Mitsubishi Electric - UA-DL2 Instantaneous Power Failure Restart Relay (AC100V to AC240V)

Mitsubishi Electric - UA-DL2 Instantaneous Power Failure Restart Relay (AC100V to AC240V)

Mitsubishi Electric MS-T/N series UA-DL2 instantaneous power failure restart relay that automatically restarts load equipment stopped by a short voltage dip or power failure once the supply recovers.

Key features

  • Three voltage designations cover AC100/200V, AC120V and AC240V, with an operating circuit tolerance of 85 to 110 percent of rated voltage and an operation indicator lamp on the front
  • It plugs into the PF-08RM or PF-08TM surface connection socket

Specifications

Type Instantaneous power failure restart relay
Operating Circuit Voltage Tolerance 85 to 110 percent of rated voltage
Indication Operation indicator lamp
UA-DL2 AC100/200V UA-DL2 instantaneous power failure restart relay, AC100/200V rated | Type: Instantaneous power failure restart relay | Voltage Designation: AC100/200V | Rated Voltage: 100-110V 50/60Hz and 200-220V 50/60Hz | Operating Circuit Voltage Tolerance: 85 to 110 percent of rated voltage | Indication: Operation indicator lamp
UA-DL2 AC120V UA-DL2 instantaneous power failure restart relay, AC120V rated | Type: Instantaneous power failure restart relay | Voltage Designation: AC120V | Rated Voltage: 100-110V 50/60Hz and 110-120V 50/60Hz | Operating Circuit Voltage Tolerance: 85 to 110 percent of rated voltage | Indication: Operation indicator lamp
UA-DL2 AC240V UA-DL2 instantaneous power failure restart relay, AC240V rated | Type: Instantaneous power failure restart relay | Voltage Designation: AC240V | Rated Voltage: 200-220V 50/60Hz and 220-240V 50/60Hz | Operating Circuit Voltage Tolerance: 85 to 110 percent of rated voltage | Indication: Operation indicator lamp
Auxiliary RelaysMitsubishi Electric
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - UA-DL2 Instantaneous Power Failure Restart Relay (AC100V to AC240V)

Brand Mitsubishi Electric·Auxiliary Relays

Available part numbers (3)

UA-DL2 AC100/200V, UA-DL2 AC120V, UA-DL2 AC240V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UA-DL2 AC100/200VUA-DL2 instantaneous power failure restart relay, AC100/200V rated | Type: Instantaneous power failure restart relay | Voltage Designation: AC100/200V | Rated Voltage: 100-110V 50/60Hz and 200-220V 50/60Hz | Operating Circuit Voltage Tolerance: 85 to 110 percent of rated voltage | Indication: Operation indicator lamp
UA-DL2 AC120VUA-DL2 instantaneous power failure restart relay, AC120V rated | Type: Instantaneous power failure restart relay | Voltage Designation: AC120V | Rated Voltage: 100-110V 50/60Hz and 110-120V 50/60Hz | Operating Circuit Voltage Tolerance: 85 to 110 percent of rated voltage | Indication: Operation indicator lamp
UA-DL2 AC240VUA-DL2 instantaneous power failure restart relay, AC240V rated | Type: Instantaneous power failure restart relay | Voltage Designation: AC240V | Rated Voltage: 200-220V 50/60Hz and 220-240V 50/60Hz | Operating Circuit Voltage Tolerance: 85 to 110 percent of rated voltage | Indication: Operation indicator lamp
