• NTN SC Small Ball Bearings with Snap Ring, Shielded (ZZN, ZZNR)
1 1

NTN SC Small Ball Bearings with Snap Ring, Shielded (ZZN, ZZNR)

NTN SC Small Ball Bearings with Snap Ring, Shielded (ZZN, ZZNR)

NTN SC-series small deep groove ball bearings with shields on both sides and a snap ring groove (ZZN) or fitted snap ring (ZZNR).

Key features

  • Shielded both sides (ZZ)
  • Snap ring groove (N) or snap ring fitted (NR) for axial location
  • Small bores for compact equipment
  • Load ratings shown in kN

Specifications

Bearing type Small deep groove ball bearing with snap ring
Shield ZZ both sides
Load rating unit kN
Brand NTN
Product category Miniature Bearings
Source NTN NTN Ball and Roller Bearings catalogue, p. 21
SC559ZZN d: 5 mm | D: 13 mm | B: 4 mm | Cr: 1.08 kN | C0r: 0.43 kN
SC559ZZNR d: 5 mm | D: 13 mm | B: 4 mm | Cr: 1.08 kN | C0r: 0.43 kN
SC571ZZN d: 5 mm | D: 14 mm | B: 5 mm | Cr: 1.33 kN | C0r: 0.505 kN
SC571ZZNR d: 5 mm | D: 14 mm | B: 5 mm | Cr: 1.33 kN | C0r: 0.505 kN
SC669ZZN d: 6 mm | D: 19 mm | B: 6 mm | Cr: 2.34 kN | C0r: 0.885 kN
SC669ZZNR d: 6 mm | D: 19 mm | B: 6 mm | Cr: 2.34 kN | C0r: 0.885 kN
SC890ZZN d: 8 mm | D: 16 mm | B: 5 mm | Cr: 1.26 kN | C0r: 0.585 kN
SC890ZZNR d: 8 mm | D: 16 mm | B: 5 mm | Cr: 1.26 kN | C0r: 0.585 kN
SC850ZZN d: 8 mm | D: 22 mm | B: 7 mm | Cr: 3.35 kN | C0r: 1.4 kN
SC850ZZNR d: 8 mm | D: 22 mm | B: 7 mm | Cr: 3.35 kN | C0r: 1.4 kN
SC0039ZZN d: 10 mm | D: 26 mm | B: 8 mm | Cr: 4.55 kN | C0r: 1.96 kN
SC0039ZZNR d: 10 mm | D: 26 mm | B: 8 mm | Cr: 4.55 kN | C0r: 1.96 kN
SC0142ZZN d: 12 mm | D: 28 mm | B: 8 mm | Cr: 5.1 kN | C0r: 2.39 kN
SC0142ZZNR d: 12 mm | D: 28 mm | B: 8 mm | Cr: 5.1 kN | C0r: 2.39 kN
Miniature BearingsNTN
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NTN SC Small Ball Bearings with Snap Ring, Shielded (ZZN, ZZNR)

Brand NTN·Miniature Bearings

Available part numbers (14)

SC559ZZN, SC559ZZNR, SC571ZZN, SC571ZZNR, SC669ZZN, SC669ZZNR, SC890ZZN, SC890ZZNR, SC850ZZN, SC850ZZNR + 4 more — see full table ↓

How to order

Send the NTN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SC559ZZNd: 5 mm | D: 13 mm | B: 4 mm | Cr: 1.08 kN | C0r: 0.43 kN
SC559ZZNRd: 5 mm | D: 13 mm | B: 4 mm | Cr: 1.08 kN | C0r: 0.43 kN
SC571ZZNd: 5 mm | D: 14 mm | B: 5 mm | Cr: 1.33 kN | C0r: 0.505 kN
SC571ZZNRd: 5 mm | D: 14 mm | B: 5 mm | Cr: 1.33 kN | C0r: 0.505 kN
SC669ZZNd: 6 mm | D: 19 mm | B: 6 mm | Cr: 2.34 kN | C0r: 0.885 kN
SC669ZZNRd: 6 mm | D: 19 mm | B: 6 mm | Cr: 2.34 kN | C0r: 0.885 kN
SC890ZZNd: 8 mm | D: 16 mm | B: 5 mm | Cr: 1.26 kN | C0r: 0.585 kN
SC890ZZNRd: 8 mm | D: 16 mm | B: 5 mm | Cr: 1.26 kN | C0r: 0.585 kN
SC850ZZNd: 8 mm | D: 22 mm | B: 7 mm | Cr: 3.35 kN | C0r: 1.4 kN
SC850ZZNRd: 8 mm | D: 22 mm | B: 7 mm | Cr: 3.35 kN | C0r: 1.4 kN
SC0039ZZNd: 10 mm | D: 26 mm | B: 8 mm | Cr: 4.55 kN | C0r: 1.96 kN
SC0039ZZNRd: 10 mm | D: 26 mm | B: 8 mm | Cr: 4.55 kN | C0r: 1.96 kN
SC0142ZZNd: 12 mm | D: 28 mm | B: 8 mm | Cr: 5.1 kN | C0r: 2.39 kN
SC0142ZZNRd: 12 mm | D: 28 mm | B: 8 mm | Cr: 5.1 kN | C0r: 2.39 kN
