Omron E3C-LDA Laser Photoelectric Sensor Head (Diffuse / Retro-reflective, Spot/Line/Area)

Omron E3C-LDA Laser Photoelectric Sensor Head (Diffuse / Retro-reflective, Spot/Line/Area)

OMRON E3C-LDA series laser photoelectric sensor heads with separate digital amplifier.

Key features

  • Variable laser beam — spot, line, or area detection
  • E3C-LD11N 2M: diffuse-reflective, variable spot, sensing distance 1 m, Class 2
  • E3C-LR11N 2M: coaxial retro-reflective with MSR function, variable spot, 7 m, Class 2 (requires reflector E39-R12/R13/R14/RS4/RS5, sold separately)
  • E3C-LR12N 2M: coaxial retro-reflective with MSR function, 2.0 mm fixed spot, 7 m, Class 1
  • Beam Units (E39-P11/P21 for LD11N, E39-P31/P41 for LR11N) for line/area beam sold separately
  • Compatible amplifier: E3C-LDA series only

Specifications

Cable Length 2 m
Compatible Amplifier E3C-LDA series only
E3C-LD11N 2M Diffuse-reflective laser sensor head, variable spot, 1m, Class 2, 2m cable | Model: E3C-LD11N 2M | Sensing Method: Diffuse-reflective | Beam Shape: Spot (variable) | Sensing Distance: 1 m | Laser Class: Class 2 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Optional Beam Unit: E39-P11 (line beam) / E39-P21 (area beam) — sold separately
E3C-LR11N 2M Retro-reflective MSR laser sensor head, variable spot, 7m, Class 2, 2m cable | Model: E3C-LR11N 2M | Sensing Method: Coaxial Retro-reflective with MSR function | Beam Shape: Spot (variable) | Sensing Distance: 7 m | Laser Class: Class 2 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Required Reflector: E39-R12 (23x23mm) / E39-R13 (7x7mm) / E39-R14 (transparent) / E39-RS4/RS5 sheet — sold separately | Optional Beam Unit: E39-P31 (line beam) / E39-P41 (area beam) — sold separately | Note: Use E39-R12/R13 for dist 400mm or more; E39-R14 for less than 400mm
E3C-LR12N 2M Retro-reflective MSR laser sensor head, 2.0mm fixed spot, 7m, Class 1, 2m cable | Model: E3C-LR12N 2M | Sensing Method: Coaxial Retro-reflective with MSR function | Beam Shape: Spot (2.0 mm fixed dia.) | Sensing Distance: 7 m | Laser Class: Class 1 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Required Reflector: E39-R12 / E39-R13 / E39-R14 / E39-RS4 / E39-RS5 — sold separately
PhotoelectricOmron
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E3C-LDA Laser Photoelectric Sensor Head (Diffuse / Retro-reflective, Spot/Line/Area)

Brand Omron·Photoelectric

Available part numbers (3)

E3C-LD11N 2M, E3C-LR11N 2M, E3C-LR12N 2M

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E3C-LD11N 2MDiffuse-reflective laser sensor head, variable spot, 1m, Class 2, 2m cable | Model: E3C-LD11N 2M | Sensing Method: Diffuse-reflective | Beam Shape: Spot (variable) | Sensing Distance: 1 m | Laser Class: Class 2 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Optional Beam Unit: E39-P11 (line beam) / E39-P21 (area beam) — sold separately
E3C-LR11N 2MRetro-reflective MSR laser sensor head, variable spot, 7m, Class 2, 2m cable | Model: E3C-LR11N 2M | Sensing Method: Coaxial Retro-reflective with MSR function | Beam Shape: Spot (variable) | Sensing Distance: 7 m | Laser Class: Class 2 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Required Reflector: E39-R12 (23x23mm) / E39-R13 (7x7mm) / E39-R14 (transparent) / E39-RS4/RS5 sheet — sold separately | Optional Beam Unit: E39-P31 (line beam) / E39-P41 (area beam) — sold separately | Note: Use E39-R12/R13 for dist 400mm or more; E39-R14 for less than 400mm
E3C-LR12N 2MRetro-reflective MSR laser sensor head, 2.0mm fixed spot, 7m, Class 1, 2m cable | Model: E3C-LR12N 2M | Sensing Method: Coaxial Retro-reflective with MSR function | Beam Shape: Spot (2.0 mm fixed dia.) | Sensing Distance: 7 m | Laser Class: Class 1 | Cable Length: 2 m | Compatible Amplifier: E3C-LDA series only | Required Reflector: E39-R12 / E39-R13 / E39-R14 / E39-RS4 / E39-RS5 — sold separately
