NTN UCPG2 Pillow Block Units (Steel Series)

NTN UCPG2 Pillow Block Units (Steel Series)

NTN UCPG2 series pillow blocks (steel series), set screw locking type, for shafts 12-90 mm.

Key features

  • Pillow blocks (Steel series) with UC type insert bearing, set screw locking
  • Insert bearing has spherical outside diameter for initial misalignment compensation
  • Metric bores
  • D1 suffix: relubricatable design

Specifications

Series UCPG2
Unit type Pillow blocks (Steel series)
Shaft range 12-90 mm
Locking Set screw
Brand NTN
Source NTN NTN Bearing Units Dimension Table, p. 84-85
UCPG201D1 Shaft: 12 mm | Insert bearing: UC201D1 | Housing: PG203D1
UCPG202D1 Shaft: 15 mm | Insert bearing: UC202D1 | Housing: PG203D1
UCPG203D1 Shaft: 17 mm | Insert bearing: UC203D1 | Housing: PG203D1
UCPG204D1 Shaft: 20 mm | Insert bearing: UC204D1 | Housing: PG204D1
UCPG205D1 Shaft: 25 mm | Insert bearing: UC205D1 | Housing: PG205D1
UCPG206D1 Shaft: 30 mm | Insert bearing: UC206D1 | Housing: PG206D1
UCPG207D1 Shaft: 35 mm | Insert bearing: UC207D1 | Housing: PG207D1
UCPG208D1 Shaft: 40 mm | Insert bearing: UC208D1 | Housing: PG208D1
UCPG209D1 Shaft: 45 mm | Insert bearing: UC209D1 | Housing: PG209D1
UCPG210D1 Shaft: 50 mm | Insert bearing: UC210D1 | Housing: PG210D1
UCPG211D1 Shaft: 55 mm | Insert bearing: UC211D1 | Housing: PG211D1
UCPG212D1 Shaft: 60 mm | Insert bearing: UC212D1 | Housing: PG212D1
UCPG213D1 Shaft: 65 mm | Insert bearing: UC213D1 | Housing: PG213D1
UCPG214D1 Shaft: 70 mm | Insert bearing: UC214D1 | Housing: PG214D1
UCPG215D1 Shaft: 75 mm | Insert bearing: UC215D1 | Housing: PG215D1
UCPG216D1 Shaft: 80 mm | Insert bearing: UC216D1 | Housing: PG216D1
UCPG217D1 Shaft: 85 mm | Insert bearing: UC217D1 | Housing: PG217D1
UCPG218D1 Shaft: 90 mm | Insert bearing: UC218D1 | Housing: PG218D1
Mounted Bearing UnitsNTN
18 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NTN UCPG2 Pillow Block Units (Steel Series)

Brand NTN·Mounted Bearing Units

Available part numbers (18)

UCPG201D1, UCPG202D1, UCPG203D1, UCPG204D1, UCPG205D1, UCPG206D1, UCPG207D1, UCPG208D1, UCPG209D1, UCPG210D1 + 8 more — see full table ↓

How to order

Send the NTN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UCPG201D1Shaft: 12 mm | Insert bearing: UC201D1 | Housing: PG203D1
UCPG202D1Shaft: 15 mm | Insert bearing: UC202D1 | Housing: PG203D1
UCPG203D1Shaft: 17 mm | Insert bearing: UC203D1 | Housing: PG203D1
UCPG204D1Shaft: 20 mm | Insert bearing: UC204D1 | Housing: PG204D1
UCPG205D1Shaft: 25 mm | Insert bearing: UC205D1 | Housing: PG205D1
UCPG206D1Shaft: 30 mm | Insert bearing: UC206D1 | Housing: PG206D1
UCPG207D1Shaft: 35 mm | Insert bearing: UC207D1 | Housing: PG207D1
UCPG208D1Shaft: 40 mm | Insert bearing: UC208D1 | Housing: PG208D1
UCPG209D1Shaft: 45 mm | Insert bearing: UC209D1 | Housing: PG209D1
UCPG210D1Shaft: 50 mm | Insert bearing: UC210D1 | Housing: PG210D1
UCPG211D1Shaft: 55 mm | Insert bearing: UC211D1 | Housing: PG211D1
UCPG212D1Shaft: 60 mm | Insert bearing: UC212D1 | Housing: PG212D1
UCPG213D1Shaft: 65 mm | Insert bearing: UC213D1 | Housing: PG213D1
UCPG214D1Shaft: 70 mm | Insert bearing: UC214D1 | Housing: PG214D1
UCPG215D1Shaft: 75 mm | Insert bearing: UC215D1 | Housing: PG215D1
UCPG216D1Shaft: 80 mm | Insert bearing: UC216D1 | Housing: PG216D1
UCPG217D1Shaft: 85 mm | Insert bearing: UC217D1 | Housing: PG217D1
UCPG218D1Shaft: 90 mm | Insert bearing: UC218D1 | Housing: PG218D1
