NSK TAC Thrust Angular Contact Ball Bearings for Ball Screw Support

NSK TAC Thrust Angular Contact Ball Bearings for Ball Screw Support

Thrust angular contact ball bearings with a 60-degree contact angle, used as highly rigid support bearings for machine tool ball screws.

Key features

  • High axial rigidity from many balls and a 60-degree contact angle
  • Low friction torque compared with tapered or cylindrical roller bearings
  • Combination sets DF, DFD and DFF with factory-set preload (axial play code C10)
  • Polyamide resin retainer
  • Accuracy PN7A for combined sets

Specifications

Contact angle 60 deg
Axial play code C10
Accuracy PN7A (combined bearing)
Retainer Polyamide resin
Product type Angular Contact Ball Bearings
Source NSK Precision Machine Components (CAT. E3162), p. B457-B464
15TAC47BDFC10PN7A d: 15 mm | D: 47 mm | B: 15 mm | Set: DF | Preload: 2150 N
15TAC47BDFDC10PN7A d: 15 mm | D: 47 mm | B: 15 mm | Set: DFD | Preload: 2950 N
15TAC47BDFFC10PN7A d: 15 mm | D: 47 mm | B: 15 mm | Set: DFF | Preload: 4300 N
17TAC47BDFC10PN7A d: 17 mm | D: 47 mm | B: 15 mm | Set: DF | Preload: 2150 N
17TAC47BDFDC10PN7A d: 17 mm | D: 47 mm | B: 15 mm | Set: DFD | Preload: 2950 N
17TAC47BDFFC10PN7A d: 17 mm | D: 47 mm | B: 15 mm | Set: DFF | Preload: 4300 N
20TAC47BDFC10PN7A d: 20 mm | D: 47 mm | B: 15 mm | Set: DF | Preload: 2150 N
20TAC47BDFDC10PN7A d: 20 mm | D: 47 mm | B: 15 mm | Set: DFD | Preload: 2950 N
20TAC47BDFFC10PN7A d: 20 mm | D: 47 mm | B: 15 mm | Set: DFF | Preload: 4300 N
25TAC62BDFC10PN7A d: 25 mm | D: 62 mm | B: 15 mm | Set: DF | Preload: 3150 N
25TAC62BDFDC10PN7A d: 25 mm | D: 62 mm | B: 15 mm | Set: DFD | Preload: 4300 N
25TAC62BDFFC10PN7A d: 25 mm | D: 62 mm | B: 15 mm | Set: DFF | Preload: 6250 N
30TAC62BDFC10PN7A d: 30 mm | D: 62 mm | B: 15 mm | Set: DF | Preload: 3350 N
30TAC62BDFDC10PN7A d: 30 mm | D: 62 mm | B: 15 mm | Set: DFD | Preload: 4500 N
30TAC62BDFFC10PN7A d: 30 mm | D: 62 mm | B: 15 mm | Set: DFF | Preload: 6650 N
35TAC72BDFC10PN7A d: 35 mm | D: 72 mm | B: 15 mm | Set: DF | Preload: 3800 N
35TAC72BDFDC10PN7A d: 35 mm | D: 72 mm | B: 15 mm | Set: DFD | Preload: 5200 N
35TAC72BDFFC10PN7A d: 35 mm | D: 72 mm | B: 15 mm | Set: DFF | Preload: 7650 N
40TAC72BDFC10PN7A d: 40 mm | D: 72 mm | B: 15 mm | Set: DF | Preload: 3900 N
40TAC72BDFDC10PN7A d: 40 mm | D: 72 mm | B: 15 mm | Set: DFD | Preload: 5300 N
40TAC72BDFFC10PN7A d: 40 mm | D: 72 mm | B: 15 mm | Set: DFF | Preload: 7850 N
40TAC90BDFC10PN7A d: 40 mm | D: 90 mm | B: 20 mm | Set: DF | Preload: 5000 N
40TAC90BDFDC10PN7A d: 40 mm | D: 90 mm | B: 20 mm | Set: DFD | Preload: 6750 N
40TAC90BDFFC10PN7A d: 40 mm | D: 90 mm | B: 20 mm | Set: DFF | Preload: 10300 N
45TAC75BDFC10PN7A d: 45 mm | D: 75 mm | B: 15 mm | Set: DF | Preload: 4100 N
45TAC75BDFDC10PN7A d: 45 mm | D: 75 mm | B: 15 mm | Set: DFD | Preload: 5600 N
45TAC75BDFFC10PN7A d: 45 mm | D: 75 mm | B: 15 mm | Set: DFF | Preload: 8250 N
45TAC100BDFC10PN7A d: 45 mm | D: 100 mm | B: 20 mm | Set: DF | Preload: 5900 N
45TAC100BDFDC10PN7A d: 45 mm | D: 100 mm | B: 20 mm | Set: DFD | Preload: 8050 N
45TAC100BDFFC10PN7A d: 45 mm | D: 100 mm | B: 20 mm | Set: DFF | Preload: 11800 N
50TAC100BDFC10PN7A d: 50 mm | D: 100 mm | B: 20 mm | Set: DF | Preload: 6100 N
50TAC100BDFDC10PN7A d: 50 mm | D: 100 mm | B: 20 mm | Set: DFD | Preload: 8250 N
50TAC100BDFFC10PN7A d: 50 mm | D: 100 mm | B: 20 mm | Set: DFF | Preload: 12300 N
55TAC100BDFC10PN7A d: 55 mm | D: 100 mm | B: 20 mm | Set: DF | Preload: 6100 N
55TAC100BDFDC10PN7A d: 55 mm | D: 100 mm | B: 20 mm | Set: DFD | Preload: 8250 N
55TAC100BDFFC10PN7A d: 55 mm | D: 100 mm | B: 20 mm | Set: DFF | Preload: 12300 N
55TAC120BDFC10PN7A d: 55 mm | D: 120 mm | B: 20 mm | Set: DF | Preload: 6650 N
55TAC120BDFDC10PN7A d: 55 mm | D: 120 mm | B: 20 mm | Set: DFD | Preload: 9100 N
55TAC120BDFFC10PN7A d: 55 mm | D: 120 mm | B: 20 mm | Set: DFF | Preload: 13200 N
60TAC120BDFC10PN7A d: 60 mm | D: 120 mm | B: 20 mm | Set: DF | Preload: 6650 N
60TAC120BDFDC10PN7A d: 60 mm | D: 120 mm | B: 20 mm | Set: DFD | Preload: 9100 N
60TAC120BDFFC10PN7A d: 60 mm | D: 120 mm | B: 20 mm | Set: DFF | Preload: 13200 N
Angular Contact Ball BearingsNSK
42 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NSK TAC Thrust Angular Contact Ball Bearings for Ball Screw Support

Brand NSK·Angular Contact Ball Bearings

Available part numbers (42)

15TAC47BDFC10PN7A, 15TAC47BDFDC10PN7A, 15TAC47BDFFC10PN7A, 17TAC47BDFC10PN7A, 17TAC47BDFDC10PN7A, 17TAC47BDFFC10PN7A, 20TAC47BDFC10PN7A, 20TAC47BDFDC10PN7A, 20TAC47BDFFC10PN7A, 25TAC62BDFC10PN7A + 32 more — see full table ↓
