• Omron E3Z IO-Link Through-beam Photoelectric Sensor (15m, PNP, COM2/COM3)
1 1

Omron E3Z IO-Link Through-beam Photoelectric Sensor (15m, PNP, COM2/COM3)

Omron E3Z IO-Link Through-beam Photoelectric Sensor (15m, PNP, COM2/COM3)

OMRON E3Z IO-Link Series through-beam photoelectric sensor. 15 m sensing distance, infrared light.

Key features

  • PNP output only
  • IO-Link COM2 (38.4 kbps, IL2) and COM3 (230.4 kbps, IL3)
  • Available as set, emitter-only, or receiver-only
  • Connection: pre-wired 2 m, M12 Smartclick pre-wired 0.3 m, or M8 connector
  • Slits (E39-S65A~F) sold separately
  • IODD file available from OMRON sales representative

Specifications

Sensing Distance 15 m
Light Source Infrared
Sensing Method Through-beam (IO-Link)
Output PNP
E3Z-T81-IL2 2M IO-Link through-beam COM2 (38.4 kbps) Through-beam Set 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: Pre-wired 2 m
E3Z-T81-L-IL2 2M IO-Link through-beam COM2 (38.4 kbps) Through-beam Emitter 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Emitter | Connection: Pre-wired 2 m | Pair With: E3Z-T81-D-IL2 2M (Receiver)
E3Z-T81-D-IL2 2M IO-Link through-beam COM2 (38.4 kbps) Through-beam Receiver 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Receiver | Connection: Pre-wired 2 m | Pair With: E3Z-T81-L-IL2 2M (Emitter)
E3Z-T81-M1TJ-IL2 0.3M IO-Link through-beam COM2 (38.4 kbps) Through-beam Set M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately)
E3Z-T81-L-M1TJ-IL2 0.3M IO-Link through-beam COM2 (38.4 kbps) Through-beam Emitter M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Emitter | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately) | Pair With: E3Z-T81-D-M1TJ-IL2 0.3M (Receiver)
E3Z-T81-D-M1TJ-IL2 0.3M IO-Link through-beam COM2 (38.4 kbps) Through-beam Receiver M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Receiver | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately) | Pair With: E3Z-T81-L-M1TJ-IL2 0.3M (Emitter)
E3Z-T86-IL2 IO-Link through-beam COM2 (38.4 kbps) Through-beam Set M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-T86-L-IL2 IO-Link through-beam COM2 (38.4 kbps) Through-beam Emitter M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Emitter | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Pair With: E3Z-T86-D-IL2 (Receiver)
E3Z-T86-D-IL2 IO-Link through-beam COM2 (38.4 kbps) Through-beam Receiver M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Receiver | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Pair With: E3Z-T86-L-IL2 (Emitter)
E3Z-T81-IL3 2M IO-Link through-beam COM3 (230.4 kbps) Through-beam Set 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: Pre-wired 2 m
E3Z-T81-L-IL3 2M IO-Link through-beam COM3 (230.4 kbps) Through-beam Emitter 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Emitter | Connection: Pre-wired 2 m | Pair With: E3Z-T81-D-IL3 2M (Receiver)
E3Z-T81-D-IL3 2M IO-Link through-beam COM3 (230.4 kbps) Through-beam Receiver 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Receiver | Connection: Pre-wired 2 m | Pair With: E3Z-T81-L-IL3 2M (Emitter)
E3Z-T81-M1TJ-IL3 0.3M IO-Link through-beam COM3 (230.4 kbps) Through-beam Set M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately)
E3Z-T81-L-M1TJ-IL3 0.3M IO-Link through-beam COM3 (230.4 kbps) Through-beam Emitter M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Emitter | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately) | Pair With: E3Z-T81-D-M1TJ-IL3 0.3M (Receiver)
E3Z-T81-D-M1TJ-IL3 0.3M IO-Link through-beam COM3 (230.4 kbps) Through-beam Receiver M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Receiver | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately) | Pair With: E3Z-T81-L-M1TJ-IL3 0.3M (Emitter)
E3Z-T86-IL3 IO-Link through-beam COM3 (230.4 kbps) Through-beam Set M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-T86-L-IL3 IO-Link through-beam COM3 (230.4 kbps) Through-beam Emitter M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Emitter | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Pair With: E3Z-T86-D-IL3 (Receiver)
E3Z-T86-D-IL3 IO-Link through-beam COM3 (230.4 kbps) Through-beam Receiver M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Receiver | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Pair With: E3Z-T86-L-IL3 (Emitter)
PhotoelectricOmron
18 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E3Z IO-Link Through-beam Photoelectric Sensor (15m, PNP, COM2/COM3)

Brand Omron·Photoelectric

Available part numbers (18)

E3Z-T81-IL2 2M, E3Z-T81-L-IL2 2M, E3Z-T81-D-IL2 2M, E3Z-T81-M1TJ-IL2 0.3M, E3Z-T81-L-M1TJ-IL2 0.3M, E3Z-T81-D-M1TJ-IL2 0.3M, E3Z-T86-IL2, E3Z-T86-L-IL2, E3Z-T86-D-IL2, E3Z-T81-IL3 2M + 8 more — see full table ↓

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E3Z-T81-IL2 2MIO-Link through-beam COM2 (38.4 kbps) Through-beam Set 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: Pre-wired 2 m
E3Z-T81-L-IL2 2MIO-Link through-beam COM2 (38.4 kbps) Through-beam Emitter 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Emitter | Connection: Pre-wired 2 m | Pair With: E3Z-T81-D-IL2 2M (Receiver)
E3Z-T81-D-IL2 2MIO-Link through-beam COM2 (38.4 kbps) Through-beam Receiver 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Receiver | Connection: Pre-wired 2 m | Pair With: E3Z-T81-L-IL2 2M (Emitter)
E3Z-T81-M1TJ-IL2 0.3MIO-Link through-beam COM2 (38.4 kbps) Through-beam Set M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately)
E3Z-T81-L-M1TJ-IL2 0.3MIO-Link through-beam COM2 (38.4 kbps) Through-beam Emitter M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Emitter | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately) | Pair With: E3Z-T81-D-M1TJ-IL2 0.3M (Receiver)
E3Z-T81-D-M1TJ-IL2 0.3MIO-Link through-beam COM2 (38.4 kbps) Through-beam Receiver M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Receiver | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately) | Pair With: E3Z-T81-L-M1TJ-IL2 0.3M (Emitter)
E3Z-T86-IL2IO-Link through-beam COM2 (38.4 kbps) Through-beam Set M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-T86-L-IL2IO-Link through-beam COM2 (38.4 kbps) Through-beam Emitter M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Emitter | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Pair With: E3Z-T86-D-IL2 (Receiver)
E3Z-T86-D-IL2IO-Link through-beam COM2 (38.4 kbps) Through-beam Receiver M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM2 (38.4 kbps) | Type: Through-beam Receiver | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Pair With: E3Z-T86-L-IL2 (Emitter)
E3Z-T81-IL3 2MIO-Link through-beam COM3 (230.4 kbps) Through-beam Set 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: Pre-wired 2 m
E3Z-T81-L-IL3 2MIO-Link through-beam COM3 (230.4 kbps) Through-beam Emitter 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Emitter | Connection: Pre-wired 2 m | Pair With: E3Z-T81-D-IL3 2M (Receiver)
E3Z-T81-D-IL3 2MIO-Link through-beam COM3 (230.4 kbps) Through-beam Receiver 2m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Receiver | Connection: Pre-wired 2 m | Pair With: E3Z-T81-L-IL3 2M (Emitter)
E3Z-T81-M1TJ-IL3 0.3MIO-Link through-beam COM3 (230.4 kbps) Through-beam Set M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately)
E3Z-T81-L-M1TJ-IL3 0.3MIO-Link through-beam COM3 (230.4 kbps) Through-beam Emitter M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Emitter | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately) | Pair With: E3Z-T81-D-M1TJ-IL3 0.3M (Receiver)
E3Z-T81-D-M1TJ-IL3 0.3MIO-Link through-beam COM3 (230.4 kbps) Through-beam Receiver M12 0.3m | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Receiver | Connection: M12 Pre-wired Smartclick Connector 0.3 m | Required Cable: Requires XS5F-D421-D80-F (2m) / XS5F-D421-G80-F (5m) M12 Smartclick straight or XS5F-D422 L-shaped (sold separately) | Pair With: E3Z-T81-L-M1TJ-IL3 0.3M (Emitter)
E3Z-T86-IL3IO-Link through-beam COM3 (230.4 kbps) Through-beam Set M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Set (Emitter+Receiver) | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-T86-L-IL3IO-Link through-beam COM3 (230.4 kbps) Through-beam Emitter M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Emitter | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Pair With: E3Z-T86-D-IL3 (Receiver)
E3Z-T86-D-IL3IO-Link through-beam COM3 (230.4 kbps) Through-beam Receiver M8 | Sensing Distance: 15 m | Light Source: Infrared | Sensing Method: Through-beam (IO-Link) | Output: PNP | IO-Link: COM3 (230.4 kbps) | Type: Through-beam Receiver | Connection: M8 Connector | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately) | Pair With: E3Z-T86-L-IL3 (Emitter)
