Mitsubishi Electric S-2xT21BC / SD-2xT21BC Reversing Contactor

Mitsubishi Electric S-2xT21BC / SD-2xT21BC reversing magnetic contactor with wiring-streamlining (BC) finger-safe terminals per DIN EN 50274 / VDE 0660 Part 514.

Key features

Wiring-streamlining terminals: wire without removing the terminal cover; finger-safe to DIN EN 50274
AC-3 rating 4 kW / 20 A at 200-220V, 7.5 kW / 20 A at 380-440V; Ith 32 A
Auxiliary contacts: 2a2b per contactor
AC-operated S-2xT21BC and DC-operated SD-2xT21BC
Mechanical interlock fitted; two auxiliary b contacts wired as electrical interlock

Specifications

Series	MS-T series
Frame	T21
Terminals	BC wiring-streamlining (finger safe)
AC-3 rating 200-220V	4 kW / 20 A
AC-3 rating 380-440V	7.5 kW / 20 A
Conventional thermal current Ith	32 A
Source	Mitsubishi Electric MS-T/N Series catalogue (Korean ed.), p. 119-120

S-2xT21BC AC24V		Model: S-2xT21BC \| Operation: AC \| Coil: AC24V \| Coil rated voltage: 24V 50/60Hz
S-2xT21BC AC48V		Model: S-2xT21BC \| Operation: AC \| Coil: AC48V \| Coil rated voltage: 48-50V 50/60Hz
S-2xT21BC AC100V		Model: S-2xT21BC \| Operation: AC \| Coil: AC100V \| Coil rated voltage: 100-127V 50/60Hz
S-2xT21BC AC200V		Model: S-2xT21BC \| Operation: AC \| Coil: AC200V \| Coil rated voltage: 200-240V 50/60Hz
S-2xT21BC AC300V		Model: S-2xT21BC \| Operation: AC \| Coil: AC300V \| Coil rated voltage: 260-300V 50/60Hz
S-2xT21BC AC400V		Model: S-2xT21BC \| Operation: AC \| Coil: AC400V \| Coil rated voltage: 380-440V 50/60Hz
S-2xT21BC AC500V		Model: S-2xT21BC \| Operation: AC \| Coil: AC500V \| Coil rated voltage: 460-550V 50/60Hz
SD-2xT21BC DC12V		Model: SD-2xT21BC \| Operation: DC \| Coil: DC12V \| Coil rated voltage: DC12V
SD-2xT21BC DC24V		Model: SD-2xT21BC \| Operation: DC \| Coil: DC24V \| Coil rated voltage: DC24V
SD-2xT21BC DC48V		Model: SD-2xT21BC \| Operation: DC \| Coil: DC48V \| Coil rated voltage: DC48V
SD-2xT21BC DC100V		Model: SD-2xT21BC \| Operation: DC \| Coil: DC100V \| Coil rated voltage: DC100V
SD-2xT21BC DC110V		Model: SD-2xT21BC \| Operation: DC \| Coil: DC110V \| Coil rated voltage: DC110V
SD-2xT21BC DC125V		Model: SD-2xT21BC \| Operation: DC \| Coil: DC125V \| Coil rated voltage: DC120-125V
SD-2xT21BC DC200V		Model: SD-2xT21BC \| Operation: DC \| Coil: DC200V \| Coil rated voltage: DC200V
SD-2xT21BC DC220V		Model: SD-2xT21BC \| Operation: DC \| Coil: DC220V \| Coil rated voltage: DC220V

Magnetic ContactorsMitsubishi Electric

15 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric S-2xT21BC / SD-2xT21BC Reversing Contactor

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (15)

S-2xT21BC AC24V, S-2xT21BC AC48V, S-2xT21BC AC100V, S-2xT21BC AC200V, S-2xT21BC AC300V, S-2xT21BC AC400V, S-2xT21BC AC500V, SD-2xT21BC DC12V, SD-2xT21BC DC24V, SD-2xT21BC DC48V + 5 more — see full table ↓
