NTN 29200 Series Spherical Roller Thrust Bearings

NTN 29200 Series Spherical Roller Thrust Bearings

NTN 29200 series spherical roller thrust bearings, bore 150-480 mm, for heavy axial loads with some radial load and misalignment.

Key features

  • Very high axial load capacity
  • Accommodates misalignment through spherical housing washer raceway
  • Can also carry radial load up to a set proportion of axial load
  • Oil lubrication generally recommended

Specifications

Series 29200
Bearing type Spherical roller thrust bearing
Bore range 150-480 mm
Load rating unit kN (axial)
Brand NTN
Source NTN NTN Ball and Roller Bearings catalogue, p. 164-166
29230 d: 150 mm | D: 215 mm | T: 39 mm | Ca: 340 kN | C0a: 1340 kN | Mass: 4.56 kg
29232 d: 160 mm | D: 225 mm | T: 39 mm | Ca: 360 kN | C0a: 1460 kN | Mass: 4.88 kg
29234 d: 170 mm | D: 240 mm | T: 42 mm | Ca: 425 kN | C0a: 1770 kN | Mass: 6.02 kg
29236 d: 180 mm | D: 250 mm | T: 42 mm | Ca: 450 kN | C0a: 1920 kN | Mass: 6.27 kg
29238 d: 190 mm | D: 270 mm | T: 48 mm | Ca: 530 kN | C0a: 2230 kN | Mass: 8.8 kg
29240 d: 200 mm | D: 280 mm | T: 48 mm | Ca: 535 kN | C0a: 2300 kN | Mass: 9.14 kg
29244 d: 220 mm | D: 300 mm | T: 48 mm | Ca: 2555 kN | C0a: 2480 kN | Mass: 9.94 kg
29248 d: 240 mm | D: 340 mm | T: 60 mm | Ca: 825 kN | C0a: 3600 kN | Mass: 17.5 kg
29252 d: 260 mm | D: 360 mm | T: 60 mm | Ca: 870 kN | C0a: 3950 kN | Mass: 18.6 kg
29256 d: 280 mm | D: 380 mm | T: 60 mm | Ca: 875 kN | C0a: 4050 kN | Mass: 19.8 kg
29260 d: 300 mm | D: 420 mm | T: 73 mm | Ca: 1190 kN | C0a: 5350 kN | Mass: 30.9 kg
29264 d: 320 mm | D: 440 mm | T: 73 mm | Ca: 1260 kN | C0a: 5800 kN | Mass: 33.5 kg
29268 d: 340 mm | D: 460 mm | T: 73 mm | Ca: 1240 kN | C0a: 5800 kN | Mass: 34.4 kg
29272 d: 360 mm | D: 500 mm | T: 85 mm | Ca: 1510 kN | C0a: 7050 kN | Mass: 50.5 kg
29276 d: 380 mm | D: 520 mm | T: 85 mm | Ca: 1590 kN | C0a: 7650 kN | Mass: 53.4 kg
29280 d: 400 mm | D: 540 mm | T: 85 mm | Ca: 1620 kN | C0a: 7950 kN | Mass: 55.8 kg
29284 d: 420 mm | D: 580 mm | T: 95 mm | Ca: 2100 kN | C0a: 10400 kN | Mass: 76.6 kg
29288 d: 440 mm | D: 600 mm | T: 95 mm | Ca: 2150 kN | C0a: 10900 kN | Mass: 79.6 kg
29292 d: 460 mm | D: 620 mm | T: 95 mm | Ca: 2150 kN | C0a: 11000 kN | Mass: 82.8 kg
29296 d: 480 mm | D: 650 mm | T: 103 mm | Ca: 2400 kN | C0a: 12000 kN | Mass: 98.6 kg
