NSK 22 Series Self-Aligning Ball Bearings (Cylindrical & K Bore)

NSK 22 Series Self-Aligning Ball Bearings (Cylindrical & K Bore)

NSK 22 series self-aligning ball bearings, bore 10-110 mm, with cylindrical bore and, where listed, tapered bore (K suffix, taper 1:12).

Key features

  • Double-row balls with spherical outer-ring raceway
  • Accommodates misalignment between shaft and housing
  • K suffix: tapered bore 1:12 for adapter or withdrawal sleeve mounting
  • Low friction and low heat generation

Specifications

Bearing type Self-aligning ball bearing
Series 22
Bore range 10-110 mm
Bore type Cylindrical; K = tapered 1:12
Load ratings Basic dynamic Cr / static C0r
Speed basis Grease lubrication limit
Source NSK Rolling Bearings Catalogue (Korean ed.), p. B74-B79
2200 d: 10 mm | D: 30 mm | B: 14 mm | Cr: 7.45 kN | C0r: 1.59 kN | Grease speed: 24000 rpm
2201 d: 12 mm | D: 32 mm | B: 14 mm | Cr: 7.75 kN | C0r: 1.73 kN | Grease speed: 22000 rpm
2202 d: 15 mm | D: 35 mm | B: 14 mm | Cr: 7.8 kN | C0r: 1.85 kN | Grease speed: 18000 rpm
2203 d: 17 mm | D: 40 mm | B: 16 mm | Cr: 9.95 kN | C0r: 2.42 kN | Grease speed: 16000 rpm
2204 d: 20 mm | D: 47 mm | B: 18 mm | Cr: 12.8 kN | C0r: 3.3 kN | Grease speed: 14000 rpm
2204K d: 20 mm | D: 47 mm | B: 18 mm | Cr: 12.8 kN | C0r: 3.3 kN | Grease speed: 14000 rpm
2205 d: 25 mm | D: 52 mm | B: 18 mm | Cr: 12.4 kN | C0r: 3.45 kN | Grease speed: 12000 rpm
2205K d: 25 mm | D: 52 mm | B: 18 mm | Cr: 12.4 kN | C0r: 3.45 kN | Grease speed: 12000 rpm
2206 d: 30 mm | D: 62 mm | B: 20 mm | Cr: 16.3 kN | C0r: 4.55 kN | Grease speed: 10000 rpm
2206K d: 30 mm | D: 62 mm | B: 20 mm | Cr: 16.3 kN | C0r: 4.55 kN | Grease speed: 10000 rpm
2207 d: 35 mm | D: 72 mm | B: 23 mm | Cr: 21.7 kN | C0r: 6.6 kN | Grease speed: 8500 rpm
2207K d: 35 mm | D: 72 mm | B: 23 mm | Cr: 21.7 kN | C0r: 6.6 kN | Grease speed: 8500 rpm
2208 d: 40 mm | D: 80 mm | B: 23 mm | Cr: 22.4 kN | C0r: 7.35 kN | Grease speed: 7500 rpm
2208K d: 40 mm | D: 80 mm | B: 23 mm | Cr: 22.4 kN | C0r: 7.35 kN | Grease speed: 7500 rpm
2209 d: 45 mm | D: 85 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.15 kN | Grease speed: 7100 rpm
2209K d: 45 mm | D: 85 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.15 kN | Grease speed: 7100 rpm
2210 d: 50 mm | D: 90 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.45 kN | Grease speed: 6300 rpm
2210K d: 50 mm | D: 90 mm | B: 23 mm | Cr: 23.3 kN | C0r: 8.45 kN | Grease speed: 6300 rpm
2211 d: 55 mm | D: 100 mm | B: 25 mm | Cr: 26.7 kN | C0r: 9.9 kN | Grease speed: 6000 rpm
2211K d: 55 mm | D: 100 mm | B: 25 mm | Cr: 26.7 kN | C0r: 9.9 kN | Grease speed: 6000 rpm
2212 d: 60 mm | D: 110 mm | B: 28 mm | Cr: 34 kN | C0r: 12.6 kN | Grease speed: 5300 rpm
2212K d: 60 mm | D: 110 mm | B: 28 mm | Cr: 34 kN | C0r: 12.6 kN | Grease speed: 5300 rpm
2213 d: 65 mm | D: 120 mm | B: 31 mm | Cr: 43.5 kN | C0r: 16.4 kN | Grease speed: 4800 rpm
2213K d: 65 mm | D: 120 mm | B: 31 mm | Cr: 43.5 kN | C0r: 16.4 kN | Grease speed: 4800 rpm
2214 d: 70 mm | D: 125 mm | B: 31 mm | Cr: 44 kN | C0r: 17.1 kN | Grease speed: 4500 rpm
2215 d: 75 mm | D: 130 mm | B: 31 mm | Cr: 44.5 kN | C0r: 17.8 kN | Grease speed: 4300 rpm
2215K d: 75 mm | D: 130 mm | B: 31 mm | Cr: 44.5 kN | C0r: 17.8 kN | Grease speed: 4300 rpm
2216 d: 80 mm | D: 140 mm | B: 33 mm | Cr: 49 kN | C0r: 19.9 kN | Grease speed: 4000 rpm
2216K d: 80 mm | D: 140 mm | B: 33 mm | Cr: 49 kN | C0r: 19.9 kN | Grease speed: 4000 rpm
2217 d: 85 mm | D: 150 mm | B: 36 mm | Cr: 58.5 kN | C0r: 23.6 kN | Grease speed: 3800 rpm
2217K d: 85 mm | D: 150 mm | B: 36 mm | Cr: 58.5 kN | C0r: 23.6 kN | Grease speed: 3800 rpm
2218 d: 90 mm | D: 160 mm | B: 40 mm | Cr: 70.5 kN | C0r: 28.7 kN | Grease speed: 3600 rpm
2218K d: 90 mm | D: 160 mm | B: 40 mm | Cr: 70.5 kN | C0r: 28.7 kN | Grease speed: 3600 rpm
2219 d: 95 mm | D: 170 mm | B: 43 mm | Cr: 84 kN | C0r: 34.5 kN | Grease speed: 3400 rpm
2219K d: 95 mm | D: 170 mm | B: 43 mm | Cr: 84 kN | C0r: 34.5 kN | Grease speed: 3400 rpm
2220 d: 100 mm | D: 180 mm | B: 46 mm | Cr: 94.5 kN | C0r: 38.5 kN | Grease speed: 3200 rpm
2220K d: 100 mm | D: 180 mm | B: 46 mm | Cr: 94.5 kN | C0r: 38.5 kN | Grease speed: 3200 rpm
2221 d: 105 mm | D: 190 mm | B: 50 mm | Cr: 109 kN | C0r: 45 kN | Grease speed: 3000 rpm
2222 d: 110 mm | D: 200 mm | B: 53 mm | Cr: 122 kN | C0r: 51.5 kN | Grease speed: 2600 rpm
2222K d: 110 mm | D: 200 mm | B: 53 mm | Cr: 122 kN | C0r: 51.5 kN | Grease speed: 2600 rpm
