• Mitsubishi Electric MSOL(D)-T80 Mechanically Latched Magnetic Starter
1 1

Mitsubishi Electric MSO-T80FSKP Quick-Trip Magnetic Starter (67-67A)

Mitsubishi Electric MSO-T80FSKP Quick-Trip Magnetic Starter (67-67A)

The Mitsubishi Electric MSO-T80FSKP is an MS-T/N series open-type magnetic starter with a quick-trip thermal overload relay for motors with low thermal capacity.

Key features

  • Combines an S-T80 contactor with a TH-T100FSKP quick-acting thermal overload relay
  • Trip time shorter than the standard TH relay for motors with small heat capacity (submersible pumps, compressors)
  • Rated AC-3 capacity 19 / 37 / 45 kW at 220/440/550V; Ith 120 A
  • Heater designations 67A-67A; coils AC24V, AC48V, AC100V, AC200V, AC300V, AC400V, AC500V
  • 3-element (2E) relay adds open-phase protection

Specifications

Series MS-T/N
Frame T80
Construction Open type
Rated capacity AC-3 (200/400/500V) 19/37/45 kW
Rated current AC-3 (220/440/550V) 80/80/75 A
Auxiliary contacts 2a2b
Trip class 5
Coil type AC operated (50/60Hz)
Thermal relay TH-T100FSKP
Model MSO-T80FSKP
Setting range 54-80A
Source Mitsubishi Electric MS-T/N Series catalogue (Korea ed.), p. 116, 41, 125, 141
MSO-T80FSKP 67A AC24V Heater: 67A | Coil: AC24V | Coil rating: 24V 50/60Hz
MSO-T80FSKP 67A AC48V Heater: 67A | Coil: AC48V | Coil rating: 48-50V 50/60Hz
MSO-T80FSKP 67A AC100V Heater: 67A | Coil: AC100V | Coil rating: 100-127V 50/60Hz
MSO-T80FSKP 67A AC200V Heater: 67A | Coil: AC200V | Coil rating: 200-240V 50/60Hz
MSO-T80FSKP 67A AC300V Heater: 67A | Coil: AC300V | Coil rating: 260-350V 50/60Hz
MSO-T80FSKP 67A AC400V Heater: 67A | Coil: AC400V | Coil rating: 380-440V 50/60Hz
MSO-T80FSKP 67A AC500V Heater: 67A | Coil: AC500V | Coil rating: 460-550V 50/60Hz
Magnetic StartersMitsubishi Electric
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MSO-T80FSKP Quick-Trip Magnetic Starter (67-67A)

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (7)

MSO-T80FSKP 67A AC24V, MSO-T80FSKP 67A AC48V, MSO-T80FSKP 67A AC100V, MSO-T80FSKP 67A AC200V, MSO-T80FSKP 67A AC300V, MSO-T80FSKP 67A AC400V, MSO-T80FSKP 67A AC500V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MSO-T80FSKP 67A AC24VHeater: 67A | Coil: AC24V | Coil rating: 24V 50/60Hz
MSO-T80FSKP 67A AC48VHeater: 67A | Coil: AC48V | Coil rating: 48-50V 50/60Hz
MSO-T80FSKP 67A AC100VHeater: 67A | Coil: AC100V | Coil rating: 100-127V 50/60Hz
MSO-T80FSKP 67A AC200VHeater: 67A | Coil: AC200V | Coil rating: 200-240V 50/60Hz
MSO-T80FSKP 67A AC300VHeater: 67A | Coil: AC300V | Coil rating: 260-350V 50/60Hz
MSO-T80FSKP 67A AC400VHeater: 67A | Coil: AC400V | Coil rating: 380-440V 50/60Hz
MSO-T80FSKP 67A AC500VHeater: 67A | Coil: AC500V | Coil rating: 460-550V 50/60Hz
