Omron E3Z-LL Compact Laser Distance-settable Photoelectric Sensor (BGS, 20~300mm / 25~300mm, NPN/PNP)

Omron E3Z-LL Compact Laser Distance-settable Photoelectric Sensor (BGS, 20~300mm / 25~300mm, NPN/PNP)

OMRON E3Z-LL Series compact laser distance-settable photoelectric sensor, BGS type.

Key features

  • Red light
  • NPN and PNP output
  • Standard speed (E3Z-LL61/81): response time 1 ms, BGS range 20~300 mm
  • High-speed (E3Z-LL63/83): response time 0.5 ms, BGS range 25~300 mm
  • Pre-wired 2 m and M8 connector (4-pin)
  • M8 cables (XS3F-M421/422) and mounting brackets sold separately

Specifications

Light Source Red light
E3Z-LL61 2M Laser distance-settable BGS 20~300mm NPN pre-wired 2m | Sensing Method: Distance-settable BGS (Laser) | Light Source: Red light | Response Time: 1 ms | Output: NPN | Sensing Distance: BGS min: 20~40 mm / BGS max: 20~300 mm | Connection: Pre-wired 2 m
E3Z-LL66 Laser distance-settable BGS 20~300mm NPN M8 connector | Sensing Method: Distance-settable BGS (Laser) | Light Source: Red light | Response Time: 1 ms | Output: NPN | Sensing Distance: BGS min: 20~40 mm / BGS max: 20~300 mm | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-LL81 2M Laser distance-settable BGS 20~300mm PNP pre-wired 2m | Sensing Method: Distance-settable BGS (Laser) | Light Source: Red light | Response Time: 1 ms | Output: PNP | Sensing Distance: BGS min: 20~40 mm / BGS max: 20~300 mm | Connection: Pre-wired 2 m
E3Z-LL86 Laser distance-settable BGS 20~300mm PNP M8 connector | Sensing Method: Distance-settable BGS (Laser) | Light Source: Red light | Response Time: 1 ms | Output: PNP | Sensing Distance: BGS min: 20~40 mm / BGS max: 20~300 mm | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-LL63 2M Laser distance-settable BGS 25~300mm 0.5ms NPN pre-wired 2m | Sensing Method: Distance-settable BGS (Laser, High-speed) | Light Source: Red light | Response Time: 0.5 ms | Output: NPN | Sensing Distance: BGS min: 25~40 mm / BGS max: 25~300 mm | Connection: Pre-wired 2 m
E3Z-LL68 Laser distance-settable BGS 25~300mm 0.5ms NPN M8 connector | Sensing Method: Distance-settable BGS (Laser, High-speed) | Light Source: Red light | Response Time: 0.5 ms | Output: NPN | Sensing Distance: BGS min: 25~40 mm / BGS max: 25~300 mm | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-LL83 2M Laser distance-settable BGS 25~300mm 0.5ms PNP pre-wired 2m | Sensing Method: Distance-settable BGS (Laser, High-speed) | Light Source: Red light | Response Time: 0.5 ms | Output: PNP | Sensing Distance: BGS min: 25~40 mm / BGS max: 25~300 mm | Connection: Pre-wired 2 m
E3Z-LL88 Laser distance-settable BGS 25~300mm 0.5ms PNP M8 connector | Sensing Method: Distance-settable BGS (Laser, High-speed) | Light Source: Red light | Response Time: 0.5 ms | Output: PNP | Sensing Distance: BGS min: 25~40 mm / BGS max: 25~300 mm | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
PhotoelectricOmron
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E3Z-LL Compact Laser Distance-settable Photoelectric Sensor (BGS, 20~300mm / 25~300mm, NPN/PNP)

Brand Omron·Photoelectric

Available part numbers (8)

E3Z-LL61 2M, E3Z-LL66, E3Z-LL81 2M, E3Z-LL86, E3Z-LL63 2M, E3Z-LL68, E3Z-LL83 2M, E3Z-LL88

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E3Z-LL61 2MLaser distance-settable BGS 20~300mm NPN pre-wired 2m | Sensing Method: Distance-settable BGS (Laser) | Light Source: Red light | Response Time: 1 ms | Output: NPN | Sensing Distance: BGS min: 20~40 mm / BGS max: 20~300 mm | Connection: Pre-wired 2 m
E3Z-LL66Laser distance-settable BGS 20~300mm NPN M8 connector | Sensing Method: Distance-settable BGS (Laser) | Light Source: Red light | Response Time: 1 ms | Output: NPN | Sensing Distance: BGS min: 20~40 mm / BGS max: 20~300 mm | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-LL81 2MLaser distance-settable BGS 20~300mm PNP pre-wired 2m | Sensing Method: Distance-settable BGS (Laser) | Light Source: Red light | Response Time: 1 ms | Output: PNP | Sensing Distance: BGS min: 20~40 mm / BGS max: 20~300 mm | Connection: Pre-wired 2 m
E3Z-LL86Laser distance-settable BGS 20~300mm PNP M8 connector | Sensing Method: Distance-settable BGS (Laser) | Light Source: Red light | Response Time: 1 ms | Output: PNP | Sensing Distance: BGS min: 20~40 mm / BGS max: 20~300 mm | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-LL63 2MLaser distance-settable BGS 25~300mm 0.5ms NPN pre-wired 2m | Sensing Method: Distance-settable BGS (Laser, High-speed) | Light Source: Red light | Response Time: 0.5 ms | Output: NPN | Sensing Distance: BGS min: 25~40 mm / BGS max: 25~300 mm | Connection: Pre-wired 2 m
E3Z-LL68Laser distance-settable BGS 25~300mm 0.5ms NPN M8 connector | Sensing Method: Distance-settable BGS (Laser, High-speed) | Light Source: Red light | Response Time: 0.5 ms | Output: NPN | Sensing Distance: BGS min: 25~40 mm / BGS max: 25~300 mm | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-LL83 2MLaser distance-settable BGS 25~300mm 0.5ms PNP pre-wired 2m | Sensing Method: Distance-settable BGS (Laser, High-speed) | Light Source: Red light | Response Time: 0.5 ms | Output: PNP | Sensing Distance: BGS min: 25~40 mm / BGS max: 25~300 mm | Connection: Pre-wired 2 m
E3Z-LL88Laser distance-settable BGS 25~300mm 0.5ms PNP M8 connector | Sensing Method: Distance-settable BGS (Laser, High-speed) | Light Source: Red light | Response Time: 0.5 ms | Output: PNP | Sensing Distance: BGS min: 25~40 mm / BGS max: 25~300 mm | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
