NTN UC2 Series Insert Bearings (Set Screw Type)

NTN UC2 Series Insert Bearings (Set Screw Type)

NTN UC2 series insert bearings (bearing unit inserts) with set screw locking and spherical outer ring, as listed in the NTN bearing unit tables.

Key features

  • Spherical outer ring self-aligns in the housing
  • Set screw locking to the shaft
  • Sealed and pre-lubricated
  • Replacement insert for NTN housed units of the matching series

Specifications

Series UC2
Product type Insert bearing (set screw type)
Locking Set screw
Brand NTN
Product category Insert Bearings
Source NTN NTN Bearing Units Dimension Table, p. 62-67
UC201-008D1 Shaft: 1/2 in | Bore: Inch | Used in e.g.: UCP201-008D1
UC201D1 Shaft: 12 mm | Bore: Metric | Used in e.g.: UCP201D1
UC202-009D1 Shaft: 9/16 in | Bore: Inch | Used in e.g.: UCP202-009D1
UC202-010D1 Shaft: 5/8 in | Bore: Inch | Used in e.g.: UCP202-010D1
UC202D1 Shaft: 15 mm | Bore: Metric | Used in e.g.: UCP202D1
UC203-011D1 Shaft: 11/16 in | Bore: Inch | Used in e.g.: UCP203-011D1
UC203D1 Shaft: 17 mm | Bore: Metric | Used in e.g.: UCP203D1
UC204-012D1 Shaft: 3/4 in | Bore: Inch | Used in e.g.: UCP204-012D1
UC204D1 Shaft: 20 mm | Bore: Metric | Used in e.g.: UCP204D1
UC205-013D1 Shaft: 13/16 in | Bore: Inch | Used in e.g.: UCP205-013D1
UC205-014D1 Shaft: 7/8 in | Bore: Inch | Used in e.g.: UCP205-014D1
UC205-015D1 Shaft: 15/16 in | Bore: Inch | Used in e.g.: UCP205-015D1
UC205-100D1 Shaft: 1 in | Bore: Inch | Used in e.g.: UCP205-100D1
UC205D1 Shaft: 25 mm | Bore: Metric | Used in e.g.: UCP205D1
UC206-101D1 Shaft: 1-1/16 in | Bore: Inch | Used in e.g.: UCP206-101D1
UC206-102D1 Shaft: 1-1/8 in | Bore: Inch | Used in e.g.: UCP206-102D1
UC206-103D1 Shaft: 1-3/16 in | Bore: Inch | Used in e.g.: UCP206-103D1
UC206-104D1 Shaft: 1-1/4 in | Bore: Inch | Used in e.g.: UCP206-104D1
UC206D1 Shaft: 30 mm | Bore: Metric | Used in e.g.: UCP206D1
UC207-104D1 Shaft: 1-1/4 in | Bore: Inch | Used in e.g.: UCP207-104D1
UC207-105D1 Shaft: 1-5/16 in | Bore: Inch | Used in e.g.: UCP207-105D1
UC207-106D1 Shaft: 1-3/8 in | Bore: Inch | Used in e.g.: UCP207-106D1
UC207-107D1 Shaft: 1-7/16 in | Bore: Inch | Used in e.g.: UCP207-107D1
UC207D1 Shaft: 35 mm | Bore: Metric | Used in e.g.: UCP207D1
UC208-108D1 Shaft: 1-1/2 in | Bore: Inch | Used in e.g.: UCP208-108D1
UC208-109D1 Shaft: 1-9/16 in | Bore: Inch | Used in e.g.: UCP208-109D1
UC208D1 Shaft: 40 mm | Bore: Metric | Used in e.g.: UCP208D1
UC209-110D1 Shaft: 1-5/8 in | Bore: Inch | Used in e.g.: UCP209-110D1
UC209-111D1 Shaft: 1-11/16 in | Bore: Inch | Used in e.g.: UCP209-111D1
UC209-112D1 Shaft: 1-3/4 in | Bore: Inch | Used in e.g.: UCP209-112D1
UC209D1 Shaft: 45 mm | Bore: Metric | Used in e.g.: UCP209D1
UC210-113D1 Shaft: 1-13/16 in | Bore: Inch | Used in e.g.: UCP210-113D1
UC210-114D1 Shaft: 1-7/8 in | Bore: Inch | Used in e.g.: UCP210-114D1
UC210-115D1 Shaft: 1-15/16 in | Bore: Inch | Used in e.g.: UCP210-115D1
UC210-200D1 Shaft: 2 in | Bore: Inch | Used in e.g.: UCP210-200D1
UC210D1 Shaft: 50 mm | Bore: Metric | Used in e.g.: UCP210D1
UC211-200D1 Shaft: 2 in | Bore: Inch | Used in e.g.: UCP211-200D1
UC211-201D1 Shaft: 2-1/16 in | Bore: Inch | Used in e.g.: UCP211-201D1
UC211-202D1 Shaft: 2-1/8 in | Bore: Inch | Used in e.g.: UCP211-202D1
UC211-203D1 Shaft: 2-3/16 in | Bore: Inch | Used in e.g.: UCP211-203D1
UC211D1 Shaft: 55 mm | Bore: Metric | Used in e.g.: UCP211D1
UC212-204D1 Shaft: 2-1/4 in | Bore: Inch | Used in e.g.: UCP212-204D1
UC212-205D1 Shaft: 2-5/16 in | Bore: Inch | Used in e.g.: UCP212-205D1
UC212-206D1 Shaft: 2-3/8 in | Bore: Inch | Used in e.g.: UCP212-206D1
UC212-207D1 Shaft: 2-7/16 in | Bore: Inch | Used in e.g.: UCP212-207D1
UC212D1 Shaft: 60 mm | Bore: Metric | Used in e.g.: UCP212D1
UC213-208D1 Shaft: 2-1/2 in | Bore: Inch | Used in e.g.: UCP213-208D1
UC213-209D1 Shaft: 2-9/16 in | Bore: Inch | Used in e.g.: UCP213-209D1
UC213D1 Shaft: 65 mm | Bore: Metric | Used in e.g.: UCP213D1
UC214-210D1 Shaft: 2-5/8 in | Bore: Inch | Used in e.g.: UCP214-210D1
UC214-211D1 Shaft: 2-11/16 in | Bore: Inch | Used in e.g.: UCP214-211D1
UC214-212D1 Shaft: 2-3/4 in | Bore: Inch | Used in e.g.: UCP214-212D1
UC214D1 Shaft: 70 mm | Bore: Metric | Used in e.g.: UCP214D1
UC215-213D1 Shaft: 2-13/16 in | Bore: Inch | Used in e.g.: UCP215-213D1
UC215-214D1 Shaft: 2-7/8 in | Bore: Inch | Used in e.g.: UCP215-214D1
UC215-215D1 Shaft: 2-15/16 in | Bore: Inch | Used in e.g.: UCP215-215D1
UC215-300D1 Shaft: 3 in | Bore: Inch | Used in e.g.: UCP215-300D1
UC215D1 Shaft: 75 mm | Bore: Metric | Used in e.g.: UCP215D1
UC216-301D1 Shaft: 3-1/16 in | Bore: Inch | Used in e.g.: UCP216-301D1
UC216-302D1 Shaft: 3-1/8 in | Bore: Inch | Used in e.g.: UCP216-302D1
UC216-303D1 Shaft: 3-3/16 in | Bore: Inch | Used in e.g.: UCP216-303D1
UC216D1 Shaft: 80 mm | Bore: Metric | Used in e.g.: UCP216D1
UC217-304D1 Shaft: 3-1/4 in | Bore: Inch | Used in e.g.: UCP217-304D1
UC217-305D1 Shaft: 3-5/16 in | Bore: Inch | Used in e.g.: UCP217-305D1
UC217-307D1 Shaft: 3-7/16 in | Bore: Inch | Used in e.g.: UCP217-307D1
UC217D1 Shaft: 85 mm | Bore: Metric | Used in e.g.: UCP217D1
UC218-308D1 Shaft: 3-1/2 in | Bore: Inch | Used in e.g.: UCP218-308D1
UC218D1 Shaft: 90 mm | Bore: Metric | Used in e.g.: UCP218D1
Insert BearingsNTN
68 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NTN UC2 Series Insert Bearings (Set Screw Type)

Brand NTN·Insert Bearings

Available part numbers (68)

UC201-008D1, UC201D1, UC202-009D1, UC202-010D1, UC202D1, UC203-011D1, UC203D1, UC204-012D1, UC204D1, UC205-013D1 + 58 more — see full table ↓

How to order

Send the NTN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
