NSK UBPP / ENPP Pressed Steel Pillow Block Units (Shaft 12-35)

NSK UBPP / ENPP Pressed Steel Pillow Block Units (Shaft 12-35)

NSK UBPP (set screw) and ENPP (eccentric collar) pressed steel pillow block units for light-duty applications, shaft diameters 12 to 35 mm.

Key features

  • Lightweight pressed steel pillow block housing
  • UBPP: set-screw locking; ENPP: eccentric collar locking
  • Self-aligning insert bearing
  • Low-cost solution for light loads

Specifications

Product Ball bearing unit
Housing Pressed steel
Insert UB / EN deep groove ball bearing
Locking Set screw (UBPP), eccentric collar (ENPP)
Shaft 12-35 mm
Source NSK Rolling Bearings Catalogue (Part 3), p. 296-297
UBPP 201 Shaft: 12 mm | Bearing: UB 201 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
ENPP 201 Shaft: 12 mm | Bearing: EN 201 | L: 86 mm | H: 22.32 mm | Cr: 9.55 kN
UBPP 202 Shaft: 15 mm | Bearing: UB 202 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
ENPP 202 Shaft: 15 mm | Bearing: EN 202 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
UBPP 203 Shaft: 17 mm | Bearing: UB 203 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
ENPP 203 Shaft: 17 mm | Bearing: EN 203 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
UBPP 204 Shaft: 20 mm | Bearing: UB 204 | L: 98 mm | H: 25.4 mm | Cr: 12.8 kN
ENPP 204 Shaft: 20 mm | Bearing: EN 204 | L: 98 mm | H: 25.4 mm | Cr: 12.8 kN
UBPP 205 Shaft: 25 mm | Bearing: UB 205 | L: 108 mm | H: 28.6 mm | Cr: 14 kN
ENPP 205 Shaft: 25 mm | Bearing: EN 205 | L: 108 mm | H: 28.6 mm | Cr: 14 kN
UBPP 206 Shaft: 30 mm | Bearing: UB 206 | L: 117 mm | H: 33.3 mm | Cr: 19.5 kN
ENPP 206 Shaft: 30 mm | Bearing: EN 206 | L: 117 mm | H: 33.3 mm | Cr: 19.5 kN
UBPP 207 Shaft: 35 mm | Bearing: UB 207 | L: 129 mm | H: 39.7 mm | Cr: 25.7 kN
ENPP 207 Shaft: 35 mm | Bearing: EN 207 | L: 129 mm | H: 39.7 mm | Cr: 25.7 kN
Mounted Bearing UnitsNSK
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NSK UBPP / ENPP Pressed Steel Pillow Block Units (Shaft 12-35)

Brand NSK·Mounted Bearing Units

Available part numbers (14)

UBPP 201, ENPP 201, UBPP 202, ENPP 202, UBPP 203, ENPP 203, UBPP 204, ENPP 204, UBPP 205, ENPP 205 + 4 more — see full table ↓

How to order

Send the NSK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UBPP 201Shaft: 12 mm | Bearing: UB 201 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
ENPP 201Shaft: 12 mm | Bearing: EN 201 | L: 86 mm | H: 22.32 mm | Cr: 9.55 kN
UBPP 202Shaft: 15 mm | Bearing: UB 202 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
ENPP 202Shaft: 15 mm | Bearing: EN 202 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
UBPP 203Shaft: 17 mm | Bearing: UB 203 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
ENPP 203Shaft: 17 mm | Bearing: EN 203 | L: 86 mm | H: 22.2 mm | Cr: 9.55 kN
UBPP 204Shaft: 20 mm | Bearing: UB 204 | L: 98 mm | H: 25.4 mm | Cr: 12.8 kN
ENPP 204Shaft: 20 mm | Bearing: EN 204 | L: 98 mm | H: 25.4 mm | Cr: 12.8 kN
UBPP 205Shaft: 25 mm | Bearing: UB 205 | L: 108 mm | H: 28.6 mm | Cr: 14 kN
ENPP 205Shaft: 25 mm | Bearing: EN 205 | L: 108 mm | H: 28.6 mm | Cr: 14 kN
UBPP 206Shaft: 30 mm | Bearing: UB 206 | L: 117 mm | H: 33.3 mm | Cr: 19.5 kN
ENPP 206Shaft: 30 mm | Bearing: EN 206 | L: 117 mm | H: 33.3 mm | Cr: 19.5 kN
UBPP 207Shaft: 35 mm | Bearing: UB 207 | L: 129 mm | H: 39.7 mm | Cr: 25.7 kN
ENPP 207Shaft: 35 mm | Bearing: EN 207 | L: 129 mm | H: 39.7 mm | Cr: 25.7 kN
