Omron E32 Area Detection Fiber Units (11 mm and 30 mm Sensing Width)

Omron E32 Area Detection Fiber Units (11 mm and 30 mm Sensing Width)

OMRON E32 Series area detection fiber units for detecting presence across a sensing width.

Key features

  • Through-beam area types: E32-T16PR / E32-T16JR (11 mm width, up to 3,100 mm sensing), E32-T16WR (30 mm width), E32-A13 (11 mm, variable range 40~420 mm, IP40)
  • Array type E32-G16 (10 mm array, 10 mm sensing distance)
  • Reflective array type E32-D36P1 (11 mm width, bend-resistant R4, IP67)
  • All IP50 unless noted
  • Compatible with E3X-ZV, E3X-HD, and E3NX-FA
  • PDF ref: E32 full catalog, Area Detection section

Specifications

Cable Length 2 m (Free Cutting)
E32-T16PR 2M Area through-beam 11 mm width, flexible R1, IP50, sensing up to 3,100 mm | Model: E32-T16PR 2M | Type: Through-beam Area Detection (Set of 2) | Sensing Width: 11 mm | Bending Radius: Flexible R1 | IP Rating: IP50 | Cable Length: 2 m (Free Cutting) | Sensing Dist. ZV ST: 1,700 mm | Sensing Dist. FA ST: 2,550 mm | Min. Sensing Object: 0.2 dia. / 0.07 dia. (at 300 mm sensing distance)
E32-T16JR 2M Area through-beam 11 mm width variant, flexible R1, IP50 | Model: E32-T16JR 2M | Type: Through-beam Area Detection (Set of 2) | Sensing Width: 11 mm | Bending Radius: Flexible R1 | IP Rating: IP50 | Cable Length: 2 m (Free Cutting) | Sensing Dist. ZV ST: 1,500 mm | Sensing Dist. FA ST: 2,250 mm | Min. Sensing Object: 0.2 dia. / 0.07 dia. (at 300 mm sensing distance)
E32-A13 2M Area through-beam 11 mm width variable range 40~420 mm, IP40 | Model: E32-A13 2M | Type: Through-beam Area Detection (Set of 2) | Sensing Width: 11 mm | IP Rating: IP40 | Cable Length: 2 m (Free Cutting) | Sensing Range ZV: 40 to 420 mm | Sensing Range FA: 40 to 630 mm
E32-T16WR 2M Area through-beam 30 mm width, flexible R1, IP50, sensing up to 4,000 mm | Model: E32-T16WR 2M | Type: Through-beam Area Detection (Set of 2) | Sensing Width: 30 mm | Bending Radius: Flexible R1 | IP Rating: IP50 | Cable Length: 2 m (Free Cutting) | Sensing Dist. ZV ST: 2,600 mm | Sensing Dist. FA ST: 3,900 mm | Min. Sensing Object: 0.3 dia. / 0.1 dia. (at 300 mm sensing distance)
E32-G16 2M Array through-beam 10 mm array, sensing distance 10 mm, R5, IP50 | Model: E32-G16 2M | Type: Through-beam Array | Sensing Width: 10 mm array | Bending Radius: R5 | IP Rating: IP50 | Cable Length: 2 m (Free Cutting) | Sensing Dist.: 10 mm | Optical Axis Dia.: 0.5 dia.
E32-D36P1 2M Reflective array 11 mm width, bend-resistant R4, IP67 | Model: E32-D36P1 2M | Type: Reflective Array | Sensing Width: 11 mm | Bending Radius: Bend-resistant R4 | IP Rating: IP67 | Cable Length: 2 m (Free Cutting) | Sensing Dist. ZV ST: 300 mm | Sensing Dist. FA ST: 450 mm | Min. Sensing Object: 5 μm dia. / 2 μm dia.
Fiber OpticOmron
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E32 Area Detection Fiber Units (11 mm and 30 mm Sensing Width)

Brand Omron·Fiber Optic

Available part numbers (6)

E32-T16PR 2M, E32-T16JR 2M, E32-A13 2M, E32-T16WR 2M, E32-G16 2M, E32-D36P1 2M

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E32-T16PR 2MArea through-beam 11 mm width, flexible R1, IP50, sensing up to 3,100 mm | Model: E32-T16PR 2M | Type: Through-beam Area Detection (Set of 2) | Sensing Width: 11 mm | Bending Radius: Flexible R1 | IP Rating: IP50 | Cable Length: 2 m (Free Cutting) | Sensing Dist. ZV ST: 1,700 mm | Sensing Dist. FA ST: 2,550 mm | Min. Sensing Object: 0.2 dia. / 0.07 dia. (at 300 mm sensing distance)
E32-T16JR 2MArea through-beam 11 mm width variant, flexible R1, IP50 | Model: E32-T16JR 2M | Type: Through-beam Area Detection (Set of 2) | Sensing Width: 11 mm | Bending Radius: Flexible R1 | IP Rating: IP50 | Cable Length: 2 m (Free Cutting) | Sensing Dist. ZV ST: 1,500 mm | Sensing Dist. FA ST: 2,250 mm | Min. Sensing Object: 0.2 dia. / 0.07 dia. (at 300 mm sensing distance)
E32-A13 2MArea through-beam 11 mm width variable range 40~420 mm, IP40 | Model: E32-A13 2M | Type: Through-beam Area Detection (Set of 2) | Sensing Width: 11 mm | IP Rating: IP40 | Cable Length: 2 m (Free Cutting) | Sensing Range ZV: 40 to 420 mm | Sensing Range FA: 40 to 630 mm
E32-T16WR 2MArea through-beam 30 mm width, flexible R1, IP50, sensing up to 4,000 mm | Model: E32-T16WR 2M | Type: Through-beam Area Detection (Set of 2) | Sensing Width: 30 mm | Bending Radius: Flexible R1 | IP Rating: IP50 | Cable Length: 2 m (Free Cutting) | Sensing Dist. ZV ST: 2,600 mm | Sensing Dist. FA ST: 3,900 mm | Min. Sensing Object: 0.3 dia. / 0.1 dia. (at 300 mm sensing distance)
E32-G16 2MArray through-beam 10 mm array, sensing distance 10 mm, R5, IP50 | Model: E32-G16 2M | Type: Through-beam Array | Sensing Width: 10 mm array | Bending Radius: R5 | IP Rating: IP50 | Cable Length: 2 m (Free Cutting) | Sensing Dist.: 10 mm | Optical Axis Dia.: 0.5 dia.
E32-D36P1 2MReflective array 11 mm width, bend-resistant R4, IP67 | Model: E32-D36P1 2M | Type: Reflective Array | Sensing Width: 11 mm | Bending Radius: Bend-resistant R4 | IP Rating: IP67 | Cable Length: 2 m (Free Cutting) | Sensing Dist. ZV ST: 300 mm | Sensing Dist. FA ST: 450 mm | Min. Sensing Object: 5 μm dia. / 2 μm dia.
