NTN UCX Series Insert Bearings (Set Screw Type)

NTN UCX Series Insert Bearings (Set Screw Type)

NTN UCX series insert bearings (bearing unit inserts) with set screw locking and spherical outer ring, as listed in the NTN bearing unit tables.

Key features

  • Spherical outer ring self-aligns in the housing
  • Set screw locking to the shaft
  • Sealed and pre-lubricated
  • Replacement insert for NTN housed units of the matching series

Specifications

Series UCX
Product type Insert bearing (set screw type)
Locking Set screw
Brand NTN
Product category Insert Bearings
Source NTN NTN Bearing Units Dimension Table, p. 74-225
UCX05-013D1 Shaft: 13/16 in | Bore: Inch | Used in e.g.: UCPX05-013D1
UCX05-014D1 Shaft: 7/8 in | Bore: Inch | Used in e.g.: UCPX05-014D1
UCX05-015D1 Shaft: 15/16 in | Bore: Inch | Used in e.g.: UCPX05-015D1
UCX05-100D1 Shaft: 1 in | Bore: Inch | Used in e.g.: UCPX05-100D1
UCX05D1 Shaft: 25 mm | Bore: Metric | Used in e.g.: UCPX05D1
UCX06-101D1 Shaft: 1-1/16 in | Bore: Inch | Used in e.g.: UCPX06-101D1
UCX06-102D1 Shaft: 1-1/8 in | Bore: Inch | Used in e.g.: UCPX06-102D1
UCX06-103D1 Shaft: 1-3/16 in | Bore: Inch | Used in e.g.: UCPX06-103D1
UCX06D1 Shaft: 30 mm | Bore: Metric | Used in e.g.: UCPX06D1
UCX07-105D1 Shaft: 1-5/16 in | Bore: Inch | Used in e.g.: UCPX07-105D1
UCX07-106D1 Shaft: 1-3/8 in | Bore: Inch | Used in e.g.: UCPX07-106D1
UCX07-107D1 Shaft: 1-7/16 in | Bore: Inch | Used in e.g.: UCPX07-107D1
UCX07D1 Shaft: 35 mm | Bore: Metric | Used in e.g.: UCPX07D1
UCX08-108D1 Shaft: 1-1/2 in | Bore: Inch | Used in e.g.: UCPX08-108D1
UCX08-109D1 Shaft: 1-9/16 in | Bore: Inch | Used in e.g.: UCPX08-109D1
UCX08D1 Shaft: 40 mm | Bore: Metric | Used in e.g.: UCPX08D1
UCX09-110D1 Shaft: 1-5/8 in | Bore: Inch | Used in e.g.: UCPX09-110D1
UCX09-111D1 Shaft: 1-11/16 in | Bore: Inch | Used in e.g.: UCPX09-111D1
UCX09-112D1 Shaft: 1-3/4 in | Bore: Inch | Used in e.g.: UCPX09-112D1
UCX09D1 Shaft: 45 mm | Bore: Metric | Used in e.g.: UCPX09D1
UCX10-114D1 Shaft: 1-7/8 in | Bore: Inch | Used in e.g.: UCPX10-114D1
UCX10-115D1 Shaft: 1-15/16 in | Bore: Inch | Used in e.g.: UCPX10-115D1
UCX10D1 Shaft: 50 mm | Bore: Metric | Used in e.g.: UCPX10D1
UCX11-201D1 Shaft: 2-1/16 in | Bore: Inch | Used in e.g.: UCPX11-201D1
UCX11-202D1 Shaft: 2-1/8 in | Bore: Inch | Used in e.g.: UCPX11-202D1
UCX11-203D1 Shaft: 2-3/16 in | Bore: Inch | Used in e.g.: UCPX11-203D1
UCX11D1 Shaft: 55 mm | Bore: Metric | Used in e.g.: UCPX11D1
UCX12-206D1 Shaft: 2-3/8 in | Bore: Inch | Used in e.g.: UCPX12-206D1
UCX12-207D1 Shaft: 2-7/16 in | Bore: Inch | Used in e.g.: UCPX12-207D1
UCX12D1 Shaft: 60 mm | Bore: Metric | Used in e.g.: UCPX12D1
UCX13-208D1 Shaft: 2-1/2 in | Bore: Inch | Used in e.g.: UCPX13-208D1
UCX13-209D1 Shaft: 2-9/16 in | Bore: Inch | Used in e.g.: UCPX13-209D1
UCX13D1 Shaft: 65 mm | Bore: Metric | Used in e.g.: UCPX13D1
UCX14-210D1 Shaft: 2-5/8 in | Bore: Inch | Used in e.g.: UCPX14-210D1
UCX14-211D1 Shaft: 2-11/16 in | Bore: Inch | Used in e.g.: UCPX14-211D1
UCX14-212D1 Shaft: 2-3/4 in | Bore: Inch | Used in e.g.: UCPX14-212D1
UCX14D1 Shaft: 70 mm | Bore: Metric | Used in e.g.: UCPX14D1
UCX15-213D1 Shaft: 2-13/16 in | Bore: Inch | Used in e.g.: UCPX15-213D1
UCX15-214D1 Shaft: 2-7/8 in | Bore: Inch | Used in e.g.: UCPX15-214D1
UCX15-215D1 Shaft: 2-15/16 in | Bore: Inch | Used in e.g.: UCPX15-215D1
UCX15-300D1 Shaft: 3 in | Bore: Inch | Used in e.g.: UCPX15-300D1
UCX15D1 Shaft: 75 mm | Bore: Metric | Used in e.g.: UCPX15D1
UCX16-301D1 Shaft: 3-1/16 in | Bore: Inch | Used in e.g.: UCPX16-301D1
UCX16-302D1 Shaft: 3-1/8 in | Bore: Inch | Used in e.g.: UCPX16-302D1
UCX16-303D1 Shaft: 3-3/16 in | Bore: Inch | Used in e.g.: UCPX16-303D1
UCX16D1 Shaft: 80 mm | Bore: Metric | Used in e.g.: UCPX16D1
UCX17-305D1 Shaft: 3-5/16 in | Bore: Inch | Used in e.g.: UCPX17-305D1
UCX17-307D1 Shaft: 3-7/16 in | Bore: Inch | Used in e.g.: UCPX17-307D1
UCX17D1 Shaft: 85 mm | Bore: Metric | Used in e.g.: UCPX17D1
UCX18-307D1 Shaft: 3-7/16 in | Bore: Inch | Used in e.g.: UCPX18-307D1
UCX18-308D1 Shaft: 3-1/2 in | Bore: Inch | Used in e.g.: UCPX18-308D1
UCX18D1 Shaft: 90 mm | Bore: Metric | Used in e.g.: UCPX18D1
UCX20-313D1 Shaft: 3-13/16 in | Bore: Inch | Used in e.g.: UCPX20-313D1
UCX20-314D1 Shaft: 3-7/8 in | Bore: Inch | Used in e.g.: UCPX20-314D1
UCX20-315D1 Shaft: 3-15/16 in | Bore: Inch | Used in e.g.: UCPX20-315D1
UCX20-400D1 Shaft: 4 in | Bore: Inch | Used in e.g.: UCPX20-400D1
UCX20D1 Shaft: 100 mm | Bore: Metric | Used in e.g.: UCPX20D1
UCX06-104D1 Shaft: 1-1/4 in | Bore: Inch | Used in e.g.: UCTX06-104D1
UCX09-113D1 Shaft: 1-13/16 in | Bore: Inch | Used in e.g.: UCTX09-113D1
Insert BearingsNTN
59 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NTN UCX Series Insert Bearings (Set Screw Type)

Brand NTN·Insert Bearings

Available part numbers (59)

UCX05-013D1, UCX05-014D1, UCX05-015D1, UCX05-100D1, UCX05D1, UCX06-101D1, UCX06-102D1, UCX06-103D1, UCX06D1, UCX07-105D1 + 49 more — see full table ↓

How to order

Send the NTN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
