NSK ISO-Designated Tapered Roller Bearings (T2ED, T4CB, T7FC)

NSK ISO-Designated Tapered Roller Bearings (T2ED, T4CB, T7FC)

NSK metric tapered roller bearings listed under ISO 355 designations (T2ED, T4CB, T7FC), bore 45-120 mm.

Key features

  • Designation follows ISO 355 angle, diameter and width series coding
  • Separable cone and cup assemblies
  • Carries combined radial and axial load in one direction
  • Assembled width T shown per row

Specifications

Bearing type Single-row tapered roller bearing
Designation system ISO 355
Dimension system Metric
Load ratings Basic dynamic Cr / static C0r
Speed basis Grease lubrication limit
Source NSK Rolling Bearings Catalogue (Korean ed.), p. B118-B131
T7FC045 d: 45 mm | D: 95 mm | T: 29 mm | Cr: 91 kN | C0r: 116 kN | Grease speed: 3600 rpm
T2ED050 d: 50 mm | D: 100 mm | T: 36 mm | Cr: 144 kN | C0r: 185 kN | Grease speed: 3800 rpm
T7FC055 d: 55 mm | D: 115 mm | T: 34 mm | Cr: 126 kN | C0r: 164 kN | Grease speed: 3000 rpm
T7FC060 d: 60 mm | D: 125 mm | T: 37 mm | Cr: 161 kN | C0r: 197 kN | Grease speed: 2800 rpm
T4CB100 d: 100 mm | D: 145 mm | T: 24 mm | Cr: 113 kN | C0r: 163 kN | Grease speed: 2200 rpm
T4CB120 d: 120 mm | D: 170 mm | T: 27 mm | Cr: 153 kN | C0r: 243 kN | Grease speed: 1800 rpm
Tapered Roller BearingsNSK
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NSK ISO-Designated Tapered Roller Bearings (T2ED, T4CB, T7FC)

Brand NSK·Tapered Roller Bearings

Available part numbers (6)

T7FC045, T2ED050, T7FC055, T7FC060, T4CB100, T4CB120

How to order

Send the NSK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
T7FC045d: 45 mm | D: 95 mm | T: 29 mm | Cr: 91 kN | C0r: 116 kN | Grease speed: 3600 rpm
T2ED050d: 50 mm | D: 100 mm | T: 36 mm | Cr: 144 kN | C0r: 185 kN | Grease speed: 3800 rpm
T7FC055d: 55 mm | D: 115 mm | T: 34 mm | Cr: 126 kN | C0r: 164 kN | Grease speed: 3000 rpm
T7FC060d: 60 mm | D: 125 mm | T: 37 mm | Cr: 161 kN | C0r: 197 kN | Grease speed: 2800 rpm
T4CB100d: 100 mm | D: 145 mm | T: 24 mm | Cr: 113 kN | C0r: 163 kN | Grease speed: 2200 rpm
T4CB120d: 120 mm | D: 170 mm | T: 27 mm | Cr: 153 kN | C0r: 243 kN | Grease speed: 1800 rpm
