• NS Precision CR-V Inch Cam Followers (Full Complement)
1 1

NS Precision CR-V Inch Cam Followers (Full Complement)

NS Precision CR-V Inch Cam Followers (Full Complement)

NS CR..V inch-dimension stud-type track rollers with full-complement needle rollers, outer diameter 1/2 in to 2-1/4 in.

Key features

  • Full complement, inch dimensions
  • Thick-walled outer ring runs directly on cam or track surfaces
  • Threaded stud with hexagon socket for easy mounting
  • Cylindrical (no R) or crowned (R) outer ring
  • Sealed (UU) versions retain grease and exclude contamination

Specifications

Product Stud-type track roller (cam follower)
Series CR-V
Suffixes R = crowned outer ring; UU = sealed
Load rating unit kgf
Brand NS
Source NS NS Precision catalogue (CAT No. NS-2019-01), p. 42-43
CR8V Outer D: 12.7 mm | Stud: 4.826 mm | C: 380 kgf | C0: 290 kgf | Mass: 9 g
CR8VR Outer D: 12.7 mm | Stud: 4.826 mm | C: 380 kgf | C0: 290 kgf | Mass: 9 g
CR8VUU Outer D: 12.7 mm | Stud: 4.826 mm | C: 380 kgf | C0: 290 kgf | Mass: 9 g
CR8VUUR Outer D: 12.7 mm | Stud: 4.826 mm | C: 380 kgf | C0: 290 kgf | Mass: 9 g
CR8-1V Outer D: 12.7 mm | Stud: 4.826 mm | C: 380 kgf | C0: 290 kgf | Mass: 10 g
CR8-1VR Outer D: 12.7 mm | Stud: 4.826 mm | C: 380 kgf | C0: 290 kgf | Mass: 10 g
CR8-1VUU Outer D: 12.7 mm | Stud: 4.826 mm | C: 380 kgf | C0: 290 kgf | Mass: 10 g
CR8-1VUUR Outer D: 12.7 mm | Stud: 4.826 mm | C: 380 kgf | C0: 290 kgf | Mass: 10 g
CR10V Outer D: 15.875 mm | Stud: 6.35 mm | C: 510 kgf | C0: 400 kgf | Mass: 19 g
CR10VR Outer D: 15.875 mm | Stud: 6.35 mm | C: 510 kgf | C0: 400 kgf | Mass: 19 g
CR10VUU Outer D: 15.875 mm | Stud: 6.35 mm | C: 510 kgf | C0: 400 kgf | Mass: 19 g
CR10VUUR Outer D: 15.875 mm | Stud: 6.35 mm | C: 510 kgf | C0: 400 kgf | Mass: 19 g
CR10-1V Outer D: 15.875 mm | Stud: 6.35 mm | C: 510 kgf | C0: 400 kgf | Mass: 21 g
CR10-1VR Outer D: 15.875 mm | Stud: 6.35 mm | C: 510 kgf | C0: 400 kgf | Mass: 21 g
CR10-1VUU Outer D: 15.875 mm | Stud: 6.35 mm | C: 510 kgf | C0: 400 kgf | Mass: 21 g
CR10-1VUUR Outer D: 15.875 mm | Stud: 6.35 mm | C: 510 kgf | C0: 400 kgf | Mass: 21 g
CR12V Outer D: 19.05 mm | Stud: 9.525 mm | C: 680 kgf | C0: 630 kgf | Mass: 35 g
CR12VR Outer D: 19.05 mm | Stud: 9.525 mm | C: 680 kgf | C0: 630 kgf | Mass: 35 g
CR12VUU Outer D: 19.05 mm | Stud: 9.525 mm | C: 680 kgf | C0: 630 kgf | Mass: 35 g
CR12VUUR Outer D: 19.05 mm | Stud: 9.525 mm | C: 680 kgf | C0: 630 kgf | Mass: 35 g
CR14V Outer D: 22.225 mm | Stud: 9.525 mm | C: 720 kgf | C0: 670 kgf | Mass: 46 g
CR14VR Outer D: 22.225 mm | Stud: 9.525 mm | C: 720 kgf | C0: 670 kgf | Mass: 46 g
CR14VUU Outer D: 22.225 mm | Stud: 9.525 mm | C: 720 kgf | C0: 670 kgf | Mass: 46 g
CR14VUUR Outer D: 22.225 mm | Stud: 9.525 mm | C: 720 kgf | C0: 670 kgf | Mass: 46 g
CR16V Outer D: 25.4 mm | Stud: 11.112 mm | C: 1180 kgf | C0: 980 kgf | Mass: 73 g
CR16VR Outer D: 25.4 mm | Stud: 11.112 mm | C: 1180 kgf | C0: 980 kgf | Mass: 73 g
CR16VUU Outer D: 25.4 mm | Stud: 11.112 mm | C: 1180 kgf | C0: 980 kgf | Mass: 73 g
CR16VUUR Outer D: 25.4 mm | Stud: 11.112 mm | C: 1180 kgf | C0: 980 kgf | Mass: 73 g
CR18V Outer D: 28.575 mm | Stud: 11.112 mm | C: 1150 kgf | C0: 1060 kgf | Mass: 88 g
CR18VR Outer D: 28.575 mm | Stud: 11.112 mm | C: 1150 kgf | C0: 1060 kgf | Mass: 88 g
CR18VUU Outer D: 28.575 mm | Stud: 11.112 mm | C: 1150 kgf | C0: 1060 kgf | Mass: 88 g
CR18VUUR Outer D: 28.575 mm | Stud: 11.112 mm | C: 1150 kgf | C0: 1060 kgf | Mass: 88 g
CR20V Outer D: 31.75 mm | Stud: 12.7 mm | C: 1840 kgf | C0: 1630 kgf | Mass: 132 g
CR20VR Outer D: 31.75 mm | Stud: 12.7 mm | C: 1840 kgf | C0: 1630 kgf | Mass: 132 g
CR20VUU Outer D: 31.75 mm | Stud: 12.7 mm | C: 1840 kgf | C0: 1630 kgf | Mass: 132 g
CR20VUUR Outer D: 31.75 mm | Stud: 12.7 mm | C: 1840 kgf | C0: 1630 kgf | Mass: 132 g
CR22V Outer D: 34.925 mm | Stud: 12.7 mm | C: 1840 kgf | C0: 1630 kgf | Mass: 157 g
CR22VR Outer D: 34.925 mm | Stud: 12.7 mm | C: 1840 kgf | C0: 1630 kgf | Mass: 157 g
CR22VUU Outer D: 34.925 mm | Stud: 12.7 mm | C: 1840 kgf | C0: 1630 kgf | Mass: 157 g
CR22VUUR Outer D: 34.925 mm | Stud: 12.7 mm | C: 1840 kgf | C0: 1630 kgf | Mass: 157 g
CR24V Outer D: 38.1 mm | Stud: 15.875 mm | C: 2500 kgf | C0: 2500 kgf | Mass: 225 g
CR24VR Outer D: 38.1 mm | Stud: 15.875 mm | C: 2500 kgf | C0: 2500 kgf | Mass: 225 g
CR24VUU Outer D: 38.1 mm | Stud: 15.875 mm | C: 2500 kgf | C0: 2500 kgf | Mass: 225 g
CR24VUUR Outer D: 38.1 mm | Stud: 15.875 mm | C: 2500 kgf | C0: 2500 kgf | Mass: 225 g
CR26V Outer D: 41.275 mm | Stud: 15.875 mm | C: 2500 kgf | C0: 2500 kgf | Mass: 260 g
CR26VR Outer D: 41.275 mm | Stud: 15.875 mm | C: 2500 kgf | C0: 2500 kgf | Mass: 260 g
CR26VUU Outer D: 41.275 mm | Stud: 15.875 mm | C: 2500 kgf | C0: 2500 kgf | Mass: 260 g
CR26VUUR Outer D: 41.275 mm | Stud: 15.875 mm | C: 2500 kgf | C0: 2500 kgf | Mass: 260 g
CR28V Outer D: 44.45 mm | Stud: 19.05 mm | C: 2930 kgf | C0: 3160 kgf | Mass: 365 g
CR28VR Outer D: 44.45 mm | Stud: 19.05 mm | C: 2930 kgf | C0: 3160 kgf | Mass: 365 g
CR28VUU Outer D: 44.45 mm | Stud: 19.05 mm | C: 2930 kgf | C0: 3160 kgf | Mass: 365 g
CR28VUUR Outer D: 44.45 mm | Stud: 19.05 mm | C: 2930 kgf | C0: 3160 kgf | Mass: 365 g
CR30V Outer D: 47.625 mm | Stud: 19.05 mm | C: 2930 kgf | C0: 3160 kgf | Mass: 410 g
CR30VR Outer D: 47.625 mm | Stud: 19.05 mm | C: 2930 kgf | C0: 3160 kgf | Mass: 410 g
CR30VUU Outer D: 47.625 mm | Stud: 19.05 mm | C: 2930 kgf | C0: 3160 kgf | Mass: 410 g
CR30VUUR Outer D: 47.625 mm | Stud: 19.05 mm | C: 2930 kgf | C0: 3160 kgf | Mass: 410 g
CR32V Outer D: 50.8 mm | Stud: 22.225 mm | C: 3650 kgf | C0: 4920 kgf | Mass: 615 g
CR32VR Outer D: 50.8 mm | Stud: 22.225 mm | C: 3650 kgf | C0: 4920 kgf | Mass: 615 g
CR32VUU Outer D: 50.8 mm | Stud: 22.225 mm | C: 3650 kgf | C0: 4920 kgf | Mass: 615 g
CR32VUUR Outer D: 50.8 mm | Stud: 22.225 mm | C: 3650 kgf | C0: 4920 kgf | Mass: 615 g
CR36V Outer D: 57.15 mm | Stud: 22.225 mm | C: 3650 kgf | C0: 4920 kgf | Mass: 750 g
CR36VR Outer D: 57.15 mm | Stud: 22.225 mm | C: 3650 kgf | C0: 4920 kgf | Mass: 750 g
CR36VUU Outer D: 57.15 mm | Stud: 22.225 mm | C: 3650 kgf | C0: 4920 kgf | Mass: 750 g
CR36VUUR Outer D: 57.15 mm | Stud: 22.225 mm | C: 3650 kgf | C0: 4920 kgf | Mass: 750 g
Track RollersNS Precision
64 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NS Precision CR-V Inch Cam Followers (Full Complement)

Brand NS Precision·Track Rollers

Available part numbers (64)

CR8V, CR8VR, CR8VUU, CR8VUUR, CR8-1V, CR8-1VR, CR8-1VUU, CR8-1VUUR, CR10V, CR10VR + 54 more — see full table ↓

How to order

Send the NS Precision part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
