Omron E3NC-LA Compact Laser Sensor Amplifier Unit (NPN/PNP, Pre-wired / Wire-saving / M8 / Network)

Omron E3NC-LA Compact Laser Sensor Amplifier Unit (NPN/PNP, Pre-wired / Wire-saving / M8 / Network)

OMRON E3NC-L Series laser sensor amplifier units.

Key features

  • Compatible sensor head: E3NC-LH series only
  • Pre-wired 2 m (E3NC-LA21/51 2M): 2 outputs + 1 input, NPN/PNP
  • Wire-saving Connector (E3NC-LA7/9): 1 output + 1 input, NPN/PNP (requires E3X-CN21 master + E3X-CN22 slave connector, sold separately)
  • M8 Connector (E3NC-LA24/54): 1 output + 1 input, NPN/PNP (requires XS3F-M421/422 cable, sold separately)
  • E3NC-LA0: for Sensor Communications Unit (E3NW-ECT/CRT/CCL), network connection only
  • Mounting bracket E39-L143 and DIN track PFP-100N/50N sold separately

Specifications

Compatible Head E3NC-LH series only
Cover E39-G24 (sold separately)
E3NC-LA21 2M L-series amplifier NPN 2out+1in pre-wired 2m | Model: E3NC-LA21 2M | Output: NPN 2 outputs + 1 input | Connection: Pre-wired 2 m | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA51 2M L-series amplifier PNP 2out+1in pre-wired 2m | Model: E3NC-LA51 2M | Output: PNP 2 outputs + 1 input | Connection: Pre-wired 2 m | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA7 L-series amplifier NPN 1out+1in Wire-saving Connector | Model: E3NC-LA7 | Output: NPN 1 output + 1 input | Connection: Wire-saving Connector | Required Connector: E3X-CN21 master + E3X-CN22 slave (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA9 L-series amplifier PNP 1out+1in Wire-saving Connector | Model: E3NC-LA9 | Output: PNP 1 output + 1 input | Connection: Wire-saving Connector | Required Connector: E3X-CN21 master + E3X-CN22 slave (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA24 L-series amplifier NPN 1out+1in M8 Connector | Model: E3NC-LA24 | Output: NPN 1 output + 1 input | Connection: M8 Connector | Required Cable: XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA54 L-series amplifier PNP 1out+1in M8 Connector | Model: E3NC-LA54 | Output: PNP 1 output + 1 input | Connection: M8 Connector | Required Cable: XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA0 L-series amplifier for Sensor Communications Unit (E3NW-ECT/CRT/CCL network) | Model: E3NC-LA0 | Output: Network only (no standalone output) | Connection: Connector for Sensor Communications Unit | Compatible Head: E3NC-LH series only | Required: E3NW-ECT / E3NW-CRT / E3NW-CCL Sensor Communications Unit | Cover: E39-G24 (sold separately)
PhotoelectricOmron
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E3NC-LA Compact Laser Sensor Amplifier Unit (NPN/PNP, Pre-wired / Wire-saving / M8 / Network)

Brand Omron·Photoelectric

Available part numbers (7)

E3NC-LA21 2M, E3NC-LA51 2M, E3NC-LA7, E3NC-LA9, E3NC-LA24, E3NC-LA54, E3NC-LA0

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E3NC-LA21 2ML-series amplifier NPN 2out+1in pre-wired 2m | Model: E3NC-LA21 2M | Output: NPN 2 outputs + 1 input | Connection: Pre-wired 2 m | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA51 2ML-series amplifier PNP 2out+1in pre-wired 2m | Model: E3NC-LA51 2M | Output: PNP 2 outputs + 1 input | Connection: Pre-wired 2 m | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA7L-series amplifier NPN 1out+1in Wire-saving Connector | Model: E3NC-LA7 | Output: NPN 1 output + 1 input | Connection: Wire-saving Connector | Required Connector: E3X-CN21 master + E3X-CN22 slave (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA9L-series amplifier PNP 1out+1in Wire-saving Connector | Model: E3NC-LA9 | Output: PNP 1 output + 1 input | Connection: Wire-saving Connector | Required Connector: E3X-CN21 master + E3X-CN22 slave (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA24L-series amplifier NPN 1out+1in M8 Connector | Model: E3NC-LA24 | Output: NPN 1 output + 1 input | Connection: M8 Connector | Required Cable: XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA54L-series amplifier PNP 1out+1in M8 Connector | Model: E3NC-LA54 | Output: PNP 1 output + 1 input | Connection: M8 Connector | Required Cable: XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Compatible Head: E3NC-LH series only | Cover: E39-G24 (sold separately)
E3NC-LA0L-series amplifier for Sensor Communications Unit (E3NW-ECT/CRT/CCL network) | Model: E3NC-LA0 | Output: Network only (no standalone output) | Connection: Connector for Sensor Communications Unit | Compatible Head: E3NC-LH series only | Required: E3NW-ECT / E3NW-CRT / E3NW-CCL Sensor Communications Unit | Cover: E39-G24 (sold separately)
