NS Precision SC..LUU Long Linear Slide Units (8-60 mm)

NS Precision SC..LUU Long Linear Slide Units (8-60 mm)

NS SC..LUU long aluminium slide units with two LM..UU linear bushings, 8-60 mm shafts; -S versions are alternative-length executions.

Key features

  • Two LM..UU bushings inserted
  • Aluminium housing with tapped mounting holes
  • Double-sealed (UU) as standard
  • Load ratings refer to the inserted bushing(s)

Specifications

Product Linear slide unit
Series SC-L
Load rating unit kgf
Brand NS
Product type Linear Bushings
Source NS NS Precision catalogue (CAT No. NS-2019-01), p. 83
SC8LUU Shaft: 8 mm | W: 34 mm | L: 58 mm | C: 44 kgf | C0: 80 kgf | Mass: 102 g
SC10LUU Shaft: 10 mm | W: 40 mm | L: 68 mm | C: 60 kgf | C0: 112 kgf | Mass: 180 g
SC12LUU Shaft: 12 mm | W: 42 mm | L: 70 mm | C: 67 kgf | C0: 120 kgf | Mass: 205 g
SC12LUU-S Shaft: 12 mm | W: 42 mm | L: 77 mm | C: 67 kgf | C0: 120 kgf | Mass: 214 g
SC13LUU Shaft: 13 mm | W: 44 mm | L: 75 mm | C: 83 kgf | C0: 160 kgf | Mass: 240 g
SC13LUU-S Shaft: 13 mm | W: 44 mm | L: 77 mm | C: 83 kgf | C0: 160 kgf | Mass: 246 g
SC16LUU Shaft: 16 mm | W: 50 mm | L: 85 mm | C: 125 kgf | C0: 240 kgf | Mass: 400 g
SC16LUU-S Shaft: 16 mm | W: 50 mm | L: 89 mm | C: 125 kgf | C0: 240 kgf | Mass: 410 g
SC20LUU Shaft: 20 mm | W: 54 mm | L: 96 mm | C: 144 kgf | C0: 280 kgf | Mass: 570 g
SC20LUU-S Shaft: 20 mm | W: 54 mm | L: 100 mm | C: 144 kgf | C0: 280 kgf | Mass: 582 g
SC25LUU Shaft: 25 mm | W: 76 mm | L: 130 mm | C: 164 kgf | C0: 320 kgf | Mass: 1200 g
SC25LUU-S Shaft: 25 mm | W: 76 mm | L: 136 mm | C: 164 kgf | C0: 320 kgf | Mass: 1228 g
SC30LUU Shaft: 30 mm | W: 78 mm | L: 140 mm | C: 250 kgf | C0: 560 kgf | Mass: 1480 g
SC30LUU-S Shaft: 30 mm | W: 78 mm | L: 146 mm | C: 250 kgf | C0: 560 kgf | Mass: 1532 g
SC35LUU Shaft: 35 mm | W: 90 mm | L: 155 mm | C: 270 kgf | C0: 640 kgf | Mass: 2200 g
SC35LUU-S Shaft: 35 mm | W: 90 mm | L: 160 mm | C: 270 kgf | C0: 640 kgf | Mass: 2236 g
SC40LUU Shaft: 40 mm | W: 102 mm | L: 175 mm | C: 350 kgf | C0: 820 kgf | Mass: 3200 g
SC40LUU-S Shaft: 40 mm | W: 102 mm | L: 180 mm | C: 350 kgf | C0: 820 kgf | Mass: 3245 g
SC50LUU Shaft: 50 mm | W: 122 mm | L: 215 mm | C: 620 kgf | C0: 1620 kgf | Mass: 6700 g
SC50LUU-S Shaft: 50 mm | W: 122 mm | L: 230 mm | C: 620 kgf | C0: 1620 kgf | Mass: 6805 g
SC60LUU Shaft: 60 mm | W: 132 mm | L: 240 mm | C: 770 kgf | C0: 2040 kgf | Mass: 8560 g
Linear BushingsNS Precision
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NS Precision SC..LUU Long Linear Slide Units (8-60 mm)

Brand NS Precision·Linear Bushings

Available part numbers (21)

SC8LUU, SC10LUU, SC12LUU, SC12LUU-S, SC13LUU, SC13LUU-S, SC16LUU, SC16LUU-S, SC20LUU, SC20LUU-S + 11 more — see full table ↓

How to order

Send the NS Precision part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SC8LUUShaft: 8 mm | W: 34 mm | L: 58 mm | C: 44 kgf | C0: 80 kgf | Mass: 102 g
SC10LUUShaft: 10 mm | W: 40 mm | L: 68 mm | C: 60 kgf | C0: 112 kgf | Mass: 180 g
SC12LUUShaft: 12 mm | W: 42 mm | L: 70 mm | C: 67 kgf | C0: 120 kgf | Mass: 205 g
SC12LUU-SShaft: 12 mm | W: 42 mm | L: 77 mm | C: 67 kgf | C0: 120 kgf | Mass: 214 g
SC13LUUShaft: 13 mm | W: 44 mm | L: 75 mm | C: 83 kgf | C0: 160 kgf | Mass: 240 g
SC13LUU-SShaft: 13 mm | W: 44 mm | L: 77 mm | C: 83 kgf | C0: 160 kgf | Mass: 246 g
SC16LUUShaft: 16 mm | W: 50 mm | L: 85 mm | C: 125 kgf | C0: 240 kgf | Mass: 400 g
SC16LUU-SShaft: 16 mm | W: 50 mm | L: 89 mm | C: 125 kgf | C0: 240 kgf | Mass: 410 g
SC20LUUShaft: 20 mm | W: 54 mm | L: 96 mm | C: 144 kgf | C0: 280 kgf | Mass: 570 g
SC20LUU-SShaft: 20 mm | W: 54 mm | L: 100 mm | C: 144 kgf | C0: 280 kgf | Mass: 582 g
SC25LUUShaft: 25 mm | W: 76 mm | L: 130 mm | C: 164 kgf | C0: 320 kgf | Mass: 1200 g
SC25LUU-SShaft: 25 mm | W: 76 mm | L: 136 mm | C: 164 kgf | C0: 320 kgf | Mass: 1228 g
SC30LUUShaft: 30 mm | W: 78 mm | L: 140 mm | C: 250 kgf | C0: 560 kgf | Mass: 1480 g
SC30LUU-SShaft: 30 mm | W: 78 mm | L: 146 mm | C: 250 kgf | C0: 560 kgf | Mass: 1532 g
SC35LUUShaft: 35 mm | W: 90 mm | L: 155 mm | C: 270 kgf | C0: 640 kgf | Mass: 2200 g
SC35LUU-SShaft: 35 mm | W: 90 mm | L: 160 mm | C: 270 kgf | C0: 640 kgf | Mass: 2236 g
SC40LUUShaft: 40 mm | W: 102 mm | L: 175 mm | C: 350 kgf | C0: 820 kgf | Mass: 3200 g
SC40LUU-SShaft: 40 mm | W: 102 mm | L: 180 mm | C: 350 kgf | C0: 820 kgf | Mass: 3245 g
SC50LUUShaft: 50 mm | W: 122 mm | L: 215 mm | C: 620 kgf | C0: 1620 kgf | Mass: 6700 g
SC50LUU-SShaft: 50 mm | W: 122 mm | L: 230 mm | C: 620 kgf | C0: 1620 kgf | Mass: 6805 g
SC60LUUShaft: 60 mm | W: 132 mm | L: 240 mm | C: 770 kgf | C0: 2040 kgf | Mass: 8560 g
