• NSK 292 / 293 / 294 Spherical Roller Thrust Bearings
1 1

NSK 292 / 293 / 294 Spherical Roller Thrust Bearings

NSK 292 / 293 / 294 Spherical Roller Thrust Bearings

NSK 292, 293 and 294 series spherical roller thrust bearings, bore 60-500 mm, combining very high axial capacity with self-alignment.

Key features

  • Spherical housing-washer raceway allows self-alignment
  • Very high axial load capacity; can also carry some radial load
  • E suffix: high-capacity design
  • Speed shown for oil lubrication as printed

Specifications

Bearing type Spherical roller thrust bearing
Series 292, 293, 294
Bore range 60-500 mm
Load ratings Axial dynamic Ca / static C0a
Speed basis Oil lubrication limit
Source NSK Rolling Bearings Catalogue (Korean ed.), p. B224-B229
29412E d: 60 mm | D: 130 mm | Height: 42 mm | Ca: 330 kN | C0a: 885 kN | Oil speed: 2600 rpm
29413E d: 65 mm | D: 140 mm | Height: 45 mm | Ca: 405 kN | C0a: 1100 kN | Oil speed: 2400 rpm
29414E d: 70 mm | D: 150 mm | Height: 48 mm | Ca: 450 kN | C0a: 1240 kN | Oil speed: 2400 rpm
29415E d: 75 mm | D: 160 mm | Height: 51 mm | Ca: 515 kN | C0a: 1430 kN | Oil speed: 2200 rpm
29416E d: 80 mm | D: 170 mm | Height: 54 mm | Ca: 575 kN | C0a: 1600 kN | Oil speed: 2000 rpm
29317E d: 85 mm | D: 150 mm | Height: 39 mm | Ca: 330 kN | C0a: 104 kN | Oil speed: 2400 rpm
29417E d: 85 mm | D: 180 mm | Height: 58 mm | Ca: 630 kN | C0a: 1760 kN | Oil speed: 1900 rpm
29318E d: 90 mm | D: 155 mm | Height: 39 mm | Ca: 350 kN | C0a: 1080 kN | Oil speed: 2200 rpm
29418E d: 90 mm | D: 190 mm | Height: 60 mm | Ca: 695 kN | C0a: 1950 kN | Oil speed: 1800 rpm
29320E d: 100 mm | D: 170 mm | Height: 42 mm | Ca: 410 kN | C0a: 1280 kN | Oil speed: 2000 rpm
29420E d: 100 mm | D: 210 mm | Height: 67 mm | Ca: 840 kN | C0a: 2400 kN | Oil speed: 1600 rpm
29322E d: 110 mm | D: 190 mm | Height: 48 mm | Ca: 630 kN | C0a: 1710 kN | Oil speed: 1800 rpm
29422E d: 110 mm | D: 230 mm | Height: 73 mm | Ca: 1010 kN | C0a: 2930 kN | Oil speed: 1500 rpm
29324E d: 120 mm | D: 210 mm | Height: 54 mm | Ca: 645 kN | C0a: 2101 kN | Oil speed: 1600 rpm
29424E d: 120 mm | D: 250 mm | Height: 78 mm | Ca: 1160 kN | C0a: 3400 kN | Oil speed: 1400 rpm
29326E d: 130 mm | D: 225 mm | Height: 58 mm | Ca: 740 kN | C0a: 2450 kN | Oil speed: 1500 rpm
29426E d: 130 mm | D: 270 mm | Height: 85 mm | Ca: 1330 kN | C0a: 3900 kN | Oil speed: 200 rpm
29328E d: 140 mm | D: 240 mm | Height: 60 mm | Ca: 840 kN | C0a: 2810 kN | Oil speed: 1400 rpm
29428E d: 140 mm | D: 280 mm | Height: 85 mm | Ca: 1370 kN | C0a: 4200 kN | Oil speed: 1200 rpm
29330E d: 150 mm | D: 250 mm | Height: 60 mm | Ca: 870 kN | C0a: 2900 kN | Oil speed: 1400 rpm
29430E d: 150 mm | D: 300 mm | Height: 90 mm | Ca: 1580 kN | C0a: 4900 kN | Oil speed: 1100 rpm
29332E d: 160 mm | D: 270 mm | Height: 67 mm | Ca: 1010 kN | C0a: 3400 kN | Oil speed: 1300 rpm
29432E d: 160 mm | D: 320 mm | Height: 95 mm | Ca: 1740 kN | C0a: 5400 kN | Oil speed: 1100 rpm
29334E d: 170 mm | D: 280 mm | Height: 67 mm | Ca: 1050 kN | C0a: 3500 kN | Oil speed: 1200 rpm
29434 d: 170 mm | D: 340 mm | Height: 103 mm | Ca: 1680 kN | C0a: 5800 kN | Oil speed: 1000 rpm
29336E d: 180 mm | D: 300 mm | Height: 73 mm | Ca: 1230 kN | C0a: 4200 kN | Oil speed: 1100 rpm
29436 d: 180 mm | D: 360 mm | Height: 108 mm | Ca: 1870 kN | C0a: 6500 kN | Oil speed: 900 rpm
29338E d: 190 mm | D: 320 mm | Height: 78 mm | Ca: 1370 kN | C0a: 4700 kN | Oil speed: 1100 rpm
29438 d: 190 mm | D: 380 mm | Height: 115 mm | Ca: 2100 kN | C0a: 7450 kN | Oil speed: 850 rpm
29240 d: 200 mm | D: 280 mm | Height: 48 mm | Ca: 540 kN | C0a: 2310 kN | Oil speed: 1600 rpm
29340E d: 200 mm | D: 340 mm | Height: 85 mm | Ca: 1570 kN | C0a: 6460 kN | Oil speed: 1000 rpm
29440 d: 200 mm | D: 400 mm | Height: 122 mm | Ca: 2290 kN | C0a: 8150 kN | Oil speed: 800 rpm
29244 d: 220 mm | D: 300 mm | Height: 48 mm | Ca: 560 kN | C0a: 2500 kN | Oil speed: 1400 rpm
29344 d: 220 mm | D: 360 mm | Height: 85 mm | Ca: 1340 kN | C0a: 5200 kN | Oil speed: 950 rpm
29444 d: 220 mm | D: 420 mm | Height: 122 mm | Ca: 2360 kN | C0a: 8650 kN | Oil speed: 800 rpm
29248 d: 240 mm | D: 340 mm | Height: 60 mm | Ca: 800 kN | C0a: 3450 kN | Oil speed: 1200 rpm
29348 d: 240 mm | D: 380 mm | Height: 85 mm | Ca: 1360 kN | C0a: 5400 kN | Oil speed: 950 rpm
29448 d: 240 mm | D: 440 mm | Height: 122 mm | Ca: 2420 kN | C0a: 9100 kN | Oil speed: 750 rpm
29252 d: 260 mm | D: 360 mm | Height: 60 mm | Ca: 855 kN | C0a: 3850 kN | Oil speed: 1200 rpm
29352 d: 260 mm | D: 420 mm | Height: 95 mm | Ca: 1700 kN | C0a: 6800 kN | Oil speed: 800 rpm
29452 d: 260 mm | D: 480 mm | Height: 132 mm | Ca: 2820 kN | C0a: 10700 kN | Oil speed: 710 rpm
29256 d: 280 mm | D: 380 mm | Height: 60 mm | Ca: 885 kN | C0a: 4100 kN | Oil speed: 1100 rpm
29356 d: 280 mm | D: 440 mm | Height: 95 mm | Ca: 1830 kN | C0a: 7650 kN | Oil speed: 800 rpm
29456 d: 280 mm | D: 520 mm | Height: 145 mm | Ca: 3400 kN | C0a: 13100 kN | Oil speed: 630 rpm
29260 d: 300 mm | D: 420 mm | Height: 73 mm | Ca: 1160 kN | C0a: 5150 kN | Oil speed: 950 rpm
29360 d: 300 mm | D: 480 mm | Height: 109 mm | Ca: 2198 kN | C0a: 9100 kN | Oil speed: 710 rpm
29460 d: 300 mm | D: 540 mm | Height: 145 mm | Ca: 3500 kN | C0a: 13700 kN | Oil speed: 630 rpm
29264 d: 320 mm | D: 440 mm | Height: 73 mm | Ca: 1180 kN | C0a: 5450 kN | Oil speed: 950 rpm
29364 d: 320 mm | D: 500 mm | Height: 109 mm | Ca: 2230 kN | C0a: 9400 kN | Oil speed: 670 rpm
29464 d: 320 mm | D: 580 mm | Height: 155 mm | Ca: 3650 kN | C0a: 14600 kN | Oil speed: 560 rpm
29268 d: 340 mm | D: 460 mm | Height: 73 mm | Ca: 1230 kN | C0a: 5750 kN | Oil speed: 900 rpm
29368 d: 340 mm | D: 540 mm | Height: 122 mm | Ca: 2640 kN | C0a: 11200 kN | Oil speed: 630 rpm
29468 d: 340 mm | D: 620 mm | Height: 170 mm | Ca: 4400 kN | C0a: 17400 kN | Oil speed: 530 rpm
29272 d: 360 mm | D: 500 mm | Height: 85 mm | Ca: 1550 kN | C0a: 7300 kN | Oil speed: 800 rpm
29372 d: 360 mm | D: 560 mm | Height: 122 mm | Ca: 2670 kN | C0a: 11500 kN | Oil speed: 600 rpm
29472 d: 360 mm | D: 640 mm | Height: 170 mm | Ca: 4200 kN | C0a: 17200 kN | Oil speed: 500 rpm
29276 d: 380 mm | D: 520 mm | Height: 85 mm | Ca: 1620 kN | C0a: 7800 kN | Oil speed: 800 rpm
29376 d: 380 mm | D: 600 mm | Height: 132 mm | Ca: 3300 kN | C0a: 14500 kN | Oil speed: 560 rpm
29476 d: 380 mm | D: 670 mm | Height: 175 mm | Ca: 4800 kN | C0a: 19500 kN | Oil speed: 480 rpm
29280 d: 400 mm | D: 540 mm | Height: 85 mm | Ca: 1640 kN | C0a: 8000 kN | Oil speed: 750 rpm
29380 d: 400 mm | D: 620 mm | Height: 132 mm | Ca: 3250 kN | C0a: 14500 kN | Oil speed: 530 rpm
29480 d: 400 mm | D: 710 mm | Height: 185 mm | Ca: 5400 kN | C0a: 22100 kN | Oil speed: 450 rpm
29284 d: 420 mm | D: 580 mm | Height: 95 mm | Ca: 2010 kN | C0a: 9800 kN | Oil speed: 670 rpm
29384 d: 420 mm | D: 650 mm | Height: 140 mm | Ca: 3500 kN | C0a: 15700 kN | Oil speed: 500 rpm
29484 d: 420 mm | D: 730 mm | Height: 185 mm | Ca: 5650 kN | C0a: 23500 kN | Oil speed: 450 rpm
29288 d: 440 mm | D: 600 mm | Height: 95 mm | Ca: 2030 kN | C0a: 10100 kN | Oil speed: 670 rpm
29388 d: 440 mm | D: 680 mm | Height: 145 mm | Ca: 3750 kN | C0a: 16700 kN | Oil speed: 480 rpm
29488 d: 440 mm | D: 780 mm | Height: 206 mm | Ca: 6550 kN | C0a: 27200 kN | Oil speed: 400 rpm
29292 d: 460 mm | D: 620 mm | Height: 95 mm | Ca: 2060 kN | C0a: 10300 kN | Oil speed: 670 rpm
29392 d: 460 mm | D: 710 mm | Height: 150 mm | Ca: 4100 kN | C0a: 18400 kN | Oil speed: 450 rpm
29492 d: 460 mm | D: 800 mm | Height: 206 mm | Ca: 6750 kN | C0a: 28600 kN | Oil speed: 380 rpm
29296 d: 480 mm | D: 650 mm | Height: 103 mm | Ca: 2370 kN | C0a: 12100 kN | Oil speed: 600 rpm
29396 d: 480 mm | D: 730 mm | Height: 150 mm | Ca: 4150 kN | C0a: 19000 kN | Oil speed: 450 rpm
29496 d: 480 mm | D: 850 mm | Height: 224 mm | Ca: 7200 kN | C0a: 31000 kN | Oil speed: 360 rpm
292/500 d: 500 mm | D: 670 mm | Height: 103 mm | Ca: 2390 kN | C0a: 12400 kN | Oil speed: 600 rpm
293/500 d: 500 mm | D: 750 mm | Height: 150 mm | Ca: 4350 kN | C0a: 20400 kN | Oil speed: 450 rpm
294/500 d: 500 mm | D: 870 mm | Height: 224 mm | Ca: 7850 kN | C0a: 33000 kN | Oil speed: 340 rpm
Thrust BearingsNSK
77 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NSK 292 / 293 / 294 Spherical Roller Thrust Bearings

Brand NSK·Thrust Bearings

Available part numbers (77)

29412E, 29413E, 29414E, 29415E, 29416E, 29317E, 29417E, 29318E, 29418E, 29320E + 67 more — see full table ↓

How to order

Send the NSK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
29412Ed: 60 mm | D: 130 mm | Height: 42 mm | Ca: 330 kN | C0a: 885 kN | Oil speed: 2600 rpm
29413Ed: 65 mm | D: 140 mm | Height: 45 mm | Ca: 405 kN | C0a: 1100 kN | Oil speed: 2400 rpm
29414Ed: 70 mm | D: 150 mm | Height: 48 mm | Ca: 450 kN | C0a: 1240 kN | Oil speed: 2400 rpm
29415Ed: 75 mm | D: 160 mm | Height: 51 mm | Ca: 515 kN | C0a: 1430 kN | Oil speed: 2200 rpm
29416Ed: 80 mm | D: 170 mm | Height: 54 mm | Ca: 575 kN | C0a: 1600 kN | Oil speed: 2000 rpm
29317Ed: 85 mm | D: 150 mm | Height: 39 mm | Ca: 330 kN | C0a: 104 kN | Oil speed: 2400 rpm
29417Ed: 85 mm | D: 180 mm | Height: 58 mm | Ca: 630 kN | C0a: 1760 kN | Oil speed: 1900 rpm
29318Ed: 90 mm | D: 155 mm | Height: 39 mm | Ca: 350 kN | C0a: 1080 kN | Oil speed: 2200 rpm
29418Ed: 90 mm | D: 190 mm | Height: 60 mm | Ca: 695 kN | C0a: 1950 kN | Oil speed: 1800 rpm
29320Ed: 100 mm | D: 170 mm | Height: 42 mm | Ca: 410 kN | C0a: 1280 kN | Oil speed: 2000 rpm
29420Ed: 100 mm | D: 210 mm | Height: 67 mm | Ca: 840 kN | C0a: 2400 kN | Oil speed: 1600 rpm
29322Ed: 110 mm | D: 190 mm | Height: 48 mm | Ca: 630 kN | C0a: 1710 kN | Oil speed: 1800 rpm
29422Ed: 110 mm | D: 230 mm | Height: 73 mm | Ca: 1010 kN | C0a: 2930 kN | Oil speed: 1500 rpm
29324Ed: 120 mm | D: 210 mm | Height: 54 mm | Ca: 645 kN | C0a: 2101 kN | Oil speed: 1600 rpm
29424Ed: 120 mm | D: 250 mm | Height: 78 mm | Ca: 1160 kN | C0a: 3400 kN | Oil speed: 1400 rpm
29326Ed: 130 mm | D: 225 mm | Height: 58 mm | Ca: 740 kN | C0a: 2450 kN | Oil speed: 1500 rpm
29426Ed: 130 mm | D: 270 mm | Height: 85 mm | Ca: 1330 kN | C0a: 3900 kN | Oil speed: 200 rpm
29328Ed: 140 mm | D: 240 mm | Height: 60 mm | Ca: 840 kN | C0a: 2810 kN | Oil speed: 1400 rpm
29428Ed: 140 mm | D: 280 mm | Height: 85 mm | Ca: 1370 kN | C0a: 4200 kN | Oil speed: 1200 rpm
29330Ed: 150 mm | D: 250 mm | Height: 60 mm | Ca: 870 kN | C0a: 2900 kN | Oil speed: 1400 rpm
29430Ed: 150 mm | D: 300 mm | Height: 90 mm | Ca: 1580 kN | C0a: 4900 kN | Oil speed: 1100 rpm
29332Ed: 160 mm | D: 270 mm | Height: 67 mm | Ca: 1010 kN | C0a: 3400 kN | Oil speed: 1300 rpm
29432Ed: 160 mm | D: 320 mm | Height: 95 mm | Ca: 1740 kN | C0a: 5400 kN | Oil speed: 1100 rpm
29334Ed: 170 mm | D: 280 mm | Height: 67 mm | Ca: 1050 kN | C0a: 3500 kN | Oil speed: 1200 rpm
29434d: 170 mm | D: 340 mm | Height: 103 mm | Ca: 1680 kN | C0a: 5800 kN | Oil speed: 1000 rpm
29336Ed: 180 mm | D: 300 mm | Height: 73 mm | Ca: 1230 kN | C0a: 4200 kN | Oil speed: 1100 rpm
29436d: 180 mm | D: 360 mm | Height: 108 mm | Ca: 1870 kN | C0a: 6500 kN | Oil speed: 900 rpm
29338Ed: 190 mm | D: 320 mm | Height: 78 mm | Ca: 1370 kN | C0a: 4700 kN | Oil speed: 1100 rpm
29438d: 190 mm | D: 380 mm | Height: 115 mm | Ca: 2100 kN | C0a: 7450 kN | Oil speed: 850 rpm
29240d: 200 mm | D: 280 mm | Height: 48 mm | Ca: 540 kN | C0a: 2310 kN | Oil speed: 1600 rpm
29340Ed: 200 mm | D: 340 mm | Height: 85 mm | Ca: 1570 kN | C0a: 6460 kN | Oil speed: 1000 rpm
29440d: 200 mm | D: 400 mm | Height: 122 mm | Ca: 2290 kN | C0a: 8150 kN | Oil speed: 800 rpm
29244d: 220 mm | D: 300 mm | Height: 48 mm | Ca: 560 kN | C0a: 2500 kN | Oil speed: 1400 rpm
29344d: 220 mm | D: 360 mm | Height: 85 mm | Ca: 1340 kN | C0a: 5200 kN | Oil speed: 950 rpm
29444d: 220 mm | D: 420 mm | Height: 122 mm | Ca: 2360 kN | C0a: 8650 kN | Oil speed: 800 rpm
29248d: 240 mm | D: 340 mm | Height: 60 mm | Ca: 800 kN | C0a: 3450 kN | Oil speed: 1200 rpm
29348d: 240 mm | D: 380 mm | Height: 85 mm | Ca: 1360 kN | C0a: 5400 kN | Oil speed: 950 rpm
29448d: 240 mm | D: 440 mm | Height: 122 mm | Ca: 2420 kN | C0a: 9100 kN | Oil speed: 750 rpm
29252d: 260 mm | D: 360 mm | Height: 60 mm | Ca: 855 kN | C0a: 3850 kN | Oil speed: 1200 rpm
29352d: 260 mm | D: 420 mm | Height: 95 mm | Ca: 1700 kN | C0a: 6800 kN | Oil speed: 800 rpm
29452d: 260 mm | D: 480 mm | Height: 132 mm | Ca: 2820 kN | C0a: 10700 kN | Oil speed: 710 rpm
29256d: 280 mm | D: 380 mm | Height: 60 mm | Ca: 885 kN | C0a: 4100 kN | Oil speed: 1100 rpm
29356d: 280 mm | D: 440 mm | Height: 95 mm | Ca: 1830 kN | C0a: 7650 kN | Oil speed: 800 rpm
29456d: 280 mm | D: 520 mm | Height: 145 mm | Ca: 3400 kN | C0a: 13100 kN | Oil speed: 630 rpm
29260d: 300 mm | D: 420 mm | Height: 73 mm | Ca: 1160 kN | C0a: 5150 kN | Oil speed: 950 rpm
29360d: 300 mm | D: 480 mm | Height: 109 mm | Ca: 2198 kN | C0a: 9100 kN | Oil speed: 710 rpm
29460d: 300 mm | D: 540 mm | Height: 145 mm | Ca: 3500 kN | C0a: 13700 kN | Oil speed: 630 rpm
29264d: 320 mm | D: 440 mm | Height: 73 mm | Ca: 1180 kN | C0a: 5450 kN | Oil speed: 950 rpm
29364d: 320 mm | D: 500 mm | Height: 109 mm | Ca: 2230 kN | C0a: 9400 kN | Oil speed: 670 rpm
29464d: 320 mm | D: 580 mm | Height: 155 mm | Ca: 3650 kN | C0a: 14600 kN | Oil speed: 560 rpm
29268d: 340 mm | D: 460 mm | Height: 73 mm | Ca: 1230 kN | C0a: 5750 kN | Oil speed: 900 rpm
29368d: 340 mm | D: 540 mm | Height: 122 mm | Ca: 2640 kN | C0a: 11200 kN | Oil speed: 630 rpm
29468d: 340 mm | D: 620 mm | Height: 170 mm | Ca: 4400 kN | C0a: 17400 kN | Oil speed: 530 rpm
29272d: 360 mm | D: 500 mm | Height: 85 mm | Ca: 1550 kN | C0a: 7300 kN | Oil speed: 800 rpm
29372d: 360 mm | D: 560 mm | Height: 122 mm | Ca: 2670 kN | C0a: 11500 kN | Oil speed: 600 rpm
29472d: 360 mm | D: 640 mm | Height: 170 mm | Ca: 4200 kN | C0a: 17200 kN | Oil speed: 500 rpm
29276d: 380 mm | D: 520 mm | Height: 85 mm | Ca: 1620 kN | C0a: 7800 kN | Oil speed: 800 rpm
29376d: 380 mm | D: 600 mm | Height: 132 mm | Ca: 3300 kN | C0a: 14500 kN | Oil speed: 560 rpm
29476d: 380 mm | D: 670 mm | Height: 175 mm | Ca: 4800 kN | C0a: 19500 kN | Oil speed: 480 rpm
29280d: 400 mm | D: 540 mm | Height: 85 mm | Ca: 1640 kN | C0a: 8000 kN | Oil speed: 750 rpm
29380d: 400 mm | D: 620 mm | Height: 132 mm | Ca: 3250 kN | C0a: 14500 kN | Oil speed: 530 rpm
29480d: 400 mm | D: 710 mm | Height: 185 mm | Ca: 5400 kN | C0a: 22100 kN | Oil speed: 450 rpm
29284d: 420 mm | D: 580 mm | Height: 95 mm | Ca: 2010 kN | C0a: 9800 kN | Oil speed: 670 rpm
29384d: 420 mm | D: 650 mm | Height: 140 mm | Ca: 3500 kN | C0a: 15700 kN | Oil speed: 500 rpm
29484d: 420 mm | D: 730 mm | Height: 185 mm | Ca: 5650 kN | C0a: 23500 kN | Oil speed: 450 rpm
29288d: 440 mm | D: 600 mm | Height: 95 mm | Ca: 2030 kN | C0a: 10100 kN | Oil speed: 670 rpm
29388d: 440 mm | D: 680 mm | Height: 145 mm | Ca: 3750 kN | C0a: 16700 kN | Oil speed: 480 rpm
29488d: 440 mm | D: 780 mm | Height: 206 mm | Ca: 6550 kN | C0a: 27200 kN | Oil speed: 400 rpm
29292d: 460 mm | D: 620 mm | Height: 95 mm | Ca: 2060 kN | C0a: 10300 kN | Oil speed: 670 rpm
29392d: 460 mm | D: 710 mm | Height: 150 mm | Ca: 4100 kN | C0a: 18400 kN | Oil speed: 450 rpm
29492d: 460 mm | D: 800 mm | Height: 206 mm | Ca: 6750 kN | C0a: 28600 kN | Oil speed: 380 rpm
29296d: 480 mm | D: 650 mm | Height: 103 mm | Ca: 2370 kN | C0a: 12100 kN | Oil speed: 600 rpm
29396d: 480 mm | D: 730 mm | Height: 150 mm | Ca: 4150 kN | C0a: 19000 kN | Oil speed: 450 rpm
29496d: 480 mm | D: 850 mm | Height: 224 mm | Ca: 7200 kN | C0a: 31000 kN | Oil speed: 360 rpm
292/500d: 500 mm | D: 670 mm | Height: 103 mm | Ca: 2390 kN | C0a: 12400 kN | Oil speed: 600 rpm
293/500d: 500 mm | D: 750 mm | Height: 150 mm | Ca: 4350 kN | C0a: 20400 kN | Oil speed: 450 rpm
294/500d: 500 mm | D: 870 mm | Height: 224 mm | Ca: 7850 kN | C0a: 33000 kN | Oil speed: 340 rpm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
