Omron E3NX-FA Communications Smart Fiber Amplifier (for E3NW Sensor Communications Unit — EtherCAT/CompoNet/CC-Link)

Omron E3NX-FA Communications Smart Fiber Amplifier (for E3NW Sensor Communications Unit — EtherCAT/CompoNet/CC-Link)

Communications-type smart fiber amplifier designed for connection to OMRON E3NW Sensor Communications Unit, enabling network-based sensor data management over EtherCAT, CompoNet, or CC-Link.

Key features

  • Includes both connector-only types (FA0/FAH0) and pre-wired output types (FA10/FA40 with 1× digital open-collector)
  • All models share GIGA RAY2S light source, Smart Tuning, Solution Viewer, and APC + DPC auto-compensation of the standard E3NX-FA
  • Power supplied through E3NW unit — no separate wiring required for amplifier itself. 32μs high-speed response available for network-connected sensors
  • Compatible with OMRON E32 series fiber optic heads

Specifications

Light Source — FA0/FA10/FA40 Red 4-element LED (625 nm) — GIGA RAY2S
Light Source — FAH0 Infrared LED (870 nm) — GIGA RAY2S
Power Supply Supplied via E3NW Sensor Communications Unit
Control Output (FA10/FA40) NPN or PNP open-collector, 30 VDC max., 1 output
Compatibility Note E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet)
Response Time — SHS (Super-high-speed) 30 μs
Response Time — HS (High-speed) 250 μs
Response Time — Stnd (Standard) 1 ms
Response Time — GIGA (Giga-power) 16 ms
Display 7-segment digital display (white) — sub digital + main digital, dual-direction switchable
Indicators OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green)
Auto Power Control (APC) Always ON
E3NX-FA0 OMRON E3NX-FA0 communications smart fiber amplifier, red LED, for E3NW Sensor Communications Unit (EtherCAT/CompoNet/CC-Link). | Output: Communications-only (no direct output) | I/O Configuration: Communications connector type (red LED 625nm) | Connection: Communications connector — requires E3NW-ECT/CRT/CCL/DS Sensor Communications Unit sold separately | Light Source — FA0/FA10/FA40: Red 4-element LED (625 nm) — GIGA RAY2S | Light Source — FAH0: Infrared LED (870 nm) — GIGA RAY2S | Power Supply: Supplied via E3NW Sensor Communications Unit | Control Output (FA10/FA40): NPN or PNP open-collector, 30 VDC max., 1 output | Required Communications Unit (sold separately): E3NW-ECT (EtherCAT) / E3NW-CRT (CompoNet) / E3NW-CCL (CC-Link) / E3NW-DS (Distributed Unit) | Compatibility Note: E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet) | Response Time — SHS (Super-high-speed): 30 μs | Response Time — HS (High-speed): 250 μs | Response Time — Stnd (Standard): 1 ms | Response Time — GIGA (Giga-power): 16 ms | Connection Topology: Daisy-chain via E3NW Sensor Communications Unit — provides centralized data management, parameter setting from PLC, and real-time diagnostics | Application Notes: For network-based factory automation: production data collection, remote sensor parameter management, PLC-integrated diagnostics, Industry 4.0 smart factory integration | Display: 7-segment digital display (white) — sub digital + main digital, dual-direction switchable | Indicators: OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green) | Power Supply: 10 to 30 VDC, ripple (p-p) 10% max. | Sensitivity Setting: Smart Tuning [2-point tuning / Full auto tuning / Position tuning / Max sensitivity tuning / Power tuning / Percent tuning -99% to +99%] or Manual adjustment | Auto Power Control (APC): Always ON | Dynamic Power Control (DPC): Active — auto-compensates incident level for dirt, vibration, and LED aged deterioration | Timer Function: Selectable: OFF / OFF-delay / ON-delay / One-shot / ON-OFF delay (1ms ~ 9999ms range) | Bank Switching: BANK 1~4 selectable | Power Tuning: ON / OFF / via External Input | Eco Mode: OFF / ECO ON (display dim) / ECO LO (display off) | Output 1 Mode: Standard detection / Area detection / Differential detection | Maximum Connectable Units: 30 units | Mutual Interference Prevention: HS/Stnd/GIGA modes: 10 units (optical sync). SHS mode: disabled (E3NX-FA11-5 only: 2 units in SHS2) | Ambient Temperature (Operating): -25°C to 55°C (1-2 amps), -25°C to 50°C (3-10), -25°C to 45°C (11-16), -25°C to 40°C (17-30) | Ambient Humidity: 35% to 85% RH (no condensation) | Altitude: 2,000 m max. | Pollution Degree: 3 (per IEC 60947-1) | Insulation Resistance: 20 MΩ min. (at 500 VDC) | Dielectric Strength: 1,000 VAC at 50/60 Hz for 1 minute | Vibration Resistance: 10-55 Hz, 1.5mm double amplitude, 2 hours each axis (X/Y/Z) | Shock Resistance: 500 m/s² × 3 times each axis (X/Y/Z) | Material: Case/Cover: Polycarbonate (PC), Cable: PVC | Compatible Fiber Heads: OMRON E32 series fiber optic head units | Mounting: DIN track or Mounting Bracket E39-L143 (sold separately)
E3NX-FAH0 OMRON E3NX-FAH0 infrared communications smart fiber amplifier, IR LED 870nm, for E3NW Sensor Communications Unit (EtherCAT/CC-Link/Distributed only). | Output: Communications-only (no direct output) | I/O Configuration: Communications connector type (infrared LED 870nm) — NOT compatible with E3NW-CRT | Connection: Communications connector — requires E3NW-ECT/CCL/DS Sensor Communications Unit sold separately (NOT E3NW-CRT) | Light Source — FA0/FA10/FA40: Red 4-element LED (625 nm) — GIGA RAY2S | Light Source — FAH0: Infrared LED (870 nm) — GIGA RAY2S | Power Supply: Supplied via E3NW Sensor Communications Unit | Control Output (FA10/FA40): NPN or PNP open-collector, 30 VDC max., 1 output | Required Communications Unit (sold separately): E3NW-ECT (EtherCAT) / E3NW-CRT (CompoNet) / E3NW-CCL (CC-Link) / E3NW-DS (Distributed Unit) | Compatibility Note: E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet) | Response Time — SHS (Super-high-speed): 30 μs | Response Time — HS (High-speed): 250 μs | Response Time — Stnd (Standard): 1 ms | Response Time — GIGA (Giga-power): 16 ms | Connection Topology: Daisy-chain via E3NW Sensor Communications Unit — provides centralized data management, parameter setting from PLC, and real-time diagnostics | Application Notes: For network-based factory automation: production data collection, remote sensor parameter management, PLC-integrated diagnostics, Industry 4.0 smart factory integration | Display: 7-segment digital display (white) — sub digital + main digital, dual-direction switchable | Indicators: OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green) | Power Supply: 10 to 30 VDC, ripple (p-p) 10% max. | Sensitivity Setting: Smart Tuning [2-point tuning / Full auto tuning / Position tuning / Max sensitivity tuning / Power tuning / Percent tuning -99% to +99%] or Manual adjustment | Auto Power Control (APC): Always ON | Dynamic Power Control (DPC): Active — auto-compensates incident level for dirt, vibration, and LED aged deterioration | Timer Function: Selectable: OFF / OFF-delay / ON-delay / One-shot / ON-OFF delay (1ms ~ 9999ms range) | Bank Switching: BANK 1~4 selectable | Power Tuning: ON / OFF / via External Input | Eco Mode: OFF / ECO ON (display dim) / ECO LO (display off) | Output 1 Mode: Standard detection / Area detection / Differential detection | Maximum Connectable Units: 30 units | Mutual Interference Prevention: HS/Stnd/GIGA modes: 10 units (optical sync). SHS mode: disabled (E3NX-FA11-5 only: 2 units in SHS2) | Ambient Temperature (Operating): -25°C to 55°C (1-2 amps), -25°C to 50°C (3-10), -25°C to 45°C (11-16), -25°C to 40°C (17-30) | Ambient Humidity: 35% to 85% RH (no condensation) | Altitude: 2,000 m max. | Pollution Degree: 3 (per IEC 60947-1) | Insulation Resistance: 20 MΩ min. (at 500 VDC) | Dielectric Strength: 1,000 VAC at 50/60 Hz for 1 minute | Vibration Resistance: 10-55 Hz, 1.5mm double amplitude, 2 hours each axis (X/Y/Z) | Shock Resistance: 500 m/s² × 3 times each axis (X/Y/Z) | Material: Case/Cover: Polycarbonate (PC), Cable: PVC | Compatible Fiber Heads: OMRON E32 series fiber optic head units | Mounting: DIN track or Mounting Bracket E39-L143 (sold separately)
E3NX-FA10 2M OMRON E3NX-FA10 communications smart fiber amplifier, NPN 1-output, 2m pre-wired, for E3NW Sensor Communications Unit. | Output: NPN | I/O Configuration: 1 output + Communications | Connection: Communications connector + 2m pre-wired output cable — requires E3NW-ECT/CRT/CCL/DS Sensor Communications Unit sold separately | Light Source — FA0/FA10/FA40: Red 4-element LED (625 nm) — GIGA RAY2S | Light Source — FAH0: Infrared LED (870 nm) — GIGA RAY2S | Power Supply: Supplied via E3NW Sensor Communications Unit | Control Output (FA10/FA40): NPN or PNP open-collector, 30 VDC max., 1 output | Required Communications Unit (sold separately): E3NW-ECT (EtherCAT) / E3NW-CRT (CompoNet) / E3NW-CCL (CC-Link) / E3NW-DS (Distributed Unit) | Compatibility Note: E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet) | Response Time — SHS (Super-high-speed): 30 μs | Response Time — HS (High-speed): 250 μs | Response Time — Stnd (Standard): 1 ms | Response Time — GIGA (Giga-power): 16 ms | Connection Topology: Daisy-chain via E3NW Sensor Communications Unit — provides centralized data management, parameter setting from PLC, and real-time diagnostics | Application Notes: For network-based factory automation: production data collection, remote sensor parameter management, PLC-integrated diagnostics, Industry 4.0 smart factory integration | Display: 7-segment digital display (white) — sub digital + main digital, dual-direction switchable | Indicators: OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green) | Power Supply: 10 to 30 VDC, ripple (p-p) 10% max. | Sensitivity Setting: Smart Tuning [2-point tuning / Full auto tuning / Position tuning / Max sensitivity tuning / Power tuning / Percent tuning -99% to +99%] or Manual adjustment | Auto Power Control (APC): Always ON | Dynamic Power Control (DPC): Active — auto-compensates incident level for dirt, vibration, and LED aged deterioration | Timer Function: Selectable: OFF / OFF-delay / ON-delay / One-shot / ON-OFF delay (1ms ~ 9999ms range) | Bank Switching: BANK 1~4 selectable | Power Tuning: ON / OFF / via External Input | Eco Mode: OFF / ECO ON (display dim) / ECO LO (display off) | Output 1 Mode: Standard detection / Area detection / Differential detection | Maximum Connectable Units: 30 units | Mutual Interference Prevention: HS/Stnd/GIGA modes: 10 units (optical sync). SHS mode: disabled (E3NX-FA11-5 only: 2 units in SHS2) | Ambient Temperature (Operating): -25°C to 55°C (1-2 amps), -25°C to 50°C (3-10), -25°C to 45°C (11-16), -25°C to 40°C (17-30) | Ambient Humidity: 35% to 85% RH (no condensation) | Altitude: 2,000 m max. | Pollution Degree: 3 (per IEC 60947-1) | Insulation Resistance: 20 MΩ min. (at 500 VDC) | Dielectric Strength: 1,000 VAC at 50/60 Hz for 1 minute | Vibration Resistance: 10-55 Hz, 1.5mm double amplitude, 2 hours each axis (X/Y/Z) | Shock Resistance: 500 m/s² × 3 times each axis (X/Y/Z) | Material: Case/Cover: Polycarbonate (PC), Cable: PVC | Compatible Fiber Heads: OMRON E32 series fiber optic head units | Mounting: DIN track or Mounting Bracket E39-L143 (sold separately)
E3NX-FA40 2M OMRON E3NX-FA40 communications smart fiber amplifier, PNP 1-output, 2m pre-wired, for E3NW Sensor Communications Unit. | Output: PNP | I/O Configuration: 1 output + Communications | Connection: Communications connector + 2m pre-wired output cable — requires E3NW-ECT/CRT/CCL/DS Sensor Communications Unit sold separately | Light Source — FA0/FA10/FA40: Red 4-element LED (625 nm) — GIGA RAY2S | Light Source — FAH0: Infrared LED (870 nm) — GIGA RAY2S | Power Supply: Supplied via E3NW Sensor Communications Unit | Control Output (FA10/FA40): NPN or PNP open-collector, 30 VDC max., 1 output | Required Communications Unit (sold separately): E3NW-ECT (EtherCAT) / E3NW-CRT (CompoNet) / E3NW-CCL (CC-Link) / E3NW-DS (Distributed Unit) | Compatibility Note: E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet) | Response Time — SHS (Super-high-speed): 30 μs | Response Time — HS (High-speed): 250 μs | Response Time — Stnd (Standard): 1 ms | Response Time — GIGA (Giga-power): 16 ms | Connection Topology: Daisy-chain via E3NW Sensor Communications Unit — provides centralized data management, parameter setting from PLC, and real-time diagnostics | Application Notes: For network-based factory automation: production data collection, remote sensor parameter management, PLC-integrated diagnostics, Industry 4.0 smart factory integration | Display: 7-segment digital display (white) — sub digital + main digital, dual-direction switchable | Indicators: OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green) | Power Supply: 10 to 30 VDC, ripple (p-p) 10% max. | Sensitivity Setting: Smart Tuning [2-point tuning / Full auto tuning / Position tuning / Max sensitivity tuning / Power tuning / Percent tuning -99% to +99%] or Manual adjustment | Auto Power Control (APC): Always ON | Dynamic Power Control (DPC): Active — auto-compensates incident level for dirt, vibration, and LED aged deterioration | Timer Function: Selectable: OFF / OFF-delay / ON-delay / One-shot / ON-OFF delay (1ms ~ 9999ms range) | Bank Switching: BANK 1~4 selectable | Power Tuning: ON / OFF / via External Input | Eco Mode: OFF / ECO ON (display dim) / ECO LO (display off) | Output 1 Mode: Standard detection / Area detection / Differential detection | Maximum Connectable Units: 30 units | Mutual Interference Prevention: HS/Stnd/GIGA modes: 10 units (optical sync). SHS mode: disabled (E3NX-FA11-5 only: 2 units in SHS2) | Ambient Temperature (Operating): -25°C to 55°C (1-2 amps), -25°C to 50°C (3-10), -25°C to 45°C (11-16), -25°C to 40°C (17-30) | Ambient Humidity: 35% to 85% RH (no condensation) | Altitude: 2,000 m max. | Pollution Degree: 3 (per IEC 60947-1) | Insulation Resistance: 20 MΩ min. (at 500 VDC) | Dielectric Strength: 1,000 VAC at 50/60 Hz for 1 minute | Vibration Resistance: 10-55 Hz, 1.5mm double amplitude, 2 hours each axis (X/Y/Z) | Shock Resistance: 500 m/s² × 3 times each axis (X/Y/Z) | Material: Case/Cover: Polycarbonate (PC), Cable: PVC | Compatible Fiber Heads: OMRON E32 series fiber optic head units | Mounting: DIN track or Mounting Bracket E39-L143 (sold separately)
Fiber OpticOmron
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E3NX-FA Communications Smart Fiber Amplifier (for E3NW Sensor Communications Unit — EtherCAT/CompoNet/CC-Link)

Brand Omron·Fiber Optic

Available part numbers (4)

E3NX-FA0, E3NX-FAH0, E3NX-FA10 2M, E3NX-FA40 2M

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E3NX-FA0OMRON E3NX-FA0 communications smart fiber amplifier, red LED, for E3NW Sensor Communications Unit (EtherCAT/CompoNet/CC-Link). | Output: Communications-only (no direct output) | I/O Configuration: Communications connector type (red LED 625nm) | Connection: Communications connector — requires E3NW-ECT/CRT/CCL/DS Sensor Communications Unit sold separately | Light Source — FA0/FA10/FA40: Red 4-element LED (625 nm) — GIGA RAY2S | Light Source — FAH0: Infrared LED (870 nm) — GIGA RAY2S | Power Supply: Supplied via E3NW Sensor Communications Unit | Control Output (FA10/FA40): NPN or PNP open-collector, 30 VDC max., 1 output | Required Communications Unit (sold separately): E3NW-ECT (EtherCAT) / E3NW-CRT (CompoNet) / E3NW-CCL (CC-Link) / E3NW-DS (Distributed Unit) | Compatibility Note: E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet) | Response Time — SHS (Super-high-speed): 30 μs | Response Time — HS (High-speed): 250 μs | Response Time — Stnd (Standard): 1 ms | Response Time — GIGA (Giga-power): 16 ms | Connection Topology: Daisy-chain via E3NW Sensor Communications Unit — provides centralized data management, parameter setting from PLC, and real-time diagnostics | Application Notes: For network-based factory automation: production data collection, remote sensor parameter management, PLC-integrated diagnostics, Industry 4.0 smart factory integration | Display: 7-segment digital display (white) — sub digital + main digital, dual-direction switchable | Indicators: OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green) | Power Supply: 10 to 30 VDC, ripple (p-p) 10% max. | Sensitivity Setting: Smart Tuning [2-point tuning / Full auto tuning / Position tuning / Max sensitivity tuning / Power tuning / Percent tuning -99% to +99%] or Manual adjustment | Auto Power Control (APC): Always ON | Dynamic Power Control (DPC): Active — auto-compensates incident level for dirt, vibration, and LED aged deterioration | Timer Function: Selectable: OFF / OFF-delay / ON-delay / One-shot / ON-OFF delay (1ms ~ 9999ms range) | Bank Switching: BANK 1~4 selectable | Power Tuning: ON / OFF / via External Input | Eco Mode: OFF / ECO ON (display dim) / ECO LO (display off) | Output 1 Mode: Standard detection / Area detection / Differential detection | Maximum Connectable Units: 30 units | Mutual Interference Prevention: HS/Stnd/GIGA modes: 10 units (optical sync). SHS mode: disabled (E3NX-FA11-5 only: 2 units in SHS2) | Ambient Temperature (Operating): -25°C to 55°C (1-2 amps), -25°C to 50°C (3-10), -25°C to 45°C (11-16), -25°C to 40°C (17-30) | Ambient Humidity: 35% to 85% RH (no condensation) | Altitude: 2,000 m max. | Pollution Degree: 3 (per IEC 60947-1) | Insulation Resistance: 20 MΩ min. (at 500 VDC) | Dielectric Strength: 1,000 VAC at 50/60 Hz for 1 minute | Vibration Resistance: 10-55 Hz, 1.5mm double amplitude, 2 hours each axis (X/Y/Z) | Shock Resistance: 500 m/s² × 3 times each axis (X/Y/Z) | Material: Case/Cover: Polycarbonate (PC), Cable: PVC | Compatible Fiber Heads: OMRON E32 series fiber optic head units | Mounting: DIN track or Mounting Bracket E39-L143 (sold separately)
E3NX-FAH0OMRON E3NX-FAH0 infrared communications smart fiber amplifier, IR LED 870nm, for E3NW Sensor Communications Unit (EtherCAT/CC-Link/Distributed only). | Output: Communications-only (no direct output) | I/O Configuration: Communications connector type (infrared LED 870nm) — NOT compatible with E3NW-CRT | Connection: Communications connector — requires E3NW-ECT/CCL/DS Sensor Communications Unit sold separately (NOT E3NW-CRT) | Light Source — FA0/FA10/FA40: Red 4-element LED (625 nm) — GIGA RAY2S | Light Source — FAH0: Infrared LED (870 nm) — GIGA RAY2S | Power Supply: Supplied via E3NW Sensor Communications Unit | Control Output (FA10/FA40): NPN or PNP open-collector, 30 VDC max., 1 output | Required Communications Unit (sold separately): E3NW-ECT (EtherCAT) / E3NW-CRT (CompoNet) / E3NW-CCL (CC-Link) / E3NW-DS (Distributed Unit) | Compatibility Note: E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet) | Response Time — SHS (Super-high-speed): 30 μs | Response Time — HS (High-speed): 250 μs | Response Time — Stnd (Standard): 1 ms | Response Time — GIGA (Giga-power): 16 ms | Connection Topology: Daisy-chain via E3NW Sensor Communications Unit — provides centralized data management, parameter setting from PLC, and real-time diagnostics | Application Notes: For network-based factory automation: production data collection, remote sensor parameter management, PLC-integrated diagnostics, Industry 4.0 smart factory integration | Display: 7-segment digital display (white) — sub digital + main digital, dual-direction switchable | Indicators: OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green) | Power Supply: 10 to 30 VDC, ripple (p-p) 10% max. | Sensitivity Setting: Smart Tuning [2-point tuning / Full auto tuning / Position tuning / Max sensitivity tuning / Power tuning / Percent tuning -99% to +99%] or Manual adjustment | Auto Power Control (APC): Always ON | Dynamic Power Control (DPC): Active — auto-compensates incident level for dirt, vibration, and LED aged deterioration | Timer Function: Selectable: OFF / OFF-delay / ON-delay / One-shot / ON-OFF delay (1ms ~ 9999ms range) | Bank Switching: BANK 1~4 selectable | Power Tuning: ON / OFF / via External Input | Eco Mode: OFF / ECO ON (display dim) / ECO LO (display off) | Output 1 Mode: Standard detection / Area detection / Differential detection | Maximum Connectable Units: 30 units | Mutual Interference Prevention: HS/Stnd/GIGA modes: 10 units (optical sync). SHS mode: disabled (E3NX-FA11-5 only: 2 units in SHS2) | Ambient Temperature (Operating): -25°C to 55°C (1-2 amps), -25°C to 50°C (3-10), -25°C to 45°C (11-16), -25°C to 40°C (17-30) | Ambient Humidity: 35% to 85% RH (no condensation) | Altitude: 2,000 m max. | Pollution Degree: 3 (per IEC 60947-1) | Insulation Resistance: 20 MΩ min. (at 500 VDC) | Dielectric Strength: 1,000 VAC at 50/60 Hz for 1 minute | Vibration Resistance: 10-55 Hz, 1.5mm double amplitude, 2 hours each axis (X/Y/Z) | Shock Resistance: 500 m/s² × 3 times each axis (X/Y/Z) | Material: Case/Cover: Polycarbonate (PC), Cable: PVC | Compatible Fiber Heads: OMRON E32 series fiber optic head units | Mounting: DIN track or Mounting Bracket E39-L143 (sold separately)
E3NX-FA10 2MOMRON E3NX-FA10 communications smart fiber amplifier, NPN 1-output, 2m pre-wired, for E3NW Sensor Communications Unit. | Output: NPN | I/O Configuration: 1 output + Communications | Connection: Communications connector + 2m pre-wired output cable — requires E3NW-ECT/CRT/CCL/DS Sensor Communications Unit sold separately | Light Source — FA0/FA10/FA40: Red 4-element LED (625 nm) — GIGA RAY2S | Light Source — FAH0: Infrared LED (870 nm) — GIGA RAY2S | Power Supply: Supplied via E3NW Sensor Communications Unit | Control Output (FA10/FA40): NPN or PNP open-collector, 30 VDC max., 1 output | Required Communications Unit (sold separately): E3NW-ECT (EtherCAT) / E3NW-CRT (CompoNet) / E3NW-CCL (CC-Link) / E3NW-DS (Distributed Unit) | Compatibility Note: E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet) | Response Time — SHS (Super-high-speed): 30 μs | Response Time — HS (High-speed): 250 μs | Response Time — Stnd (Standard): 1 ms | Response Time — GIGA (Giga-power): 16 ms | Connection Topology: Daisy-chain via E3NW Sensor Communications Unit — provides centralized data management, parameter setting from PLC, and real-time diagnostics | Application Notes: For network-based factory automation: production data collection, remote sensor parameter management, PLC-integrated diagnostics, Industry 4.0 smart factory integration | Display: 7-segment digital display (white) — sub digital + main digital, dual-direction switchable | Indicators: OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green) | Power Supply: 10 to 30 VDC, ripple (p-p) 10% max. | Sensitivity Setting: Smart Tuning [2-point tuning / Full auto tuning / Position tuning / Max sensitivity tuning / Power tuning / Percent tuning -99% to +99%] or Manual adjustment | Auto Power Control (APC): Always ON | Dynamic Power Control (DPC): Active — auto-compensates incident level for dirt, vibration, and LED aged deterioration | Timer Function: Selectable: OFF / OFF-delay / ON-delay / One-shot / ON-OFF delay (1ms ~ 9999ms range) | Bank Switching: BANK 1~4 selectable | Power Tuning: ON / OFF / via External Input | Eco Mode: OFF / ECO ON (display dim) / ECO LO (display off) | Output 1 Mode: Standard detection / Area detection / Differential detection | Maximum Connectable Units: 30 units | Mutual Interference Prevention: HS/Stnd/GIGA modes: 10 units (optical sync). SHS mode: disabled (E3NX-FA11-5 only: 2 units in SHS2) | Ambient Temperature (Operating): -25°C to 55°C (1-2 amps), -25°C to 50°C (3-10), -25°C to 45°C (11-16), -25°C to 40°C (17-30) | Ambient Humidity: 35% to 85% RH (no condensation) | Altitude: 2,000 m max. | Pollution Degree: 3 (per IEC 60947-1) | Insulation Resistance: 20 MΩ min. (at 500 VDC) | Dielectric Strength: 1,000 VAC at 50/60 Hz for 1 minute | Vibration Resistance: 10-55 Hz, 1.5mm double amplitude, 2 hours each axis (X/Y/Z) | Shock Resistance: 500 m/s² × 3 times each axis (X/Y/Z) | Material: Case/Cover: Polycarbonate (PC), Cable: PVC | Compatible Fiber Heads: OMRON E32 series fiber optic head units | Mounting: DIN track or Mounting Bracket E39-L143 (sold separately)
E3NX-FA40 2MOMRON E3NX-FA40 communications smart fiber amplifier, PNP 1-output, 2m pre-wired, for E3NW Sensor Communications Unit. | Output: PNP | I/O Configuration: 1 output + Communications | Connection: Communications connector + 2m pre-wired output cable — requires E3NW-ECT/CRT/CCL/DS Sensor Communications Unit sold separately | Light Source — FA0/FA10/FA40: Red 4-element LED (625 nm) — GIGA RAY2S | Light Source — FAH0: Infrared LED (870 nm) — GIGA RAY2S | Power Supply: Supplied via E3NW Sensor Communications Unit | Control Output (FA10/FA40): NPN or PNP open-collector, 30 VDC max., 1 output | Required Communications Unit (sold separately): E3NW-ECT (EtherCAT) / E3NW-CRT (CompoNet) / E3NW-CCL (CC-Link) / E3NW-DS (Distributed Unit) | Compatibility Note: E3NX-FAH0 (infrared) cannot connect to E3NW-CRT (CompoNet) | Response Time — SHS (Super-high-speed): 30 μs | Response Time — HS (High-speed): 250 μs | Response Time — Stnd (Standard): 1 ms | Response Time — GIGA (Giga-power): 16 ms | Connection Topology: Daisy-chain via E3NW Sensor Communications Unit — provides centralized data management, parameter setting from PLC, and real-time diagnostics | Application Notes: For network-based factory automation: production data collection, remote sensor parameter management, PLC-integrated diagnostics, Industry 4.0 smart factory integration | Display: 7-segment digital display (white) — sub digital + main digital, dual-direction switchable | Indicators: OUT (orange/green selectable for 2-output models), L/D (orange), ST (green), DPC (green) | Power Supply: 10 to 30 VDC, ripple (p-p) 10% max. | Sensitivity Setting: Smart Tuning [2-point tuning / Full auto tuning / Position tuning / Max sensitivity tuning / Power tuning / Percent tuning -99% to +99%] or Manual adjustment | Auto Power Control (APC): Always ON | Dynamic Power Control (DPC): Active — auto-compensates incident level for dirt, vibration, and LED aged deterioration | Timer Function: Selectable: OFF / OFF-delay / ON-delay / One-shot / ON-OFF delay (1ms ~ 9999ms range) | Bank Switching: BANK 1~4 selectable | Power Tuning: ON / OFF / via External Input | Eco Mode: OFF / ECO ON (display dim) / ECO LO (display off) | Output 1 Mode: Standard detection / Area detection / Differential detection | Maximum Connectable Units: 30 units | Mutual Interference Prevention: HS/Stnd/GIGA modes: 10 units (optical sync). SHS mode: disabled (E3NX-FA11-5 only: 2 units in SHS2) | Ambient Temperature (Operating): -25°C to 55°C (1-2 amps), -25°C to 50°C (3-10), -25°C to 45°C (11-16), -25°C to 40°C (17-30) | Ambient Humidity: 35% to 85% RH (no condensation) | Altitude: 2,000 m max. | Pollution Degree: 3 (per IEC 60947-1) | Insulation Resistance: 20 MΩ min. (at 500 VDC) | Dielectric Strength: 1,000 VAC at 50/60 Hz for 1 minute | Vibration Resistance: 10-55 Hz, 1.5mm double amplitude, 2 hours each axis (X/Y/Z) | Shock Resistance: 500 m/s² × 3 times each axis (X/Y/Z) | Material: Case/Cover: Polycarbonate (PC), Cable: PVC | Compatible Fiber Heads: OMRON E32 series fiber optic head units | Mounting: DIN track or Mounting Bracket E39-L143 (sold separately)
