NSK TMP Cylindrical Roller Thrust Bearings

NSK TMP Cylindrical Roller Thrust Bearings

NSK TMP series thrust cylindrical roller bearings, bore 35-320 mm, for heavy axial loads in one direction.

Key features

  • Cylindrical rollers give high axial load capacity and rigidity
  • Carries axial load in one direction only
  • Low axial space requirement
  • Machined brass cage

Specifications

Bearing type Thrust cylindrical roller bearing
Series TMP
Bore range 35-320 mm
Load ratings Axial dynamic Ca / static C0a
Speed basis Grease lubrication limit
Source NSK Rolling Bearings Catalogue (Korean ed.), p. B220-B223
35TMP14 d: 35 mm | D: 80 mm | Height: 32 mm | Ca: 95.5 kN | C0a: 247 kN | Grease speed: 1000 rpm
40TMP93 d: 40 mm | D: 78 mm | Height: 22 mm | Ca: 63 kN | C0a: 194 kN | Grease speed: 1200 rpm
45TMP11 d: 45 mm | D: 65 mm | Height: 14 mm | Ca: 33 kN | C0a: 100 kN | Grease speed: 1700 rpm
45TMP93 d: 45 mm | D: 85 mm | Height: 24 mm | Ca: 71 kN | C0a: 233 kN | Grease speed: 1100 rpm
50TMP74 d: 50 mm | D: 110 mm | Height: 27 mm | Ca: 139 kN | C0a: 470 kN | Grease speed: 900 rpm
50TMP93 d: 50 mm | D: 95 mm | Height: 27 mm | Ca: 113 kN | C0a: 350 kN | Grease speed: 1000 rpm
55TMP93 d: 55 mm | D: 105 mm | Height: 30 mm | Ca: 134 kN | C0a: 450 kN | Grease speed: 900 rpm
60TMP12 d: 60 mm | D: 95 mm | Height: 26 mm | Ca: 99 kN | C0a: 325 kN | Grease speed: 1000 rpm
60TMP93 d: 60 mm | D: 110 mm | Height: 30 mm | Ca: 139 kN | C0a: 480 kN | Grease speed: 650 rpm
65TMP12 d: 65 mm | D: 100 mm | Height: 27 mm | Ca: 110 kN | C0a: 325 kN | Grease speed: 950 rpm
65TMP93 d: 65 mm | D: 115 mm | Height: 30 mm | Ca: 145 kN | C0a: 515 kN | Grease speed: 850 rpm
70TMP74 d: 70 mm | D: 150 mm | Height: 36 mm | Ca: 259 kN | C0a: 935 kN | Grease speed: 670 rpm
70TMP93 d: 70 mm | D: 125 mm | Height: 34 mm | Ca: 191 kN | C0a: 635 kN | Grease speed: 750 rpm
75TMP11 d: 75 mm | D: 100 mm | Height: 19 mm | Ca: 63.5 kN | C0a: 221 kN | Grease speed: 1100 rpm
75TMP93 d: 75 mm | D: 135 mm | Height: 36 mm | Ca: 209 kN | C0a: 735 kN | Grease speed: 710 rpm
80TMP12 d: 80 mm | D: 115 mm | Height: 28 mm | Ca: 120 kN | C0a: 420 kN | Grease speed: 900 rpm
80TMP93 d: 80 mm | D: 140 mm | Height: 36 mm | Ca: 208 kN | C0a: 740 kN | Grease speed: 710 rpm
85TMP11 d: 85 mm | D: 110 mm | Height: 19 mm | Ca: 75 kN | C0a: 298 kN | Grease speed: 1100 rpm
85TMP12 d: 85 mm | D: 125 mm | Height: 31 mm | Ca: 151 kN | C0a: 485 kN | Grease speed: 800 rpm
85TMP93 d: 85 mm | D: 150 mm | Height: 39 mm | Ca: 257 kN | C0a: 995 kN | Grease speed: 530 rpm
90TMP11 d: 90 mm | D: 120 mm | Height: 22 mm | Ca: 96 kN | C0a: 370 kN | Grease speed: 950 rpm
90TMP93 d: 90 mm | D: 155 mm | Height: 39 mm | Ca: 250 kN | C0a: 885 kN | Grease speed: 630 rpm
100TMP93 d: 100 mm | D: 170 mm | Height: 42 mm | Ca: 292 kN | C0a: 1710 kN | Grease speed: 560 rpm
110TMP12 d: 110 mm | D: 160 mm | Height: 38 mm | Ca: 228 kN | C0a: 855 kN | Grease speed: 530 rpm
110TMP93 d: 110 mm | D: 190 mm | Height: 48 mm | Ca: 390 kN | C0a: 1490 kN | Grease speed: 500 rpm
120TMP12 d: 120 mm | D: 170 mm | Height: 39 mm | Ca: 233 kN | C0a: 895 kN | Grease speed: 500 rpm
120TMP93 d: 120 mm | D: 210 mm | Height: 54 mm | Ca: 505 kN | C0a: 1930 kN | Grease speed: 450 rpm
130TMP12 d: 130 mm | D: 190 mm | Height: 45 mm | Ca: 300 kN | C0a: 1090 kN | Grease speed: 530 rpm
130TMP93 d: 130 mm | D: 225 mm | Height: 58 mm | Ca: 585 kN | C0a: 2370 kN | Grease speed: 430 rpm
130TMP94 d: 130 mm | D: 270 mm | Height: 85 mm | Ca: 895 kN | C0a: 3300 kN | Grease speed: 320 rpm
140TMP12 d: 140 mm | D: 200 mm | Height: 46 mm | Ca: 285 kN | C0a: 1120 kN | Grease speed: 500 rpm
140TMP93 d: 140 mm | D: 240 mm | Height: 60 mm | Ca: 610 kN | C0a: 2360 kN | Grease speed: 400 rpm
140TMP94 d: 140 mm | D: 280 mm | Height: 85 mm | Ca: 990 kN | C0a: 3800 kN | Grease speed: 300 rpm
150TMP12 d: 150 mm | D: 215 mm | Height: 50 mm | Ca: 375 kN | C0a: 150 kN | Grease speed: 480 rpm
150TMP93 d: 150 mm | D: 250 mm | Height: 60 mm | Ca: 635 kN | C0a: 2510 kN | Grease speed: 400 rpm
160TMP11 d: 160 mm | D: 200 mm | Height: 31 mm | Ca: 173 kN | C0a: 815 kN | Grease speed: 630 rpm
160TMP93 d: 160 mm | D: 270 mm | Height: 67 mm | Ca: 745 kN | C0a: 3150 kN | Grease speed: 360 rpm
170TMP12 d: 170 mm | D: 240 mm | Height: 55 mm | Ca: 485 kN | C0a: 1960 kN | Grease speed: 430 rpm
170TMP93 d: 170 mm | D: 280 mm | Height: 67 mm | Ca: 800 kN | C0a: 350 kN | Grease speed: 340 rpm
180TMP93 d: 180 mm | D: 300 mm | Height: 73 mm | Ca: 1000 kN | C0a: 4000 kN | Grease speed: 320 rpm
180TMP94 d: 180 mm | D: 360 mm | Height: 109 mm | Ca: 1640 kN | C0a: 6200 kN | Grease speed: 240 rpm
190TMP12 d: 190 mm | D: 270 mm | Height: 62 mm | Ca: 70.5 kN | C0a: 2630 kN | Grease speed: 360 rpm
190TMP93 d: 190 mm | D: 320 mm | Height: 78 mm | Ca: 1080 kN | C0a: 4500 kN | Grease speed: 300 rpm
200TMP11 d: 200 mm | D: 250 mm | Height: 37 mm | Ca: 365 kN | C0a: 1690 kN | Grease speed: 500 rpm
200TMP93 d: 200 mm | D: 340 mm | Height: 85 mm | Ca: 1180 kN | C0a: 6150 kN | Grease speed: 280 rpm
220TMP11 d: 220 mm | D: 270 mm | Height: 37 mm | Ca: 385 kN | C0a: 1860 kN | Grease speed: 480 rpm
220TMP12 d: 220 mm | D: 300 mm | Height: 63 mm | Ca: 770 kN | C0a: 3100 kN | Grease speed: 340 rpm
240TMP11 d: 240 mm | D: 300 mm | Height: 45 mm | Ca: 435 kN | C0a: 2160 kN | Grease speed: 400 rpm
240TMP12 d: 240 mm | D: 340 mm | Height: 78 mm | Ca: 965 kN | C0a: 4100 kN | Grease speed: 280 rpm
260TMP11 d: 260 mm | D: 320 mm | Height: 45 mm | Ca: 460 kN | C0a: 2350 kN | Grease speed: 400 rpm
260TMP12 d: 260 mm | D: 360 mm | Height: 79 mm | Ca: 995 kN | C0a: 4350 kN | Grease speed: 280 rpm
280TMP11 d: 280 mm | D: 350 mm | Height: 53 mm | Ca: 545 kN | C0a: 2800 kN | Grease speed: 340 rpm
280TMP12 d: 280 mm | D: 380 mm | Height: 80 mm | Ca: 1050 kN | C0a: 4750 kN | Grease speed: 260 rpm
300TMP11 d: 300 mm | D: 380 mm | Height: 62 mm | Ca: 795 kN | C0a: 4000 kN | Grease speed: 300 rpm
300TMP12 d: 300 mm | D: 420 mm | Height: 95 mm | Ca: 1390 kN | C0a: 6250 kN | Grease speed: 220 rpm
320TMP11 d: 320 mm | D: 400 mm | Height: 63 mm | Ca: 820 kN | C0a: 4250 kN | Grease speed: 300 rpm
320TMP12 d: 320 mm | D: 440 mm | Height: 95 mm | Ca: 1420 kN | C0a: 6550 kN | Grease speed: 220 rpm
Thrust BearingsNSK
57 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NSK TMP Cylindrical Roller Thrust Bearings

Brand NSK·Thrust Bearings

Available part numbers (57)

35TMP14, 40TMP93, 45TMP11, 45TMP93, 50TMP74, 50TMP93, 55TMP93, 60TMP12, 60TMP93, 65TMP12 + 47 more — see full table ↓

How to order

Send the NSK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
35TMP14d: 35 mm | D: 80 mm | Height: 32 mm | Ca: 95.5 kN | C0a: 247 kN | Grease speed: 1000 rpm
40TMP93d: 40 mm | D: 78 mm | Height: 22 mm | Ca: 63 kN | C0a: 194 kN | Grease speed: 1200 rpm
45TMP11d: 45 mm | D: 65 mm | Height: 14 mm | Ca: 33 kN | C0a: 100 kN | Grease speed: 1700 rpm
45TMP93d: 45 mm | D: 85 mm | Height: 24 mm | Ca: 71 kN | C0a: 233 kN | Grease speed: 1100 rpm
50TMP74d: 50 mm | D: 110 mm | Height: 27 mm | Ca: 139 kN | C0a: 470 kN | Grease speed: 900 rpm
50TMP93d: 50 mm | D: 95 mm | Height: 27 mm | Ca: 113 kN | C0a: 350 kN | Grease speed: 1000 rpm
55TMP93d: 55 mm | D: 105 mm | Height: 30 mm | Ca: 134 kN | C0a: 450 kN | Grease speed: 900 rpm
60TMP12d: 60 mm | D: 95 mm | Height: 26 mm | Ca: 99 kN | C0a: 325 kN | Grease speed: 1000 rpm
60TMP93d: 60 mm | D: 110 mm | Height: 30 mm | Ca: 139 kN | C0a: 480 kN | Grease speed: 650 rpm
65TMP12d: 65 mm | D: 100 mm | Height: 27 mm | Ca: 110 kN | C0a: 325 kN | Grease speed: 950 rpm
65TMP93d: 65 mm | D: 115 mm | Height: 30 mm | Ca: 145 kN | C0a: 515 kN | Grease speed: 850 rpm
70TMP74d: 70 mm | D: 150 mm | Height: 36 mm | Ca: 259 kN | C0a: 935 kN | Grease speed: 670 rpm
70TMP93d: 70 mm | D: 125 mm | Height: 34 mm | Ca: 191 kN | C0a: 635 kN | Grease speed: 750 rpm
75TMP11d: 75 mm | D: 100 mm | Height: 19 mm | Ca: 63.5 kN | C0a: 221 kN | Grease speed: 1100 rpm
75TMP93d: 75 mm | D: 135 mm | Height: 36 mm | Ca: 209 kN | C0a: 735 kN | Grease speed: 710 rpm
80TMP12d: 80 mm | D: 115 mm | Height: 28 mm | Ca: 120 kN | C0a: 420 kN | Grease speed: 900 rpm
80TMP93d: 80 mm | D: 140 mm | Height: 36 mm | Ca: 208 kN | C0a: 740 kN | Grease speed: 710 rpm
85TMP11d: 85 mm | D: 110 mm | Height: 19 mm | Ca: 75 kN | C0a: 298 kN | Grease speed: 1100 rpm
85TMP12d: 85 mm | D: 125 mm | Height: 31 mm | Ca: 151 kN | C0a: 485 kN | Grease speed: 800 rpm
85TMP93d: 85 mm | D: 150 mm | Height: 39 mm | Ca: 257 kN | C0a: 995 kN | Grease speed: 530 rpm
90TMP11d: 90 mm | D: 120 mm | Height: 22 mm | Ca: 96 kN | C0a: 370 kN | Grease speed: 950 rpm
90TMP93d: 90 mm | D: 155 mm | Height: 39 mm | Ca: 250 kN | C0a: 885 kN | Grease speed: 630 rpm
100TMP93d: 100 mm | D: 170 mm | Height: 42 mm | Ca: 292 kN | C0a: 1710 kN | Grease speed: 560 rpm
110TMP12d: 110 mm | D: 160 mm | Height: 38 mm | Ca: 228 kN | C0a: 855 kN | Grease speed: 530 rpm
110TMP93d: 110 mm | D: 190 mm | Height: 48 mm | Ca: 390 kN | C0a: 1490 kN | Grease speed: 500 rpm
120TMP12d: 120 mm | D: 170 mm | Height: 39 mm | Ca: 233 kN | C0a: 895 kN | Grease speed: 500 rpm
120TMP93d: 120 mm | D: 210 mm | Height: 54 mm | Ca: 505 kN | C0a: 1930 kN | Grease speed: 450 rpm
130TMP12d: 130 mm | D: 190 mm | Height: 45 mm | Ca: 300 kN | C0a: 1090 kN | Grease speed: 530 rpm
130TMP93d: 130 mm | D: 225 mm | Height: 58 mm | Ca: 585 kN | C0a: 2370 kN | Grease speed: 430 rpm
130TMP94d: 130 mm | D: 270 mm | Height: 85 mm | Ca: 895 kN | C0a: 3300 kN | Grease speed: 320 rpm
140TMP12d: 140 mm | D: 200 mm | Height: 46 mm | Ca: 285 kN | C0a: 1120 kN | Grease speed: 500 rpm
140TMP93d: 140 mm | D: 240 mm | Height: 60 mm | Ca: 610 kN | C0a: 2360 kN | Grease speed: 400 rpm
140TMP94d: 140 mm | D: 280 mm | Height: 85 mm | Ca: 990 kN | C0a: 3800 kN | Grease speed: 300 rpm
150TMP12d: 150 mm | D: 215 mm | Height: 50 mm | Ca: 375 kN | C0a: 150 kN | Grease speed: 480 rpm
150TMP93d: 150 mm | D: 250 mm | Height: 60 mm | Ca: 635 kN | C0a: 2510 kN | Grease speed: 400 rpm
160TMP11d: 160 mm | D: 200 mm | Height: 31 mm | Ca: 173 kN | C0a: 815 kN | Grease speed: 630 rpm
160TMP93d: 160 mm | D: 270 mm | Height: 67 mm | Ca: 745 kN | C0a: 3150 kN | Grease speed: 360 rpm
170TMP12d: 170 mm | D: 240 mm | Height: 55 mm | Ca: 485 kN | C0a: 1960 kN | Grease speed: 430 rpm
170TMP93d: 170 mm | D: 280 mm | Height: 67 mm | Ca: 800 kN | C0a: 350 kN | Grease speed: 340 rpm
180TMP93d: 180 mm | D: 300 mm | Height: 73 mm | Ca: 1000 kN | C0a: 4000 kN | Grease speed: 320 rpm
180TMP94d: 180 mm | D: 360 mm | Height: 109 mm | Ca: 1640 kN | C0a: 6200 kN | Grease speed: 240 rpm
190TMP12d: 190 mm | D: 270 mm | Height: 62 mm | Ca: 70.5 kN | C0a: 2630 kN | Grease speed: 360 rpm
190TMP93d: 190 mm | D: 320 mm | Height: 78 mm | Ca: 1080 kN | C0a: 4500 kN | Grease speed: 300 rpm
200TMP11d: 200 mm | D: 250 mm | Height: 37 mm | Ca: 365 kN | C0a: 1690 kN | Grease speed: 500 rpm
200TMP93d: 200 mm | D: 340 mm | Height: 85 mm | Ca: 1180 kN | C0a: 6150 kN | Grease speed: 280 rpm
220TMP11d: 220 mm | D: 270 mm | Height: 37 mm | Ca: 385 kN | C0a: 1860 kN | Grease speed: 480 rpm
220TMP12d: 220 mm | D: 300 mm | Height: 63 mm | Ca: 770 kN | C0a: 3100 kN | Grease speed: 340 rpm
240TMP11d: 240 mm | D: 300 mm | Height: 45 mm | Ca: 435 kN | C0a: 2160 kN | Grease speed: 400 rpm
240TMP12d: 240 mm | D: 340 mm | Height: 78 mm | Ca: 965 kN | C0a: 4100 kN | Grease speed: 280 rpm
260TMP11d: 260 mm | D: 320 mm | Height: 45 mm | Ca: 460 kN | C0a: 2350 kN | Grease speed: 400 rpm
260TMP12d: 260 mm | D: 360 mm | Height: 79 mm | Ca: 995 kN | C0a: 4350 kN | Grease speed: 280 rpm
280TMP11d: 280 mm | D: 350 mm | Height: 53 mm | Ca: 545 kN | C0a: 2800 kN | Grease speed: 340 rpm
280TMP12d: 280 mm | D: 380 mm | Height: 80 mm | Ca: 1050 kN | C0a: 4750 kN | Grease speed: 260 rpm
300TMP11d: 300 mm | D: 380 mm | Height: 62 mm | Ca: 795 kN | C0a: 4000 kN | Grease speed: 300 rpm
300TMP12d: 300 mm | D: 420 mm | Height: 95 mm | Ca: 1390 kN | C0a: 6250 kN | Grease speed: 220 rpm
320TMP11d: 320 mm | D: 400 mm | Height: 63 mm | Ca: 820 kN | C0a: 4250 kN | Grease speed: 300 rpm
320TMP12d: 320 mm | D: 440 mm | Height: 95 mm | Ca: 1420 kN | C0a: 6550 kN | Grease speed: 220 rpm
