-220V 50/60Hz | Thermal relay: TH-T50
