Omron E3Z-LR Compact Laser Retro-reflective Photoelectric Sensor (MSR, 15m/7m, NPN/PNP)

Omron E3Z-LR Compact Laser Retro-reflective Photoelectric Sensor (MSR, 15m/7m, NPN/PNP)

OMRON E3Z-LR Series compact laser retro-reflective photoelectric sensor with MSR function.

Key features

  • Red light
  • Response time 1 ms
  • NPN (E3Z-LR61) and PNP (E3Z-LR81)
  • Sensing distance: 15 m (min 300 mm) with E39-R1 reflector, or 7 m (min 200 mm) with E39-R12 / E39-R6
  • Reflectors sold separately
  • Pre-wired 2 m and M8 connector (4-pin)

Specifications

Sensing Method Retro-reflective with MSR function (Laser)
Light Source Red light
Response Time 1 ms
Sensing Distance 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6
Required Reflector E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately
E3Z-LR61 2M Laser retro-reflective MSR NPN pre-wired 2m | Sensing Method: Retro-reflective with MSR function (Laser) | Light Source: Red light | Response Time: 1 ms | Output: NPN | Sensing Distance: 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6 | Required Reflector: E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately | Connection: Pre-wired 2 m
E3Z-LR66 Laser retro-reflective MSR NPN M8 connector | Sensing Method: Retro-reflective with MSR function (Laser) | Light Source: Red light | Response Time: 1 ms | Output: NPN | Sensing Distance: 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6 | Required Reflector: E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-LR81 2M Laser retro-reflective MSR PNP pre-wired 2m | Sensing Method: Retro-reflective with MSR function (Laser) | Light Source: Red light | Response Time: 1 ms | Output: PNP | Sensing Distance: 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6 | Required Reflector: E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately | Connection: Pre-wired 2 m
E3Z-LR86 Laser retro-reflective MSR PNP M8 connector | Sensing Method: Retro-reflective with MSR function (Laser) | Light Source: Red light | Response Time: 1 ms | Output: PNP | Sensing Distance: 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6 | Required Reflector: E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
PhotoelectricOmron
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E3Z-LR Compact Laser Retro-reflective Photoelectric Sensor (MSR, 15m/7m, NPN/PNP)

Brand Omron·Photoelectric

Available part numbers (4)

E3Z-LR61 2M, E3Z-LR66, E3Z-LR81 2M, E3Z-LR86

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E3Z-LR61 2MLaser retro-reflective MSR NPN pre-wired 2m | Sensing Method: Retro-reflective with MSR function (Laser) | Light Source: Red light | Response Time: 1 ms | Output: NPN | Sensing Distance: 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6 | Required Reflector: E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately | Connection: Pre-wired 2 m
E3Z-LR66Laser retro-reflective MSR NPN M8 connector | Sensing Method: Retro-reflective with MSR function (Laser) | Light Source: Red light | Response Time: 1 ms | Output: NPN | Sensing Distance: 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6 | Required Reflector: E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
E3Z-LR81 2MLaser retro-reflective MSR PNP pre-wired 2m | Sensing Method: Retro-reflective with MSR function (Laser) | Light Source: Red light | Response Time: 1 ms | Output: PNP | Sensing Distance: 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6 | Required Reflector: E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately | Connection: Pre-wired 2 m
E3Z-LR86Laser retro-reflective MSR PNP M8 connector | Sensing Method: Retro-reflective with MSR function (Laser) | Light Source: Red light | Response Time: 1 ms | Output: PNP | Sensing Distance: 15 m (min 300 mm) with E39-R1 / 7 m (min 200 mm) with E39-R12 or E39-R6 | Required Reflector: E39-R1 (15m) / E39-R12 (7m) / E39-R6 (7m) — sold separately | Connection: M8 Connector (4-pin) | Required Cable: Requires XS3F-M421-402-A (2m) / XS3F-M421-405-A (5m) straight or XS3F-M422 L-shaped (sold separately)
