Mitsubishi Electric S-2xT10BC Reversing Contactor (BC Terminals)

Mitsubishi Electric S-2xT10BC Reversing Contactor (BC Terminals)

Mitsubishi Electric S-2xT10BC reversing magnetic contactor with wiring-streamlining (BC) finger-safe terminals per DIN EN 50274 / VDE 0660 Part 514.

Key features

  • Wiring-streamlining terminals: wire without removing the terminal cover; finger-safe to DIN EN 50274
  • AC-3 rating 2.2 kW / 11 A at 200-220V, 2.7 kW / 7 A at 380-440V; Ith 20 A
  • Auxiliary contacts: 1a or 1b per contactor (+2b of UT-ML11BC interlock)
  • AC-operated only (no DC-operated version for T10)
  • Mechanical interlock fitted; two auxiliary b contacts wired as electrical interlock

Specifications

Series MS-T series
Frame T10
Terminals BC wiring-streamlining (finger safe)
AC-3 rating 200-220V 2.2 kW / 11 A
AC-3 rating 380-440V 2.7 kW / 7 A
Conventional thermal current Ith 20 A
Operation AC
Source Mitsubishi Electric MS-T/N Series catalogue (Korean ed.), p. 119-120
S-2xT10BC AC24V Model: S-2xT10BC | Coil: AC24V | Coil rated voltage: 24V 50/60Hz
S-2xT10BC AC48V Model: S-2xT10BC | Coil: AC48V | Coil rated voltage: 48-50V 50/60Hz
S-2xT10BC AC100V Model: S-2xT10BC | Coil: AC100V | Coil rated voltage: 100-127V 50/60Hz
S-2xT10BC AC200V Model: S-2xT10BC | Coil: AC200V | Coil rated voltage: 200-240V 50/60Hz
S-2xT10BC AC300V Model: S-2xT10BC | Coil: AC300V | Coil rated voltage: 260-300V 50/60Hz
S-2xT10BC AC400V Model: S-2xT10BC | Coil: AC400V | Coil rated voltage: 380-440V 50/60Hz
S-2xT10BC AC500V Model: S-2xT10BC | Coil: AC500V | Coil rated voltage: 460-550V 50/60Hz
Magnetic ContactorsMitsubishi Electric
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric S-2xT10BC Reversing Contactor (BC Terminals)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (7)

S-2xT10BC AC24V, S-2xT10BC AC48V, S-2xT10BC AC100V, S-2xT10BC AC200V, S-2xT10BC AC300V, S-2xT10BC AC400V, S-2xT10BC AC500V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S-2xT10BC AC24VModel: S-2xT10BC | Coil: AC24V | Coil rated voltage: 24V 50/60Hz
S-2xT10BC AC48VModel: S-2xT10BC | Coil: AC48V | Coil rated voltage: 48-50V 50/60Hz
S-2xT10BC AC100VModel: S-2xT10BC | Coil: AC100V | Coil rated voltage: 100-127V 50/60Hz
S-2xT10BC AC200VModel: S-2xT10BC | Coil: AC200V | Coil rated voltage: 200-240V 50/60Hz
S-2xT10BC AC300VModel: S-2xT10BC | Coil: AC300V | Coil rated voltage: 260-300V 50/60Hz
S-2xT10BC AC400VModel: S-2xT10BC | Coil: AC400V | Coil rated voltage: 380-440V 50/60Hz
S-2xT10BC AC500VModel: S-2xT10BC | Coil: AC500V | Coil rated voltage: 460-550V 50/60Hz
