NSK 222 Series Spherical Roller Bearings (Cylindrical & K Bore)

NSK 222 Series Spherical Roller Bearings (Cylindrical & K Bore)

NSK 222 series double-row spherical roller bearings, bore 25-320 mm, with cylindrical bore and tapered bore (K) designations as listed.

Key features

  • Double-row barrel rollers with spherical outer-ring raceway for self-alignment
  • High radial and moderate two-direction axial load capacity
  • K suffix: tapered bore (1:12) for sleeve mounting
  • Cage and design suffixes (EA, CA, CD, C, H, E4) as printed
  • Suitable for heavy-duty, misaligned or shock-loaded applications

Specifications

Bearing type Spherical roller bearing
Series 222
Bore range 25-320 mm
Bore type Cylindrical; K = tapered
Load ratings Basic dynamic Cr / static C0r
Speed basis Grease lubrication limit
Source NSK Rolling Bearings Catalogue (Korean ed.), p. B180-B201
22205H d: 25 mm | D: 52 mm | B: 18 mm | Cr: 44 kN | C0r: 45.5 kN | Grease speed: 8000 rpm
22205HK d: 25 mm | D: 52 mm | B: 18 mm | Cr: 44 kN | C0r: 45.5 kN | Grease speed: 8000 rpm
22205C d: 25 mm | D: 52 mm | B: 18 mm | Cr: 37.5 kN | C0r: 37 kN | Grease speed: 7100 rpm
22205CK d: 25 mm | D: 52 mm | B: 18 mm | Cr: 37.5 kN | C0r: 37 kN | Grease speed: 7100 rpm
22206H d: 30 mm | D: 62 mm | B: 20 mm | Cr: 58.5 kN | C0r: 61.5 kN | Grease speed: 6700 rpm
22206HK d: 30 mm | D: 62 mm | B: 20 mm | Cr: 58.5 kN | C0r: 61.5 kN | Grease speed: 6700 rpm
22206C d: 30 mm | D: 62 mm | B: 20 mm | Cr: 50 kN | C0r: 50 kN | Grease speed: 6000 rpm
22206CK d: 30 mm | D: 62 mm | B: 20 mm | Cr: 50 kN | C0r: 50 kN | Grease speed: 6000 rpm
22207H d: 35 mm | D: 72 mm | B: 23 mm | Cr: 78.5 kN | C0r: 84 kN | Grease speed: 5600 rpm
22207HK d: 35 mm | D: 72 mm | B: 23 mm | Cr: 78.5 kN | C0r: 84 kN | Grease speed: 5600 rpm
22207C d: 35 mm | D: 72 mm | B: 23 mm | Cr: 69 kN | C0r: 71 kN | Grease speed: 5300 rpm
22207CK d: 35 mm | D: 72 mm | B: 23 mm | Cr: 69 kN | C0r: 71 kN | Grease speed: 5300 rpm
22208H d: 40 mm | D: 80 mm | B: 23 mm | Cr: 89.5 kN | C0r: 95 kN | Grease speed: 5000 rpm
22208HK d: 40 mm | D: 80 mm | B: 23 mm | Cr: 89.5 kN | C0r: 95 kN | Grease speed: 5000 rpm
22208CD d: 40 mm | D: 80 mm | B: 23 mm | Cr: 74.5 kN | C0r: 81.5 kN | Grease speed: 4300 rpm
22208CDK d: 40 mm | D: 80 mm | B: 23 mm | Cr: 74.5 kN | C0r: 81.5 kN | Grease speed: 4300 rpm
22209H d: 45 mm | D: 85 mm | B: 23 mm | Cr: 95 kN | C0r: 107 kN | Grease speed: 4500 rpm
22209HK d: 45 mm | D: 85 mm | B: 23 mm | Cr: 95 kN | C0r: 107 kN | Grease speed: 4500 rpm
22209CD d: 45 mm | D: 85 mm | B: 23 mm | Cr: 78 kN | C0r: 88 kN | Grease speed: 4300 rpm
22209CDK d: 45 mm | D: 85 mm | B: 23 mm | Cr: 78 kN | C0r: 88 kN | Grease speed: 4300 rpm
22210EAE4 d: 50 mm | D: 90 mm | B: 23 mm | Cr: 99 kN | C0r: 119 kN | Grease speed: 5000 rpm
22210EAKE4 d: 50 mm | D: 90 mm | B: 23 mm | Cr: 99 kN | C0r: 119 kN | Grease speed: 5000 rpm
22210H d: 50 mm | D: 90 mm | B: 23 mm | Cr: 99.5 kN | C0r: 116 kN | Grease speed: 4300 rpm
22210HK d: 50 mm | D: 90 mm | B: 23 mm | Cr: 99.5 kN | C0r: 116 kN | Grease speed: 4300 rpm
22211EAE4 d: 55 mm | D: 100 mm | B: 25 mm | Cr: 119 kN | C0r: 144 kN | Grease speed: 4500 rpm
22211EAKE4 d: 55 mm | D: 100 mm | B: 25 mm | Cr: 119 kN | C0r: 144 kN | Grease speed: 4500 rpm
22211H d: 55 mm | D: 100 mm | B: 25 mm | Cr: 122 kN | C0r: 143 kN | Grease speed: 3800 rpm
22211HK d: 55 mm | D: 100 mm | B: 25 mm | Cr: 122 kN | C0r: 143 kN | Grease speed: 3800 rpm
22212EAE4 d: 60 mm | D: 110 mm | B: 28 mm | Cr: 142 kN | C0r: 174 kN | Grease speed: 4300 rpm
22212EAKE4 d: 60 mm | D: 110 mm | B: 28 mm | Cr: 142 kN | C0r: 174 kN | Grease speed: 4300 rpm
22212H d: 60 mm | D: 110 mm | B: 28 mm | Cr: 150 kN | C0r: 174 kN | Grease speed: 3600 rpm
22212HK d: 60 mm | D: 110 mm | B: 28 mm | Cr: 150 kN | C0r: 174 kN | Grease speed: 3600 rpm
22213EAE4 d: 65 mm | D: 120 mm | B: 31 mm | Cr: 177 kN | C0r: 230 kN | Grease speed: 3800 rpm
22213EAKE4 d: 65 mm | D: 120 mm | B: 31 mm | Cr: 177 kN | C0r: 230 kN | Grease speed: 3800 rpm
22213H d: 65 mm | D: 120 mm | B: 31 mm | Cr: 175 kN | C0r: 216 kN | Grease speed: 3200 rpm
22213HK d: 65 mm | D: 120 mm | B: 31 mm | Cr: 175 kN | C0r: 216 kN | Grease speed: 3200 rpm
22214EAE4 d: 70 mm | D: 125 mm | B: 31 mm | Cr: 180 kN | C0r: 232 kN | Grease speed: 3600 rpm
22214EAKE4 d: 70 mm | D: 125 mm | B: 31 mm | Cr: 180 kN | C0r: 232 kN | Grease speed: 3600 rpm
22214H d: 70 mm | D: 125 mm | B: 31 mm | Cr: 182 kN | C0r: 230 kN | Grease speed: 3000 rpm
22214HK d: 70 mm | D: 125 mm | B: 31 mm | Cr: 182 kN | C0r: 230 kN | Grease speed: 3000 rpm
22215EAE4 d: 75 mm | D: 130 mm | B: 31 mm | Cr: 190 kN | C0r: 244 kN | Grease speed: 3400 rpm
22215EAKE4 d: 75 mm | D: 130 mm | B: 31 mm | Cr: 190 kN | C0r: 244 kN | Grease speed: 3400 rpm
22215H d: 75 mm | D: 130 mm | B: 31 mm | Cr: 190 kN | C0r: 247 kN | Grease speed: 3000 rpm
22215HK d: 75 mm | D: 130 mm | B: 31 mm | Cr: 190 kN | C0r: 247 kN | Grease speed: 3000 rpm
22216EAE4 d: 80 mm | D: 140 mm | B: 33 mm | Cr: 212 kN | C0r: 275 kN | Grease speed: 3200 rpm
22216EAKE4 d: 80 mm | D: 140 mm | B: 33 mm | Cr: 212 kN | C0r: 275 kN | Grease speed: 3200 rpm
22216H d: 80 mm | D: 140 mm | B: 33 mm | Cr: 214 kN | C0r: 273 kN | Grease speed: 2800 rpm
22216HK d: 80 mm | D: 140 mm | B: 33 mm | Cr: 214 kN | C0r: 273 kN | Grease speed: 2800 rpm
22217EAE4 d: 85 mm | D: 150 mm | B: 36 mm | Cr: 250 kN | C0r: 325 kN | Grease speed: 3000 rpm
22217EAKE4 d: 85 mm | D: 150 mm | B: 36 mm | Cr: 250 kN | C0r: 325 kN | Grease speed: 3000 rpm
22217H d: 85 mm | D: 150 mm | B: 36 mm | Cr: 251 kN | C0r: 315 kN | Grease speed: 2600 rpm
22217HK d: 85 mm | D: 150 mm | B: 36 mm | Cr: 251 kN | C0r: 315 kN | Grease speed: 2600 rpm
22218EAE4 d: 90 mm | D: 160 mm | B: 40 mm | Cr: 289 kN | C0r: 395 kN | Grease speed: 2800 rpm
22218EAKE4 d: 90 mm | D: 160 mm | B: 40 mm | Cr: 289 kN | C0r: 395 kN | Grease speed: 2800 rpm
22218H d: 90 mm | D: 160 mm | B: 40 mm | Cr: 292 kN | C0r: 375 kN | Grease speed: 2400 rpm
22218HK d: 90 mm | D: 160 mm | B: 40 mm | Cr: 292 kN | C0r: 375 kN | Grease speed: 2400 rpm
22219EAE4 d: 95 mm | D: 170 mm | B: 43 mm | Cr: 330 kN | C0r: 450 kN | Grease speed: 2600 rpm
22219EAKE4 d: 95 mm | D: 170 mm | B: 43 mm | Cr: 330 kN | C0r: 450 kN | Grease speed: 2600 rpm
22219H d: 95 mm | D: 170 mm | B: 43 mm | Cr: 330 kN | C0r: 425 kN | Grease speed: 2200 rpm
22219HK d: 95 mm | D: 170 mm | B: 43 mm | Cr: 330 kN | C0r: 425 kN | Grease speed: 2200 rpm
22220EAE4 d: 100 mm | D: 180 mm | B: 46 mm | Cr: 365 kN | C0r: 490 kN | Grease speed: 2400 rpm
22220EAKE4 d: 100 mm | D: 180 mm | B: 46 mm | Cr: 365 kN | C0r: 490 kN | Grease speed: 2400 rpm
22220H d: 100 mm | D: 180 mm | B: 46 mm | Cr: 375 kN | C0r: 490 kN | Grease speed: 2200 rpm
22220HK d: 100 mm | D: 180 mm | B: 46 mm | Cr: 375 kN | C0r: 490 kN | Grease speed: 2200 rpm
22222EAE4 d: 110 mm | D: 200 mm | B: 53 mm | Cr: 485 kN | C0r: 645 kN | Grease speed: 2200 rpm
22222EAKE4 d: 110 mm | D: 200 mm | B: 53 mm | Cr: 485 kN | C0r: 645 kN | Grease speed: 2200 rpm
22222H d: 110 mm | D: 200 mm | B: 53 mm | Cr: 475 kN | C0r: 635 kN | Grease speed: 1900 rpm
22222HK d: 110 mm | D: 200 mm | B: 53 mm | Cr: 475 kN | C0r: 635 kN | Grease speed: 1900 rpm
22224EAE4 d: 120 mm | D: 215 mm | B: 58 mm | Cr: 55 kN | C0r: 765 kN | Grease speed: 2000 rpm
22224EAKE4 d: 120 mm | D: 215 mm | B: 58 mm | Cr: 55 kN | C0r: 765 kN | Grease speed: 2000 rpm
22224H d: 120 mm | D: 215 mm | B: 58 mm | Cr: 550 kN | C0r: 755 kN | Grease speed: 1700 rpm
22224HK d: 120 mm | D: 215 mm | B: 58 mm | Cr: 550 kN | C0r: 755 kN | Grease speed: 1700 rpm
22226EAE4 d: 130 mm | D: 230 mm | B: 64 mm | Cr: 655 kN | C0r: 940 kN | Grease speed: 1900 rpm
22226EAKE4 d: 130 mm | D: 230 mm | B: 64 mm | Cr: 655 kN | C0r: 940 kN | Grease speed: 1900 rpm
22226H d: 130 mm | D: 230 mm | B: 64 mm | Cr: 655 kN | C0r: 915 kN | Grease speed: 1600 rpm
22226HK d: 130 mm | D: 230 mm | B: 64 mm | Cr: 655 kN | C0r: 915 kN | Grease speed: 1600 rpm
22228CD d: 140 mm | D: 250 mm | B: 68 mm | Cr: 645 kN | C0r: 930 kN | Grease speed: 1400 rpm
22228CDK d: 140 mm | D: 250 mm | B: 68 mm | Cr: 645 kN | C0r: 930 kN | Grease speed: 1400 rpm
22230CD d: 150 mm | D: 270 mm | B: 73 mm | Cr: 76.5 kN | C0r: 1120 kN | Grease speed: 1300 rpm
22230CDK d: 150 mm | D: 270 mm | B: 73 mm | Cr: 76.5 kN | C0r: 1120 kN | Grease speed: 1300 rpm
22232CD d: 160 mm | D: 290 mm | B: 80 mm | Cr: 910 kN | C0r: 1320 kN | Grease speed: 1200 rpm
22232CDK d: 160 mm | D: 290 mm | B: 80 mm | Cr: 910 kN | C0r: 1320 kN | Grease speed: 1200 rpm
22234CD d: 170 mm | D: 310 mm | B: 86 mm | Cr: 990 kN | C0r: 1500 kN | Grease speed: 1100 rpm
22234CDK d: 170 mm | D: 310 mm | B: 86 mm | Cr: 990 kN | C0r: 1500 kN | Grease speed: 1100 rpm
22236CD d: 180 mm | D: 320 mm | B: 86 mm | Cr: 1020 kN | C0r: 1540 kN | Grease speed: 1100 rpm
22236CDK d: 180 mm | D: 320 mm | B: 86 mm | Cr: 1020 kN | C0r: 1540 kN | Grease speed: 1100 rpm
22238CA d: 190 mm | D: 340 mm | B: 92 mm | Cr: 1140 kN | C0r: 1730 kN | Grease speed: 1000 rpm
22238CAK d: 190 mm | D: 340 mm | B: 92 mm | Cr: 1140 kN | C0r: 1730 kN | Grease speed: 1000 rpm
22240CA d: 200 mm | D: 360 mm | B: 98 mm | Cr: 1300 kN | C0r: 2010 kN | Grease speed: 950 rpm
22240CAK d: 200 mm | D: 360 mm | B: 98 mm | Cr: 1300 kN | C0r: 2010 kN | Grease speed: 950 rpm
22244CA d: 220 mm | D: 400 mm | B: 108 mm | Cr: 1570 kN | C0r: 2430 kN | Grease speed: 850 rpm
22244CAK d: 220 mm | D: 400 mm | B: 108 mm | Cr: 1570 kN | C0r: 2430 kN | Grease speed: 850 rpm
22248CA d: 240 mm | D: 440 mm | B: 120 mm | Cr: 1870 kN | C0r: 2890 kN | Grease speed: 750 rpm
22248CAK d: 240 mm | D: 440 mm | B: 120 mm | Cr: 1870 kN | C0r: 2890 kN | Grease speed: 750 rpm
22252CA d: 260 mm | D: 480 mm | B: 130 mm | Cr: 2180 kN | C0r: 3400 kN | Grease speed: 670 rpm
22252CAK d: 260 mm | D: 480 mm | B: 130 mm | Cr: 2180 kN | C0r: 3400 kN | Grease speed: 670 rpm
22256CA d: 280 mm | D: 500 mm | B: 130 mm | Cr: 2280 kN | C0r: 3650 kN | Grease speed: 630 rpm
22256CAK d: 280 mm | D: 500 mm | B: 130 mm | Cr: 2280 kN | C0r: 3650 kN | Grease speed: 630 rpm
22260CA d: 300 mm | D: 540 mm | B: 140 mm | Cr: 2610 kN | C0r: 4250 kN | Grease speed: 600 rpm
22260CAK d: 300 mm | D: 540 mm | B: 140 mm | Cr: 2610 kN | C0r: 4250 kN | Grease speed: 600 rpm
22264CA d: 320 mm | D: 580 mm | B: 150 mm | Cr: 2990 kN | C0r: 4850 kN | Grease speed: 630 rpm
22264CAK d: 320 mm | D: 580 mm | B: 150 mm | Cr: 2990 kN | C0r: 4850 kN | Grease speed: 630 rpm
