NSK EWP 2 / EWP 3 Pillow Block Units with Eccentric Collar

NSK EWP cast iron pillow block units with EW insert bearings locked by an eccentric locking collar, shaft diameters 20 to 65 mm.

Key features

Cast iron pillow block housing with self-aligning spherical seat
Eccentric collar locking of the EW insert bearing
Sealed and pre-greased insert
Light (EWP 2) and medium (EWP 3) series

Specifications

Product	Ball bearing unit
Housing	Cast iron
Insert	Deep groove ball bearing, spherical OD
Locking	Eccentric collar
Shaft	20-65 mm
Series	EWP 2, EWP 3
Source	NSK Rolling Bearings Catalogue (Part 3), p. 286-287

EWP 204		Shaft: 20 mm \| Bearing: EW 204 \| L: 127 mm \| H: 33.3 mm \| Cr: 12.8 kN
EWP 205		Shaft: 25 mm \| Bearing: EW 205 \| L: 140 mm \| H: 36.5 mm \| Cr: 14 kN
EWP 305		Shaft: 25 mm \| Bearing: EW 305 \| L: 175 mm \| H: 45 mm \| Cr: 20.6 kN
EWP 206		Shaft: 30 mm \| Bearing: EW 206 \| L: 165 mm \| H: 42.9 mm \| Cr: 19.5 kN
EWP 306		Shaft: 30 mm \| Bearing: EW 306 \| L: 180 mm \| H: 50 mm \| Cr: 26.7 kN
EWP 207		Shaft: 35 mm \| Bearing: EW 207 \| L: 167 mm \| H: 47.6 mm \| Cr: 25.7 kN
EWP 307		Shaft: 35 mm \| Bearing: EW 307 \| L: 210 mm \| H: 56 mm \| Cr: 33.5 kN
EWP 208		Shaft: 40 mm \| Bearing: EW 208 \| L: 184 mm \| H: 49.2 mm \| Cr: 29.1 kN
EWP 308		Shaft: 40 mm \| Bearing: EW 308 \| L: 220 mm \| H: 60 mm \| Cr: 40.5 kN
EWP 209		Shaft: 45 mm \| Bearing: EW 209 \| L: 190 mm \| H: 54 mm \| Cr: 31.5 kN
EWP 309		Shaft: 45 mm \| Bearing: EW 309 \| L: 245 mm \| H: 67 mm \| Cr: 53 kN
EWP 210		Shaft: 50 mm \| Bearing: EW 210 \| L: 206 mm \| H: 57.2 mm \| Cr: 35 kN
EWP 310		Shaft: 50 mm \| Bearing: EW 310 \| L: 275 mm \| H: 75 mm \| Cr: 62 kN
EWP 211		Shaft: 55 mm \| Bearing: EW 211 \| L: 219 mm \| H: 63.5 mm \| Cr: 43.5 kN
EWP 311		Shaft: 55 mm \| Bearing: EW 311 \| L: 310 mm \| H: 80 mm \| Cr: 71.5 kN
EWP 212		Shaft: 60 mm \| Bearing: EW 212 \| L: 241 mm \| H: 69.8 mm \| Cr: 52.5 kN
EWP 312		Shaft: 60 mm \| Bearing: EW 312 \| L: 330 mm \| H: 85 mm \| Cr: 82 kN
EWP 313		Shaft: 65 mm \| Bearing: EW 313 \| L: 340 mm \| H: 90 mm \| Cr: 92.5 kN

Mounted Bearing UnitsNSK

18 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NSK EWP 2 / EWP 3 Pillow Block Units with Eccentric Collar

Brand NSK·Mounted Bearing Units

Available part numbers (18)

EWP 204, EWP 205, EWP 305, EWP 206, EWP 306, EWP 207, EWP 307, EWP 208, EWP 308, EWP 209 + 8 more — see full table ↓

How to order

Send the NSK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
